Please read this entire manual before installing or operating your umbrella.
Thank you for purchasing Shademaker's Solaris / Polaris side post umbrella. Please
remove all contents from packaging, inspect and review diagram.
Some parts may be included in the Styrofoam packaging. Do not discard any
packaging or box until assembly is complete.
9
8
6
7
5
4
2
1
1. Internal Stem (not shown)
2. Internal Stem Cover (optional)
3. Turning Handle
4. Mast
5. Slider Car
6. Slider Car Stop Pin
7. Crank Handle
8. Main Arm
9. Main Support Arm
10. Finial

SOLARIS / POLARIS DIAGRAM

3
10
11
12
11. Upper Hub Assembly
12. Lower Hub Assembly
13. Short Rib Assembly (square only)
14. Medium Rib Assembly (rectangle only)
15. Long Rib Assembly
16. Locking Canopy Fastener
17. Canopy
18. Valance (optional)
19. Canopy Strap (not shown)
20. Protective Cover (not shown)
17
13
14
15
16
18
