- Page 1 Pre-Installation Guide Quasar Laser Systems Spectra-Physics 3635 Peterson Way Santa Clara, CA 95054 800- 456-2552 March 2020 ©Newport Corporation MKS Spectra-Physics Confidential 1 of 29...
-
Page 2: Table Of Contents
Unpacking the Laser Head (Cont’d) ......................23 Unpacking the Optional Chiller ........................24 Packing the Laser System for Transportation or Return to Spectra-Physics ..........25 Indexing and Multiple Mounting Schemes ....................25 Primary (Recommended) Installation Options for Bench Testing .............. 25 Additional Installation Options ........................ -
Page 3: Introduction
Introduction Congratulations on your purchase of a Spectra-Physics laser system. The purpose of this document is to assist the user in establishing a suitable location and operating environment for optimum performance of the Quasar system. Proper power and room temperatures are required for each system. You are responsible for meeting these requirements prior to installation, with due consideration given to all applicable building and safety codes. -
Page 4: When Your System Arrives
Make sure that each system has a user’s Packet, which contains a USB stick. Note that some items may have been installed at the factory. Report any missing or damaged items to Spectra-Physics. ©Newport Corporation... -
Page 5: Pre-Installation Considerations
Pre-Installation Considerations Environmental Specifications The environmental conditions under which the laser system functions are listed on Spectra-Physics website at http://www.newport.com/Quasar These specifications reflect indoor use conditions. Feature Specifications Altitude Up to 3000M Temperatures 15C to 35C Maximum relative humidity 85% non-condensing for temperatures up to 31C... -
Page 6: Utility Requirements (Cont'd)
The LASER HEAD control cable is a standard 5 m (16 ft.). The SHUTTER control cable is a standard 5 m (16 ft.). The air hoses with connectors are a standard 5 m (16 ft.). ©Newport Corporation MKS Spectra-Physics Confidential 6 of 29... -
Page 7: Outline Drawings
Outline Drawings Laser Head ______________________________________________________ All dimensions in the figures are inches over mm. ______________________________________________________ Figure 1-1 Quasar laser head outline, top and side view ©Newport Corporation MKS Spectra-Physics Confidential 7 of 29... -
Page 8: Outline Drawings (Cont'd)
Outline Drawings (Cont’d) Laser Head (Cont’d) Figure 1-2 Quasar laser head outline, bottom view Figure 1-3 Quasar laser head outline, front (left) and rear (right) view ©Newport Corporation MKS Spectra-Physics Confidential 8 of 29... -
Page 9: Outline Drawings (Cont'd)
Outline Drawings (Cont’d) Power Supply _______________________________________________________ All dimensions in the figures are inches over mm ____________________________________________________________ Figure 1-5 QPS power supply outline, front Figure 1-6 QPS power supply outline, side ©Newport Corporation MKS Spectra-Physics Confidential 9 of 29... -
Page 10: Outline Drawings (Cont'd)
Outline Drawings (Cont’d) Chiller Drawings ©Newport Corporation MKS Spectra-Physics Confidential 10 of 29... -
Page 11: Heat Dissipation Requirements
It is designed to protect ferrous metals and copper alloys from corrosion. It is nitrite free and it minimizes the problems associated with bacteria control. Nalco can be ordered directly from Spectra-Physics, P/N 1607-0546. See Appendix B, “Nalco MSDS,” in the User’s Manuel for more information about the Nalco product. -
Page 12: Computer Requirements
Connect your control device (e.g., a computer) to this type-B connector using a standard USB cable. The USB port is the recommended means of providing serial control. ©Newport Corporation MKS Spectra-Physics Confidential 12 of 29... -
Page 13: Computer Requirements (Cont'd)
Only three of the nine pins are used. Refer to the pin descriptions in Table 1-5. Table 1-5 IBM/PMAT Serial Computer or Terminal RS-232-C -Signal Name Signal Pin No. (9-Pin) Pin No. Signal Transmit data Receive data Signal ground Protective ground SHELL SHELL ©Newport Corporation MKS Spectra-Physics Confidential 13 of 29... -
Page 14: Baud Rate Default
Your Quasar laser was packed with great care and its container was inspected prior to shipment— it left Spectra-Physics in good condition. Upon receiving your system, immediately inspect the outside of the shipping container. If there is any major damage (holes in the container, crushing, etc.), insist that a representative of the carrier be present when you unpack the contents. -
Page 15: Accessory Kit Parts List
A 5/32” hex ball driver (length ~ 10") A hoist with load capacity of 181 kg (400 lb.) to move the laser from the crate onto the table where it will operate ©Newport Corporation MKS Spectra-Physics Confidential 15 of 29... -
Page 16: Lifting And Moving The Laser
Lifting and Moving the Laser Spectra-Physics has specifically designed two service handles (ordered separately) to assist in moving the laser. Ensure that all the hardware is tight before moving the laser. Four people are required to move the laser if the lifting handles are going to be used. -
Page 17: Unpacking The Laser System
Unpacking the Laser System For customers who integrate the laser into a tool, Spectra-Physics recommends that the laser be shipped in its original container. The shipping crate offers the best protection. Spectra-Physics further recommends that you repackage the laser and vacuum seal the laser in a new shipping bag. -
Page 18: Unpacking The Power Supply/Accessory Kit Crate (Cont'd)
Using two people, lift the cover up so that it clears the contents, then set it aside. d) Inspect the shock watches on each box. If they are tripped, call your Spectra-Physics representative immediately. If they are not tripped, proceed. -
Page 19: Unpacking The Power Supply
Open the inner bag, then open the inner box and remove the white styrofoam piece. When the inner box is opened, remove the accessory bags, and place them in a safe location. They are needed to connect the laser system. ©Newport Corporation MKS Spectra-Physics Confidential 19 of 29... -
Page 20: Unpacking The Power Supply (Cont'd)
Do a preliminary inspection of the power supply for damage and, if found, report the damage to Spectra-Physics. If there is no damage, proceed with the next step. Place all the packing materials in the crate and reseal the crate. -
Page 21: Unpacking The Laser Head
Unfasten the four clamps around the bottom of the crate that fasten the top portion of the crate (the cover) to the palette. Turn the handles counter-clockwise and disengage the latch as shown c) Undo the locks from the crate to the base ©Newport Corporation MKS Spectra-Physics Confidential 21 of 29... -
Page 22: Unpacking The Laser Head (Cont'd)
4. Unscrew the clamps on the front and back of the laser head using a 1/2 in. driver. Open all of the bags to expose the lifting eyelet. This is where the lifting mechanism attaches to the laser to remove it from the crate. ©Newport Corporation MKS Spectra-Physics Confidential 22 of 29... -
Page 23: Unpacking The Laser Head (Cont'd)
Alternatively, two handles are provided to assist in moving the laser. The hardware is already attached to the laser while inside the crate. Four people are required to move the laser. Place all packing material in the crate and close the crate. ©Newport Corporation MKS Spectra-Physics Confidential 23 of 29... -
Page 24: Unpacking The Optional Chiller
Place all packing material in the crate and close the crate. If the installation site is properly prepared, the Quasar is now ready for installation. Please refer to the Quasar User’s Manual for Instructions. ©Newport Corporation MKS Spectra-Physics Confidential 24 of 29... -
Page 25: Packing The Laser System For Transportation Or Return To Spectra-Physics
Packing the Laser System for Transportation or Return to Spectra- Physics To return the Quasar system to Spectra-Physics for service, repair, or upgrade, use the original crates, boxes, bags, and packing material to repack it. Just reverse the unpacking instructions in the previous section to repack the system. -
Page 26: Additional Installation Options
Ensure that the electrical cables and interface cables are safely routed and are not under any strain. Avoid conditions where these cables can be stepped on by personnel. ©Newport Corporation MKS Spectra-Physics Confidential 26 of 29... -
Page 27: Installation Requirements For The Chiller
(4 Gallon Capacity, preferred mix is 2 Gallons of Nalco and 2 Gallons of distilled water.) Spectra-Physics provides optional chillers that are suitable for use with the Quasar laser system. If your chiller was ordered from the factory with your laser, it meets these requirements. For specific information about the chiller shipped with your system, consult the chiller manual included with the system. -
Page 28: Interconnect Diagram
Interconnect Diagram ©Newport Corporation MKS Spectra-Physics Confidential 28 of 29... -
Page 29: Required Maintenance
Chiller should have its fluid changed every 6 months at a minimum. Check chiller hoses every 3 to 6 months. Laser head desiccant should be replaced every 12 months. ALPS (active laser purification system) should be replaced every 12 months. ©Newport Corporation MKS Spectra-Physics Confidential 29 of 29...
