- Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
- Page 3 S P E C I F I C A T I O N S Canopy to Total Height Height to Arm Canopy Clearance Item No. Mast Width Closed GALAXY-35S 12’11” 10’1” 7’11” 1’4” GALAXY-40S 14’6” 9’10” 7’5”...
- Page 4 D I A G R A M & P A R T S L I S T 1. Upper Internal Stem 9. Boom 2. Acetal Ring (between Internal Stems) 10. Head Fitting 3. Lower Internal Stem 11. Spacer Buttons 4. Locator Screws 12.
- Page 5 I N S T A L L A T I O N A N D A S S E M B L Y Due to the Galaxy’s massive size, we recommend either anchoring the Galaxy to an existing substantial concrete slab or installing it into a newly poured concrete pier using our in-ground fitting.
- Page 6 c. Expose the mast cord. The cord should be visible Elbow between the boom’s elbow (8) and the mast (7). Mast Mast Cord d. Carefully remove plastic covering from the mast cord, using caution not to damage the cord itself. Mast NOTE: Take note of the pulley at the end of the mast cord.
- Page 7 STEP 3: NOTE: If Galaxy is installed on a Zeus base, base lid must be placed over the base frame prior to the next step. 1. Using at least a two-person team, lift frame out of packaging and slide onto stem. 2.
- Page 8 STEP 4: 1. Remove the canopy structure from box #2. 2. Place a ladder next to the boom. 3. Stand up the closed canopy structure on the end of its arms near the boom and ladder. Ensure that the open end of the head fitting (10) is facing the boom (9). 4.
- Page 9 STEP 5: 1. Using at least a two-person team, lift the closed canopy structure and insert the head fitting into the boom. a. One person on the ladder to help guide the head fitting into the boom. b. One or more persons to lift the canopy structure up and align the head fitting with the boom.
- Page 10 The manufacturer accepts no liability whatsoever for any resulting damage due to the non-installation of spacer buttons. If spacers are missing, contact Shademaker to request more. 1. Pull bottom of arms outward and turn winder to open the canopy about halfway. Do NOT continue to turn if you experience resistance;...
- Page 11 T O P R O P E R L Y F O L D C A N O P Y The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
