Terminal assignment
14
Multidrop current:
4 mA
Time to establish connection:
< 30 s
Power supply
Single compartment housing
3
2
1
3
Connection terminals and ground terminal in the connection compartment
1
Positive terminal
2
Negative terminal
3
Internal ground terminal
Dual compartment housing
4
Connection terminals and ground terminal in the connection compartment
1
Positive terminal
2
Negative terminal
3
Internal ground terminal
Micropilot FMR60B HART
3
2
1
A0042594
A0042803
Endress+Hauser
