Summary of Contents for JWA GARRISON 75134
- Page 1 GARRISON Corner Desk ITEM CODE 75134 Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 Allow 30min For 2 person...
- Page 3 M6X30mm M6X15mm M6X40mm 22pcs 8pcs 2pcs 10pcs 16pcs ST3.5X14mm ST4X25mm M8X20X10mm 2pcs 2pcs 2pcs 6pcs Right top panel Left main frame connection frame Left top panel Left main frame top connection frame Layer panel Top panel support frame Left main frame X shape frame Front left main frame Back left main frame Right main frame X shape frame...
- Page 4 1. Insert part F into frames P1, P2 and P3. 1. Attach connection frames P4 and P5 to frames P1 and P2 with part C.
- Page 5 1. Attach panel 3 to connection frame P4 with part A. 1. Attach panels 1 and 2 to frames P1, P2, P3, P5 and P6 with part A.
- Page 6 STEP 5: 1. Attach frame P6 to frames P3 and P5 with part C. STEP 6: 1. Attach frame P8 to frames P2 and P3 with parts B and D. 2. Attach frame P7 to frames P1 and P2 with parts B and D.
- Page 7 STEP 7: 1. Connect frame P7 with part B and E. 2. Connect frame P8 with part B and E. STEP 8: Install Tip Kit 1. Attach part G to the back of panels 1 and 2 with part I. 2.
- Page 8 STEP 9: Assembly complete!
