Summary of Contents for Shademaker SR-27S
- Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
- Page 3 I M P O R T A N T : Please read this entire manual before installing or operating your Sirius umbrella. S I R I U S W I N D R E S I S T A N C E G U I D E L I N E S : Light to Moderate Winds (if used with mount kits) When installed properly, the Sirius is engineered to handle light to moderate wind conditions in the open canopy position.
- Page 4 S P E C I F I C A T I O N S Canopy to Total Height Height to Canopy Height to Item No. Mast Width Clearance Canopy Top Closed SR-27S 9’11” 8’9” 6’8” 2’ 8’5” SR-30S 11’ 9’ 6’8” 1’7”...
- Page 5 D I A G R A M & P A R T S L I S T 3 3 3 1. Internal Stem 6. Crank Handle 11. Canopy 2. Internal Stem Cover (optional) 7. Slider Car Stop Pin 12. Strut 3.
- Page 6 I N S T A L L A T I O N O P T I O N S A N D G U I D E L I N E S There are four standard installation options which provide the best stability for the Sirius. Depending on your situation, you will have requested one or more of the Sirius base options at the time of your order.
- Page 7 Slide internal stem cover over bottom of Sirius mast. Using a two person team, lift umbrella with cover and insert bottom of mast onto internal stem. Tighten 5 bolts to secure umbrella in place with allen wrench. Note: Do not use power drill. May cause damage to umbrella.
- Page 8 Option B: If you wish not to use optional internal stem cover, proceed below. Using a two person team, lift umbrella with attached internal stem and install umbrella onto mount kit, SM PLATE on your steel base weight. Tighten 5 bolts to secure umbrella in place with allen wrench.
- Page 9 O P E R A T I N G I N S T R U C T I O N S Remove all packaging from umbrella. To Open and Tilt Canopy The following instructions will walk you through the sequential progression of opening the Sirius canopy structure.
- Page 10 Open to the third position: 1. Repeat steps 1-3 outlined on previous page. 2. The canopy will now be in the Horizontal position. HELPFUL HINT: At any time, you may skip a position and open to the desired position by turning the slider car stop pin parallel with the mast. In this position, the pin will NOT auto locate as it passes over the predetermined holes.
- Page 11 T O P R O P E R L Y F O L D C A N O P Y The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
- Page 12 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com ©2017 Shademaker. All rights reserved. SMOM-SIRIUS-1017...
