- Page 1 CALDWELL Coffee Table ITEM CODE 75129 Imported by JWA Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please refer to your receipt...
- Page 2 For 1 person...
- Page 3 ST3 5X14mm 8X30mm ST5X50mm 18pcs 4pcs 56pcs 20pcs 8pcs ST4X25mm M4X18mm 2pcs 2pcs 2pcs 4pcs Bottom middle panel Top panel Drawer left panel Top middle panel Drawer right panel Layer panel Drawer back panel Bottom panel Foot panel Drawer bottom panel Back baffle panel Left side panel Drawer front panel...
- Page 4 1. Separate parts E1 and E2 (runners) as shown below. 2. Attach part E1 to panels 4 and 5 with part D. 1. Attach part E1 to the back and front of panel 6 with part D.
- Page 5 1. Insert part A into panel 3. 2. Attach panel 8 to panel 3 with part A. 1. Insert part A into panel 3. 2. Attach panel 9 to panel 3 with part A.
- Page 6 1. Insert parts A and B into panel 3. 2. Attach panel 6 to panel 3 with parts A and B. 1. Insert parts A and B into panel 2. 2. Attach panel 2 to panels 6 and 9 with parts A and B.
- Page 7 STEP 7: 1. Insert parts A and B into panel 2. 2. Attach panel 7 to panel 2 with parts A and B. STEP 8: 1. Insert parts A and B into panels 4 and 5.
- Page 8 STEP 9: 1. Insert panel 4 to panel 2 with parts A and B. STEP 10: 1. Attach panel 5 to panel 2 with parts A and B.
- Page 9 STEP 11: 1. Insert parts A and B into panel 1. 2. Attach panel 1 to panels 4, 5 and 7 with parts A and B. STEP 12: 1. Attach panels 11 and 12 to panel 13 with part C. 2.
- Page 10 STEP 13: 1. Insert part A into panel 10. 2. Attach panel 10 to panels 11 and 12 with part A. STEP 14: 1. Attach part E2 to panels 11 and 12 with part D. 2. Attach part G to panel 10 with part F.
- Page 11 STEP 15: 1. Install drawer 10 to the cabinet, ensure runners are correctly aligned. Install Tip Kit 1. Attach part I to the back of panel 1 with part D. 2. Attach part I to the wall with part H.
- Page 12 STEP 17: Assembly complete!
