QTY
NO
PART
L24
1
L25
4
Z01
3
M4.2X16
Z03
8
M4.2X16
S02
24
M5X12
1
Left Door
6 x S02
Door Assembly
Left Door
Use 3 x Z01 to secure L24 onto L07A.
Z01
L24
6 x S02
L04B
1
1
1
L24
Use S02 to install 4 x Door Hinges L25
onto each door profile and L04A & L04B,
then secure them with Z03 as shown below.
L04A
Right Door
31
Right Door
2 x Z03
2 x Z03
