- Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
- Page 3 S P E C I F I C A T I O N S Mast End to Height to Arm End Arm End Height to Item No. Canopy Edge Mast Top Height Height Canopy Top (Open) (Closed) (Open) POLARIS-30S 11’ 9’2” 7’ 2’4” 8’8” POLARIS-35S 12’9” 9’5” 7’3” 1’4” 9’3” POLARIS-40S 14’3” 9’6”...
- Page 4 D I A G R A M & P A R T S L I S T 1. Internal Stem 6. Slider Car Stop Pin 11. Arm 2. Internal Stem Cover (optional) 7. Crank 12. Canopy 3. Bore Holes 8. Slider Car 13.
- Page 5 I N S T A L L A T I O N O P T I O N S A N D G U I D E L I N E S There are four standard installation options which provide the best stability for the Polaris. Depending on your situation, you will have requested one or more of the Polaris base options at the time of your order.
- Page 6 Slide internal stem cover over bottom of Polaris mast. Using a two person team, lift umbrella with cover and insert bottom of mast onto internal stem. Tighten 5 bolts to secure umbrella in place. Slide internal stem cover down to cover internal stem. (Astral-TC Internal Stem shown) Internal Mast Stem Cover Installed Attaching Polaris to Internal Stem...
- Page 7 Option B: If you wish not to use optional internal stem cover, proceed below. Using a two person team, lift umbrella with attached internal stem and install umbrella onto mount kit, SM PLATE on your steel base weight. Tighten 5 bolts to secure umbrella in place with allen wrench.
- Page 8 O P E R A T I N G I N S T R U C T I O N S Remove all packaging from umbrella. To Open Canopy 1. Remove the strap that holds the Polaris to the mast when in the closed position. Take note of the “parachute”...
- Page 9 To Rotate 360° 1. There are (8) 45° locking rotating positions. Raise the turning handle above 90° and rotate mast to one of the 8 preset positions. 2. Lower handle to lock into place. To Close Canopy 1. Turn slider car pin counter clockwise to disengage. Move slider car pin downward to a comfortable position.
- Page 10 L I G H T A D A P T E R To open light adapter: Loosen light adapter built into the umbrella runner by turning counter-clockwise. After loosening, pull down light adapter post and attach umbrella light (sold separately). To close light adapter: Gently push up the light adapter post back into umbrella runner and tighten turning clockwise NOTE: It is not...
- Page 11 T O P R O P E R L Y F O L D C A N O P Y The 100% solution dyed canopy will last longer if you fold it as it was packed and shipped. This technique is similar to the way a parachute is folded and is especially important when folding the canopy for seasonal storage or when left in the closed position for an extended period of time.
- Page 12 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com ©2018 Shademaker. All rights reserved. SMOM-POLARIS-0718...
