Owner's Manual
ORION
SERIES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ORION Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Shademaker ORION Series

Summary of Contents for Shademaker ORION Series

  • Page 1 Owner's Manual ORION SERIES...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Page No. Orion Diagram Wind Resistance and Guidelines Installation Guidelines Assembly Instructions Operating Instructions How to Properly Fold Canopy Protective Cover Canopy Structure Removal Canopy Removal and Replacement Maintanence Safety and Precautions Warranty...

  • Page 3: Orion Diagram

    Please read this entire manual before installing or operating your umbrella. Thank you for purchasing Shademaker's Orion side post umbrella. Please remove all contents from packaging, inspect and review diagram. Some parts may be included in the Styrofoam packaging. Do not discard any packaging or box until assembly is complete.

  • Page 4: Wind Resistance And Guidelines

    • ORI-40 is 500 lbs. NOTE: If using a free-standing base, wind guidelines change to light winds only. Using a Shademaker mount kit is always the preferred method of securing your umbrella above all other methods. We recommend a licensed contractor to secure your Shademaker umbrellas.

  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Two-person team is recommended for assembly. By now, you have installed your mount kit or free-standing base, with the required minimum base weight. Assembling Boom to Mast 1. Unpack the Orion and lay it out on a clean, soft surface.
  • Page 6 OPTION B: If you wish not to use optional internal stem cover, proceed below. 1. With your umbrella laying on a clean soft surface, remove internal stem from bottom of mast by removing the (3) turning handle bolts underneath the turning handle.
  • Page 7 Attach Mast to Internal Stem 1. Lift rotating handle from mast. 2. Rotate umbrella mast until the bore holes for the turning handle bolts in the internal stem line up in the mast. 3. Insert (3) turning handle bolts into mast and internal stem. Tighten with 5mm hexagon wrench to secure.
  • Page 8 Attaching Canopy Structure to Head Fitting 1. Lift canopy structure and connect sister clip on the canopy structure to the clip on the stainless wire. 2. Slide the canopy structure into the head fitting by aligning the set screw on the top of the canopy structure with the slot in the head fitting.

  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Remove all packaging from umbrella and umbrella parts. To Open Canopy 1. Remove the strap from canopy structure. Take note of the “parachute” folding method used to fold the canopy when closed. See TO PROPERLY FOLD CANOPY section on page 10 for more details. 2.
  • Page 10 ° To Rotate 360 IMPORTANT: PRIOR TO USING ROTATION FEATURE. To avoid personal injury or damage to the umbrella, make sure the umbrella is in a horizontal position and the area behind you is clear and free from any furniture or structure.

  • Page 11: How To Properly Fold Canopy

    TO PROPERLY FOLD CANOPY The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.

  • Page 12: Canopy Structure Removal

    CANOPY STRUCTURE REMOVAL In anticipation of, and during extremely severe weather conditions, it is advisable to remove and store the entire umbrella structure to protect it from storm-related debris. 1. Lower the canopy to the closed position. 2. Disconnect sister clips on canopy structure from the clip on stainless wire. 3.

  • Page 13: Maintanence

    • Sufficient base weight must be used to secure umbrellas at all times. Please base weight matrix at www.shademakerusa.com for required minimum weight for free-standing applications. Using a Shademaker mount kit is always the preferred method of securing your umbrella above all other methods. We...

  • Page 14: Warranty

    Our only business and focus is shade and shade type products. Our goal is that each and every Shademaker style will exceed your expectations at a competitive price that will make you smile.
  • Page 15 Irregularities in Production Process: The possibility of “Irregularities” in the product surface may occur during the production process. However, these irregularities do not reduce the quality of the product. Shademaker monitors every stage of production to ensure a clean and consistent appearance on every part.
  • Page 16 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com ©2022 Shademaker. All rights reserved. SMOM-ORI-102722...

This manual is also suitable for:

Or-30Or-30sOr-40
