QTY
NO
PART
L03D
4
1
W24
M01
2
M8
S01
16
M5X12
Install 4 x L03D on the roof as shown, and secure them with S01.
W23
L03D
S01
W24
L03D
L03D
S01
Twist M01 into the bolt on the cap bracket W24,
and then insert the bolt on W24 through W23.
Adjust the position of the top M01 to allow enough
space for the bottom M01 to tighten it up.
M01
W23
26
W24
