Summary of Contents for Shademaker LIBRA-20S

  • Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
  • Page 3 Libra to protect it from storm-related debris. S P E C I F I C A T I O N S Canopy Width Overall Height Arm End Height Arm End Height Item No. Open Closed LIBRA-20S 6’6” 7’8” 6’5” 3’1” LIBRA-25S 8’2” 8’ 6’5”...
  • Page 4 D I A G R A M & P A R T S L I S T 1. External Mast Stem (for mount kit or steel base weight option) 2. Clamp with Handle 6. Strut 3. Pole 7. Arm 4. Lower Hub 8.
  • Page 5 I N S T A L L A T I O N O P T I O N S A N D G U I D E L I N E S There are four standard installation options which provide the best stability for the Libra. Depending on your situation, you will have requested one or more of the Libra base options at the time of your order.
  • Page 6 O P E R A T I N G I N S T R U C T I O N S To open canopy: 1. Undo strap and position yourself under the canopy arms. 2. Push lower hub up center pole until lower hub locks into place. CAUTION: Arms will need to be freed manually to facilitate opening the first time.
  • Page 7 T O P R O P E R L Y F O L D C A N O P Y The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
  • Page 8 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com © 2018 Shademaker. All rights reserved. SMOM-LIBRA-0718...
