- Page 1 Gazebo Glasshouse Assembly Instructions MODEL: LARGE GAZEBO PRODUCT SIZE(LxWxH):436x295x270cm PLEASE READ CAREFULLY BEFORE ASSEMBLY...
- Page 2 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that this product is assembled by at least two people. 2. Some components have sharp metal edges. Please be careful when handling metal components. Please wear gloves, shoes and safety goggles during assembly. 3.
-
Page 3: Functions And Features
Functions and Features: 1. Compared with traditional greenhouses this new product features many significant improvements. The hollow box profile aluminium framing is much stronger than other greenhouses and it can withstand much greater pressure. 2. Base anchor brackets are included as standard with expanding bolts to ensure a secure fixing into concrete or paving. - Page 4 5. Manual window handles are included as standard with the roof vents. If required, automatic roof vent openers are available as an inexpensive optional extra. Manual Opener Automatic Opener 6. Each Polycarbonate Panel comes with UV protected properties. Please ensure the clear film with the text faces out, toward the sun. Remove both films before installation of the panels.
- Page 5 POLYCARBONATE ORIENTATION PLEASE NOTE: We have recently changed our polycarbonate film. All panels must be installed with the white film facing inside and the clear film with writing facing the sun. If you have any questions please feel free to contact us.
- Page 6 LARGE GAZEBO (ALU Box No. 1) PART PART L04A L04B L05A L05B L07A L07B L08A L08B L09A L09B L23A L01A M5X12 M5X12 M4.2X16 Ø4X14D M4.2X16 M8X60 M6X12...
- Page 7 LARGE GAZEBO (ALU Box No. 2) PART Door Assembly L02E Vent Assembly x 2 PART L03B PART L03C L16A L19A L03D L16B L19B L03E L06A L18A L05C L18B L15A L05E L18C L18D L03A L05G...
- Page 8 LARGE GAZEBO (PC/Glass Box No. 1) PART PART 160M Rubber Sealing for Walls & Roof (Provided for Glass Panels only) PC/Glass PART NO.1 Rubber Sealing for Walls only (Provided for Glass Panels only)
-
Page 9: Vent Assembly
PART L19A Vent Assembly L19B M4.2X16 L19A L19A Install Vent Arm W06 in the middle L19B of L19B, 322mm from each end. Screws position L19B Screws position 20MM Insert Connector B & W07 into each end of the profiles L19A & L19B & L20, and then mark the distance from each end about 20MM. - Page 10 PART PART 2.65M L15A L15A M4.2X16 Ø4X14D Insert the Rubber J11 between Glass panels and Profiles as shown below (Not Provided for PC panels).
- Page 11 PART Left Door L16A L18A L16B L18A L05G L18B L18C L16B L18D L18D L05G M5X12 L05G M4.2X16 M6X12 L18B Insert Connector A into each end of the profiles L16B & L18A & L18B & L18D, and then mark the distance from each end about 20/30MM. 20MM Lastly, secure them with screws Z01.
-
Page 12: Right Door
Right Door L18B L05G L18C L16A L05G L18A Insert Connector A into each end of the profiles L16A & L18A & L18B & L18C, and then mark the distance from each end about 20/30MM. 20MM Lastly, secure them with screws Z01. 30MM * Please ensure there is no gaps between each profile. - Page 13 PART 12.2M Insert the Rubber J11 between Glass panels and Profiles as shown below (Not Provided for PC panels).
- Page 14 10mm Expansion Screw / Concrete Ground It is essential the dimensions a + b are the same to ensure the base is square. Support at the corners only is inadequate.
-
Page 15: Expansion Bolt Installation
PART M8X60 2949MM Expansion bolt installation 2899MM 10mm * This shows a layout for W05's positions where it is placed in the middle of the panel for each section. - Page 16 PART L01A L08B L08A L08A L08B L08A M5X12 L08B Insert the J02 into L08A & L08B as shown. L08B L08A L01A L01A L01A L01A L01A Install L01A onto L08A & L08B through the J02 using the screw S01.
- Page 17 PART L07A L07B Insert the J01 into L01A from the top, then connect L07A & L07B; Lastly, secure all parts using the screw S01. M5X12 * Please ensure all parts are in correct angle before tightening up screw S01. L07B L07A L07A L07B...
-
Page 18: Back Wall Assembly
PART L03A Back Wall Assembly M5X12 L03A L03A L03A L03A L03A Insert the first Panel Y5 into the channel of L01A, and then install L03A. Secure them with screw S01. L08B Do the same for another 4 sections. Lastly, slide the last Panel Y5 from the top into the channels of L01A &... -
Page 19: Side Wall Assembly
PART Side Wall Assembly L03A M5X12 L03A L03A Repeat the sequence as per the Back Wall Assembly, Y6 is the last panel to slide in. L07A L03A L08A L03A The last panel... -
Page 20: Front Wall Assembly
PART Front Wall Assembly L04A L04B L03A L03A L05C L03A M5X12 L04B M4.2X16 L04A L07B L03A L03A L08B L05C L05C L04A/L04B L01A L05C L05C... - Page 21 PART L05A L05B L05B M5X12 M4.2X16 L05A L05A L03A L01A L01A L05A/L05B L05A/L05B L05A/L05B Install each end of 2 x L05A & 1 x L05B onto each L01A, secure them with S01, and then use Z01 to fix them onto each L03A with the powered screw-driver.
- Page 22 PART L02E M4.2X16 L02E Keep L05A flush to L02E. L02E L05A Insert another end of Y6 into the channel of each L02E, and then align L02E & L05A, use Z01 to secure them with the powered screw-driver. * Please ensure L02E and L05A are flush & aligned.
- Page 23 PART Side Vent M5X12 M4.2X16 L02E 1. Use S01 to secure bracket W03 onto the vent profile L11 as shown in FIG. 1; 2. Mark on L03A through the holes of bracket W03 at distance 643MM from L02E as shown in FIG.2; Do the same on the other end;...
- Page 24 PART Insert the Rubber J11 between Glass panels and Profiles as shown below (Not Provided for PC panels).
-
Page 25: Roof Assembly
PART L23A Roof Assembly L03D M5X12 L03D L23A Use the bracket W25 to connect 2 x L23A & L03D 2 x L03D as shown, then secure them with S01 bolts. L23A L03D L23A L03D L23A Use S01 to secure the eave profiles Use the bracket W21 to connect all roof profiles L07B and the roof profiles L03D L23A and the eave profiles L07A &... - Page 26 PART L06A L03D L03D L03E L06A L03E L03D M5X12 Install 2 x L03D & 2 x L03E & 1 x L06A on the roof as shown, and secure them with S01. L03D L03D L07A L06A L03E L07B L03E L06A L03E...
- Page 27 PART PART L03B L03C L09A L03B L03C L09B M5X12 *Please ensure the orientation of Y1 & Y2 is correct when panel assembly. L03B/ L03C The longer edge, 826.8MM, should be L03B/ L03C placed vertically as shown. Use the bracket W22 to connect L03B & C, and secure them with S01.
- Page 28 Y8 Y8 Y3 Y8 Y8 Y4 Slide 1 x Y3, 1 x Y4 & 2 x Y8 in. Insert the Rubber J11 between Glass panels and Profiles as shown below (Not Provided for PC panels).
- Page 29 Gutter Assembly L09B Install the gutter profile L09B once all panels are completely inserted. Then tap L09B gently into the channel of L07B with a rubber mallet. Do the same on the other side. * Ensure none of the glass panels move or slide back during this process.
- Page 30 PART Bracing Assembly L05A L05C L05A L05E L05E L05C L05E M4.2X16 L05E M5X12 L05C L05A L05E L05E L05E Use S01 to secure each roof brace L05A & C onto L03B & C at each end, then use Z01 to secure them onto L03D & E in the middle. L03D L03B/ L03C L03B/ L03C...
-
Page 31: Door Assembly
PART Door Assembly M4.2X16 M4.2X16 M5X12 Right Door Left Door Use 3 x Z01 to secure L24 onto L07B. Use S02 to install 4 x Door Hinges L25 onto each door profile and L04A & L04B, then secure them with Z03 as shown below. 6 x S02 L04A 2 x Z03... - Page 32 PART Downpipe Assembly M4.2X16 Use Silicone to avoid leaking Drill a hole in L01A, roughly 3MM diameter (not provided). 700MM distance from the bottom. Use Z01 to secure the bracket J08 and then clip the downpipe J06 into the bracket J08.
