Endress+Hauser Micropilot FMR60B Technical Information page 10

10
PTFE Drip-off antenna, 50 mm (2 in) in buffer vessel
Measurement in vessel with agitator
Vessel with agitator - measuring conditions
Turbulent medium surface (e.g. from filling from above, stirrers and baffles)
Integrated antenna, PEEK, 20 mm (0.75 in) in vessel with agitator
Integrated antenna, PEEK, 40 mm (1.5 in) in vessel with agitator
Media group
A0 (ε 1.2 to 1.4)
r
A (ε 1.4 to 1.9)
r
B (ε 1.9 to 4)
r
C (ε 4 to 10)
r
D (ε >10)
r
Media group
A (ε 1.4 to 1.9)
r
B (ε 1.9 to 4)
r
C (ε 4 to 10)
r
D (ε >10)
r
Media group
A0 (ε 1.2 to 1.4)
r
A (ε 1.4 to 1.9)
r
B (ε 1.9 to 4)
r
C (ε 4 to 10)
r
D (ε >10)
r
Micropilot FMR60B HART
Measuring range
4 m (13 ft)
7 m (23 ft)
13 m (43 ft)
28 m (92 ft)
44 m (144 ft)
Measuring range
1 m (3.3 ft)
1.5 m (5 ft)
3 m (10 ft)
5 m (16 ft)
Measuring range
1 m (3.3 ft)
1.5 m (5 ft)
3 m (10 ft)
7 m (23 ft)
11 m (36 ft)
