- Page 1 Pre-Installation Guide Talon Laser Systems Spectra-Physics 3635 Peterson Way Santa Clara, CA 95054 800-456-2552 March 2020 ©Newport Corporation MKS Spectra-Physics Confidential 1 of 9...
-
Page 2: When Your System Arrives
Up to 3000 m Temperatures: 15C to 35C Maximum relative Humidity: 85% non-condensing for temperatures up to 31C Mains supply voltage: Do not exceed +- 10% of the nominal voltage Insulation category: Pollution degree: ©Newport Corporation MKS Spectra-Physics Confidential 2 of 9... -
Page 3: Environmental Control
Fuse ratings for F1, F2 for the D-Series power supply Supply Voltage Fuses (x2, ceramic package) 100 – 240 VAC T10 A / 250 V slow blow Cooling Requirements Chiller output specifications Specifications Feature Fluid temperature 20°C ©Newport Corporation MKS Spectra-Physics Confidential 3 of 9... - Page 4 Outline Drawings Utility Module Outline Drawings Utility Unit Front View Utility Unit Back View ©Newport Corporation MKS Spectra-Physics Confidential 4 of 9...
- Page 5 Utility Module Outline Drawings (Continued) Utility Unit Top View ©Newport Corporation MKS Spectra-Physics Confidential 5 of 9...
- Page 6 Laser Module Outline Drawings Side View with optional shutter and optional mounting plate Bottom View ©Newport Corporation MKS Spectra-Physics Confidential 6 of 9...
- Page 7 Laser Module Outline Drawings (Continued) Back View Front View with Optional Mounting Plate ©Newport Corporation MKS Spectra-Physics Confidential 7 of 9...
- Page 8 Laser Module Outline Drawings (Continued) Optional Mounting Plate ©Newport Corporation MKS Spectra-Physics Confidential 8 of 9...
-
Page 9: Required Maintenance
Replace every six months Refer to “Flushing and Refilling the Chiller in the User’s Manual.” Replace every twelve months Refer to “Replacing the ALPS Filter in the Active Laser Purification User’s Manual.” System (ALPS) ©Newport Corporation MKS Spectra-Physics Confidential 9 of 9...
