Pre-Installation Considerations
Environmental Specifications
The environmental conditions under which the laser system functions are listed on Spectra-Physics
website at
http://www.newport.com/Quasar
These specifications reflect indoor use conditions.
Feature
Altitude
Temperatures
Maximum relative humidity
Mains Supply Voltage
Insulation category
Pollution degree
Utility Requirements
Provide enough room cooling capacity to remove this waste heat and prevent the system from
overheating. Provide at least 6 inches of unobstructed space around the front and 8 inches at the
rear panels of the QPS to allow cooling air to enter the front and heated air to exhaust from the
back. The power supply draws 200 CFM of air flow.
Feature
AC Power input
Maximum power consumption (EOL)
The Quasar Laser will NOT operate on 110VAC
The circuit must be capable of delivering 15 Amps. You must use two separate 15 Amp circuits
for the chiller and controller.
The QPS power supply incorporates double-pole neutral fusing for operation from 190 to 240
VAC. These two fuses are located on the rear panel of the power supply and can be accessed using
a standard screwdriver. Replacement fuses must be size 5 x 32 mm and of same type and rating
as below.
Supply Voltage
190 – 240 VAC
©Newport Corporation
Specifications
Up to 3000M
15C to 35C
85% non-condensing for temperatures up to 31C
Do not exceed + 10% of the nominal voltage
II
2
Specifications
190 to 240 VAC (15 Amp service)
2200W
Fuse (x2, ceramic package)
T15 A/250 slow blow
MKS Spectra-Physics Confidential
5 of 29
