MODEL:GRANGE - 4
PRODUCT SIZE(400x400x273CM): PLEASE REFER TO PACKING LIST BELOW
PLEASE READ CAREFULLY BEFORE ASSEMBLY
Item No. & Packing List
Product Size
(LxWxH)
406x406x273CM
607x406x273CM
807x406x273CM
1007x406x273CM
etc.
Assembly instruction
ALU. NO. 1
ALU. NO. 2
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
1 CTN
Packing List
PC NO.1
ALU. NO. 3
1 CTN
1 CTN
2 CTNS
1 CTN
3 CTNS
1 CTN
4 CTNS
1 CTN
etc.
1 CTN
PC NO.2
2 CTNS
3 CTNS
4 CTNS
5 CTNS
etc.
Advertisement
Related Manuals for Sproutwell GRANGE-4
Summary of Contents for Sproutwell GRANGE-4
- Page 1 Assembly instruction MODEL:GRANGE - 4 PRODUCT SIZE(400x400x273CM): PLEASE REFER TO PACKING LIST BELOW PLEASE READ CAREFULLY BEFORE ASSEMBLY Item No. & Packing List Packing List Product Size (LxWxH) PC NO.1 ALU. NO. 1 PC NO.2 ALU. NO. 2 ALU. NO. 3 2 CTNS 1 CTN 1 CTN...
- Page 2 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that the product will be assembled by at least two people. 2. Some parts have sharp edges. Please be careful when handling components. Always wear gloves, shoes and safety goggles during assembly. 3.
- Page 3 4. The unique design allows the greenhouse to be easily extended at any stage in 2m long sections as detailed in the table of Front Page. 5. A steel base is not required as the aluminium base frame is fixed to the necessary concrete footings with the expansion bolts provided, alternatively you can easily secure it to a timber base with timber screws (not provided).
- Page 4 POLYCARBONATE ORIENTATION PLEASE NOTE: We have recently changed our polycarbonate film. All panels must be installed with the white film facing inside and the clear film with writing facing the sun. If you have any questions please feel free to contact us.
- Page 5 ALU. Box No.1 Front Assembly Door Assembly PART PART PART PART QTY. QTY. QTY. QTY. L18A L01D Ø4X16D J03R/L 1/1 L18B L01B L18C L01C L18D L01E J02R/L 1/1 L03E L18E L03F L18F L16A L04A L16B L04B L16C L04C M6x12 L05A L08A L05G L08B...
- Page 6 ALU. Box No.2 2 Sections Assembly PART PART QTY. QTY. L02A L02B M6x12 L04B M6x20 L05B L05C Ø4X16D L05D Ø 5x30 Ø 4x10 L08B M8x60 L15A W08A M5X35 L04E...
- Page 7 ALU. Box No.3 Middle Section Assembly PART PART PART PART QTY. QTY. QTY. QTY. L02A L02A L03A L02B L02B L03B M6x12 L04B L04B L03K M6x20 L05B L05B L08A L05C L05C L05E Ø4X16D L05D L05D L05F Ø 5x30 Ø4X10 L08B L08B M8x60 L15A L15A...
- Page 8 PC Box No. 1 Back Assembly Door Assembly Front Assembly PART PART PART QTY. QTY. QTY. PC Box No.1 PC Box No. 2 2 Sections Assembly PART QTY. PC Box No.2...
- Page 9 PART PART PART PART QTY. QTY. QTY. QTY. L01D Ø4X16D J03R/L 1/1 L01B L01C L01E J02R/L 1/1 L03E L03F L04A L04B L04C M6x12 L05A Overview of Front Assembly L08A L08B M8x60 L01B L01C L04B L04A L04C L01E L04B L03F L05A L01D L03E L05A...
- Page 10 PART PART PART PART QTY. QTY. QTY. QTY. L01A Ø4X16D J03R/L 1/1 L01B L01C L02E J02R/L 1/1 L03C L03D L04B L05A M6x12 L05B Overview of Back Assembly L08A L08B L01B M8x60 L01C L04B L04B L04B L04B L01A L05A L01A L05A L08A L03C L05B...
- Page 11 PART PART PART QTY. QTY. QTY. L02A L02B M6x12 L04B M6x20 L05B L05C Ø4X16D L05D Ø 5x30 Ø4X10 L08B M8x60 L15A W08A 2 M5X35 L04E Overview of 2 Sections Assembly L15A L15A L04B L02B L04E L05D L04E L02B L05D L04B L05B L02A L05B...
- Page 12 PART PART PART PART PART QTY. QTY. QTY. QTY. QTY. L02A L03A L02B L03B M6x12 L04B L03K M6x20 L08A L05B L05E L05C Ø4X16D L05F L05D Ø 5x30 Ø4X10 L08B M8x60 L15A W08A 2 M5X35 M6x12 L04E Overview of Middle Section Assembly L05D L15A L15A L04B...
- Page 13 10mm Expansion Screw / Concrete Ground * It is crucial the a + b dimensions are the same to ensure the base is square. Support at corners only is not adequate.
-
Page 14: Front Assembly
GRANGE-4 (4 x 4M) Front Assembly Back Assembly 43.4 4 Section Assembly Item No. 6 x 4M etc. 4 x 4M 8 x 4M 10 x 4M 12 x 4M 14 x 4M 16 x 4M 18 x 4M Dimensions (mm) 4059.4... - Page 15 GRANGE-4 + 2 Section Assembly (6 x 4M) Back Assembly Front Assembly 2 Section Assembly GRANGE-4 * The basic model, GRANGE-4, can be easily extended by adding a '2 Section Assembly' each time for a longer size.
- Page 16 1000 1000 1000 1000 1000 Front Back 2 Section Assembly GRANGE-4 * This shows a layout for W05's positions where it is placed in the middle of PC panel for each section.
- Page 17 PART QTY. L18A Door 1 Assembly L18B L18C L18C L18D L18E L18F L18A L16A L16B L16C L16C L05G L05G L05G L18B L05H M6x12 Ø5X15 L18C L18C L16C L18A L16C L18A L18B L18B...
- Page 18 Door 2 Assembly L18B L18A L16A L05G L05G L16B L18B L18B L16A L18A L16A L18A L16B L16B...
- Page 19 Door 3 Assembly L18E L18E L18D L18D L18F L05H L05H L18E L18F L05H L05H L18E L18D L18F L18E L18E...
- Page 20 PART QTY. L15A Roof Vent Assembly L15A M6X20 ∅ 4X16D ∅ 4X10...
- Page 21 L08B L08B L08A L08B L08A L08A L08B L08A L08B L08B J03R/L J03R/L L08A&B L08B L08A L08B L08A L08A&B J03R/L L08B L08B L08A J03R/L L08A L08B L08B J03R/L Assemble all W05 followed by previous Page 15 after each base profile is connected.
- Page 22 Ensure orientation of the L07 profile is correct as L02E per detail. L03C L03D L01A CORRECT WRONG L01A L03A L03A L02E L03C&L03D L01A 1*S01 Slide 1 x S01 into L02E and secure it. D&E L03A L01A L03A...
- Page 23 L04B L04B L04B L04B 2*S01 L04B Slide 2 x S01 into each L04B L04B L04B as shown and secure them. L04B...
- Page 24 Note: please insert upper roof supports, L01B & C, but do not lock in place until you have aligned the polycarbonate inserts. L01B L01C L05B L05B L05A L05A L01B L01C L01B L01C L05A L05A L05B L05B L05B...
- Page 25 Ensure orientation of the L07 profile is correct as per detail. L04C L04A CORRECT WRONG L01D L03F L03E L01E L03E&L03F L01E L01D L03F&E 3*S01 L04C L04A L04A L04A Slide 3 x S01 into L04A and secure them at each end. L03B L07 G D&E...
- Page 26 L04B L04B L03E&F L04B L04B 2*S01 2*S01 L04B L01D&E Slide 2 x S01 into L04B and Slide 2 x S01 into L04B and secure them at each end secure them at each end...
- Page 27 Note: please insert upper roof supports, L01B & C, but do not lock in place until you have aligned the polycarbonate inserts. L01B L01C L05A L05A L01B L01C L01B L01D L01E L01C L05A L05A...
- Page 28 L05C L05B L05C L05B L05C L05C L05B L05B Slide 3 x S01 into L02A and secure them at each end. 3*S01 L02A L05B L05C L05C L05B L05B...
- Page 29 L03B L03B L03B L03B L03B L03B...
- Page 30 Note: L08A / L03K are only required where heavy snow beyond 10cm is likely. L05E L05F L05F L03K L03K L08A L08A L08A L03K L05F L03K L05F L08A L05E L05F L03K L05E L05F...
- Page 31 L02B L02B L02B L02B L02B L02B S01x4pcs L02B...
- Page 32 Note: If it is difficult sliding any panels in the channels, using soapy water or olive oil in the channels can reduce the friction. L04B L04E L04B L04B L04E L04E L04B L04E L04B Pay attention to the cut L04B edge of L04B which should be fixed, facing down.
- Page 33 * The roof vents should be lifted through Roof Vent Assembly x 4PCS the vent opening from the inside of the greenhouse, then lowered into position from above the greenhouse. So the holes of the L15A line up with the ridge holes.
- Page 34 Insert all Y7 panels into each roof of greenhouse. Note: If it is difficult sliding any panels in the channels, using soapy water or olive oil in the channels can reduce the friction. Insert all Y6 panels into each side of greenhouse.
- Page 35 When installing the J06 and the second section of gutter, it can help if you have 2 people, one guiding the gutter into the J06 and the other gently tapping the end of the gutter with a rubber mallet. It can help to install the J06 into one end of the gutter before hand.
- Page 36 To install the doors, simply slide the hinge pins on the doors into the corresponding hinge sleeves on the greenhouse. The latch shown in image 1 joins the two sections of the doors together. To make minor height adjustments you can remove or add the spacers provided on the pin section of the hinge.
- Page 37 L05D L05D L05D L05D Once the L09 is in place. A small bead of silicon suitable for polycarbonate can assist in preventing leaks. L05D...
