Endress+Hauser Micropilot FMR60B Technical Information page 41

Micropilot FMR60B HART
Endress+Hauser
Encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange
50 mm
R
 36 Dimensions of encapsulated antenna, PVDF, 40 mm (1.5 in), process connection UNI flange. Unit of
measurement mm (in)
R Reference point of measurement
1 Bottom edge of housing
UNI flange 3"/DN80/80A
 37 Dimensions of UNI flange 3"/DN80/80A. Unit of measurement mm (in)
Suitable for ASME B16.5, 3" 150lbs / EN1092-1; DN80 PN16 / JIS B2220; 10K 80A
Material:
PP, weight 0.50 kg (1.10 lb)
1
43.7 (1.72)
20 (0.79)
A0048829
A0048847
41
