Sproutwell SMALL GAZEBO Assembly Instructions Manual page 21

QTY
NO
PART
L05A 3
S01
12
M5X12
Z01
36
M4.2X16
1
L 01A
Use the screw S01 to secure each end of 3 x L05A onto each L01A,
and then use Z01 to install the rest part of L05A onto each L03A
with the powered screw-driver.
* Do not over tighten Z01 as you don't want the screws to strip.
3 2 1 0
2
2
L05A
1
S01 S01
L05A
L05A
* Please ensure all parts are in correct angle before securing L05A.
1
2
2
L 01A
21
2
2
L05A
2
2
2
1
2
Z01
1
L05A
