Sproutwell SMALL GAZEBO Assembly Instructions Manual page 11

QTY
NO
PART
1
L16A
L16B 1
L17
2
2
L18A
2
L18B
L18C 1
L18D 1
L05G
4
A
8
S01
10
M5X12
Z01
32
M4.2X16
S04
6
M6X12
M02
6
M6
4
Y11
20MM
30MM
0 1 2 3
L18A
A
L05G
L18D
L17
L05G
2
A
Insert Connector A into each end of
the profiles L16B & L18A & L18B &
L18D, and then mark the distance
from each end about 20/30MM.
Lastly, secure them with screws Z01
using the powered screw-driver.
1
S04
M02
Left Door Assembly
A
1
L16B
Y11
1
Y11
A
L18B
M02
11
A
Z01
2
S04
S01
Z01
