QTY
NO
PART
L05C
4
L05E
4
L05F
1
Z01
56
M4.2X16
S01
16
M5X12
Use S01 to secure each roof brace L05C onto L03B & L03C at each end,
L03B/ L03C
then use Z01 to secure them onto L03D in the middle.
1
S01
L05C
Bracing Assembly
L05F
1
2
L05C
S01
L03B/ L03C
L05C
Use Z01 to secure each eave brace L05E & L05F.
30
L05E
1
3
L05E
3
Z01
3
L03D
2
Z01
