Summary of Contents for Shademaker Orion OR-27S
- Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
- Page 3 I M P O R T A N T : Please read this entire manual before installing or operating your Orion umbrella. O R I O N W I N D R E S I S T A N C E G U I D E L I N E S : Moderate to Moderately Strong Winds (when mounted) When installed properly, the Orion is engineered to handle moderate to moderately strong wind conditions in the open canopy position.
- Page 4 D I A G R A M & P A R T S L I S T 1. Internal Stem 8. Elbow 14. Canopy Structure Pole 2. Internal Stem Cover (optional) 8a. Fastening Screws 14a. Suspension Bolt 3. Bore Holes 9.
- Page 5 I N S T A L L A T I O N O P T I O N S A N D G U I D E L I N E S There are four standard installation options which provide the best stability for the Orion. Depending on your situation, you will have requested one or more of the Orion base options at the time of your order.
- Page 6 A S S E M B L Y I N S T R U C T I O N S Two-person team is recommended for assembly. By now, you have installed your mount kit, SM PLATE onto your steel base weight, or have set up your steel base frame with recommended base weight.
- Page 7 Slide internal stem cover over bottom of Orion mast. Using a two person team, lift umbrella with cover and insert bottom of mast onto internal stem. Tighten 5 bolts to secure umbrella in place with allen wrench. Note: Do not use power drill. May cause damage to umbrella.
- Page 8 Option B: If you wish not to use optional internal stem cover, proceed below. Using a two person team, lift umbrella with attached internal stem and install umbrella onto mount kit, SM PLATE on your steel base weight. Tighten 5 bolts to secure umbrella in place with allen wrench.
- Page 9 Attaching Canopy Structure to Head Fitting Lift canopy structure and connect sister clip on the canopy structure to the clip on the stainless wire. Slide the canopy structure into the head fitting by aligning the set screw on the top of the canopy structure with the slot in the head fitting. May need to loosen cord.
- Page 10 To Rotate 360° 1. There are (8) 45° locking rotating positions. Raise the turning handle above 90° and rotate mast to one of the 8 preset positions. 2. Lower handle to lock into place. To Close Canopy 1. Turn crank handle counter-clockwise and continue winding until canopy is lowered, strap canopy.
- Page 11 T O P R O P E R L Y F O L D C A N O P Y The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
- Page 12 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com © 2018 Shademaker. All rights reserved. SMOM-ORION-0118...
