Cambium
PTP 820C/820S
User Guide
System Release 8.3
phn-3963_004v000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTP 820C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cambium Networks PTP 820C

Summary of Contents for Cambium Networks PTP 820C

  • Page 1 Cambium PTP 820C/820S User Guide System Release 8.3 phn-3963_004v000...
  • Page 2 (“High Risk Use”). Any High Risk is unauthorized, is made at your own risk and you shall be responsible for any and all losses, damage or claims arising out of any High Risk Use. © 2015 Cambium Networks Limited. All Rights Reserved. phn-3963_004v000...

  • Page 3: Table Of Contents

    Contents About This User Guide .......................... 1 Contacting Cambium Networks ....................2 Purpose ............................3 Cross references ..........................3 Feedback ............................3 Problems and warranty ........................4 Reporting problems ........................4 Repair and service .......................... 4 Hardware warranty ........................4 Security advice ............................
  • Page 4 Configuring HSB Radio Protection ....................3-28 HSB Radio Protection Overview ....................3-28 Configuring HSB Radio Protection ..................3-28 Configuring 2+2 HSB Protection on a PTP 820C Unit ............3-31 Viewing the Configuration of the Standby unit ..............3-31 Editing Standby Unit Settings ....................3-32 Viewing Link and Protection Status and Activity ..............
  • Page 5 Viewing MMI and XPI Levels ....................3-41 Deleting a MIMO or Space Diversity Group ................3-42 Operating a PTP 820C in Single Radio Carrier Mode ..............3-43 Unit Management ....................... 4-44 Defining the IP Protocol Version for Initiating Communications ..........4-45 Configuring the Remote Unit’s IP Address ..................
  • Page 6 Contents Configuring Radio Thresholds ....................5-19 Displaying MRMC Status ......................5-21 Displaying MRMC PMs ......................5-22 Displaying and Clearing Defective Block Counters ..............5-23 Displaying Signal Level PMs ....................5-25 Displaying Modem BER (Aggregate) PMs ................5-26 Displaying Modem MSE PMs ....................5-28 Displaying XPI PMs ........................
  • Page 7 Contents Enabling Marking ........................7-53 Modifying the 802.1Q Marking Table ..................7-53 Modifying the 802.1AD Marking Table ..................7-54 Configuring WRED ........................... 7-56 WRED Overview ........................7-56 Configuring WRED Profiles ...................... 7-56 Assigning WRED Profiles to Queues ..................7-59 Configuring Egress Shaping ......................7-60 Egress Shaping Overview ......................
  • Page 8 Contents Configuring User Profiles ..................... 10-108 Configuring Users ......................... 10-110 Configuring RADIUS ........................10-113 RADIUS Overview ......................... 10-113 Activating RADIUS Authentication ..................10-113 Configuring the RADIUS Server Attributes................. 10-114 Viewing RADIUS User Permissions and Connectivity ............10-115 Configuring a RADIUS Server ....................10-117 Configuring X.509 CSR Certificates and HTTPS ................
  • Page 9 HSB Radio Protection Overview (CLI) ................. 14-211 Configuring HSB Radio Protection (CLI) ................14-211 Configuring 2+2 HSB Protection on a PTP 820C Unit (CLI) ..........14-212 Viewing the Configuration of the Standby unit (CLI) ............14-213 Editing Standby Unit Settings (CLI) ..................14-213...
  • Page 10 Viewing MMI and XPI Levels (CLI) ..................14-219 Deleting a MIMO or Space Diversity Group (CLI) .............. 14-221 Operating a PTP 820C in Single Radio Carrier Mode (CLI) ............14-222 Unit Management (CLI) ..................15-223 Defining the IP Protocol Version for Initiating Communications (CLI) ........15-224 Configuring the Remote Unit’s IP Address (CLI) ...............
  • Page 11 Contents Displaying Communication Status with the Remote Radio (CLI) ........16-249 Displaying the Remote Radio’s Link ID (CLI) ..............16-249 Muting and Unmuting the Remote Radio (CLI) ..............16-249 Displaying the Remote Radio’s RX Level (CLI) ..............16-250 Configuring the Remote Radio’s TX Level (CLI) ..............16-250 Configuring Remote ATPC (CLI) ..................
  • Page 12 Contents Configuring an Interface’s Auto Negotiation State (CLI) ........... 17-310 Configuring an Interface’s IFG (CLI) ..................17-310 Configuring an Interface’s Preamble (CLI) ................17-311 Adding a Description for the Interface (CLI) ............... 17-311 Displaying Interface Statistics (RMON) (CLI) ..............17-312 Configuring Automatic State Propagation (CLI)................
  • Page 13 Contents Configuring Shapers (CLI) ......................18-357 Overview of Egress Shaping (CLI) ..................18-357 Configuring Service Bundle Shapers (CLI) ................. 18-360 Configuring Egress Line Compensation for Shaping (CLI) ..........18-363 Configuring Scheduling (CLI) ...................... 18-364 Overview of Egress Scheduling (CLI) .................. 18-364 Configuring Queue Priority (CLI) ..................
  • Page 14 Performing Ethernet Loopback (CLI) ................... 22-431 Working in CW Mode (Single or Dual Tone) (CLI) ..............22-433 Maintenance ......................23-434 PTP 820C Connector Pin-outs ..................... 23-435 Eth1/PoE - GbE Electrical+PoE/Optical ................23-435 Eth2 - GbE Electrical/Optical ....................23-436 MIMO Port ..........................23-436 MGT/PROT - Management (FE-Standard) and Protection (FE-Non-Standard) ....
  • Page 15 Contents MGT/PROT - Management (FE-Standard) and Protection (FE-Non-Standard) ....23-443 DC ............................23-443 RSL Interface .......................... 23-443 PTP 820S LEDs ..........................23-444 Electrical GbE Interface (RJ-45) LEDs .................. 23-444 Optical GbE Interface (SFP) LEDs ..................23-444 Management FE Interface (RJ-45) LEDs ................23-444 Radio LED ..........................
  • Page 16 Figure 16 Multiple Selection Operation Section (Interface Manager Page) ........2-18 Figure 17 Radio Parameters Page PTP 820C..................2-19 Figure 18 Radio Parameters Page Per Carrier – PTP 820C ..............2-20 Figure 19 MRMC Symmetrical Scripts Page (ETSI) ................2-22 Figure 20 MRMC Symmetrical Scripts Page (PTP 820C) (ETSI) ............
  • Page 17 Figure 67 Remote Networking Configuration Page – PTP 820C ............4-46 Figure 68 Remote Networking Configuration Page – PTP 820S ............4-47 Figure 69 Remote IP Configuration Page Per Carrier – PTP 820C ............. 4-48 Figure 70 SNMP Parameters Page ....................... 4-50 Figure 71 V3 Users Page ........................
  • Page 18 Figure 95 Radio Ethernet Interface Configuration Page – PTP 820C ..........5-10 Figure 96 Radio Ethernet Interface Configuration – Edit Page Per Carrier – PTP 820C ....5-11 Figure 97 Radio Ethernet Interface Counters Page – PTP 820C ............5-12 Figure 98 Radio Ethernet Interface Counters Page –...
  • Page 19 Contents Figure 125 Attached VLAN List - Add Page..................6-19 Figure 126 Ethernet General Configuration Page ................6-21 Figure 127 Physical Interfaces Page ....................6-22 Figure 128 Physical Interfaces - Edit Page ..................6-23 Figure 129: Automatic State Propagation Page................... 6-25 Figure 130: Automatic State Propagation - Add Page ................
  • Page 20 Contents Figure 168 Logical Interfaces – Shaper – Egress Queue Shaper............7-65 Figure 169 Logical Interfaces – Egress Queue Shaper Configuration – Add Page ......7-65 Figure 170 Logical Interfaces – Shaper – Egress Service Bundle Shaper ........7-67 Figure 171 Logical Interfaces – Egress Service Bundle Shaper Configuration – Add Page ... 7-68 Figure 172 Scheduler Priority Profile Page ..................
  • Page 21 Contents Figure 211 Server Manager – Creating Users .................. 10-119 Figure 212 Server Manager – Creating a RADIUS Client ..............10-120 Figure 213 Create Network Policy – Specify Name and Connection Type ........10-122 Figure 214 Create Network Policy – Select Condition ..............10-123 Figure 215 Create Network Policy –...
  • Page 22 Figure 256 ifIndex Calculator Page ....................12-174 Figure 257 MIB Reference Table Page ....................12-175 Figure 258 PTP 820C Interfaces ......................23-435 Figure 259 PTP 820C DC Port Connector ..................23-437 Figure 260 PTP 820S Interfaces ......................23-441 Figure 261 PTP 820S DC Connector ....................23-443 Figure 262: PoE Injector Connectors ....................
  • Page 23 Contents List of Tables Table 1 PTP 820 Web EMS Menu Hierarchy ..................1-6 Table 2 PTP 820 Web EMS Menu Hierarchy ..................2-12 Table 3 Activation Key-Enabled-Features Table Parameters ............2-14 Table 4 Time Services Parameters ...................... 2-16 Table 5 MRMC Symmetrical Scripts Page Parameters ..............2-25 Table 6 Available Radio Profiles ......................
  • Page 24 Contents Table 42 LLDP Read-Only Configuration Parameters ................ 8-84 Table 43 LLDP Configurable Configuration Parameters ..............8-85 Table 44 LLDP Port Configuration Status Parameters ............... 8-87 Table 45 LLDP Management TLV Parameters ..................8-89 Table 46 LLDP Remote System Management Parameters ..............8-90 Table 47 LLDP Remote System Table Parameters ................
  • Page 25 Contents Table 85 NTP CLI Parameters ......................15-246 Table 86 Remote Radio Mute/Unmute CLI Parameters ..............16-249 Table 87 Remote Radio TX Level CLI Parameters ................16-250 Table 88 Remote Radio ATPC CLI Parameters ................16-251 Table 89 Radio ATPC CLI Parameters ....................16-252 Table 90 Header De-Duplication CLI Parameters ................
  • Page 26 Contents Table 128 Configure S-VLAN Ethertype CLI Parameters ............... 17-304 Table 129 Configure MRU CLI Parameters ..................17-305 Table 130 Entering Interface View CLI Parameters ................ 17-306 Table 131 Interface Media Type CLI Parameters ................17-309 Table 132 Interface Speed and Duplex State CLI Parameters ............17-309 Table 133 Interface Auto Negotiation State CLI Parameters ............
  • Page 27 Contents Table 171 Assigning WRED Profile to Queue CLI Parameters ............18-355 Table 172 Queue Shaper Profiles CLI Parameters ................. 18-358 Table 173 Attaching Shaper Profile to Queue CLI Parameters ............. 18-359 Table 174 Service Bundle Shaper Profiles CLI Parameters ............18-361 Table 175 Attaching Shaper Profile to Service Bundle CLI Parameters ........
  • Page 28 Table 214 CW Mode CLI Parameters ....................22-433 Table 215: PTP 820C Eth1/PoE Interface- RJ-45/SFP Pinouts ............23-435 Table 216 PTP 820C Eth2 Interface - RJ-45/SFP Pinouts ..............23-436 Table 217 PTP 820C MIMO Port - RJ-45/SFP pinouts ..............23-436 Table 218 PTP 820C MGT/PROT Interface - RJ-45 Pinouts ............

  • Page 29: About This User Guide

    About This User Guide This document explains how to configure and operate a PTP 820C/820S system. This document applies to software version 8.2. The PTP 820 system is a modular system with a wide variety of configuration options. Not all configurations are described in this manual.

  • Page 30: Contacting Cambium Networks

    About This User Guide Problems and warranty  Chapter 24: Alarms List Contacting Cambium Networks Support website: http://www.cambiumnetworks.com/support Main website: http://www.cambiumnetworks.com Sales enquiries: solutions@cambiumnetworks.com Support enquiries: support@cambiumnetworks.com Repair enquiries rma@cambiumnetworks.com Telephone number list: http://www.cambiumnetworks.com/support/contact-support Address: Cambium Networks Limited, Global Headquarters...

  • Page 31: Purpose

    It is recommended that all personnel engaged in such activities be properly trained. Cambium Networks disclaims all liability whatsoever, implied or express, for any risk of damage, loss or reduction in system performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the instructions, system parameters, or recommendations made in this document.

  • Page 32: Problems And Warranty

    Hardware warranty Cambium Networks’s standard hardware warranty is for one (1) year from date of shipment from Cambium Networks or a Cambium distributor. Cambium Networks warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service.

  • Page 33: Security Advice

    Security advice Security advice Cambium Networks systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry recognized security practices. Security aspects to be considered are protecting the confidentiality, integrity, and availability of information and assets.

  • Page 34: Warnings, Cautions, And Notes

    Warnings, cautions, and notes Warnings, cautions, and notes The following describes how warnings and cautions are used in this document and in all documents of the Cambium Networks document set. Warnings Warnings precede instructions that contain potentially hazardous situations. Warnings are used to alert the reader to possible hazards that could cause loss of life or physical injury.

  • Page 35: Caring For The Environment

    Caring for the environment The following information describes national or regional requirements for the disposal of Cambium Networks supplied equipment and for the approved disposal of surplus packaging. In EU countries The following information is provided to enable regulatory compliance with the European Union (EU) directives identified and any amendments made to these directives when using Cambium equipment in EU countries.

  • Page 36: Introduction

    The Web-Based Element Management System  Reference Guide to Web EMS Menu Structure This user manual provides instructions for configuring and operating the following systems:  PTP 820C  PTP 820S Each of these systems can be used with a PoE (PoE Injector Overview).

  • Page 37: System Overview

    The PoE injector box is designed to offer a single cable solution for connecting both data and the DC power supply to the PTP 820C or PTP 820S system. To do so, the PoE injector combines 48VDC input and GbE signals via a standard CAT5E cable using a proprietary design.

  • Page 38: The Web-Based Element Management System

    Chapter 1: Introduction System Overview The Web-Based Element Management System Introduction to the Web EMS The Element Management System (Web EMS) is an HTTP web-based element manager that enables the operator to perform configuration operations and obtain statistical and performance information related to the system, including: ...

  • Page 39: Figure 1 Main Web Ems Page

    Chapter 1: Introduction System Overview Figure 1 Main Web EMS Page Optionally, you can display a representation of the PTP 820 front panel by clicking either the arrow in the center or the arrow at the right of the bottom toolbar. Figure 2 Displaying a Representation of the Front Panel Figure 3 Main Web EMS Page with Representation of Front Panel When HSB radio protection is enabled, two tabs appear on the top of the main section.

  • Page 40: Figure 4 Main Web Ems Page With Active And Standby Tabs

    Chapter 1: Introduction System Overview Figure 4 Main Web EMS Page with Active and Standby Tabs Certain pages include a Related Pages drop-down list on the upper right of the main section of the page. You can navigate to a page related to the current page by selecting the page from this list. Figure 5 Related Pages Drop-Down List phn-3963_004v000 Page 1-5...

  • Page 41: Reference Guide To Web Ems Menu Structure

    Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Reference Guide to Web EMS Menu Structure The following table shows the Web EMS menu hierarchy, with links to the sections in this document that provide instructions for the relevant menu item. Note Some menu items are only available if the relevant activation key or feature is enabled.
  • Page 42 Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Root Sub-Menus For Further Information Menu Item Reserved for future use. Configuration > Timer Parameters Viewing Current Backup Files Configuration > Backup Files Backing Up and Restoring Configurations Configuration > Configuration Management Configuring the Activation Key Activation Key >...
  • Page 43 Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Root Sub-Menus For Further Information Menu Item Viewing Current Alarms Current alarms Viewing the Event Log Faults Event Log Editing Alarm Text and Severity Alarm Configuration Configuring the Radio Parameters Radio Parameters Configuring the Remote Radio Parameters Remote Radio Parameters...
  • Page 44 Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Root Sub-Menus For Further Information Menu Item Configuring Multi-Carrier ABC Groups > Multi Radio Configuring MIMO and Space Diversity Groups > MIMO Setting the MRU Size and the S-VLAN General Configuration Ethertype Configuring Ethernet Service(s) Services...
  • Page 45 Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Root Sub-Menus For Further Information Menu Item Configuring WRED QoS > WRED > WRED Profile Configuring Queue Shaper Profiles QoS > Shaper > Queue Profiles Configuring Service Bundle Shaper Profiles QoS >...
  • Page 46 Chapter 1: Introduction Reference Guide to Web EMS Menu Structure Root Sub-Menus For Further Information Menu Item Displaying LLDP Statistics Protocols > LLDP > Advanced > Statistic > Port RX Configuring Service OAM (SOAM) Fault Protocols > SOAM > MD Management (FM) Configuring Service OAM (SOAM) Fault Protocols >...

  • Page 47: Getting Started

    Getting Started This section includes:  Assigning IP Addresses in the Network  Establishing a Connection  Logging on  Changing Your Password  Configuring In-Band Management  Changing the Management IP Address  Configuring the Activation Key  Setting the Time and Date (Optional) ...

  • Page 48: Assigning Ip Addresses In The Network

    Chapter 2: Getting Started Assigning IP Addresses in the Network Assigning IP Addresses in the Network Before connection over the radio hop is established, it is of high importance that you assign the PTP 820 unit a dedicated IP address, according to an IP plan for the total network. Changing the Management IP Address.

  • Page 49: Establishing A Connection

    Chapter 2: Getting Started Establishing a Connection Establishing a Connection Connect the PTP 820 unit to a PC by means of a Twisted Pair cable. The cable is connected to the MGT port on the PTP 820 and to the LAN port on the PC. Refer to the Installation Guide for the type of unit you are connecting for cable connection instructions.

  • Page 50: Pc Setup

    Chapter 2: Getting Started PC Setup PC Setup To obtain contact between the PC and the PTP 820 unit, it is necessary to configure an IP address on the PC within the same subnet as the PTP 820 unit. The default PTP 820 IP address is 192.168.1.1.

  • Page 51: Figure 6 Internet Protocol Properties Window

    Chapter 2: Getting Started PC Setup Figure 6 Internet Protocol Properties Window Logging on 1. Open an Internet browser (Internet Explorer or Mozilla Firefox). 2. Enter the default IP address “192.168.1.1” in the Address Bar. The Login page opens. Figure 7 Login Page 3.

  • Page 52: Logging In Without Knowing The Ip Address

    If the unit's IP address has been changed from its default of 192.168.1.1, and you do not know the new IP address, you can log into the unit by establishing a connection directly to the CPU. This requires a Cambium Networks proprietary Low Level Access Ethernet cable. This cable should be ordered from Cambium Networks (part number N000082L062A).

  • Page 53: Changing Your Password

    In addition to the Admin password, there is an additional password protected user account, “root user”, which is configured in the system. The root user password and instructions for changing this password are available from Cambium Networks Customer Support. It is strongly recommended to change this password.

  • Page 54: Configuring In-Band Management

    You can configure in-band management in order to manage the unit remotely via its radio and/or Ethernet interfaces. Each PTP 820C unit includes a pre-defined management service with Service ID 257. The management service is a multipoint service that connects the two local management ports and the network element host CPU in a single service.

  • Page 55: Changing The Management Ip Address

    Chapter 2: Getting Started Changing the Management IP Address Changing the Management IP Address Related Topics:  Defining the IP Protocol Version for Initiating Communications  Configuring the Remote Unit’s IP Address To change the management IP address of the local unit: 1.
  • Page 56 Chapter 2: Getting Started Changing the Management IP Address 6. Optionally, in the IPv6 Address field, enter an IPv6 address for the unit. You can enter the address in IPv6 format in this field, and/or in IPv4 format in the IP Address field. The unit will receive communications whether they are sent to its IPv4 address or its IPv6 address.

  • Page 57: Configuring The Activation Key

    Chapter 2: Getting Started Configuring the Activation Key Configuring the Activation Key This section includes:  Activation Key Overview  Viewing the Activation Key Status Parameters  Entering the Activation Key  Activating a Demo Activation Key  Displaying a List of Activation-Key-Enabled Features Activation Key Overview PTP 820 offers a pay-as-you-grow concept in which future capacity growth and additional functionality can be enabled with activation keys.

  • Page 58: Viewing The Activation Key Status Parameters

    Chapter 2: Getting Started Configuring the Activation Key Viewing the Activation Key Status Parameters To display the current activation key status parameters: 1. Select Platform > Activation Key > Activation Key Configuration. The Activation Key Configuration page opens. Figure 10 Activation Key Configuration Page Table 2 PTP 820 Web EMS Menu Hierarchy Parameter Definition...

  • Page 59: Entering The Activation Key

    Chapter 2: Getting Started Configuring the Activation Key Entering the Activation Key 1. To enter a new activation key: 2. Select Platform > Activation Key > Activation Key Configuration. The Activation Key Configuration page opens (Figure 10). 3. Enter the activation key cipher you have received from the vendor in the Activation Key field. The activation key cipher is a string that enables all features and capacities that have been purchased for the unit.

  • Page 60: Table 3 Activation Key-Enabled-Features Table Parameters

    Chapter 2: Getting Started Configuring the Activation Key The Activation Key Overview page displays the activation-key-enabled features and capacities for the PTP 820, and indicates the activation key status of each feature according to the activation key currently implemented in the unit. Note Some of the features listed in the Activation Key Overview page may not be supported in the currently installed software version.

  • Page 61: Setting The Time And Date (Optional)

    Chapter 2: Getting Started Setting the Time and Date (Optional) Setting the Time and Date (Optional) Related Topics:  Configuring NTP PTP 820 uses the Universal Time Coordinated (UTC) standard for time and date configuration. UTC is a more updated and accurate method of date coordination than the earlier date standard, Greenwich Mean Time (GMT).

  • Page 62: Table 4 Time Services Parameters

    Chapter 2: Getting Started Setting the Time and Date (Optional) Table 4 Time Services Parameters Parameter Definition Date & Time UTC Date and Time The UTC date and time. Configuration Local Current Date and Read-only. The calculated local date and time, Time based on the local clock, Universal Time Coordinated (UTC), and Daylight Savings Time...

  • Page 63: Enabling The Interfaces (Interface Manager)

    Chapter 2: Getting Started Enabling the Interfaces (Interface Manager) Enabling the Interfaces (Interface Manager) By default:  Ethernet traffic interfaces are disabled and must be manually enabled.  The Ethernet management interface is enabled.  Radio interfaces are enabled. Note PTP 820S units have a single radio interface.

  • Page 64: Figure 15 Interface Manager - Edit Page

    Chapter 2: Getting Started Enabling the Interfaces (Interface Manager) Figure 15 Interface Manager – Edit Page 3. In the Admin status field, select Up to enable the interface or Down to disable the interface. 4. Click Apply, then Close. To enable or disable multiple interfaces: 1.

  • Page 65: Configuring The Radio Parameters

    To configure the radio parameters: 1. Select Radio > Radio Parameters. The Radio Parameters page opens.  For PTP 820C units, the Radio Parameters page initially displays a table as shown in Figure  For PTP 820S units, a page appears, similar to Figure 18 (which shows a PTP 820C page).

  • Page 66: Figure 18 Radio Parameters Page Per Carrier - Ptp 820C

    Chapter 2: Getting Started Configuring the Radio Parameters Figure 18 Radio Parameters Page Per Carrier – PTP 820C 3. Set the radio frequency in the Frequency control (Local) section: In the TX Frequency (MHz) field, set the transmission radio frequency in MHz.
  • Page 67 Chapter 2: Getting Started Configuring the Radio Parameters 4. Set the other radio parameters in the Configuration parameters section: In the TX Level (dBm) field, enter the desired TX signal level (TSL). The range of values depends on the frequency and RFU type. To mute the TX output of the RFU, select On in the TX Mute field.

  • Page 68: Configuring The Radio (Mrmc) Script(S)

    Chapter 2: Getting Started Configuring the Radio (MRMC) Script(s) Configuring the Radio (MRMC) Script(s) Related Topics:  Displaying MRMC Status Multi-Rate Multi-Constellation (MRMC) radio scripts define how the radio utilizes its available capacity. Each script is a pre-defined collection of configuration settings that specify the radio’s transmit and receive levels, link modulation, channel spacing, and bit rate.

  • Page 69: Figure 20 Mrmc Symmetrical Scripts Page (Ptp 820C) (Etsi)

    Chapter 2: Getting Started Configuring the Radio (MRMC) Script(s) Figure 20 MRMC Symmetrical Scripts Page (PTP 820C) (ETSI) Figure 21 MRMC Symmetrical Scripts Page (PTP 820C) (FCC) 2. In the Select Radio Interface field, select the slot for which you want to configure the script.

  • Page 70: Figure 22 Mrmc Symmetrical Scripts Page (Configuration)

    Chapter 2: Getting Started Configuring the Radio (MRMC) Script(s) Figure 22 MRMC Symmetrical Scripts Page (Configuration) 5. In the MRMC Script operational mode field, select the ACM mode: Fixed or Adaptive. Fixed ACM mode applies constant Tx and Rx rates. However, unlike regular scripts, with a Fixed ACM script you can specify a maximum profile to inhibit inefficient transmission levels.

  • Page 71: Table 5 Mrmc Symmetrical Scripts Page Parameters

    Chapter 2: Getting Started Configuring the Radio (MRMC) Script(s) Table 5 MRMC Symmetrical Scripts Page Parameters Parameter Definition Script ID A unique ID assigned to the script in the system. Channel bandwidth The script's channel bandwidth (channel spacing). (MHz) Occupied bandwidth The script's occupied bandwidth.

  • Page 72: Radio Profiles

    Chapter 2: Getting Started Configuring the Radio (MRMC) Script(s) Radio Profiles Table 6 Available Radio Profiles Parameter Definition Profile 0 4 QPSK Profile 1 8 QAM Profile 2 16 QAM Profile 3 32 QAM Profile 4 64 QAM Profile 5 128 QAM Profile 6 256 QAM...

  • Page 73: Enabling Acm With Adaptive Transmit Power

    To enable ACM with adaptive transmit power: 1. Select Radio > Radio Parameters. The Radio Parameters page opens. For PTP 820C units, the Radio Parameters page initially displays a table as shown in Figure For PTP 820S units and units, a page appears, similar to...

  • Page 74: Figure 23 Radio Parameters Page Per Carrier - Ptp 820C

    Chapter 2: Getting Started Enabling ACM with Adaptive Transmit Power Figure 23 Radio Parameters Page Per Carrier – PTP 820C 3. In the Adaptive TX power admin field, select Enable. The AdaptiveTX power operational status field should now indicate Up to indicate that the feature is fully functional.

  • Page 75: Operating In Fips Mode

    Note New specific FIPS compliance hardware is required for PTP820C and PTP820S. From release 8.3, PTP 820C and PTP 820S can be configured to be FIPS 140-2-compliant in specific hardware and software configurations, as described in this section. Requirements for FIPS Compliance For PTP 820C or PTP 820S node to be FIPS-compliant, the unit must be FIPS-compliant hardware.

  • Page 76: Figure 24 Security General Configuration Page

    Chapter 2: Getting Started Operating in FIPS Mode Figure 24 Security General Configuration Page In the FIPS admin configuration field, select Enable. Click Apply. Note Changing the FIPS configuration causes a unit reset. After enabling FIPS:  The MD5 option for SNMPv3 is blocked. ...

  • Page 77: Configuring Grouping (Optional)

    Chapter 2: Getting Started Configuring Grouping (Optional) Configuring Grouping (Optional) At this point in the configuration process, you should configure any interface groups that need to be set up according to your network plan. For details on available grouping and other configuration options, as well as configuration instructions, see System Configurations.

  • Page 78: Creating Service(S) For Traffic

    Chapter 2: Getting Started Creating Service(s) for Traffic Creating Service(s) for Traffic In order to pass traffic through the PTP 820, you must configure Ethernet traffic services. For configuration instructions, see Configuring Ethernet Service(s). phn-3963_004v000 Page 2-32...

  • Page 79: Configuration Guide

    Configuring MIMO and Space Diversity  Operating a PTP 820C in Single Radio Carrier Mode Note Multi-Carrier ABC, XPIC, MIMO, and Space Diversity are only supported with PTP 820C. HSB radio protection is supported with PTP 820C and PTP 820S. phn-3963_004v000 Page 3-1...

  • Page 80: System Configurations

    PTP 820C Configuring MIMO and Space Diversity Diversity PTP 820C in Single PTP 820C Operating a PTP 820C in Single Radio Carrier Radio Carrier Mode Mode Configuring a Link Using the Quick Configuration Wizard The Web EMS provides wizards to configure radio links. The wizards guide you through configuration of the basic radio parameters and services necessary to establish a working pipe link.

  • Page 81: Configuring A 1+0 Link Using The Quick Configuration Wizard

    Configuring XPIC. Note 1+0 Repeater links and Multi-Carrier ABC are only available for PTP 820C dual-carrier units. Because the Quick Configuration wizard creates Pipe links, you cannot add an interface to a link using the Quick Configuration wizard if any service points are attached to the interface prior to configuring the link.
  • Page 82 Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard s-tag – A single S-VLAN is classified into the service points. dot1q - A single C-VLAN is classified into the service points. Note For a full explanation of Ethernet Services, service types, and attached interface types, Configuring Ethernet Service(s).

  • Page 83: Figure 26 1+0 Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 26 1+0 Quick Configuration Wizard – Page 2 In the TX Frequency (MHz) field, set the transmission radio frequency in MHz. In the RX Frequency (MHz) field, set the received radio frequency in MHz. In the TX Level (dBm) field, enter the desired TX signal level (TSL).

  • Page 84: Figure 28 1+0 Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard If you selected Fixed in the Operational Mode field, the next field is Profile. Select the ACM profile for the radio in the Profile field. If you selected Adaptive in the Operational Mode field, the next field is Maximum Profile. Enter the maximum profile for the script in the Maximum Profile field.

  • Page 85: Configuring A 1+0 (Repeater) Link Using The Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 29 1+0 Quick Configuration Wizard – Page 5 (Summary Page) 18 To complete configuration of the link, click Submit. If you want to go back and change any of the parameters, click Back.

  • Page 86: Figure 31 1+0 Repeater Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard In the Radio #1 Interface field, select the first radio interface for the link. Click Next. Page 2 of the 1+0 Repeater Quick Configuration wizard opens. Figure 31 1+0 Repeater Quick Configuration Wizard – Page 2 In the Radio #2 Interface field, select the second radio interface for the link.

  • Page 87: Figure 32 1+0 Repeater Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 32 1+0 Repeater Quick Configuration Wizard – Page 3 For each interface, configure the following parameters: In the TX Frequency (MHz) field, set the transmission radio frequency in MHz. In the RX Frequency (MHz) field, set the received radio frequency in MHz.

  • Page 88: Figure 34 1+0 Repeater Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard In Adaptive ACM mode, TX and RX rates are dynamic. An ACM-enabled radio system automatically chooses which profile to use according to the channel fading conditions. III. Do one of the following: If you selected Fixed in the Operational Mode field, the next field is Profile.

  • Page 89: Configuring A 2+0 Multi-Carrier Abc Link Using The Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 35 1+0 Repeater Quick Configuration Wizard – Page 6 14 To complete configuration of the link, click Submit. If you want to go back and change any of the parameters, click Back.

  • Page 90: Figure 36 2 + 0 Multi Carrier Abc Quick Configuration Wizard

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 36 2 + 0 Multi Carrier ABC Quick Configuration Wizard – Page 1 In the Ethernet Interface field, select an Ethernet interface or a LAG for the group. Note To create a LAG, click Create LAG.

  • Page 91: Figure 37 2 + 0 Multi Carrier Abc Quick Configuration Wizard - Radio #2 Selection Page

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 37 2 + 0 Multi Carrier ABC Quick Configuration Wizard – Radio #2 Selection Page In the Radio #2 Interface field, select the second radio interface for the group. Click Next.

  • Page 92: Figure 39 2 + 0 Multi Carrier Abc Quick Configuration Wizard - Radio Parameters Configuration Page

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 39 2 + 0 Multi Carrier ABC Quick Configuration Wizard – Radio Parameters Configuration Page Figure 40 2 + 0 Multi Carrier ABC Quick Configuration Wizard – Radio Parameters Configuration Page (XPIC) For each interface or XPIC group, configure the following radio parameters.
  • Page 93 Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Click Next. The Radio MRMC Script Configuration page opens. You can configure the MRMC script parameters for each interface. For an XPIC group, you configure the parameters for the group rather than the individual interfaces.
  • Page 94 Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard If you selected Adaptive in the Operational Mode field, the next field is Maximum Profile. Enter the maximum profile for the script in the Maximum Profile field. See Configuring the Radio (MRMC) Script(s).

  • Page 95: Configuring Multi-Carrier Abc

    To complete configuration of the Multi-Carrier ABC group, click Submit. If you want to go back and change any of the parameters, click Back. After you click Submit, the unit is reset. Configuring Multi-Carrier ABC Note This option is only relevant for PTP 820C units. This section includes:  Multi-Carrier ABC Overview ...

  • Page 96: Configuring A Multi-Carrier Abc Group

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Configuring a Multi-Carrier ABC Group To configure a Multi-Carrier ABC group: 1. Select Radio > Groups > Multi Carrier ABC. The Multi Carrier ABC page opens. Figure 45 Multi-Carrier ABC Group Page (Empty) 2.
  • Page 97 Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Figure 47 Create ABC Group Wizard – Second Page 5. In the Member 1 field, select a radio interface. Note Although you may select the Radio members in any order you wish, ABC configuration will not succeed unless Radio slot 2 port 1 is selected first and Radio slot 2 port 2 is selected second.

  • Page 98: Deleting A Multi-Carrier Abc Group

    Chapter 3: Configuration Guide Configuring a Link Using the Quick Configuration Wizard Adding and Removing Group Members You can add and remove interfaces from the group after creating the group. This is relevant if you want to delete a Multi-Carrier ABC group, since you must remove the members individually before deleting the group.

  • Page 99: Configuring Link Aggregation (Lag)

    Chapter 3: Configuration Guide Configuring Link Aggregation (LAG) Configuring Link Aggregation (LAG) Link aggregation (LAG) enables you to group several physical Ethernet or radio interfaces into a single logical interface bound to a single MAC address. This logical interface is known as a LAG group.

  • Page 100: Configuring A Lag Group

    Chapter 3: Configuration Guide Configuring Link Aggregation (LAG) Configuring a LAG Group Creating a LAG Group To create a LAG group: 1. Select Ethernet > Interfaces > Groups > LAG. The LAG page opens. 2. Click Create LAG underneath the Link Aggregation table. The Create LAG Group page opens. Figure 50 Create LAG Group –...
  • Page 101 Chapter 3: Configuration Guide Configuring Link Aggregation (LAG) Figure 52 Create LAG Group – Final Page 9. Click Submit. If all the interfaces meet the criteria listed above, a message appears that the LAG group has been successfully created. If not, a message appears indicating that the LAG group was not created and giving the reason.

  • Page 102: Deleting A Lag Group

    Chapter 3: Configuration Guide Configuring Link Aggregation (LAG) Note When removing an interface from a LAG group, the removed interface is assigned the default interface values. Deleting a LAG Group In order to delete a LAG group, you must first make sure that no service points are attached to the LAG group.

  • Page 103: Configuring Xpic

    Chapter 3: Configuration Guide Configuring XPIC Configuring XPIC Note This option is only relevant for PTP 820C units. This section includes:  XPIC Overview  Configuring the Antennas  Configuring the Radio Carriers  Creating an XPIC Group XPIC Overview Cross Polarization Interference Canceller (XPIC) is a feature that enables two radio carriers to use the same frequency with a polarity separation between them.

  • Page 104: Configuring The Radio Carriers

    XPIC support is indicated by an X in the script name. For example, mdN_A2828X_111_1205 is an XPIC-enabled script. mdN_A2828N_130_100 is not an XPIC-enabled script. For a list of XPIC support-enabled scripts, refer to the most recent PTP 820C Release Notes. phn-3963_004v000 Page 3-26...

  • Page 105: Creating An Xpic Group

    Chapter 3: Configuration Guide Configuring XPIC 3. In the XPIC page, create an XPIC group that consists of the two RMCs that will be in the XPIC group. See Creating an XPIC Group. Creating an XPIC Group To create an XPIC group: 1.

  • Page 106: Configuring Hsb Radio Protection

    Disabling Unit Protection HSB Radio Protection Overview PTP 820C and PTP 820S support 1+1 HSB radio protection. PTP 820C also supports 2+2 HSB radio protection. In HSB radio protection, one PTP 820 operates in active mode and the other operates in standby mode.
  • Page 107 Chapter 3: Configuration Guide Configuring HSB Radio Protection iii. Establish a management connection to one of the units. You can select either unit; once you enable Protection Administration, the system will determine which unit becomes the Active unit. 2. Select Platform > Management > Unit Redundancy. The Unit Redundancy (HSB Protection) page opens.
  • Page 108 Chapter 3: Configuration Guide Configuring HSB Radio Protection Figure 56 Unit Redundancy Page when Redundancy Enabled In additional, almost every Web EMS page will now include two tabs on top of the main section of the page: Active – Enables you to configure the Active unit. Standby –...

  • Page 109: Configuring 2+2 Hsb Protection On A Ptp 820C Unit

    Configuring 2+2 HSB Protection on a PTP 820C Unit In order to configure 2+2 HSB unit protection on a PTP 820C unit, you must simply enable the second radio carrier on both units on both sides of the link. No other configuration is necessary other than the configuration described above.

  • Page 110: Editing Standby Unit Settings

    Chapter 3: Configuration Guide Configuring HSB Radio Protection Figure 58 Standby Tab of Radio Parameters Page Editing Standby Unit Settings Almost all settings of the standby unit are view-only. However, several settings are editable on the Standby unit. They must be configured separately for the Standby unit, and are not copied via copy-to-mate, nor do they trigger a configuration mismatch in the CLI.

  • Page 111: Manually Switching To The Standby Unit

    Chapter 3: Configuration Guide Configuring HSB Radio Protection Figure 59 Unit Redundancy Page The following information is displayed:  Protection Operational State – Indicates whether HSB protection is functional (available in practice). Radio protection is not functional if any of the following occurred: MIMO is configured.

  • Page 112: Disabling Automatic Switchover To The Standby Unit

    Chapter 3: Configuration Guide Configuring HSB Radio Protection Disabling Automatic Switchover to the Standby Unit At any point, you can perform lockout, which disables automatic switchover to the standby unit. To disable automatic switchover to the Standby unit: 1. Select Platform > Management > Unit Redundancy. The Unit Redundancy (HSB Protection) page opens.

  • Page 113: Configuring Mimo And Space Diversity

    In MIMO 4x4, each antenna uses dual polarization. The phase difference caused by the antenna separation enables the receiver to distinguish between the streams. PTP 820C supports both MIMO 2x2 and MIMO 4x4. For a full explanation of MIMO support in PTP 820C, refer to the PTP 820C Technical Description.

  • Page 114: Mimo Mate Management Access

    In effect, a 2+2 HSB configuration is a protected 2+0 Space Diversity configuration. Each PTP 820C monitors both of its cores. If the active PTP 820C detects a radio failure in either of its cores, it initiates a switchover to the standby PTP 820C.

  • Page 115: Creating A Mimo Or Space Diversity Group

    Creating a MIMO or Space Diversity Group Note Only one MIMO or Space Diversity group can be created per PTP 820C unit. To create a MIMO or Space Diversity group: 1. Select Radio > Groups> MIMO. The MIMO page opens.

  • Page 116: Enabling/Disabling A Mimo Or Space Diversity Group

    Chapter 3: Configuration Guide Configuring MIMO and Space Diversity Figure 61 Create MIMO Group – Page 2 5. Click Submit, to create the MIMO or Space Diversity group. Click Close to cancel and close the window. 6. After creating the group, you must enable the group in the MIMO - Edit page. Enabling/Disabling a MIMO or Space Diversity Group.

  • Page 117: Setting The Role Of A Mimo Or Space Diversity Group

    Setting the Role of a MIMO or Space Diversity Group For 4x4 MIMO configurations and 2+2 Space Diversity configurations, you must set the role of the group to Master or Slave. This determines the role of the PTP 820C unit in the overall MIMO or Space Diversity configuration.

  • Page 118: Resetting Mimo

    4. Perform the following: For 4x4 MIMO configurations and 2+2 Space Diversity configurations, select Master or Slave in the Role field. This determines the role of the PTP 820C unit in the overall MIMO or Space Diversity configuration. For MIMO 2x2 configurations and 1+0 Space Diversity configurations, select Not- Relevant in the Role field.

  • Page 119: Viewing Mmi And Xpi Levels

    Chapter 3: Configuration Guide Configuring MIMO and Space Diversity To reset MIMO: 1. Select Radio > Groups> MIMO. The MIMO page opens. 2. Select the MIMO group from the table. 3. Click Edit Group. The MIMO - Edit page opens. Figure 64 MIMO - Edit Page 4.

  • Page 120: Deleting A Mimo Or Space Diversity Group

    Chapter 3: Configuration Guide Configuring MIMO and Space Diversity 3. Click Edit Members. The MIMO - Edit Members page opens. Figure 65 MIMO - Edit Members Page The MIMO - Edit Members page provides the following information for each radio carrier in the MIMO group: ...

  • Page 121: Operating A Ptp 820C In Single Radio Carrier Mode

    Operating a PTP 820C in Single Radio Carrier Mode Operating a PTP 820C in Single Radio Carrier Mode If you wish to operate a PTP 820C unit in single radio carrier mode, you must perform the following steps: 1. Verify that XPIC is disabled. See Configuring XPIC.

  • Page 122: Unit Management

    Chapter 4: Unit Management Operating a PTP 820C in Single Radio Carrier Mode Unit Management This section includes:  Defining the IP Protocol Version for Initiating Communications  Configuring the Remote Unit’s IP Address  Configuration SNMP  Configuring Trap Managers ...

  • Page 123: Defining The Ip Protocol Version For Initiating Communications

    Chapter 4: Unit Management Defining the IP Protocol Version for Initiating Communications Defining the IP Protocol Version for Initiating Communications You can specify which IP protocol the unit will use when initiating communications, such as downloading software, sending traps, pinging, or exporting configurations. The options are IPv4 or IPv6.

  • Page 124: Configuring The Remote Unit's Ip Address

    1. Select Platform > Management > Networking > Remote. The Remote Networking Configuration page opens. For PTP 820C units, the Radio Parameters page initially displays a table as shown in Figure For PTP 820S units, the page appears as shown in Figure 68.
  • Page 125 2. For PTP 820C units, select the carrier in the Radio table (see Figure 67) and click Edit. A separate Remote IP Configuration page opens. The page is identical to the PTP 820C and PTP 820S page. phn-3963_004v000 Page 4-47...

  • Page 126: Changing The Subnet Of The Remote Ip Address

    Chapter 4: Unit Management Configuring the Remote Unit’s IP Address Figure 69 Remote IP Configuration Page Per Carrier – PTP 820C 3. In the Remote IP address field, enter an IP address for the remote unit. You can enter the address in IPv4 format in this field, and/or in IPv6 format in the IPv6 Address field.
  • Page 127 Chapter 4: Unit Management Configuring the Remote Unit’s IP Address Similarly, if you wish to change the Remote IPv6 Address to a different subnet: 1. Change the address of the Remote IPv6 Default Gateway to 0:0:0:0:0:0:0:0. 2. Click Apply. 3. Set the Remote IPv6 Address as desired, and the Remote IPv6 Default Gateway as desired. phn-3963_004v000 Page 4-49...

  • Page 128: Configuration Snmp

    Chapter 4: Unit Management Configuration SNMP Configuration SNMP PTP 820C and PTP 820S support SNMP v1, V2c, and v3. You can set community strings for access to PTP 820 units. PTP 820C and PTP 820S support the following MIBs: ...
  • Page 129 Chapter 4: Unit Management Configuration SNMP Note The Operational Status field indicates whether SNMP monitoring is currently active (Up) or inactive (Down). 3. In the SNMP Read Community field, enter the community string for the SNMP read community. 4. In the SNMP Write Community field, enter the community string for the SNMP write community 5.

  • Page 130: Table 8 Snmp V3 Authentication Parameters

    Chapter 4: Unit Management Configuration SNMP Figure 72 V3 Users - Add Page 3. Configure the SNMP V3 Authentication parameters, as described below. 4. Click Apply, then Close. Table 8 SNMP V3 Authentication Parameters Parameter Definition User Name Enter the SNMPv3 user name. Password Enter a password for SNMPv3 authentication.

  • Page 131: Configuring Trap Managers

    Chapter 4: Unit Management Configuring Trap Managers Configuring Trap Managers You can configure trap forwarding parameters by editing the Trap Managers table. Each line in the Trap Managers table displays the setup for a manager defined in the system. To configure trap managers: 1.

  • Page 132: Table 9 Trap Manager Parameters

    Chapter 4: Unit Management Configuring Trap Managers Figure 74 Trap Managers - Edit Page 3. Configure the trap manager parameters, as described in Table 9 Trap Manager Parameters. 4. Click Apply, then Close. Table 9 Trap Manager Parameters Parameter Definition IPv4 Address If the IP address family is configured to be IPv4, enter the destination IPv4 address.
  • Page 133 Chapter 4: Unit Management Configuring Trap Managers Parameter Definition  CLLI Enter a Common Language Location Identifier (CLLI). The CLLI is free text that will be sent with the trap. You can enter up to 100 characters. V3 User Name If the SNMP Trap version selected in Figure 70 SNMP Parameters Page...

  • Page 134: Installing And Configuring An Ftp Or Sftp Server

    Chapter 4: Unit Management Installing and Configuring an FTP or SFTP Server Installing and Configuring an FTP or SFTP Server Several tasks, such as software upgrade and configuration backup, export, and import, require the use of FTP or SFTP. The PTP 820 can function as an FTP or SFTP client. If you wish to use FTP/SFTP, you must install FTP/SFTP server software on the PC or laptop you are using.
  • Page 135 Chapter 4: Unit Management Installing and Configuring an FTP or SFTP Server Figure 75 FileZilla Server User Configuration 2. Create a shared FTP/SFTP folder on the PC or laptop you are using to perform the software upgrade (for example, C:\FTPServer). 3.
  • Page 136 Chapter 4: Unit Management Installing and Configuring an FTP or SFTP Server Figure 76 FileZilla Server Shared Folder Setup phn-3963_004v000 Page 4-58...

  • Page 137: Upgrading The Software

    Chapter 4: Unit Management Upgrading the Software Upgrading the Software PTP 820 software and firmware releases are provided in a single bundle that includes software and firmware for all components in the system. Software is first downloaded to the system, then installed.

  • Page 138: Software Upgrade Overview

    Chapter 4: Unit Management Upgrading the Software Parameter Definition Installed Version The software version currently installed for the component. If the installed version is not already the running version, it will become the running version after the next reset takes place. Downloaded Version The version, if any, that has been downloaded from the server but not yet installed.

  • Page 139: Downloading And Installing Software

    Chapter 4: Unit Management Upgrading the Software Downloading and Installing Software When downloading software, the PTP 820 functions as an FTP or SFTP client. You must install FTP or SFTP server software on the PC or laptop you are using to perform the software upgrade. For details, see Installing and Configuring an FTP or SFTP Server.
  • Page 140 Chapter 4: Unit Management Upgrading the Software 9. If the IP address family is configured to be IPv6, enter the IPv6 address of the PC or laptop you are using as the FTP/SFTP server in the Server IPv6 Address field. See Defining the IP Protocol Version for Initiating Communications.
  • Page 141 Chapter 4: Unit Management Upgrading the Software • Sometimes the installation process can take up to 30 minutes. • Only in the event that software installation was not successfully finished and more than 30 minutes have passed can the unit be rebooted. phn-3963_004v000 Page 4-63...

  • Page 142: Table 11 Download & Install Status Parameters

    Chapter 4: Unit Management Upgrading the Software Table 11 Download & Install Status Parameters Parameter Definition Download status The status of any pending software download. Possible values are:  Ready – The default value, which appears when no download is in progress.

  • Page 143: Configuring A Timed Installation

    Chapter 4: Unit Management Upgrading the Software Configuring a Timed Installation You can schedule a timed (deferred) software installation to take place at any time within 24 hours after you configure the installation. To schedule a timed software installation: 1. Download the software version you want to install. See Downloading and Installing Software.
  • Page 144 Chapter 4: Unit Management Upgrading the Software Figure 80 Download & Install Page – Timed Installation phn-3963_004v000 Page 4-66...

  • Page 145: Backing Up And Restoring Configurations

    You can import and export PTP 820 configuration files. This enables you to copy the system configuration to multiple PTP 820 units. You can also backup and save configuration files. Configuration files can only be copied between units of the same type, i.e., PTP 820C to PTP 820C and PTP 820S to PTP 820S.

  • Page 146: Table 12 Backup Files Page Columns

    Chapter 4: Unit Management Backing Up and Restoring Configurations To display the configuration files currently saved at the system restore points: 1. Select Platform > Configuration > Backup Files. The Backup Files page opens. For a description of the information provided in the Backup Files page, see Table 12 Backup Files Page Columns.

  • Page 147: Setting The Configuration Management Parameters

    Chapter 4: Unit Management Backing Up and Restoring Configurations Setting the Configuration Management Parameters When importing and exporting configuration files, the PTP 820 functions as an FTP or SFTP client. You must install FTP or SFTP server software on the PC or laptop you are using to perform the import or export.
  • Page 148 Chapter 4: Unit Management Backing Up and Restoring Configurations 8. If the IP address family is configured to be IPv6, enter the IPv6 address of the PC or laptop you are using as the FTP server in the IPv6 Server Address field. See Defining the IP Protocol Version for Initiating Communications.

  • Page 149: Exporting A Configuration File

    Chapter 4: Unit Management Backing Up and Restoring Configurations Exporting a Configuration File You can export a saved configuration file from one of the system's three restore points to a PC or laptop. To export a configuration file: 1. Verify that you have followed all the steps in Setting the Configuration Management Parameters.

  • Page 150: Deleting A Configuration File

    Chapter 4: Unit Management Backing Up and Restoring Configurations When the import or export is complete, one of the following status indications appears: Succeeded Failure The next time the system is reset, the File Transfer status field returns to Ready. After importing the configuration file, you can apply the configuration by restoring the file from the restore point to which you saved it.

  • Page 151: Editing Cli Scripts

    Chapter 4: Unit Management Backing Up and Restoring Configurations To restore a configuration file: 1. Select Platform > Configuration > Configuration Management. The Configuration Management page opens (Figure 82 Configuration Management Page). 2. In the File Number field, select the restore point that holds the configuration you want to restore.

  • Page 152: Setting The Unit To The Factory Default Configuration

    Chapter 4: Unit Management Setting the Unit to the Factory Default Configuration Setting the Unit to the Factory Default Configuration You can restore the unit to its factory default configuration, while retaining the unit’s IP address settings and logs. To restore the factory default settings: 1.

  • Page 153: Performing A Hard (Cold) Reset

    Chapter 4: Unit Management Performing a Hard (Cold) Reset Performing a Hard (Cold) Reset To initiate a hard (cold) reset on the unit: 1. Select Platform > Management > Reset. The Reset page opens. Figure 84 Reset Page 2. Click Reset. 3.

  • Page 154: Configuring Unit Parameters

    Chapter 4: Unit Management Configuring Unit Parameters Configuring Unit Parameters To view and configure system information: 1. Select Platform > Management > Unit Parameters. The Unit Parameters page opens. Table 13 describes the fields in the Unit Parameters page. Figure 85 Unit Parameters Page Table 13 Unit Parameters Parameter Definition...
  • Page 155 Chapter 4: Unit Management Configuring Unit Parameters Parameter Definition Measurement format The type of measurement you want the system to use: Metric or Imperial. Unit Temperature The current temperature of the unit. Voltage input (Volt) The voltage input of the unit. phn-3963_004v000 Page 4-77...

  • Page 156: Configuring Ntp

    Chapter 4: Unit Management Configuring NTP Configuring NTP PTP 820 supports Network Time Protocol (NTP). NTP distributes Coordinated Universal Time (UTC) throughout the system, using a jitter buffer to neutralize the effects of variable latency. To view and configure the NTP Parameters: 1.
  • Page 157 Chapter 4: Unit Management Configuring NTP Parameter Definition Client lock status Indicates if the NTP client is locked on a remote NTP server. Possible values are:  LOCK – The NTP client is locked on the remote server.  LOCAL – The NTP client is locked on the local system clock (free running clock).

  • Page 158: Displaying Unit Inventory

    Chapter 4: Unit Management Displaying Unit Inventory Displaying Unit Inventory To view the unit's part number and serial number: Select Platform > Management > Inventory. The Inventory page opens, showing the unit's part number and serial number. Figure 87 Inventory Page phn-3963_004v000 Page 4-80...

  • Page 159: Radio Configuration

    Configuring the Radio (MRMC) Script(s)  System Configurations  Configuring Multi-Carrier ABC  Configuring XPIC  Configuring HSB Radio Protection  Configuring MIMO and Space Diversity  Operating a PTP 820C in Single Radio Carrier Mode  Performing Radio Loopback phn-3963_004v000 Page 5-1...

  • Page 160: Viewing The Radio Status And Settings

    To display the radio parameters: 1. Select Radio > Radio Parameters. The Radio Parameters page opens. For PTP 820C units, the Radio Parameters page initially displays a table as shown in Figure For PTP 820S units, a page appears, similar to Figure 18 (which shows a PTP 820C page).
  • Page 161 Figure 89 Radio Parameters Page Per Carrier – PTP 820C Table 15 lists and describes the parameters in the Radio table of the PTP 820C Radio Parameters page and the Status parameters section of the Radio Parameters configuration page. phn-3963_004v000...

  • Page 162: Table 15 Radio Status Parameters

    Indicates whether the carrier is operating in XPIC mode. For instructions on configuring XPIC, refer to Configuring XPIC. Note: Only relevant for PTP 820C units. TX Frequency The configured TX radio frequency. The TX radio frequency is configured in the Frequency control (Local) section of the Radio Parameters page.

  • Page 163: Configuring The Remote Radio Parameters

    To display the remote radio parameters: 1. Select Radio > Remote Radio Parameters. The Remote Radio Parameters page opens. For PTP 820C units, the Radio Parameters page initially displays a table as shown in Figure For PTP 820S units, the page appears as shown in Figure 91 Figure 90 Remote Radio Parameters Page –...

  • Page 164: Table 16 Remote Radio Parameters

    Chapter 5: Radio Configuration Configuring the Remote Radio Parameters 2. For PTP 820C units, select the carrier in the Remote Radio table (see Figure 90) and click Edit. A separate Remote Radio Parameters page opens. The page is identical to the PTP 820S page.
  • Page 165 Chapter 5: Radio Configuration Configuring the Remote Radio Parameters Parameter Definition Remote Most Severe Read-only. The level of the most severe alarm currently active Alarm on the remote unit. Remote Unit Link ID Edit page only. Identifies the link, in order to distinguish it from other links.

  • Page 166: Configuring Atpc

    (which shows a PTP 820C page). Figure 93 ATPC Page – PTP 820C 2. For PTP 820C units, select the carrier you wish to configure in the ATPC table (see Figure and click Edit. A separate ATPC –Edit page opens.
  • Page 167 Chapter 5: Radio Configuration Configuring ATPC Figure 94 ATPC – Edit Page Per Carrier – PTP 820C 3. In the Admin field, select Enable to enable ATPC or Disable to disable ATPC. 4. In the Reference RX Level (dBm) field, enter a number between -70 and -30 as the reference value for the ATPC mechanism.

  • Page 168: Configuring Header De-Duplication And Frame Cut-Through

    To configure Header De-Duplication and Frame Cut-Through: 1. Select Radio > Ethernet Interface > Configuration. The Radio Ethernet Interface Configuration page opens. For PTP 820C units, the Radio Ethernet Interface Configuration page initially displays a table as shown in Figure...
  • Page 169 Chapter 5: Radio Configuration Configuring Header De-Duplication and Frame Cut- Through 2. For PTP 820C units, select the carrier in the Radio Ethernet and Compression table (see Figure 95) and click Edit. A separate Radio Ethernet Interface Configuration page opens. The page is essentially identical to the PTP 820S page.

  • Page 170: Viewing Header De-Duplication And Frame Cut-Through Counters

    To view Header De-Duplication and Frame Cut-Through counters: 1. Select Radio > Ethernet Interface > Counters. The Radio Ethernet Interface Configuration page opens. For PTP 820C units, the Radio Ethernet Interface Configuration page initially displays a table as shown in Figure...
  • Page 171 Through Figure 98 Radio Ethernet Interface Counters Page – PTP 820S 2. For PTP 820C units, select the carrier in the Header Compression Counters table (Figure and click View. A separate Radio Ethernet Interface Configuration page opens. The page is essentially identical to the PTP 820S page.

  • Page 172: Table 17: Radio Ethernet Interface Counters Fields

    Chapter 5: Radio Configuration Configuring Header De-Duplication and Frame Cut- Through Figure 99 Radio Ethernet Interface Counters Page Per Carrier – PTP 820C Table 17 lists and describes the fields in the Radio Ethernet Interface Counters page. Table 17: Radio Ethernet Interface Counters Fields...
  • Page 173 Chapter 5: Radio Configuration Configuring Header De-Duplication and Frame Cut- Through Parameter Definition TX frames before Frames on the TX side before Header De-Duplication. enhanced HC TX frames compressed Frames on the TX side that were compressed by Header by enhanced HC De-Duplication.

  • Page 174: Configuring Aes-256 Payload Encryption

    To configure payload encryption: Select Radio > Payload Encryption. The Payload Encryption page opens. Interface Configuration page opens. For PTP 820C units, the Payload Encryption page initially displays a table as shown in Figure 100 Payload Encryption Page For PTP 820S units, a page appears, similar to...
  • Page 175 Chapter 5: Radio Configuration Configuring AES-256 Payload Encryption Figure 100 Payload Encryption Page Select the carrier you want to configure and click Edit. The Payload Encryption – Edit page opens. Figure 101 Payload Encryption – Edit Page In the Admin Mode field, select AES-256 to enable payload encryption. To disable payload encryption, select Disable.
  • Page 176 Chapter 5: Radio Configuration Configuring AES-256 Payload Encryption You must use the same master key on both sides of the link. This means that if you generate a master key automatically on one side of the link, you must copy that key and for use on the other side of the link.

  • Page 177: Configuring And Viewing Radio Pms And Statistics

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics Configuring and Viewing Radio PMs and Statistics This section includes:  Configuring Radio Thresholds  Displaying MRMC Status  Displaying MRMC PMs  Displaying and Clearing Defective Block Counters ...

  • Page 178: Table 18 Pm And Ber Thresholds

    Parameter Definition Radio Location Identifies the carrier (Slot 2, port 1 or Slot 2, port 2). Note: Only relevant for PTP 820C units. RX Level Threshold 1 Specify the threshold for counting exceeded seconds if the RSL (dBm) is below this level.

  • Page 179: Displaying Mrmc Status

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics Parameter Definition XPI PM Threshold (dB) Specify the modem XPI threshold for calculating XPI Exceed Threshold seconds. Excessive BER Select the level above which an excessive BER alarm is issued Threshold for errors detected over the radio link.

  • Page 180: Displaying Mrmc Pms

    1. Select Radio > PM & Statistics > MRMC. The MRMC PM Report page opens. Figure 106 MRMC PM Report Page 2. For the PTP 820C, In the Port field, select the port that holds the radio for which you want to display PMs.

  • Page 181: Displaying And Clearing Defective Block Counters

    To display the number of blocks in which errors were detected per radio: 1. Select Radio > PM & Statistics > Counters. The Counters page opens. For PTP 820C units, the Counters page initially displays a table as shown in Figure 107.
  • Page 182 Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics Figure 108 Counters Page – PTP 820S 2. For PTP 820C units, you can select the carrier in the Radio table (see Figure 107) and click View to display a page for that carrier. A separate Counters page opens.

  • Page 183: Displaying Signal Level Pms

    1. Select Radio > PM & Statistics > Signal Level. The Signal Level PM report page opens. Figure 110 Signal Level PM Report Page 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs.

  • Page 184: Displaying Modem Ber (Aggregate) Pms

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics Note To display the same parameters for a specific interval in a separate page, select the interval in the RF PM table and click View. Table 21 Signal Level PMs Parameter Definition Interval...

  • Page 185: Table 22 Modem Ber (Aggregate) Pms

    Configuring and Viewing Radio PMs and Statistics Figure 111 Aggregate PM Report Page 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs. 3. In the Interval Type field: To display reports in 15-minute intervals, select 15 minutes.

  • Page 186: Displaying Modem Mse Pms

    1. Select Radio > PM & Statistics > MSE. The MSE PM report page opens. Figure 112 MSE PM Report Page 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs.

  • Page 187: Displaying Xpi Pms

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics Note To display the same parameters for a specific interval in a separate page, select the interval in the Modem MSE PM table and click View. Table 23 Modem MSE PMs Parameter Definition Interval...

  • Page 188: Table 24 Xpi Pms

    Configuring and Viewing Radio PMs and Statistics Figure 113 XPI PM Report Page 4. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs. 5. In the Interval Type field: To display reports in 15-minute intervals, select 15 minutes.

  • Page 189: Displaying Traffic Pms

    1. Select Radio > PM & Statistics > Traffic > Capacity/Throughput. The Capacity PM report page opens. Figure 114 Capacity PM Report Page 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs. phn-3963_004v000...

  • Page 190: Table 25 Capacity/Throughput Pms

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics 3. In the Interval Type field: To display reports in 15-minute intervals, select 15 minutes. To display reports in daily intervals, select 24 hours. Table 25 describes the capacity and throughput PMs. Note To display the same parameters for a specific interval in a separate page, select the interval in the PM table and click View.

  • Page 191: Table 26 Utilization Pms

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs. 3. In the Interval Type field: To display reports in 15-minute intervals, select 15 minutes.
  • Page 192 1. Select Radio > PM & Statistics > Traffic > Frame error rate. The Frame error rate PM report page opens. Figure 116 Frame Error PM Report Page 2. For the PTP 820C, in the Port field, select the port that holds the radio for which you want to display PMs. phn-3963_004v000...

  • Page 193: Table 27 Frame Error Rate Pms

    Chapter 5: Radio Configuration Configuring and Viewing Radio PMs and Statistics 3. In the Interval Type field: To display reports in 15-minute intervals, select 15 minutes. To display reports in daily intervals, select 24 hours. Table 27 describes the capacity and throughput PMs. Note To display the same parameters for a specific interval in a separate page, select the interval in the PM table and click View.

  • Page 194: Ethernet Services And Interfaces

    Ethernet Services and Interfaces This section includes:  Configuring Ethernet Service(s)  Setting the MRU Size and the S-VLAN Ethertype  Configuring Ethernet Interfaces  Configuring Automatic State Propagation  Viewing Ethernet PMs and Statistics Related topics:  Configuring Link Aggregation (LAG) ...

  • Page 195: Configuring Ethernet Service(S)

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Configuring Ethernet Service(s) This section includes:  Ethernet Services Overview  General Guidelines for Provisioning Ethernet Services  The Ethernet Services Page  Adding an Ethernet Service  Editing a Service ...

  • Page 196: General Guidelines For Provisioning Ethernet Services

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) General Guidelines for Provisioning Ethernet Services When provisioning Ethernet services, it is recommended to follow these guidelines:  Use the same Service ID for all service fragments along the path of the service. ...

  • Page 197: Adding An Ethernet Service

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Table 28 Ethernet Services Page Parameters Parameter Definition Services ID A unique ID for the service. Service Type The service type:  MP – Multipoint  P2P – Point-to-Point  MNG – Management Service sub type Indicates the type of service (Ethernet).
  • Page 198 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Figure 118 Ethernet Services - Add page 3. In the Service ID field, select a unique ID for the service. You can choose any unused value from 1 to 1024. Once you have added the service, you cannot change the Service ID. Service ID 1025 is reserved for a pre-defined management service.

  • Page 199: Editing A Service

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Note Additional configuration of the MAC address table can be performed via the CLI. See Defining the MAC Address Forwarding Table for a Service. 9. In the Default CoS field, enter a default Class of Service (CoS) value (0-7). This value is assigned to frames at the service level if CoS Mode is set to Default-CoS.

  • Page 200: Enabling, Disabling, Or Deleting Multiple Services

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Enabling, Disabling, or Deleting Multiple Services To enable, disable, or delete multiple services: 1. Select Ethernet > Services. The Ethernet Services page opens (Figure 117). 2. Select the services in the Ethernet Services Configuration table, or select all the services by selecting the check box in the top row.
  • Page 201 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s)  Deleting a Service Point  Attaching VLANs Ethernet Services Points Overview Service points are logical interfaces within a service. A service point is a logical entity attached to a physical or logical interface. Service points define the movement of frames through the service. Each service point includes both ingress and egress attributes.

  • Page 202: Table 29 General Service Point Attributes

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Figure 120 Ethernet Service Points Page You can choose to display the following sets of attributes by selecting the appropriate button above the SP Attributes table:  General – See Ethernet Service Points – General SP Attributes Table ...
  • Page 203 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition Service point type The service point type. Options are:  SAP – Service Access Point.  SNP – Service Network Point.  MNG – Management service point.  PIPE – Pipe service point. The following rules apply to the mixing of different types of service points on a single logical interface: You cannot configure both SAPs and SNPs on the same logical...

  • Page 204: Table 30 Attached Interface Types

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition S-Vlan encapsulation The S-VLAN classified into the service point. Options are 1- 4094, Untagged, or N.A. (Not Applicable). Once you have added the service point, you cannot change this parameter. If you selected Bundle-S in the Attached Interface Type field, select the S-VLAN value to classify into the service point (1- 4094), or select Untagged.

  • Page 205: Table 31 Service Point Ingress Attributes

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Figure 121 Ethernet Service Points Page – Ingress Attributes Table 31 Service Point Ingress Attributes Parameter Definition Service point ID This ID is unique within the service. For Point-to-Point and Multipoint services, the range of values is 1-32. For Management services, the range of values is 1-30.

  • Page 206: Table 32 Service Point Egress Attributes

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition CoS Mode Indicates how the service point handles the CoS of frames that pass through the service point. Options are:  sp-def-cos – The service point re-defines the CoS of frames that pass through the service point, according to the Default CoS (below).
  • Page 207 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition Service point type The service point type. Options are:  SAP – Service Access Point.  SNP – Service Network Point.  MNG – Management service point.  PIPE – Pipe service point. C-Vlan CoS Determines whether the original C-VLAN CoS value is preservation...
  • Page 208 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition S-Vlan preservation Read-only. Indicates whether the original S-VLAN ID is preserved or restored for frames egressing from the service point. If S-VLAN preservation is enabled, the S-VLAN ID of frames egressing the service point is the same as the S-VLAN ID when the frame entered the service.
  • Page 209 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Figure 123 Ethernet Service Points - Add Page 6. Configure the service point attributes, as described in Table Table 31, and Table 32. phn-3963_004v000 Page 6-16...
  • Page 210 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Note Optionally, you can select from a list of pre-defined service point options in the Pre defined options field at the top of the Ethernet Service Points - Add page. The system automatically populates the remaining service point parameters according to the system-defined parameters.

  • Page 211: Table 28 Ethernet Services

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) 2. Select the relevant service in the Ethernet Services Configuration table. 3. Click Service Points. The Ethernet Service Points page opens (Figure 120). 4. Select the relevant service point in the Ethernet Services Points – General SP Attributes table. 5.

  • Page 212: Table 33 Vlan Classification Parameters

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Figure 125 Attached VLAN List - Add Page 7. Configure the VLAN Classification parameters, described in Table 33. 8. Click Apply, then Close. Table 33 VLAN Classification Parameters Parameter Definition Interface Location Read-only.
  • Page 213 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Service(s) Parameter Definition CoS Overwrite Valid If you want to assign a specific CoS and Color to frames with the C-VLAN or S-VLAN defined in the C-VLAN Encapsulation field, select true. This CoS and Color values defined below override the CoS and Color decisions made at the interface level.

  • Page 214: Setting The Mru Size And The S-Vlan Ethertype

    Chapter 6: Ethernet Services and Interfaces Setting the MRU Size and the S-VLAN Ethertype Setting the MRU Size and the S-VLAN Ethertype To configure the size of the MRU (Maximum Receive Unit) and the S-VLAN Ethertype: 1. Select Ethernet > General Configuration. The Ethernet General Configuration page opens. Figure 126 Ethernet General Configuration Page 2.

  • Page 215: Configuring Ethernet Interfaces

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Interfaces Configuring Ethernet Interfaces Related Topics:  Enabling the Interfaces (Interface Manager)  Performing Ethernet Loopback  Configuring Ethernet Service(s)  Quality of Service (QoS) The PTP 820’s switching fabric distinguishes between physical interfaces and logical interfaces. Physical and logical interfaces serve different purposes in the switching fabric.

  • Page 216: Table 34 Physical Interface Status Parameters

    Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Interfaces Figure 128 Physical Interfaces - Edit Page 3. Optionally, in the Description field, enter a description of the interface. 4. In the Media type field, select the physical interface layer 1 media type. Options are: Auto-Type –...
  • Page 217 Chapter 6: Ethernet Services and Interfaces Configuring Ethernet Interfaces Parameter Definition Admin Status Indicates whether the interface is currently enabled (Up) or disabled (Down). You can enable or disable an interface from the Interface Manager page. See Enabling the Interfaces (Interface Manager).

  • Page 218: Configuring Automatic State Propagation

    Chapter 6: Ethernet Services and Interfaces Configuring Automatic State Propagation Configuring Automatic State Propagation Automatic state propagation enables propagation of radio failures back to the Ethernet port. You can also configure Automatic State Propagation to close the Ethernet port based on a radio failure at the remote carrier.
  • Page 219 Chapter 6: Ethernet Services and Interfaces Configuring Automatic State Propagation 4. In the Monitored Radio interface field, select the Monitored Radio Interface. The Controlled Ethernet Interface, defined above, is disabled upon a failure indication on the Monitored Radio Interface. 5. In the Auto state propagation admin field, select Enable to enable Automatic State Propagation on the interface pair, or Disable to disable Automatic State Propagation on the pair.

  • Page 220: Viewing Ethernet Pms And Statistics

    Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics Viewing Ethernet PMs and Statistics PTP 820 stores and displays statistics in accordance with RMON and RMON2 standards. You can display various peak TX and RX rates (in seconds) and average TX and RX rates (in seconds), both in bytes and in packets, for each measured time interval.

  • Page 221: Port Tx Statistics

    Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics 3. Mark the interfaces you want to display and clear the interfaces you do not want to display. Figure 132 RMON Page – Hiding and Displaying Columns Port TX Statistics The Ethernet Port TX PM report page displays PMs that measure various peak transmission rates (in seconds) and average transmission rates (in seconds), both in bytes and in packets, for each measured time interval.

  • Page 222: Table 35 Ethernet Tx Port Pms

    Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics Figure 133 Ethernet Port TX PM Report Page 2. In the Interface field, select the interface for which you want to display PMs. 3. In the Interval Type field: To display reports for the past 24 hours, in 15 minute intervals, select 15 minutes.
  • Page 223 Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics Figure 134 Ethernet PM Port Admin Page 2. Select the interface. 3. Click Enable Port PM or Disable Port PM to enable or disable the gathering of Port TX PMs on the selected interface.

  • Page 224: Port Rx Statistics

    Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics 3. Click Apply, then Close. Port RX Statistics The Ethernet Port RX PM report page displays PMs that measure various peak transmission rates (in seconds) and average RX rates (in seconds), both in bytes and in packets, for each measured time interval.

  • Page 225: Table 36 Ethernet Rx Port Pms

    Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics Table 36 Ethernet RX Port PMs Parameter Definition Interval For 24-hour intervals, displays the date of the interval. For 15- minute intervals, displays the date and ending time of the interval.
  • Page 226 Chapter 6: Ethernet Services and Interfaces Viewing Ethernet PMs and Statistics 4. Click Close. Setting the Ethernet Port RX Threshold The RX bytes Layer 1 exceed threshold (sec) column shows for each interval, the number of seconds the RX bytes exceeded the specified threshold during the interval: To view and set this threshold: 1.

  • Page 227: Quality Of Service (Qos)

    Chapter 7: Quality of Service (QoS) Viewing Ethernet PMs and Statistics Quality of Service (QoS) This section includes:  QoS Overview  Configuring Classification  Configuring Policers (Rate Metering)  Configuring Marking  Configuring WRED  Configuring Egress Shaping  Configuring Scheduling Note You can display QoS egress statistics, but only via CLI.

  • Page 228: Qos Overview

    Chapter 7: Quality of Service (QoS) QoS Overview QoS Overview Quality of Service (QoS) deals with the way frames are handled within the switching fabric. QoS is required in order to deal with many different network scenarios, such as traffic congestion, packet availability, and delay restrictions.
  • Page 229 Chapter 7: Quality of Service (QoS) QoS Overview The egress path consists of the following QoS building blocks:  Queue Manager – This is the mechanism responsible for managing the transmission queues, utilizing smart WRED per queue and per packet color (Green or Yellow). ...

  • Page 230: Configuring Classification

    Chapter 7: Quality of Service (QoS) Configuring Classification Configuring Classification The hierarchical classifier consists of the following levels:  Logical interface-level classification  Service point-level classification  Service level classification This section explains how to configure classification at the logical interface level. ...

  • Page 231: Configuring Ingress Path Classification On A Logical Interface

    Chapter 7: Quality of Service (QoS) Configuring Classification PTP 820 performs the classification on each frame ingressing the system via the logical interface. Classification is performed step by step from the highest priority to the lowest priority classification method. Once a match is found, the classifier determines the CoS and Color decision for the frame for the logical interface-level.

  • Page 232: Table 37 Logical Interface Classification Parameters

    Chapter 7: Quality of Service (QoS) Configuring Classification Figure 141 Logical Interfaces - Edit Page 3. Configure the parameters described in Table 4. Click Apply, then Close. Note The Edge mode field is reserved for future use. The Ingress byte compensation and Egress byte compensation fields are described in Configuring the Ingress and Egress Byte...

  • Page 233: Modifying The C-Vlan 802.1Q Up And Cfi Bit Classification Table

    Chapter 7: Quality of Service (QoS) Configuring Classification Parameter Definition Trust DSCP Select the interface's trust mode for DSCP: Trust – The interface performs QoS and color classification according to a user-configurable table for DSCP to CoS and color classification. DSCP classification has priority over MPLS classification, so that if a match is found with the DSCP value of the ingressing frame, MPLS bits are not considered.

  • Page 234: Modifying The S-Vlan 802.1 Up And Dei Bit Classification Table

    Chapter 7: Quality of Service (QoS) Configuring Classification Figure 142 802.1Q Classification Page 2. Select the row you want to modify and click Edit. The 802.1Q Classification – Edit page opens. Figure 143 802.1Q Classification - Edit Page 3. Modify the parameters you want to change: 802.1Q UP –...

  • Page 235: Modifying The Dscp Classification Table

    Chapter 7: Quality of Service (QoS) Configuring Classification Figure 144 802.1AD Classification Page 2. Select the row you want to modify and click Edit. The 802.1AD Classification - Edit page opens. Figure 145 802.1Q Classification - Edit Page 3. Modify the parameters you want to change: 802.1AD UP –...
  • Page 236 Chapter 7: Quality of Service (QoS) Configuring Classification To modify the classification criteria for DSCPs: 1. Select Ethernet > QoS > Classification > DSCP. The DSCP Classification page opens. Figure 146 DSCP Classification Page 2. Select the row you want to modify and click Edit. The DSCP Classification - Edit page opens. Figure 147 DSCP Classification - Edit Page 3.

  • Page 237: Modifying The Mpls Exp Bit Classification Table

    Chapter 7: Quality of Service (QoS) Configuring Classification Modifying the MPLS EXP Bit Classification Table MPLS bits are used to provide QoS capabilities by utilizing the bits set in the MPLS labels. Classification by MPLS bits is supported in both untagged and 802.1Q provider-tagged frames. To modify the classification criteria for MPLS EXP bits: 1.

  • Page 238: Configuring Policers (Rate Metering)

    Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) CoS – The CoS assigned to frames with the designated MPLS EXP value. Color – The Color assigned to frames with the designated MPLS EXP value. 4. Click Apply, then Close. Configuring Policers (Rate Metering) This section includes: ...

  • Page 239: Table 38 Policer Profile Parameters

    Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) Figure 150 Policer Profile Page 2. Click Add. The Policer Profile - Add page opens. Figure 151 Policer Profile - Add Page 3. Configure the profile’s parameters. See Table 38 Policer Profile Parameters for a description of the policer profile parameters.
  • Page 240 Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) Table 38 Policer Profile Parameters Parameter Definition Profile ID A unique ID for the policer profile. You can choose from any unused value from 1 to 250. Once you have added the profile, you cannot change the Profile ID.

  • Page 241: Assigning Policers To Interfaces

    Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) Deleting a Policer Profile You cannot delete a policer profile that is attached to a logical interface. You must first remove the profile from the logical interface, then delete the profile. See Assigning Policers to Interfaces.
  • Page 242 Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) Assigning Unicast Policers To assign a policer for unicast traffic to a logical interface: 1. Select Ethernet > Interfaces > Logical Interfaces. The Logical Interfaces page opens (Figure 140). 2. Select the interface in the Ethernet Logical Port Configuration Table and click Policers. The Policers page opens.
  • Page 243 Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) 4. In the Policer profile field, select a profile from the policer profiles defined in the system. The Policer profile drop-down list includes the ID and description of all defined profiles. 5.
  • Page 244 Chapter 7: Quality of Service (QoS) Configuring Policers (Rate Metering) Assigning Ethertype Policers You can define up to three policers per Ethertype value. To assign a policer to an Ethertype: 1. Select Ethernet > Interfaces > Logical Interfaces. The Logical Interfaces page opens (Figure 140).

  • Page 245: Configuring The Ingress And Egress Byte Compensation

    Chapter 7: Quality of Service (QoS) Configuring Marking Configuring the Ingress and Egress Byte Compensation You can define the ingress and egress byte compensation value per logical interface. The policer attached to the interface uses these values to compensate for Layer 1 non-effective traffic bytes. To define the ingress byte compensation value for a logical interface: 1.

  • Page 246: Enabling Marking

    Chapter 7: Quality of Service (QoS) Configuring Marking Regular marking is only performed when:  The outer frame is S-VLAN, and S-VLAN CoS preservation is disabled, or  The outer frame is C-VLAN, and C-VLAN CoS preservation is disabled. If marking and CoS preservation for the relevant outer VLAN are both disabled, special marking is applied.

  • Page 247: Modifying The 802.1Ad Marking Table

    Chapter 7: Quality of Service (QoS) Configuring Marking Figure 157 802.1Q Marking - Edit Page 3. Enter the new 802.1Q UP and 802.1Q CFI values. 4. Click Apply, then Close. Modifying the 802.1AD Marking Table The 802.1AD Marking table enables you to modify the CoS to UP and DEI bit mapping that is implemented when marking is enabled.
  • Page 248 Chapter 7: Quality of Service (QoS) Configuring Marking 2. Select the row you want to modify and click Edit. The 802.1AD Marking - Edit page opens. Figure 159 802.1AD Marking - Edit Page 3. Enter the new 802.1AD UP and 802.1AD DEI values. 4.

  • Page 249: Configuring Wred

    Chapter 7: Quality of Service (QoS) Configuring WRED Configuring WRED This section includes:  WRED Overview  Configuring WRED Profiles  Assigning WRED Profiles to Queues WRED Overview Weighted Random Early Detection (WRED) enables differentiation between higher and lower priority traffic based on CoS. You can define up to 30 WRED profiles. Each profile contains a green traffic curve and a yellow traffic curve.
  • Page 250 Chapter 7: Quality of Service (QoS) Configuring WRED Figure 160 WRED Profile Page 2. Click ADD. The WRED Profile - Add page opens, with default values displayed. Figure 161 WRED Profile - Add Page 3. In the WRED Profile ID field, select a unique ID to identify the profile. Permitted values are 1-30. 4.
  • Page 251 Chapter 7: Quality of Service (QoS) Configuring WRED 9. In the Yellow curve max drop ratio field, enter the maximum percentage (1-100) of dropped yellow packets for queues with this profile. 10. Click Apply, then Close. Editing a WRED Profile To edit a WRED profile: 1.

  • Page 252: Assigning Wred Profiles To Queues

    Chapter 7: Quality of Service (QoS) Configuring WRED Assigning WRED Profiles to Queues To assign a WRED profile to a queue: 1. Select Ethernet > Interfaces > Logical Interfaces. The Logical Interfaces page opens (Figure 140). 2. Select an interface in the Ethernet Logical Port Configuration table and click WRED. The WRED page opens.

  • Page 253: Configuring Egress Shaping

    Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Configuring Egress Shaping This section includes:  Egress Shaping Overview  Configuring Queue Shaper Profiles  Configuring Service Bundle Shaper Profiles  Assigning a Queue Shaper Profile to a Queue  Assigning a Service Bundle Shaper Profile to a Service Bundle Egress Shaping Overview Egress shaping determines the traffic profile for each queue.
  • Page 254 Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Figure 164 Queue Shaper Profile Page 2. Click Add. The Queue Shaper – Add page opens, with default values displayed. Figure 165 Queue Shaper Profile – Add Page 3. In the Profile ID field, select a unique ID to identify the profile. Permitted values are 1-31. 4.

  • Page 255: Configuring Service Bundle Shaper Profiles

    Chapter 7: Quality of Service (QoS) Configuring Egress Shaping 2. Select the profile you want to edit and click Edit. The Queue Shaper Profile – Edit page opens. This page is similar to the Queue Shaper Profile – Add page (Figure 165).
  • Page 256 Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Figure 166 Service Bundle Shaper Profile Page 2. Click Add. The Service Bundle Shaper Profile – Add page opens, with default values displayed. Figure 167 Service Bundle Shaper Profile – Add Page 3.

  • Page 257: Assigning A Queue Shaper Profile To A Queue

    Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Editing a Service Bundle Shaper Profile To edit a service bundle shaper profile: 1. Select Ethernet > QoS > Shaper > Service Bundle Profiles. The Service Bundle Shaper Profile page opens (Figure 166).
  • Page 258 Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Figure 168 Logical Interfaces – Shaper – Egress Queue Shaper 3. Click Add. The Egress Queue Shaper Configuration – Add page opens. Figure 169 Logical Interfaces – Egress Queue Shaper Configuration – Add Page Note In this release, only one service bundle (Service Bundle ID 1) is supported.

  • Page 259: Assigning A Service Bundle Shaper Profile To A Service Bundle

    Chapter 7: Quality of Service (QoS) Configuring Egress Shaping To assign a different queue shaper profile to a queue: 1. Select Ethernet > Interfaces > Logical Interfaces. The Logical Interfaces page opens (Figure 140). 2. Select an interface in the Ethernet Logical Port Configuration table and click Shaper. The Logical Interfaces –...
  • Page 260 Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Figure 170 Logical Interfaces – Shaper – Egress Service Bundle Shaper 4. Click Add. The Egress Service Bundle Shaper Configuration – Add page opens. phn-3963_004v000 Page 7-67...
  • Page 261 Chapter 7: Quality of Service (QoS) Configuring Egress Shaping Figure 171 Logical Interfaces – Egress Service Bundle Shaper Configuration – Add Page Note In this release, only one service bundle (Service Bundle ID 1) is supported. 5. In the Profile ID field, select from a list of configured service bundle shaper profiles. See Configuring Service Bundle Shaper Profiles.

  • Page 262: Configuring Scheduling

    Chapter 7: Quality of Service (QoS) Configuring Scheduling Configuring Scheduling This section includes:  Scheduling Overview  Configuring Priority Profiles  Configuring WFQ Profiles  Assigning a Priority Profile to an Interface  Assigning a WFQ Profile to an Interface Scheduling Overview Scheduling determines the priority among the queues.
  • Page 263 Chapter 7: Quality of Service (QoS) Configuring Scheduling Figure 172 Scheduler Priority Profile Page 2. Click Add. The Scheduler Priority Profile – Add page opens, with default values displayed. phn-3963_004v000 Page 7-70...
  • Page 264 Chapter 7: Quality of Service (QoS) Configuring Scheduling Figure 173 Scheduler Priority Profile – Add Page 3. In the Profile ID field, select a unique Profile ID between 1 and 8. phn-3963_004v000 Page 7-71...
  • Page 265 Chapter 7: Quality of Service (QoS) Configuring Scheduling 4. For each CoS value, enter the Green priority, from 4 (highest) to 1 (lowest) (1-4). This priority is applied to Green frames with that CoS egressing a queue to which the profile is assigned. 5.

  • Page 266: Configuring Wfq Profiles

    Chapter 7: Quality of Service (QoS) Configuring Scheduling Configuring WFQ Profiles WFQ profiles determine the relative weight per queue. Each profile contains eight CoS-based weight values, corresponding to eight queues in an interface to which the profile is assigned. You can configure up to five WFQ profiles.
  • Page 267 Chapter 7: Quality of Service (QoS) Configuring Scheduling Figure 175 Scheduler WFQ Profile – Add Page 3. In the Profile ID field, select a unique Profile ID between 2 and 7. Profile ID 1 is used for a pre- defined WFQ profile. 4.

  • Page 268: Assigning A Priority Profile To An Interface

    Chapter 7: Quality of Service (QoS) Configuring Scheduling 1. Select the profiles in the Scheduler WFQ Profiles page or select all the profiles by selecting the check box in the top row. 2. Click Delete. The profiles are deleted. Assigning a Priority Profile to an Interface To assign a priority profile to an interface: 1.
  • Page 269 Chapter 7: Quality of Service (QoS) Configuring Scheduling 2. Select an interface in the Ethernet Logical Port Configuration table and click Scheduler. The Logical Interfaces – Scheduler page opens, with the Egress Port Scheduling Priority Configuration – Edit page open by default (Figure 176).

  • Page 270: Ethernet Protocols

    Chapter 8: Ethernet Protocols Configuring Scheduling Ethernet Protocols This section includes:  Configuring Adaptive Bandwidth Notification (ABN)  Configuring LLDP Related Topics:  Configuring Service OAM (SOAM) Fault Management (FM) phn-3963_004v000 Page 8-77...

  • Page 271: Configuring Adaptive Bandwidth Notification (Abn)

    Chapter 8: Ethernet Protocols Configuring Adaptive Bandwidth Notification (ABN) Configuring Adaptive Bandwidth Notification (ABN) This section includes:  Adaptive Bandwidth Notification Overview  Adding an ABN entity  Editing an ABN Entity  Deleting an ABN Entity  Viewing the Statistics for an ABN Entity Adaptive Bandwidth Notification Overview Adaptive Bandwidth Notification (ABN), also known as Ethernet Operation and Maintenance (EOAM), enables third party applications to learn about bandwidth changes in a radio link when...
  • Page 272 Chapter 8: Ethernet Protocols Configuring Adaptive Bandwidth Notification (ABN) 2. Click Add underneath the ABN Configuration and Status table. The ABN Configuration and Status – Add page opens. Figure 179 ABN Configuration and Status – Add Page 3. In the Name field, enter a name for the ABN entity. 4.

  • Page 273: Editing An Abn Entity

    Chapter 8: Ethernet Protocols Configuring Adaptive Bandwidth Notification (ABN) 12. Click Apply, then Close. Table 39 describes the status (read-only) fields in the ABN Configuration and Status table. Table 39 ABN Status Parameters Parameter Definition Nominal BW The nominal bandwidth of the link. Current BW The weighted average of the bandwidth readings taken during the last Monitoring Interval.

  • Page 274: Table 40 Abn Entity Statistics Parameters

    Chapter 8: Ethernet Protocols Configuring Adaptive Bandwidth Notification (ABN) Figure 180 ABN Configuration and Status - Statistics Page Table 40 describes the ABN entity statistics. Table 40 ABN Entity Statistics Parameters Parameter Definition Name The name of the ABN entity. Tx Messages Counter The number of bandwidth messages transmitted since the counter was last reset.

  • Page 275: Configuring Lldp

    Chapter 8: Ethernet Protocols Configuring LLDP Configuring LLDP This section includes:  LLDP Overview  Displaying Peer Status  Configuring the General LLDP Parameters  Configuring the LLDP Port Parameters  Displaying the Unit’s Management Parameters  Displaying Peer Unit’s Management Parameters ...

  • Page 276: Configuring The General Lldp Parameters

    Chapter 8: Ethernet Protocols Configuring LLDP Figure 181 LLDP Remote System Management Page Table 41 describes the LLDP remote system management parameters. These parameters are read- only. Table 41 LLDP Remote System Management Parameters Parameter Definition Local Interface The location of the local interface. Location Management Address The octet string used to identify the management address...
  • Page 277 Chapter 8: Ethernet Protocols Configuring LLDP Figure 182 LLDP Configuration Parameters Page 2. Modify the configurable parameters, described in Table 43. 3. Click Apply. Table 42 lists and describes the status parameters in the LLDP Configuration Parameters page. Table 42 LLDP Read-Only Configuration Parameters Parameter Definition Max TX Credit...

  • Page 278: Configuring The Lldp Port Parameters

    Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Reinit Delay (Seconds) Defines the minimum time, in seconds, the system waits after the LLDP Admin status becomes Disabled until it will process a request to reinitialize LLDP. For instructions on disabling or enabling LLDP on a port, see Configuring the LLDP Port Parameters.
  • Page 279 Chapter 8: Ethernet Protocols Configuring LLDP Figure 183 LLDP Port Configuration Page 2. Select an interface and click Edit. The LLDP Port Configuration - Edit page opens. Figure 184 LLDP Port Configuration - Edit Page 3. In the Admin field, select from the following options to define how the LLDP protocol operates for this port: TX Only –...

  • Page 280: Displaying The Unit's Management Parameters

    Chapter 8: Ethernet Protocols Configuring LLDP 4. In the Notification Enable field, select from the following options to define, on a per agent basis, whether or not notifications from the agent to the NMS are enabled: True – The agent sends a Topology Change trap to the NMS whenever the system information received from the peer changes.
  • Page 281 Chapter 8: Ethernet Protocols Configuring LLDP Figure 185 LLDP Destination Address Table Page To displays the MAC address associated with the unit for purposes of LLDP transmissions: 1. Select Ethernet > Protocols > LLDP > Advanced > Configuration > Management TLV. The LLDP Management TLV Configuration page opens.

  • Page 282: Displaying Peer Unit's Management Parameters

    Chapter 8: Ethernet Protocols Configuring LLDP Figure 186 LLDP Management TLV Configuration Page Table 45 lists and describes the status parameters in the LLDP Management TLV Configuration page. Table 45 LLDP Management TLV Parameters Parameter Definition Interface Location Identifies the port. Destination Address Defines the MAC address associated with the port for purposes of LLDP transmissions.
  • Page 283 Chapter 8: Ethernet Protocols Configuring LLDP Figure 187 LLDP Remote System Management Page Table 46 describes the LLDP remote system management parameters. These parameters are read- only. Table 46 LLDP Remote System Management Parameters Parameter Definition Local Interface The location of the local interface. Location Management Address The octet string used to identify the management address...

  • Page 284: Displaying The Local Unit's Parameters

    Chapter 8: Ethernet Protocols Configuring LLDP Figure 188 LLDP Remote System Table Page Table 47 describes the parameters in the LLDP Remote System Table page. These parameters are read-only. Table 47 LLDP Remote System Table Parameters Parameter Definition Local Interface The location of the local interface.
  • Page 285 Chapter 8: Ethernet Protocols Configuring LLDP Figure 189 LLDP Local System Parameters Page Table 48 describes the parameters in the LLDP Local System Parameters page. These parameters are read-only. Table 48 LLDP Local System Parameters Parameter Definition System Name The system name included in TLVs transmitted by the LLDP agent, as defined in the Name field of the Unit Parameters page.
  • Page 286 Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Capabilities Supported A bitmap value used to identify which system capabilities are supported on the local system, as included in TLVs transmitted by the LLDP agent. The bitmap is defined by the following parameters: 0 –...
  • Page 287 Chapter 8: Ethernet Protocols Configuring LLDP Figure 190 LLDP Local System Port Page Table 49 describes the parameters in the LLDP Local System Port page. These parameters are read-only. Table 49 LLDP Local System Port Parameters Parameter Definition Interface Location Identifies the port.
  • Page 288 Chapter 8: Ethernet Protocols Configuring LLDP Figure 191 LLDP Local System Management Page 2. To display all the parameters, select a row and click View. Figure 192 LLDP Local System Management – View Page Table 50 describes the parameters in the LLDP Local System Management page. These parameters are read-only.

  • Page 289: Displaying Lldp Statistics

    Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Address Interface ID Reserved for future use. Address Interface Sub Reserved for future use. Type Address OID Reserved for future use. Displaying LLDP Statistics To display statistics about changes reported via LLDP by the remote unit: 1.
  • Page 290 Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Inserts The number of times the information from the remote system has changed. Deletes The number of times the information from the remote system has been deleted. Drops Reserved for future use. Ageouts The number of times the information from the remote system has been deleted from the local unit's database because the...
  • Page 291 Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Destination Address The LLDP MAC address associated with this entry. Total Frames The number of LLDP frames transmitted by the LLDP agent on this port to the destination MAC address. Errored Length Frames The number of LLDPDU Length Errors recorded for this port and destination MAC address.
  • Page 292 Chapter 8: Ethernet Protocols Configuring LLDP Parameter Definition Total Discarded The number of LLDP frames received by the LLDP agent on this port, and then discarded for any reason. This counter can provide an indication that LLDP header formatting problems may exist with the local LLDP agent in the sending system or that LLDPDU validation problems may exist with the local LLDP agent in the receiving system.

  • Page 293: Synchronization

    The Sync Source, Outgoing Clock, and 1588-TC pages are reserved for future use. Configuring the Sync Regenerator Note SyncE Regenerator is supported for PTP 820C and PTP 820S. In SyncE PRC pipe regenerator mode, frequency is transported between two interfaces through the radio link.
  • Page 294 Chapter 9: Synchronization Configuring the Sync Regenerator 2. Click Add underneath the Pipe Configurations Table. The Pipe Configuration - Add window opens. Figure 197 Pipe Configurations - Add Page 3. Select a Pipe ID. 4. Select one of the available interfaces for each Sync Interface. Note One of the Sync Interfaces must be a Radio interface and the other must be an Ethernet interface.

  • Page 295: Access Management And Security

    Chapter 10: Access Management and Security Configuring the Sync Regenerator Access Management and Security This section includes:  Configuring the General Access Control Parameters  Configuring the Password Security Parameters  Configuring the Session Timeout  Configuring Users  Configuring RADIUS ...

  • Page 296: Configuring The General Access Control Parameters

    Chapter 10: Access Management and Security Configuring the General Access Control Parameters Configuring the General Access Control Parameters To avoid unauthorized login to the system, PTP 820 automatically blocks users upon a configurable number of failed login attempts. You can also configure PTP 820 to block users that have not logged into the unit for a defined number of days.
  • Page 297 Chapter 10: Access Management and Security Configuring the General Access Control Parameters Once a user is blocked, you can unblock the user from the User Accounts page. To unblock a user: 1. Select Platform > Security > Access Control > User Accounts. The Access Control User Accounts page opens (Figure 204).

  • Page 298: Configuring The Password Security Parameters

    Chapter 10: Access Management and Security Configuring the Password Security Parameters Configuring the Password Security Parameters To configure enhanced security requirements for user passwords: 1. Select Platform > Security > Access Control > Password Management. The Access Control Password Management page opens. Figure 200 Access Control Password Management Page 2.

  • Page 299: Configuring The Session Timeout

    Chapter 10: Access Management and Security Configuring the Session Timeout Configuring the Session Timeout By default, there is a 10 minute session timeout. If you do not perform any activity on the system for the period of time defined as the session timeout, the user session times out and you will have to log in to the system again.

  • Page 300: Configuring Users

    Chapter 10: Access Management and Security Configuring Users Configuring Users This section includes:  User Configuration Overview  Configuring User Profiles  Configuring Users Related topics:  Changing Your Password User Configuration Overview User configuration is based on the Role-Based Access Control (RBAC) model. According to the RBAC model, permissions to perform certain operations are assigned to specific roles.

  • Page 301: Configuring User Profiles

    Chapter 10: Access Management and Security Configuring Users Configuring User Profiles User profiles enable you to define system access levels. Each user must be assigned a user profile. Each user profile contains a detailed set of read and write permission levels per functionality group.
  • Page 302 Chapter 10: Access Management and Security Configuring Users Figure 203 Access Control User Profiles - Add Page 3. In the Profile field, enter a name for the profile. The profile name can include up to 49 characters. Once you have created the user profile, you cannot change its name. Note The Usage counter field displays the number of users to whom the user profile is assigned.

  • Page 303: Configuring Users

    Chapter 10: Access Management and Security Configuring Users Note You cannot delete a user profile if the profile is assigned to any users. Configuring Users You can configure up to 2,000 users. Each user has a user name, password, and user profile. The user profile defines a set of read and write permission levels per functionality group.
  • Page 304 Chapter 10: Access Management and Security Configuring Users Figure 205 Access Control User Accounts - Add Page 3. In the User name field, enter a user name for the user. The user name can be up to 32 characters. 4. In the Profile field, select a User Profile. The User Profile defines the user’s access levels for functionality groups in the system.
  • Page 305 Chapter 10: Access Management and Security Configuring Users In addition to the configurable parameters described above, the Access Control User Accounts page displays the following information for each user: Login Status – Indicates whether the user is currently logged into the system. Last Logout –...

  • Page 306: Configuring Radius

    Chapter 10: Access Management and Security Configuring RADIUS Configuring RADIUS This section includes:  RADIUS Overview  Activating RADIUS Authentication  Configuring the RADIUS Server Attributes  Viewing RADIUS User Permissions and Connectivity  Configuring a RADIUS Server RADIUS Overview The RADIUS protocol provides centralized user management services.

  • Page 307: Configuring The Radius Server Attributes

    Chapter 10: Access Management and Security Configuring RADIUS Figure 206 Radius Configuration Page 2. In the Radius Admin field, select Enable. 3. Click Apply. Configuring the RADIUS Server Attributes To configure the RADIUS server attributes: 1. Select Platform > Security > Access Control > Radius > Radius Configuration. The Radius Configuration page opens (Figure 206).

  • Page 308: Viewing Radius User Permissions And Connectivity

    Chapter 10: Access Management and Security Configuring RADIUS Figure 207 Radius Configuration – Edit Page 4. In the IPV4 address field, enter the IP address of the RADIUS server. 5. In the Port field, enter the port ID of the RADIUS protocol in the RADIUS server. 6.
  • Page 309 Chapter 10: Access Management and Security Configuring RADIUS Figure 208 Radius Users Page The User ID column displays the user’s name. The Access Channels column displays the access channels the user is allowed to use to access the unit. The User Instances column displays the number of open sessions the user currently has. To view the user’s authorized access levels, click + next to the user name.

  • Page 310: Configuring A Radius Server

    Chapter 10: Access Management and Security Configuring RADIUS For each of the six functional groups (Ethernet, Management, Radio, Security, Sync, TDM), the page displays the Read access level (None, Regular, or Advanced), and the Write access level (None, Regular, or Advanced). Configuring a RADIUS Server If you want to use the PTP 820 RADIUS feature, you must first install a RADIUS server and configure it to work with the PTP 820 device.
  • Page 311 Chapter 10: Access Management and Security Configuring RADIUS Figure 210 Server Manager – Creating User Groups Create three users: phn-3963_004v000 Page 10-118...
  • Page 312 Chapter 10: Access Management and Security Configuring RADIUS Figure 211 Server Manager – Creating Users Attach each user to a group, as follows: Attach u1 to Radius_Advanced Attach u2 to Radius_Normal Attach u3 to Radius_Viewer phn-3963_004v000 Page 10-119...
  • Page 313 Chapter 10: Access Management and Security Configuring RADIUS Step 2 – Creating a RADIUS Client Define the PTP 820 device as a RADIUS client, as follows: In the Server Manager, navigate to Roles > Network Policy and Access Services > NPS (Local) >...
  • Page 314 Chapter 10: Access Management and Security Configuring RADIUS In the New RADIUS Client window: Select the Enable this RADIUS client check box. Enter a descriptive Friendly name for the device, such as PTP 820X Enter the device IP Address. Select RADIUS Standard as the Vendor name. In the Shared Secret section, select Manual, and enter a Shared secret, then enter it again in Confirm shared secret.
  • Page 315 Chapter 10: Access Management and Security Configuring RADIUS Figure 213 Create Network Policy – Specify Name and Connection Type Click Next. In the Specify Conditions window, click Add. In the Select Condition window that appears, select the User Groups condition and click Add. phn-3963_004v000 Page 10-122...
  • Page 316 Chapter 10: Access Management and Security Configuring RADIUS Figure 214 Create Network Policy – Select Condition In the User Groups window that appears, click Add Groups. In the Select Group window that appears, click Advanced. In the Select Group window that appears, click Find Now to list all groups, and then select the appropriate group from the list: Radius_Advanced, Radius_Normal, or Radius_Viewer.
  • Page 317 Chapter 10: Access Management and Security Configuring RADIUS Figure 215 Create Network Policy – User Group added to Policy’s Conditions 11 Click OK to save settings. 12 Click Next. phn-3963_004v000 Page 10-124...
  • Page 318 Chapter 10: Access Management and Security Configuring RADIUS 13 In the Specify Access Permission window that appears, select the Access Granted option. Figure 216 Create Network Policy – Specifying Access Permission 14 Click Next. phn-3963_004v000 Page 10-125...
  • Page 319 Chapter 10: Access Management and Security Configuring RADIUS 15 In the Configure Authentication Methods window that appears, make sure only the Unencrypted Authentication (PAP, SPAP) option is selected. Figure 217 Create Network Policy – Configuring Authentication Methods 16 In the query window that appears, click No. Figure 218 Create Network Policy –...
  • Page 320 Chapter 10: Access Management and Security Configuring RADIUS 17 In the Configure Constraints window that appears, click Next. Figure 219 Create Network Policy – Configuring Constraints phn-3963_004v000 Page 10-127...
  • Page 321 Chapter 10: Access Management and Security Configuring RADIUS 18 In the Configure Settings window that appears: Remove all Standard RADIUS attributes. Make sure the Attributes table is empty. Figure 220 Create Network Policy – Configuring Settings ii Select the Vendor Specific checkbox and click Add under the Attributes table. phn-3963_004v000 Page 10-128...
  • Page 322 Chapter 10: Access Management and Security Configuring RADIUS 19 In the Add Vendor Specific Attribute window that appears: Select Custom in the Vendor drop down field. ii Click Add. Figure 221 Create Network Policy – Adding Vendor Specific Attributes phn-3963_004v000 Page 10-129...
  • Page 323 Chapter 10: Access Management and Security Configuring RADIUS 20 In the Attribute Information window that appears, click Add. Figure 222 Create Network Policy – Selecting to Add Attribute Information 21 In the Vendor-Specific Attribute Information window that appears: Select Enter Vendor Code. ii Enter 2281 in the Enter Vendor Code field.
  • Page 324 Chapter 10: Access Management and Security Configuring RADIUS 22 In the Configure VSA (RFC Compliant) window that appears, configure 13 attributes as follows: For Vendor-assigned attribute number from 21 till 32, select Decimal in the Attribute format field. These twelve attributes define the Read access level (None, Regular, or Advanced), and the Write access level (None, Regular, or Advanced) for each of the six functional groups (Ethernet, Management, Radio, Security, Sync, TDM).
  • Page 325 Chapter 10: Access Management and Security Configuring RADIUS corresponding to the access channels you wish to permit, where the value for each access channel is:  none=0  serial=1  telnet=2  ssh=4  web=8  nms=16  snmp=32  snmpV3=64 Thus for example, enter 127 to allow access from all channels: Serial + Telnet + SSH + Web + NMS + SNMP +SNMPv3;...
  • Page 326 Chapter 10: Access Management and Security Configuring RADIUS 26 Reset the Network Policy Server (NPS) by stopping and starting the NPS service as follows: Right click the NPS (Local) node, and select Stop NPS Service. ii Right click the NPS (Local) node, and select Start NPS Service. Figure 226 Create Network Policy –...
  • Page 327 Chapter 10: Access Management and Security Configuring RADIUS To create these RADIUS users: Add the users in the file, using any editor you like, according to the following /etc/raddb/users example: # user1 - advanced privileges auth-type := local, Cleartext-Password := "1111" security-ro = advanced, security-wo = advanced, mng-ro = advanced,...
  • Page 328 Chapter 10: Access Management and Security Configuring RADIUS # user3 - no privilege (viewer) auth-type := local, Cleartext-Password := "3333" security-ro = none, security-wo = none, mng-ro = none, mng-wo = none, radio-ro = none, radio-wo = none, tdm-ro = none, tdm-wo = none, eth-ro = none, eth-wo = none,...
  • Page 329 To define a device as a RADIUS client: In the /etc/raddb/clients.conf file, add the device according to the following example. The example shows how to add a PTP 820G device with IP address 192.168.1.118: # PTP 820C client 192.168.1.118 { secret = default_not_applicable = cambium -ptp 820G...

  • Page 330: Configuring X.509 Csr Certificates And Https

    Chapter 10: Access Management and Security Configuring X.509 CSR Certificates and HTTPS Configuring X.509 CSR Certificates and HTTPS The web interface protocol for accessing PTP 820 can be configured to HTTP (default) or HTTPS. It cannot be set to both at the same time. Before setting the protocol to HTTPS, you must: 1.
  • Page 331 Chapter 10: Access Management and Security Configuring X.509 CSR Certificates and HTTPS Figure 227 Security Certificate Request Page 2. In the Common Name field, enter the fully–qualified domain name for your web server. You must enter the exact domain name. 3.

  • Page 332: Downloading A Certificate

    Chapter 10: Access Management and Security Configuring X.509 CSR Certificates and HTTPS 14. If the IP address family is configured to be IPv4, enter the IPv4 address of the PC or laptop you are using as the SFTP server in the Server IPV4 address field. See Defining the IP Protocol Version for Initiating Communications.

  • Page 333: Blocking Telnet Access

    Chapter 10: Access Management and Security Blocking Telnet Access 4. In the Path field, enter the directory path from which you are uploading the certificate. Enter the path relative to the SFTP user’s home directory, not the absolute path. To leave the path blank, enter //.
  • Page 334 Chapter 10: Access Management and Security Blocking Telnet Access In the Telnet Admin field, select Disable to block telnet access. By default, telnet access is enabled (Enable). Click Apply. phn-3963_004v000 Page 10-141...

  • Page 335: Uploading The Security Log

    Chapter 10: Access Management and Security Uploading the Security Log Uploading the Security Log The security log is an internal system file which records all changes performed to any security feature, as well as all security related events. When uploading the security log, the PTP 820 functions as an FTP or SFTP client. You must install FTP or SFTP server software on the PC or laptop you are using to perform the import or export.
  • Page 336 Chapter 10: Access Management and Security Uploading the Security Log 7. If the IP address family is configured to be IPv6, enter the IPv6 address of the PC or laptop you are using as the FTP server in the Server IPv6 address field. See Defining the IP Protocol Version for Initiating Communications.

  • Page 337: Uploading The Configuration Log

    Chapter 10: Access Management and Security Uploading the Configuration Log Uploading the Configuration Log The configuration log lists actions performed by users to configure the system. This file is mostly used for security, to identify suspicious user actions. It can also be used for troubleshooting. When uploading the configuration log, the PTP 820 functions as an FTP or SFTP client.
  • Page 338 Chapter 10: Access Management and Security Uploading the Configuration Log 7. If the IP address family is configured to be IPv6, enter the IPv6 address of the PC or laptop you are using as the FTP server in the Server IPv6 address field. See Defining the IP Protocol Version for Initiating Communications.

  • Page 339: Alarm Management And Troubleshooting

    Chapter 11: Alarm Management and Troubleshooting Uploading the Configuration Log Alarm Management and Troubleshooting This section includes:  Viewing Current Alarms  Viewing the Event Log  Editing Alarm Text and Severity  Uploading Unit Info  Performing Diagnostics phn-3963_004v000 Page 11-146...

  • Page 340: Viewing Current Alarms

    Chapter 11: Alarm Management and Troubleshooting Viewing Current Alarms Viewing Current Alarms To display a list of current alarms in the unit: 1. Select Faults > Current Alarms. The Current Alarms page opens. The Current Alarms page displays current alarms in the unit. Each row in the Current Alarms table describes an alarm and provides basic information about the alarm.
  • Page 341 Chapter 11: Alarm Management and Troubleshooting Viewing Current Alarms Table 54 Alarm Information Parameter Definition Sequence Number (#) A unique sequence number assigned to the alarm by the system. Time The date and time the alarm was triggered. Severity The severity of the alarm. In the Current Alarms table, the severity is indicated by a symbol.

  • Page 342: Viewing The Event Log

    Chapter 11: Alarm Management and Troubleshooting Viewing the Event Log Viewing the Event Log The Event Log displays a list of current and historical events and information about each event. To display the Event Log: 1. Select Faults > Event Log. The Event Log opens. For a description of the information provided in the Event Log, see Table 55 Event Log Information.
  • Page 343 Chapter 11: Alarm Management and Troubleshooting Viewing the Event Log Parameter Definition User Text Additional text that has been added to the system-defined description of the event by users. Note: You can add user text to events in the Alarm Configuration page.

  • Page 344: Editing Alarm Text And Severity

    Chapter 11: Alarm Management and Troubleshooting Editing Alarm Text and Severity Editing Alarm Text and Severity You can view a list of alarm types, edit the severity level assigned to individual alarm types, and add additional descriptive text to individual alarm types. This section includes: ...

  • Page 345: Viewing The Probable Cause And Corrective Actions For An Alarm Type

    Chapter 11: Alarm Management and Troubleshooting Editing Alarm Text and Severity Parameter Definition Description A system-defined description of the alarm. Additional Text Additional text that has been added to the system-defined description of the alarm by users. You can edit the text in the Alarm Configuration –...

  • Page 346: Setting Alarms To Their Default Values

    Chapter 11: Alarm Management and Troubleshooting Editing Alarm Text and Severity Figure 237 Alarm Configuration - Edit Page 3. Modify the Severity and/or Additional Text fields. 4. Click Apply, then Close. Setting Alarms to their Default Values To set all alarms to their default severity levels and text descriptions, click Set All to Default in the Alarm Configuration page (Figure 235).

  • Page 347: Uploading Unit Info

    Chapter 11: Alarm Management and Troubleshooting Uploading Unit Info Uploading Unit Info You can generate a Unit Information file, which includes technical data about the unit. This file can be uploaded and forwarded to customer support, at their request, to help in analyzing issues that may occur.
  • Page 348 Chapter 11: Alarm Management and Troubleshooting Uploading Unit Info 7. If the IP address family is configured to be IPv6, enter the IPv6 address of the PC or laptop you are using as the FTP server in the IPv6 Server Address field. See Defining the IP Protocol Version for Initiating Communications.

  • Page 349: Performing Diagnostics

    Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Performing Diagnostics This section includes:  Performing Radio Loopback  Performing Ethernet Loopback  Configuring Service OAM (SOAM) Fault Management (FM) Performing Radio Loopback To perform loopback on a radio: 1. Select Radio > Diagnostics > Loopback. The Radio Loopbacks page opens. Figure 239 Radio Loopbacks Page 2.

  • Page 350: Performing Ethernet Loopback

    Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 240 Radio Loopbacks – Edit Page 3. In the Loopback timeout (minutes) field, enter the timeout, in minutes, for automatic termination of the loopback (0-1440). A value of 0 indicates that there is no timeout. 4.

  • Page 351: Configuring Service Oam (Soam) Fault Management (Fm)

    Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 241 Logical Interfaces – Loopback Page 3. In the Ethernet loopback admin field, select Enable to enable Ethernet loopback on the logical interface, or Disable to disable Ethernet loopback on the logical interface. 4.
  • Page 352 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Y.1731 Ethernet FM (Fault Management) consists of three protocols that operate together to aid in fault management:  Continuity check  Link trace  Loopback Note Link trace and Loopback are planned for future release. PTP 820 utilizes these protocols to maintain smooth system operation and non-stop data flow.
  • Page 353 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 242 SOAM MD Page 2. Click Add. The SOAM MD – Add page opens. Figure 243 SOAM MD Page 3. In the MD Name field, enter an identifier for the MD (up to 43 alphanumeric characters). The MD Name should be unique over the domain.
  • Page 354 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics 5. In the MD Level field, select the maintenance level of the MD (1-7). The maintenance level ensures that the CFM frames for each domain do not interfere with each other. Where domains are nested, the encompassing domain must have a higher level than the domain it encloses.
  • Page 355 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 245 SOAM MA/MEG – Add Page 3. Configure the fields described in Table 57. 4. Click Apply, then Close. Table 58 describes the status (read-only) fields in the SOAM MA/MEG Component table. Table 57 SOAM MA/MEG Configuration Parameters Parameter Definition...
  • Page 356 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Parameter Definition MEG Level Select a MEG level (0-7). The MEG level must be the same for MEGs on both sides of the link. Higher levels take priority over lower levels. If MEGs are nested, the OAM flow of each MEG must be clearly identifiable and separable from the OAM flows of the other MEGs.
  • Page 357 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Table 58 SOAM MA/MEG Status Parameters Parameter Definition MA/MEG ID Automatically generated by the system. MA/MEG Name Reserved for future use. In the current release, this is Char Format String only. MIP Creation Reserved for future use.
  • Page 358 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 246 MEP List Page 2. Click Add. The Add MEP page opens. phn-3963_004v000 Page 11-165...
  • Page 359 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 247 Add MEP Page 3. In the MEP ID field, enter a MEP ID (1-8191). 4. Click Apply, then Close. Configuring the Local MEPs Once you have added local and remote MEPs, you must define the MEPs and determine which are the local MEPs: 1.
  • Page 360 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics 2. Click Add. Page 1 of the Add SOAM MEP wizard opens. Figure 249 Add SOAM MEP Wizard – Page 1 3. In the MEG Name field, select an MA/MEG. 4. Click Next. Page 2 of the Add SOAM MEP wizard opens. Figure 250 Add SOAM MEP Wizard –...
  • Page 361 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Figure 251 Add SOAM MEP Wizard –Summary Page 9. Verify that you want to submit the displayed parameters and click Submit. Table 59 SOAM MEP Parameters Parameter Definition MD ID An MD ID automatically generated by the system. MA/MEG ID An MA/MEG ID automatically generated by the system.
  • Page 362 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Enabling Local MEPs Once you have added a MEP and defined it as a local MEP, you must enable the MEP. To enable a MEP: 1. In the SOAM MEP page (Figure 248), select the MEP you want to enable.
  • Page 363 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Displaying Remote MEPs To display a list of remote MEPs (RMEPs) and their parameters: 1. Select Ethernet > Protocols > SOAM > MEP. The SOAM MEP page opens (Figure 248). 2. Select a MEP and click RMEP List. The SOAM MEP DB table is displayed. Figure 253 SOAM MEP DB Table Table 60 lists and describes the parameters displayed in the SOAM MEP DB table.
  • Page 364 Chapter 11: Alarm Management and Troubleshooting Performing Diagnostics Parameter Definition RMEP Last rx CCM Reserved for future use. Chassis ID Displaying Last Invalid CCMS To display the entire frame of the last CCM error message and the last CCM cross-connect error message received by a specific local MEP: 1.

  • Page 365: Web Ems Utilities

    Chapter 12: Web EMS Utilities Performing Diagnostics Web EMS Utilities This section includes:  Restarting the HTTP Server  Calculating an ifIndex  Displaying, Searching, and Saving a list of MIB Entities phn-3963_004v000 Page 12-172...

  • Page 366: Restarting The Http Server

    Chapter 12: Web EMS Utilities Calculating an ifIndex Restarting the HTTP Server To restart the unit’s HTTP server: Select Utilities > Restart HTTP. The Restart HTTP page opens. Figure 255 Restart HTTP Page Click Restart. The system prompts you for confirmation. Click OK.
  • Page 367 Chapter 12: Web EMS Utilities Calculating an ifIndex Figure 256 ifIndex Calculator Page  If you have an ifIndex and you want to determine which hardware item in the unit it represents, enter the number in the ifIndex number field and click Calculate Index to name. A description of the object appears in the Result field.

  • Page 368: Displaying, Searching, And Saving A List Of Mib Entities

    Chapter 12: Web EMS Utilities Displaying, Searching, and Saving a list of MIB Entities Displaying, Searching, and Saving a list of MIB Entities To display a list of entities in the PTP 820 private MIB: Select Utilities > ifCalculator. The ifIndex Calculator page opens. Figure 257 MIB Reference Table Page The MIB Reference Table is customized to the type of PTP8 20 product you are using.

  • Page 369: Getting Started (Cli)

    Chapter 13: Getting Started (CLI) Displaying, Searching, and Saving a list of MIB Entities Getting Started (CLI) This section includes:  General (CLI)  Establishing a Connection (CLI)  Logging On (CLI)  General CLI Commands  Changing Your Password (CLI) ...

  • Page 370: General (Cli)

    Chapter 13: Getting Started (CLI) Establishing a Connection (CLI) General (CLI) Before connection over the radio hop is established, it is of high importance that you assign to the PTP 820 unit a dedicated IP address, according to an IP plan for the total network. See Changing the Management IP Address (CLI).

  • Page 371: Logging On (Cli)

    A password prompt appears. Enter the default password: admin The root prompt appears. For example: login: admin Password: Wind River Linux glibc_cgl (cgl) 4.1 CE.1.0 Last login: Mon Apr 13 11:27:02 on console Wind River Linux glibc_cgl (cgl) 4.1 CE.1.0 PTP 820C root> phn-3963_004v000 Page 13-178...

  • Page 372: General Cli Commands

    Chapter 13: Getting Started (CLI) General CLI Commands General CLI Commands To display all command levels available from your current level, press <TAB> twice. For example, if you press <TAB> twice at the root level, the following is displayed: root> auto-state-propagation ethernet exit...

  • Page 373: Changing Your Password (Cli)

    In addition to the Admin password, there is an additional password protected user account, “root user”, which is configured in the system. The root user password and instructions for changing this password are available from Cambium Networks Customer Support. It is strongly recommended to change this password.

  • Page 374: Configuring In-Band Management (Cli)

    Chapter 13: Getting Started (CLI) Configuring In-Band Management (CLI) Configuring In-Band Management (CLI) You can configure in-band management in order to manage the unit remotely via its radio and/or Ethernet interfaces. Each PTP 820 unit includes a pre-defined management service with Service ID 257. The management service is a multipoint service that connects the two local management ports and the network element host CPU in a single service.

  • Page 375: Changing The Management Ip Address (Cli)

    Chapter 13: Getting Started (CLI) Changing the Management IP Address (CLI) Changing the Management IP Address (CLI) Related Topics:  Defining the IP Protocol Version for Initiating Communications (CLI)  Configuring the Remote Unit’s IP Address (CLI) You can enter the unit's address in IPv4 format and/or in IPv6 format. The unit will receive communications whether they were sent to its IPv4 address or its IPv6 address.
  • Page 376 Chapter 13: Getting Started (CLI) Changing the Management IP Address (CLI) Table 62 IP Address (IPv6) CLI Parameters Parameter Input Type Permitted Values Description ipv6- Eight groups of four Any valid IPv6 The IP address for the address hexadecimal digits address.

  • Page 377: Configuring The Activation Key (Cli)

    Chapter 13: Getting Started (CLI) Configuring the Activation Key (CLI) Configuring the Activation Key (CLI) This section includes:  Activation Key Overview (CLI)  Viewing the Activation Key Status Parameters (CLI)  Entering the Activation Key (CLI)  Activating a Demo Activation Key (CLI) ...

  • Page 378: Entering The Activation Key (Cli)

    Chapter 13: Getting Started (CLI) Configuring the Activation Key (CLI) Entering the Activation Key (CLI) To enter the activation key, enter the following command in root view. root> platform activation-key set key string <key string> If the activation key is not legal (e.g., a typing mistake or an invalid serial number), an Activation Key Loading Failure event is sent to the Event Log.

  • Page 379: Setting The Time And Date (Optional) (Cli)

    Chapter 13: Getting Started (CLI) Setting the Time and Date (Optional) (CLI) Setting the Time and Date (Optional) (CLI) Related Topics:  Configuring NTP (CLI) To set the UTC time, enter the following command in root view: root> platform management time-services utc set date-and-time <date-and- time>...
  • Page 380 Chapter 13: Getting Started (CLI) Setting the Time and Date (Optional) (CLI) root> platform management time-services utc set offset hours-offset 13 minutes-offset 32 Setting the Daylight Savings Time (CLI) To set the daylight savings time parameters, enter the following command in root view: root>...

  • Page 381: Enabling The Interfaces (Cli)

    – a radio interface. slot Number Ethernet: 1 The slot on which the interface is located. Radio in PTP 820C or PTP 820S: port Number GbE 1: 1 The specific interface you want to enable or GbE 2: 2 disable.
  • Page 382 The following command enables Ethernet port 2: root> platform if-manager set interface-type ethernet slot 1 port 2 admin The following command enables radio interface 1 in a PTP 820C or PTP 820S unit: root> platform if-manager set interface-type radio slot 2 port 1 admin up The following command disables Ethernet port 3: root>...

  • Page 383: Configuring The Radio Parameters (Cli)

    Number Radio Carrier 1: 1 The specific radio carrier you want to access. Radio Carrier 2 (PTP 820C only): Examples The following command enters radio view for radio carrier 1: root> radio slot 2 port 1 The following prompt appears: radio[2/1]>...

  • Page 384: Configuring The Transmit (Tx) Level (Cli)

    Examples The following command mutes radio carrier 1: radio[2/1]>rf mute set admin on The following command unmutes radio carrier 2 in a PTP 820C unit: radio[2/2]>rf mute set admin off Configuring the Transmit (TX) Level (CLI) To set the transmit (TX) level of a radio, enter the following command: radio[x/x]>rf set tx-level <tx-level>...
  • Page 385 RX frequency of the remote unit. Examples The following command sets the TX frequency of radio carrier 1 in a PTP 820C or PTP 820S unit to 12900000 KHz, and sets the RX frequency of the remote unit to the same value.

  • Page 386: Configuring The Radio (Mrmc) Script(S) (Cli)

    Chapter 13: Getting Started (CLI) Configuring the Radio (MRMC) Script(s) (CLI) Configuring the Radio (MRMC) Script(s) (CLI) Multi-Rate Multi-Constellation (MRMC) radio scripts define how the radio utilizes its available capacity. Each script is a pre-defined collection of configuration settings that specify the radio’s transmit and receive levels, link modulation, channel spacing, and bit rate.

  • Page 387: Assigning An Mrmc Script To A Radio Carrier (Cli)

    Examples The following command displays available symmetrical (normal) scripts with ACM support for radio carrier 2 in a PTP 820C unit: radio[2/2]>mrmc script show script-type normal acm-support yes Assigning an MRMC Script to a Radio Carrier (CLI) Once you have a list of valid scripts, you can assign a script to the radio carrier.
  • Page 388 Examples The following command assigns MRMC script ID 1503, with ACM enabled and a maximum profile of 9, to radio carrier 1 in a PTP 820C and PTP 820S unit: radio[2/1]>mrmc set acm-support script-id 13 modulation adaptive max- profile 9...

  • Page 389: Enabling Acm With Adaptive Transmit Power (Cli)

    Chapter 13: Getting Started (CLI) Enabling ACM with Adaptive Transmit Power (CLI) Enabling ACM with Adaptive Transmit Power (CLI) When planning ACM-based radio links, the radio planner attempts to apply the lowest transmit power that will perform satisfactorily at the highest level of modulation. During fade conditions requiring a modulation drop, most radio systems cannot increase transmit power to compensate for the signal degradation, resulting in a deeper reduction in capacity.

  • Page 390: Operating In Fips Mode (Cli)

    Operating in FIPS Mode (CLI) Operating in FIPS Mode (CLI) From release 8.3, PTP 820C and PTP 820S can be configured to be FIPS 140-2-compliant in specific hardware and software configurations, as described in this section. Requirements for FIPS Compliance (CLI)

  • Page 391: Configuring Grouping (Optional) (Cli)

    Chapter 13: Getting Started (CLI) Configuring Grouping (Optional) (CLI) Configuring Grouping (Optional) (CLI) At this point in the configuration process, you should configure any interface groups that need to be set up according to your network plan. For details on available grouping and other configuration options, as well as configuration instructions, see System Configurations (CLI).

  • Page 392: Creating Service(S) For Traffic (Cli)

    Chapter 13: Getting Started (CLI) Creating Service(s) for Traffic (CLI) Creating Service(s) for Traffic (CLI) In order to pass traffic through the PTP 820, you must configure Ethernet traffic services. For configuration instructions, see Configuring Ethernet Services (CLI). phn-3963_004v000 Page 13-199...

  • Page 393: Configuration Guide (Cli)

    Configuring Multi-Carrier ABC (CLI)  Configuring Link Aggregation (LAG) (Optional) (CLI)  Configuring XPIC (CLI)  Configuring HSB Radio Protection (CLI)  Configuring MIMO and Space Diversity (CLI)  Operating a PTP 820C in Single Radio Carrier Mode (CLI) phn-3963_004v000 Page 14-200...

  • Page 394: System Configurations (Cli)

    PTP 820C/S Configuring HSB Radio Protection (CLI) MIMO and Space PTP 820C Configuring MIMO and Space Diversity (CLI) Diversity PTP 820C in Single Radio PTP 820C Operating a PTP 820C in Single Radio Carrier Carrier Mode Mode (CLI) phn-3963_004v000 Page 14-201...

  • Page 395: Configuring Multi-Carrier Abc (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring Multi-Carrier ABC (CLI) Configuring Multi-Carrier ABC (CLI) Note This option is only relevant for PTP 820C units. This section includes:  Multi-Carrier ABC Overview (CLI)  Configuring a Multi-Carrier ABC Group (CLI)  Removing Members from a Multi-Carrier ABC Group (CLI) ...

  • Page 396: Removing Members From A Multi-Carrier Abc Group (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring Multi-Carrier ABC (CLI) Add members to the group as follows: To add a radio interface to the group, enter the following command in Multi-Carrier ABC Group view. Repeat this command for each radio interface you want to add. multi-carrier-abc group-id [1]>...

  • Page 397: Configuring Link Aggregation (Lag) (Optional) (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring Link Aggregation (LAG) (Optional) (CLI) Configuring Link Aggregation (LAG) (Optional) (CLI) Link aggregation (LAG) enables you to group several physical Ethernet or radio interfaces into a single logical interface bound to a single MAC address. This logical interface is known as a LAG group.

  • Page 398: Configuring A Lag Group (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring Link Aggregation (LAG) (Optional) (CLI) Note To add or remove an Ethernet interface to a LAG group, the interface must be in an administrative state of “down”. This restriction does not apply to radio interfaces. For instructions on setting the administrative state of an interface, see Enabling the Interfaces (CLI)
  • Page 399 GbE 2: 2 GbE 3: 3 Radio Carrier 1: 1 Radio Carrier 2 (PTP 820C only): 2 Examples The following commands create a LAG with the ID lag2. The LAG includes the Ethernet interfaces 1 and 2 and radio interface 1: root>...
  • Page 400 Chapter 14: Configuration Guide (CLI) Configuring Link Aggregation (LAG) (Optional) (CLI) root> ethernet interfaces radio slot 2 port 1 eth type radio[2/1]> eth type radio[2/1]> static-lag add lagid lag2 eth type radio[2/1]> exit root> platform if-manager set interface-type ethernet slot 1 port 1 admin root>...

  • Page 401: Configuring Xpic (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring XPIC (CLI) Configuring XPIC (CLI) Note This option is only relevant for PTP 820C units. This section explains how to configure XPIC and includes the following topics:  XPIC Overview (CLI)  Configuring the Antennas (CLI) ...

  • Page 402: Configuring The Radio Carriers For Xpic (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring XPIC (CLI) Note To measure the second carrier, leave the Voltmeter connected to the BNC connector. In the Radio Parameters page of the Web EMS (Figure 18), change the RSL Connector Source field from PHYS1 to PHYS2 (or vice versa). The BNC connector will now measure RSL from the other carrier.

  • Page 403: Creating An Xpic Group (Cli)

    XPIC support is indicated by an X in the script name. For example, mdN_A2828X_111_1205 is an XPIC-enabled script. mdN_A2828N_130_100 is not an XPIC-enabled script. For a list of XPIC support-enabled scripts, refer to the most recent PTP 820C/S Release Notes. 3. Create an XPIC group. See Creating an XPIC Group (CLI).

  • Page 404: Configuring Hsb Radio Protection (Cli)

    Disabling Unit Protection (CLI) HSB Radio Protection Overview (CLI) PTP 820C and PTP 820S support 1+1 HSB radio protection. PTP 820C also supports 2+2 HSB radio protection. In HSB radio protection, one PTP 820 operates in active mode and the other operates in standby mode.

  • Page 405: Configuring 2+2 Hsb Protection On A Ptp 820C Unit (Cli)

    Configuring 2+2 HSB Protection on a PTP 820C Unit (CLI) In order to configure 2+2 HSB unit protection on a PTP 820C unit, you must simply enable the second radio carrier on both units on both sides of the link. No other configuration is necessary other than the configuration described above.

  • Page 406: Viewing The Configuration Of The Standby Unit (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring HSB Radio Protection (CLI) To enable the second radio carrier on both units using the CLI, enter the following commands in root view: root> platform if-manager set interface-type radio slot 2 port 2 admin up root>...

  • Page 407: Viewing Link And Protection Status And Activity (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring HSB Radio Protection (CLI) 2. Enter the specific CLI command you want to run in mate/root context. 3. To switch back to the active unit, enter the following command: mate/root> switch-back root> Viewing Link and Protection Status and Activity (CLI) You can view link and protection status and activity any time.

  • Page 408: Disabling Automatic Switchover To The Standby Unit (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring HSB Radio Protection (CLI) Disabling Automatic Switchover to the Standby Unit (CLI) At any point, you can perform lockout, which disables automatic switchover to the standby unit. To disable automatic switchover to the Standby unit, use the following command in root view: root>...

  • Page 409: Configuring Mimo And Space Diversity (Cli)

    In MIMO 4x4, each antenna uses dual polarization. The phase difference caused by the antenna separation enables the receiver to distinguish between the streams. PTP 820C supports both MIMO 2x2 and MIMO 4x4. For a full explanation of MIMO support in PTP 820C, refer to the PTP 820C Technical Description.

  • Page 410: Mimo Mate Management Access (Cli)

    In effect, a 2+2 HSB configuration is a protected 2+0 Space Diversity configuration. Each PTP 820C monitors both of its cores. If the active PTP 820C detects a radio failure in either of its cores, it initiates a switchover to the standby PTP 820C.

  • Page 411: Enabling/Disabling A Mimo Or Space Diversity Group (Cli)

    Setting the Role of a MIMO or Space Diversity Group (CLI) For 4x4 MIMO configurations and 2+2 Space Diversity configurations, you must set the role of the group to Master or Slave. This determines the role of the PTP 820C unit in the overall MIMO or Space Diversity configuration.

  • Page 412: Viewing Mmi And Xpi Levels (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring MIMO and Space Diversity (CLI) Viewing MMI and XPI Levels (CLI) You can view MMI and XPI levels for the individual radio carriers in a MIMO group. Note that the MMI value can also be calculated manually. To calculate it manually, you must measure the following RSL levels per receiver: 1.
  • Page 413 Chapter 14: Configuration Guide (CLI) Configuring MIMO and Space Diversity (CLI) Table 74 MMI and XPI Levels CLI Parameters Parameter Input Type MIMO group type The MIMO or Space Diversity configuration: mimo-2x2 – 2x2 MIMO. mimo-4x4 – 4x4 MIMO. 1-plus-0-sd – 1+0 BBS Space Diversity. 2-plus-0-sd –...

  • Page 414: Deleting A Mimo Or Space Diversity Group (Cli)

    Chapter 14: Configuration Guide (CLI) Configuring MIMO and Space Diversity (CLI) Deleting a MIMO or Space Diversity Group (CLI) You can delete a MIMO or Space Diversity Group. To delete a MIMO or Space Diversity Group: 1. Before deleting a MIMO or Space Diversity group, you must first disable the group using the following command in root view: root >...

  • Page 415: Operating A Ptp 820C In Single Radio Carrier Mode (Cli)

    (CLI) Operating a PTP 820C in Single Radio Carrier Mode (CLI) If you wish to operate a PTP 820C unit in single radio carrier mode, you must perform the following steps: 1. Verify that XPIC is disabled. See Configuring XPIC (CLI) 2.

  • Page 416: Unit Management (Cli)

    Chapter 15: Unit Management (CLI) Operating a PTP 820C in Single Radio Carrier Mode (CLI) Unit Management (CLI) This section includes:  Defining the IP Protocol Version for Initiating Communications (CLI)  Configuring the Remote Unit’s IP Address (CLI) ...

  • Page 417: Defining The Ip Protocol Version For Initiating Communications (Cli)

    Chapter 15: Unit Management (CLI) Defining the IP Protocol Version for Initiating Communications (CLI) Defining the IP Protocol Version for Initiating Communications (CLI) You can specify which IP protocol the unit will use when initiating communications, such as downloading software, sending traps, pinging, or exporting configurations. The options are IPv4 or IPv6.

  • Page 418: Configuring The Remote Unit's Ip Address (Cli)

    Chapter 15: Unit Management (CLI) Configuring the Remote Unit’s IP Address (CLI) Configuring the Remote Unit’s IP Address (CLI) You can configure the remote unit’s IP address, subnet mask and default gateway in IPv4 format and/or in IPv6 format. The remote unit will receive communications whether they were sent to its IPv4 address or its IPv6 address.

  • Page 419: Configuring The Remote Radio's Ip Address In Ipv6 Format (Cli)

    Chapter 15: Unit Management (CLI) Configuring the Remote Unit’s IP Address (CLI) Configuring the Remote Radio's IP Address in IPv6 format (CLI) To set the remote radio’s IP Address, enter the following command in radio view: radio[x/x]>remote-unit set ip-address-ipv6 <ipv6-address> To display the remote radio’s IP Address, enter the following command in radio view: radio[x/x]>remote-unit show ip-address-ipv6 To set the remote radio’s prefix length , enter the following command in radio view:...

  • Page 420: Configuring Snmp (Cli)

    Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) Configuring SNMP (CLI) PTP 820C and PTP 820S support SNMP v1, V2c, and v3. You can set community strings for access to PTP 820 units. PTP 820C and PTP 820S support the following MIBs: ...

  • Page 421: Configuring Snmpv3 (Cli)

    Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) Parameter Input Type Permitted Values Description write- Text String Any valid SNMP write The community string for community community. the SNMP write community. Example The following commands enable SNMP v2 on the unit, and set the read community to “public” and the write community to “private”: root>...

  • Page 422: Displaying The Snmp Settings (Cli)

    Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) Parameter Input Type Permitted Values Description v3-user- Text String Must be at least eight An SNMPv3 user password. password characters. v3-security- Variable authNoPriv Defines the security mode to be mode used for this user. authPriv noAuthNoPriv Variable...

  • Page 423: Configuring Trap Managers (Cli)

    Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) To display all SNMP v3 users and their authentication parameters, enter the following command in root view: root> platform security protocols-control snmp v3-authentication show To display the current MIB version used in the system, enter the following command in root view: root>...
  • Page 424 Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) Parameter Input Type Permitted Values Description manager- Dotted Any valid IPv4 If the IP protocol selected ipv4 decimal address. platform management ip set format. ip-address-family is IPv4, enter the destination IPv4 address. Traps will be sent to this IP address.
  • Page 425 Chapter 15: Unit Management (CLI) Configuring SNMP (CLI) Examples The following commands enable trap manager 2, and assign it IP address 192.168.1.250, port 164, and community “private”, with a heartbeat of 12 minutes. root> platform security protocols-control snmp trap-manager set manager- id 2 manager-admin enable manager-ip 192.168.1.250 manager-port 164 manager-community private manager-description text root>...

  • Page 426: Upgrading The Software (Cli)

    Chapter 15: Unit Management (CLI) Upgrading the Software (CLI) Upgrading the Software (CLI) PTP 820 software and firmware releases are provided in a single bundle that includes software and firmware for all components in the system. Software is first downloaded to the system, then installed.

  • Page 427: Viewing Current Software Versions (Cli)

    Chapter 15: Unit Management (CLI) Upgrading the Software (CLI) Viewing Current Software Versions (CLI) To display all current software versions, enter the following command in root view: root> platform software show versions Configuring a Software Download (CLI) When downloading software, the IDU functions as an FTP or SFTP client. You must install FTP or SFTP server software on the PC or laptop you are using to perform the software upgrade.

  • Page 428: Downloading A Software Package (Cli)

    Chapter 15: Unit Management (CLI) Upgrading the Software (CLI) Parameter Input Type Permitted Values Description directory Text String. The directory path from which you are downloading the files. Enter the path relative to the FTP user's home directory, not the absolute path.

  • Page 429: Installing And Upgrading Software (Cli)

    Chapter 15: Unit Management (CLI) Upgrading the Software (CLI) Installing and Upgrading Software (CLI) To install or upgrade the software, enter the following command in root view after downloading the software bundle: root> platform software install version If you wish to delay the start of installation, enter instead the following command. The time you enter in HH:MM format is the amount of time to delay until the start of the installation process: root>...

  • Page 430: Backing Up And Restoring Configurations (Cli)

    You can import and export PTP 820 configuration files. This enables you to copy the system configuration to multiple PTP 820 units. You can also backup and save configuration files. Configuration files can only be copied between units of the same type, i.e., PTP 820C to PTP 820C and PTP 820S to PTP 820S.

  • Page 431: Setting The Configuration Management Parameters (Cli)

    Chapter 15: Unit Management (CLI) Backing Up and Restoring Configurations (CLI) Setting the Configuration Management Parameters (CLI) When importing and exporting configuration files, the PTP 820 functions as an FTP or SFTP client. You must install FTP or SFTP server software on the PC or laptop you are using to perform the import or export.

  • Page 432: Backing Up And Exporting A Configuration File (Cli)

    Chapter 15: Unit Management (CLI) Backing Up and Restoring Configurations (CLI) Parameter Permitted Input Type Values Description directory Text String. The directory path to which you are exporting or from which you are importing the configuration file. Enter the path relative to the FTP user's home directory, not the absolute path.

  • Page 433: Importing And Restoring A Configuration File (Cli)

    Chapter 15: Unit Management (CLI) Backing Up and Restoring Configurations (CLI) Table 82 Configuration Backup and Restore CLI Parameters Parameter Input Type Permitted Values Description restore- Variable restore-point-1 Identifies the restore point to or point from which to perform the restore-point-2 backup operation.

  • Page 434: Editing Cli Scripts (Cli)

    Chapter 15: Unit Management (CLI) Backing Up and Restoring Configurations (CLI) Examples The following commands import a configuration file from an external PC or laptop to Restore Point 2 on the PTP 820, and restore the file to be the system configuration file for the PTP 820: root>...

  • Page 435: Setting The Unit To The Factory Default Configuration (Cli)

    Chapter 15: Unit Management (CLI) Setting the Unit to the Factory Default Configuration (CLI) Setting the Unit to the Factory Default Configuration (CLI) To restore the unit to its factory default configuration, while retaining the unit’s IP address settings and logs, enter the following commands in root view: root>...

  • Page 436: Performing A Hard (Cold) Reset (Cli)

    Chapter 15: Unit Management (CLI) Performing a Hard (Cold) Reset (CLI) Performing a Hard (Cold) Reset (CLI) To initiate a hard (cold) reset on the unit, enter the following command in root view: root> platform management chassis reset The following prompt appears: You are about to reset the shelf Are you sure? :(yes/no): Enter...

  • Page 437: Configuring Unit Parameters (Cli)

    Chapter 15: Unit Management (CLI) Configuring Unit Parameters (CLI) Configuring Unit Parameters (CLI) You can view and configure system information: To configure a name for the unit, enter the following command in root view: root> platform management system-name set name <name> To define a location for the unit, enter the following command in root view: root>...
  • Page 438 Chapter 15: Unit Management (CLI) Configuring Unit Parameters (CLI) Examples The following commands configure a name, location, contact person, latitude coordinates, longitude coordinates, and units of measurements for the PTP 820: root> platform management system-name set name "My-System-Name" root> platform management system-location set name "My-System-Location" root>...

  • Page 439: Configuring Ntp (Cli)

    Chapter 15: Unit Management (CLI) Displaying Unit Inventory (CLI) Configuring NTP (CLI) PTP 820 supports Network Time Protocol (NTP). NTP distributes Coordinated Universal Time (UTC) throughout the system, using a jitter buffer to neutralize the effects of variable latency. To configure NTP, enter the following command in root view: root>...
  • Page 440 Subtype : 350 part number : 22-0001-0| serial number : F493606212 company name : Cambium Networks product name : AODU DC, All-outdoor, dual radio carriers in one product product description : AODU DC, All-outdoor, dual radio carriers in one product root>...

  • Page 441: Radio Configuration (Cli)

    Configuring MIMO and Space Diversity (CLI)  Operating a PTP 820C in Single Radio Carrier Mode (CLI) Note that to view and configure radio parameters, you must first enter the radio’s view level in the CLI. For details, refer to Entering Radio View (CLI).

  • Page 442: Viewing And Configuring The Remote Radio Parameters (Cli)

    Chapter 16: Radio Configuration (CLI) Viewing and Configuring the Remote Radio Parameters (CLI) Viewing and Configuring the Remote Radio Parameters (CLI) This section includes:  Displaying Communication Status with the Remote Radio (CLI)  Displaying the Remote Radio’s Link ID (CLI) ...

  • Page 443: Displaying The Remote Radio's Rx Level (Cli)

    Chapter 16: Radio Configuration (CLI) Viewing and Configuring the Remote Radio Parameters (CLI) radio[2/1]>remote-unit mute set admin on The following command unmutes the remote radio: radio[2/1]>remote-unit mute set admin off Displaying the Remote Radio’s RX Level (CLI) To display the remote radio’s RX level, enter the following command: radio[x/x]>remote-unit show rx-level Configuring the Remote Radio’s TX Level (CLI) To set the transmit (TX) level of the remote radio, enter the following command:...
  • Page 444 Chapter 16: Radio Configuration (CLI) Viewing and Configuring the Remote Radio Parameters (CLI) Table 88 Remote Radio ATPC CLI Parameters Parameter Input Type Permitted Values Description ref-level Number -70 - -30 The RX reference level for the ATPC mechanism. The following command sets the ATPC RX reference level of the remote radio to -55: radio[2/1]>remote-unit atpc set ref-level -55 phn-3963_004v000 Page 16-251...

  • Page 445: Configuring Atpc (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring ATPC (CLI) Configuring ATPC (CLI) Automatic TX Power Control (ATPC) is a closed-loop mechanism by which each carrier changes the transmitted signal power according to the indication received across the link, in order to achieve a desired RSL on the other side of the link.

  • Page 446: Configuring Header De-Duplication (Cli)

    <mode> Note In this release, if two radio carriers in a PTP 820C unit are activated, the Header De- Duplication configuration for radio carrier 1 are applied to both carriers. You must enter radio view for radio interface 1.

  • Page 447: Displaying Header De-Duplication Information (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring Header De-Duplication (CLI) Parameter Input Type Permitted Values Description Disabled Disabled - Header De-Duplication mode Variable is disabled. Layer2 Layer2 - Header De-Duplication MPLS operates on the Ethernet level. Layer3 MPLS - Header De-Duplication Layer4 operates on the Ethernet and Tunnel...
  • Page 448 Chapter 16: Radio Configuration (CLI) Configuring Header De-Duplication (CLI)  TX frame in count - Frames on the TX side before Header De-Duplication.  TX frame out compressed count - Frames on the TX side that were compressed by Header De- Duplication.

  • Page 449: Configuring Frame Cut-Through (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring Frame Cut-Through (CLI) Configuring Frame Cut-Through (CLI) Using the Frame Cut-Through feature, frames assigned to queues with 4th priority pre-empt frames already in transmission over the radio from other queues. Transmission of the pre-empted frames is resumed after the cut -through with no capacity loss or re-transmission required.

  • Page 450: Configuring Aes-256 Payload Encryption (Cli)

    AES activation key. Until the unit is reset, an alarm will be present if you enable AES. This is not the case for other activation keys. PTP 820C and PTP 820S support AES-256 payload encryption. The purpose of payload encryption is to secure the radio link and provide protection against eavesdropping and/or personification (“man-in-the-middle”) attacks.
  • Page 451 Chapter 16: Radio Configuration (CLI) Configuring AES-256 Payload Encryption (CLI) To configure AES on a radio carrier, you must first enter traffic encryption view for the specific radio. To enter traffic encryption view, enter the following command in root view: root>...
  • Page 452 Warning Executing this command formats the unit’s disk, and renders the unit non-operational. If it is necessary to use this command, contact Cambium Networks Technical Support for instructions how to re-configure the unit. The session key is automatically regenerated at defined intervals. To set the session key regeneration interval, enter the following command in Traffic Encryption view: Traffic Encryption [x/x]>...

  • Page 453: Configuring And Viewing Radio Pms And Statistics (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) This section includes:  Displaying General Modem Status and Defective Block PMs (CLI)  Displaying Excessive BER (Aggregate) PMs (CLI) ...

  • Page 454: Displaying Excessive Ber (Aggregate) Pms (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Displaying Excessive BER (Aggregate) PMs (CLI) You can display modem BER (Bit Error Rate) PMs in either 15-minute or daily intervals. To display modem BER PMs in 15-minute intervals, enter the following command: radio [x/x]>framer pm-aggregate show interval 15min The following is a partial sample output of the framer pm-aggregate show interval...

  • Page 455: Displaying Ber Level And Configuring Ber Parameters (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 91 Aggregate PMs (CLI) Parameter Description Interval The number of the interval: 1-30 for daily PM reports, and 1-96 for 15 minute PM reports. Integrity Indicates whether the values received at the time and date of the measured interval are reliable.

  • Page 456: Configuring Rsl Thresholds (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 92 Excessive BER CLI Parameters Parameter Input Type Permitted Values Description admin Variable enable Enables or disables propagation of excessive BER as a fault. disable The following command enables excessive-ber root>...

  • Page 457: Displaying Rsl And Tsl Levels (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 94 TSL Thresholds CLI Parameters Parameter Input Type Permitted Values Description threshold1 Number -75 - -15 The first RSL threshold (dBm). threshold Number -10 - 34 The TSL threshold (dBm).

  • Page 458: Configuring The Signal Level Threshold (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 95 RSL and TSL PMs (CLI) Parameter Description Interval The number of the interval: 1-30 for daily PM reports, and 1-96 for 15 minute PM reports. Integrity Indicates whether the values received at the time and date of the measured interval are reliable.

  • Page 459: Configuring The Mse Thresholds And Displaying The Mse Pms (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 96 Signal Level Threshold CLI Parameters Parameter Input Type Permitted Values Description threshold Variable 1e -6 The BER level above which a Signal Degrade alarm is issued for errors 1e -7 detected over the radio link.
  • Page 460 Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) radio [2/1]>modem pm-mse show interval 15min Modem MSE PM Table: =================== Interval Integrity Min MSE (dB) Max MSE (dB) Exceed threshold seconds =============================================================== 0.00 0.00 0.00 0.00 0.00 0.00 0.00...

  • Page 461: Configuring The Xpi Thresholds And Displaying The Xpi Pms (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Table 98 MSE PMs (CLI) Parameter Description Interval The number of the interval: 1-30 for daily PM reports, and 1-96 for 15 minute PM reports. Integrity Indicates whether the values received at the time and date of the measured interval are reliable.
  • Page 462 Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) The following is a partial sample output of the command: modem pm-xpi show interval 15min radio [2/1]>modem pm-xpi show interval 15min Modem XPI PM Table: =================== Interval Integrity Min XPI (dB) Max XPI (dB)
  • Page 463 Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) radio [2/1]>modem pm-xpi show interval 24hr Modem XPI PM Table: =================== Interval Integrity Min XPI (dB) Max XPI (dB) XPI below threshold seconds =============================================================== 55.00 0.00 55.00 0.00 55.00 0.00...

  • Page 464: Displaying Acm Pms (Cli)

    Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) The following command sets the XPI threshold for radio carrier 2 to 15: radio[2/1]>modem set threshold-xpi-below threshold 15 Displaying ACM PMs (CLI) To display ACM PMs in 15-minute intervals, enter the following command: radio [x/x]>mrmc pm-acm show interval 15min The following is a partial sample output of the command:...
  • Page 465 Chapter 16: Radio Configuration (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Interval Integrity Min profile Max profile Min bitrate Max bitrate =========================================================================== 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 43389 radio [2/1]>...

  • Page 466: Ethernet Services And Interfaces (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring and Viewing Radio PMs and Statistics (CLI) Ethernet Services and Interfaces (CLI) This section includes:  Configuring Ethernet Services (CLI)  Setting the MRU Size and the S-VLAN Ethertype (CLI)  Configuring Ethernet Interfaces (CLI) ...

  • Page 467: Configuring Ethernet Services (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Configuring Ethernet Services (CLI) This section includes:  Ethernet Services Overview (CLI)  General Guidelines for Provisioning Ethernet Services (CLI)  Defining Services (CLI)  Configuring Service Points (CLI) ...

  • Page 468: Defining Services (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI)  Give the same EVC ID (service name) to all service fragments along the path of the service.  Do not reuse the same EVC ID within the same region. It is recommended to follow these guidelines for creating service points: ...
  • Page 469 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Parameter Input Type Permitted Values Description evc- Text String Up to 64 A text description of the service. This description characters. parameter does not affect the network element’s behavior, but is used by the NMS for topology management.
  • Page 470 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Showing Service Details (CLI) To display the attributes of a service, go to service view for the service and enter the following command: service[SID]>service info show For example: service[1]>service info show service info: service id: 1 service type: p2p...
  • Page 471 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) For example: Configuring a Service’s Operational State (CLI) To change the operational state of a service, go to service view for the service and enter the following command: service[SID]>service admin set <service admin mode> To display a service’s admin mode, go to service view for the service and enter the following command: Service[SID]>...
  • Page 472 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) If the CoS mode is set to , you must define the Default CoS. Use the following default-cos command to define the Default CoS: service[SID]>service default-cos set cos <cos> Table 106 Ethernet Service CoS Mode CLI Parameters Parameter Input Type...
  • Page 473 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) To display a service’s EVC description, go to service view for the service and enter the following command: service[SID]>service description show Table 107 Ethernet Service EVC CLI Parameters Parameter Input Type Permitted Values Description...

  • Page 474: Configuring Service Points (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Configuring Service Points (CLI) This section includes:  Service Points Overview (CLI)  Service Point Classification (CLI)  Adding a Service Point (CLI)  Configuring Service Point Ingress Attributes (CLI) ...
  • Page 475 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Table 110 Service Point Types per Interface Pipe Only one MNG SP is allowed per interface. PIPE Only one Pipe SP is allowed per interface. Service Point Classification (CLI) This section includes: ...
  • Page 476 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) SNP Classification (CLI) SNPs can be used with the following Attached Interface Types:  Dot1q – A single C-VLAN is classified to the service point.  S-Tag – A single S-VLAN is classified to the service point. Pipe Service Point Classification (CLI) Pipe service points can be used with the following Attached Interface Types: ...
  • Page 477 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) SP Type Attached 802.1q Bundle Bundle All to One Q in 802.1q S-Tag Type Interface Type Q in Q S-Tag Table 112 Legal Service Point – Interface Type Combinations per Interface – Pipe and MNG SP Type Pipe Attached...
  • Page 478 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Adding a Service Point (CLI) The command syntax for adding a service point depends on the interface type of the service point. The interface type determines which frames enter the service via this service point. To add a service point with an All-to-One interface type, go to service view for the service and enter the following command: service[SID]>sp add sp-type <sp-type>...
  • Page 479 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Parameter Input Type Permitted Values Description sp-type Variable SAP - Service Access Point SNP - Service Network Point pipe PIPE - Pipe service point MNG - Management service point int-type Variable all-to-one...
  • Page 480 The group must be defined before you add the service point. lag2 Note: Multi-Carrier ABC and HSB protection lag3 are only relevant for PTP 820C units. lag4 mc-abc1 mc-abc2 mc-abc3 mc-abc4 slot...
  • Page 481 The following command adds an SAP service point with Service Point ID 10 to Service 37, with interface type bundle-s-tag. This service point is located on radio carrier 2 in a PTP 820C unit. S- VLAN 100 is classified to the service point.
  • Page 482 The following command adds an SAP service point with Service Point ID 10 to Service 37, with interface type qinq. This service point is located on radio carrier 2 in a PTP 820C unit. S-VLAN 100 and C-VLAN 200 are classified to the service point.
  • Page 483 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Configuring Service Point Ingress Attributes (CLI) A service point’s ingress attributes are attributes that operate upon frames ingressing via the service point. This includes how the service point handles the CoS of ingress frames and how the service point forwards frames to their next destination within the service.
  • Page 484 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) To determine whether the service point modifies CoS decisions made at the interface level, go to service view for the service and enter the following command: service[SID]> sp cos-mode set spid <sp-id> mode <cos mode> If you set cos-mode to , you must then configure a default CoS.
  • Page 485 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Enabling and Disabling Flooding (CLI) The ingress service point for a frame can forward the frame within the service by means of flooding or dynamic MAC address learning in the service. To enable or disable forwarding by means of flooding for a service point, go to service view for the service and enter the following command: service[SID]>sp flooding set spid <sp-id>...

  • Page 486: Configuring C-Vlan Cos Preservation (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) This section includes:  Configuring C-VLAN CoS Preservation (CLI)  Configuring C-VLAN Preservation (CLI)  Configuring S-VLAN CoS Preservation (CLI) Configuring C-VLAN CoS Preservation (CLI) To configure CoS preservation for C-VLAN-tagged frames, go to service view for the service and enter the following command: service[SID]>sp cvlan-cos-preservation-mode set spid <sp-id>...
  • Page 487 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Configuring C-VLAN Preservation (CLI) To configure VLAN preservation for C-VLAN-tagged frames, go to service view for the service and enter the following command: service[SID]>sp cvlan-preservation-mode set spid <sp-id> mode <c- vlan preservation mode>...
  • Page 488 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Table 119 S-VLAN CoS Preservation CLI Parameters Parameter Input Type Permitted Values Description sp-id Number 1-32 for P2P and The Service Point ID. MP services. 1-30 for MNG services. s-vlan cos Variable enable...
  • Page 489 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Table 120 Service Bundle CLI Parameters Parameter Input Type Permitted Values Description sp-id Number 1-32 for P2P and The Service Point ID. MP services. 1-30 for MNG services. service- Number 1 –...
  • Page 490 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Table 121 VLAN Bundle to Service Point CLI Parameters Parameter Input Type Permitted Values Description sp-id Number 1-32 for P2P and MP The Service Point ID. services. 1-30 for MNG services. vlan Number 1-4094 (except 4092, which...
  • Page 491 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Deleting a Service Point (CLI) You can only delete a service point if no VLAN bundles are attached to the service point. This is only relevant if the interface type of the service point is bundle-c-tag or bundle-s-tag. For more information, refer to Attaching a VLAN Bundle to a Service Point (CLI).

  • Page 492: Defining The Mac Address Forwarding Table For A Service (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Table 123 Delete Service Point Attributes CLI Parameters Parameter Input Type Permitted Values Description sp-id Number 1-32 for P2P and MP The Service Point ID. services. 1-30 for MNG services. Example The following command deletes Service Point 10 from Service 37: service[37]>sp delete spid 10...
  • Page 493 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Setting the Maximum Size of the MAC Address Forwarding Table (CLI) To limit the size of the MAC address forwarding table for a specific service, go to service view for the service and enter the following command: service[SID]>service mac-limit-value set <mac limit>...
  • Page 494 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Adding a Static MAC Address to the Forwarding Table (CLI) You can add static entries to the MAC forwarding table. The global aging timer does not apply to static entries, and they are not counted with respect to the maximum size of the MAC address forwarding table.
  • Page 495 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) To display the MAC address forwarding table for an interface, go to interface view for the interface and enter the following command: eth type xxx[x/x]>mac-learning-table show To display the MAC address forwarding table for the entire unit, enter the following command: root>...
  • Page 496 Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Services (CLI) Parameter Input Type Permitted Values Description learning Variable Enable Select enable or disable to enable or disable MAC address learning for disable frames that ingress via the service point. When enabled, the service point learns the source MAC addresses of incoming frames and adds them to...

  • Page 497: Setting The Mru Size And The S-Vlan Ethertype (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Setting the MRU Size and the S-VLAN Ethertype (CLI) Setting the MRU Size and the S-VLAN Ethertype (CLI) The following parameters are configured globally for the PTP 820 switch:  S- VLAN Ethertype – Defines the ethertype recognized by the system as the S-VLAN ethertype. ...

  • Page 498: Configuring The C-Vlan Ethertype (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) root> ethernet generalcfg ethertype set svlan-value 0x88a8 Configuring the C-VLAN Ethertype (CLI) The system C-VLAN Ethertype is set by the system as 0x8100. To display the system C-VLAN ethertype, enter the following command in root view: root>...

  • Page 499: Entering Interface View (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) The basic interface characteristics, such as media type, port speed, duplex, and auto-negotiation, are configured on the physical interface level. Ethernet services, QoS, and OAM characteristics are configured on the logical interface level. Note You cannot change the configuration of the Management interface.
  • Page 500 1 port 3 The following prompt appears: eth type eth [1/3]> The following command enters interface view for radio interface 2 in a PTP 820C unit: root> ethernet interfaces radio slot 2 port 2 The following prompt appears: radio [2/2]>...

  • Page 501: Displaying The Operational State Of The Interfaces In The Unit (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) The following prompt appears: radio [16/1]> The following command enters interface view for LAG 1: root ethernet > interfaces group lag1 The following prompt appears: eth type group [64/1]> Note: For simplicity, the examples in the following sections show the prompt for an Ethernet interface.

  • Page 502: Configuring An Interface's Media Type (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) Configuring an Interface’s Media Type (CLI) The Media Type attribute defines the physical interface Layer 1 media type. Permitted values are RJ-45 and SFP. To configure an Ethernet interface’s Media Type, go to interface view for the interface and enter the following command: eth type eth [x/x]>media-type state set <media type>...

  • Page 503: Configuring An Interface's Auto Negotiation State (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) Examples The following command sets GbE 1 to 100 Mbps, full duplex: eth type eth [1/1]>speed-and-duplex state set '100fd' Note: Before performing this command, you must verify that the media-type attribute is set to rj45.

  • Page 504: Configuring An Interface's Preamble (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Ethernet Interfaces (CLI) Example The following command sets the ifg for GbE 1 to 12: eth type eth [1/1]>ifg set 12 The following displays the currently configured ifg for GbE 1: eth type eth [1/1]>ifg get Configuring an Interface’s Preamble (CLI) Although you can modify an Ethernet interface’s preamble, it is strongly recommended not to modify the default value of 8 bytes without a thorough understanding of how the modification will...

  • Page 505: Displaying Interface Statistics (Rmon) (Cli)

    1 port 1 eth type eth [1/1]>rmon statistics show clear-on-read yes layer-1 yes The following commands enter interface view for radio carrier 1 in a PTP 820C or PTP 820S unit, and display statistics for the interface, without clearing the statistics.

  • Page 506: Configuring Automatic State Propagation (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Automatic State Propagation (CLI) Configuring Automatic State Propagation (CLI) Automatic state propagation enables propagation of radio failures back to the Ethernet port. You can also configure Automatic State Propagation to close the Ethernet port based on a radio failure at the remote carrier.

  • Page 507: Enabling Automatic State Propagation (Cli)

    1 multi-radio-group 1 The following commands configure and enable automatic state propagation to propagate faults from 1+1 HSB-SD protection group 1 to Ethernet port 1 on a PTP 820C unit. root> auto-state-propagation add eth-port-to-protection-group eth-slot 1 eth-port 1 protection-group 1...

  • Page 508: Deleting Automatic State Propagation (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Automatic State Propagation (CLI) root> auto-state-propagation configure eth-port eth-slot <eth-slot> eth- port <eth-port> asp-admin <asp-admin> remote-fault-trigger-admin <remote- fault-trigger-admin>csf-mode-admin <csf-mode-admin> Table 139 Enable Automatic State Propagation CLI Parameters Parameter Input Type Permitted Values Description eth-slot Number...

  • Page 509: Displaying Automatic State Propagation Parameters (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Configuring Automatic State Propagation (CLI) Table 140 Delete Automatic State Propagation CLI Parameters Parameter Input Type Permitted Values Description eth-slot Number Always enter 1. eth-port Number The interface to which you wanted to propagate faults from the selected radio or group.

  • Page 510: Viewing Ethernet Pms And Statistics (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) Viewing Ethernet PMs and Statistics (CLI) PTP 820 stores and displays statistics in accordance with RMON and RMON2 standards. You can display various peak TX and RX rates (in seconds) and average TX and RX rates (in seconds), both in bytes and in packets, for each measured time interval.

  • Page 511: Configuring Ethernet Port Pms And Pm Thresholds (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) Configuring Ethernet Port PMs and PM Thresholds (CLI) To enable the gathering of PMs for an Ethernet interface, go to interface view for the interface and enter the following command: eth type eth [x/x]>...
  • Page 512 Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) To display RX packet PMs in 15-minute intervals, go to interface view for the interface and enter the following command: eth type eth [x/x]> pm show rx-packets interval 15min To display RX packet PMs in 24-hour intervals, go to interface view for the interface and enter the following command: eth type eth [x/x]>...
  • Page 513 Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) To display TX broadcast packet PMs in 24-hour intervals, go to interface view for the interface and enter the following command: eth type eth [x/x]> pm show tx-bcast-packets interval 24hr To display TX multicast packet PMs in 15-minute intervals, go to interface view for the interface and enter the following command: eth type eth [x/x]>...
  • Page 514 Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) Parameter Definition Peak RX Multicast The peak rate of RX multicast packets per second for the Packets measured time interval. Average RX Multicast The average rate of RX multicast packets per second for the Packets measured time interval.

  • Page 515: Clearing Ethernet Port Pms (Cli)

    Chapter 17: Ethernet Services and Interfaces (CLI) Viewing Ethernet PMs and Statistics (CLI) Clearing Ethernet Port PMs (CLI) To clear all PMs for an Ethernet interface, go to interface view for the interface and enter the following command: eth type eth [x/x]> pm clear-all phn-3963_004v000 Page 17-322...

  • Page 516: Quality Of Service (Qos) (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Viewing Ethernet PMs and Statistics (CLI) Quality of Service (QoS) (CLI) This section includes:  Configuring Classification (CLI)  Configuring Policers (Rate Metering) (CLI)  Configuring Marking (CLI)  Configuring WRED (CLI)  Configuring Shapers (CLI) ...

  • Page 517: Configuring Classification (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Configuring Classification (CLI) This section includes:  Classification Overview (CLI)  Configuring Ingress Path Classification on a Logical Interface (CLI)  Configuring VLAN Classification and Override (CLI)  Configuring 802.1p Classification (CLI) ...

  • Page 518: Configuring Vlan Classification And Override (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) PTP 820 performs the classification on each frame ingressing the system via the logical interface. Classification is performed step by step from the highest priority to the lowest priority classification method. Once a match is found, the classifier determines the CoS and Color decision for the frame for the logical interface-level.
  • Page 519 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Parameter Input Type Permitted Values Description inner-vlan-id Number 1 – 4094 (except Optional. Include this parameter 4092, which is when you want to map double- reserved for the tagged frames to specific CoS and default Color values.

  • Page 520: Configuring 802.1P Classification (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Configuring 802.1p Classification (CLI) When 802.1p classification is set to Trust mode, the interface performs QoS and Color classification according to user-configurable tables for 802.1q UP bit (C-VLAN frames) or 802.1AD UP bit (S-VLAN frames) to CoS and Color classification.
  • Page 521 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Examples The following command enables 802.1p trust mode for GbE 1: eth type eth [1/1]>classification set 802.1p trust The following command disables 802.1p trust mode for GbE 1: eth type eth [1/1]>classification set 802.1p un-trust Modifying the C-VLAN 802.1 UP and CFI Bit Classification Table (CLI) The following table shows the default values for the C-VLAN 802.1 UP and CFI bit classification table.
  • Page 522 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) root> ethernet qos 802.1q-up-bits-mapping-tbl show Table 148 C-VLAN 802.1 UP and CFI Bit Classification Table CLI Parameters Parameter Input Type Permitted Values Description 802.1p Number 0 – 7 The User Priority (UP) bit to be mapped. Number 0 –...

  • Page 523: Configuring Dscp Classification (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) 802.1 UP Color (configurable) (configurable) Yellow Green Yellow Green Yellow To modify the S-VLAN 802.1 UP and DEI bit classification table, enter the following command: root> ethernet qos 802.1ad-up-bits-mapping-tbl set 802.1p <802.1p> dei <dei>...
  • Page 524 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Configuring Trust Mode for DSCP Classification (CLI) To define the trust mode for DSCP classification, go to interface view for the interface and enter the following command: eth type eth [x/x]>classification set ip-dscp <ip-dscp> To display the trust mode for DSCP classification, go to interface view for the interface and enter the following command: eth type eth [x/x]>classification show 802.1p state...
  • Page 525 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Table 151 Trust Mode for DSCP CLI Parameters Parameter Input Type Permitted Values Description ip-dscp Variable trust Select the interface's trust mode for DSCP classification: un-trust – The interface performs QoS and trust color classification according to a user- configurable table for DSCP to CoS and...
  • Page 526 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) DSCP DSCP (bin) Description (Configurable) Color (Configurable) 011110 AF33 Yellow 100010 AF41 Green 100100 AF42 Yellow 100110 AF43 Yellow 101110 Green 001000 Green 010000 Green 011000 Green 100000 Green 101000 Green 110000 Green...

  • Page 527: Configuring Mpls Classification (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Table 153 Modify DSCP Classification Table CLI Parameters Parameter Input Type Permitted Values Description dscp Number Valid DSCP The DSCP value to be mapped. values. Refer to the DSCP column in the table above.
  • Page 528 Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Table 154 Trust Mode for MPLS CLI Parameters Parameter Input Type Permitted Values Description mpls Variable Trust Select the interface's trust mode for MPLS bits: un-trust – The interface performs QoS trust and color classification according to a user-configurable table for MPLS...

  • Page 529: Configuring A Default Cos (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Table 156 MPLS EXP Bit Classification Table Modification CLI Parameters Parameter Input Type Permitted Values Description mpls-exp Number 0 – 7 The MPLS EXP bit to be mapped. Number 0 – 7 The CoS assigned to frames with the designated MPLS EXP bit value.

  • Page 530: Configuring Ingress Path Classification On A Service Point (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Classification (CLI) Configuring Ingress Path Classification on a Service Point (CLI) For instruction on configuring ingress path classification on a service point, see CoS Preservation and Modification on a Service Point (CLI). Configuring Ingress Path Classification on a Service (CLI) For instruction on configuring ingress path classification on a service, see Configuring a Service’s...

  • Page 531: Configuring Policers (Rate Metering) (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Configuring Policers (Rate Metering) (CLI) This section includes:  Overview of Rate Metering (Policing) (CLI)  Configuring Rate Meter (Policer) Profiles (CLI)  Displaying Rate Meter Profiles (CLI) ...
  • Page 532 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Table 158 Rate Meter Profile CLI Parameters Parameter Input Type Permitted Values Description profile-id Number 1 – 250 A unique ID for the rate meter (policer) profile. Number 0, or 64,000 - The Committed Information Rate 1,000,000,000...

  • Page 533: Displaying Rate Meter Profiles (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Examples The following command creates a rate meter (policer) profile with Profile ID 50, named “64k.” root> ethernet qos rate-meter add profile-id 50 cir 64000 cbs 5 eir 64000 ebs 5 color-mode color-blind coupling-flag disable rate-meter-profile- name 64k This profile includes the following parameters:...

  • Page 534: Attaching A Rate Meter (Policer) To An Interface (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) To delete a rate meter (policer) profile, use the following command: root> ethernet qos rate-meter delete profile-id <profile-id> Example The following command deletes Rate Meter Profile 50: root> ethernet qos rate-meter delete profile-id 50 Attaching a Rate Meter (Policer) to an Interface (CLI) On the logical interface level, you can assign rate meter (policer) profiles as follows: ...
  • Page 535 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Table 159 Assigning Rate Meter for Unicast Traffic CLI Parameters Parameter Input Type Permitted Values Description admin-state Variable enable Enables or disables rate metering on unicast traffic flows from the logical disable interface.
  • Page 536 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Table 160 Assigning Rate Meter for Multicast Traffic CLI Parameters Parameter Input Type Permitted Values Description admin-state Variable enable Enables or disables rate metering on multicast traffic flows from the disable logical interface.
  • Page 537 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Table 161 Assigning Rate Meter for Broadcast Traffic CLI Parameters Parameter Input Type Permitted Values Description admin-state Variable enable Enables or disables rate metering on broadcast traffic flows from the disable logical interface.
  • Page 538 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Table 162 Assigning Rate Meter per Ethertype CLI Parameters Parameter Input Type Permitted Values Description ethertype# Variable ethertype1 Identifies which of three possible policer-per-Ethertype combinations ethertype2 you are defining. ethertype3 I ethertype- Hexadecima...

  • Page 539: Configuring The Line Compensation Value For A Rate Meter (Policer) (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Configuring the Line Compensation Value for a Rate Meter (Policer) (CLI) A rate meter can measure CIR and EIR at Layer 1 or Layer 2 rates. Layer 1 capacity is equal to Layer 2 capacity plus 20 additional bytes for each frame due to the preamble and Inter Frame Gap (IFG).
  • Page 540 Chapter 18: Quality of Service (QoS) (CLI) Configuring Policers (Rate Metering) (CLI) Note Rate meter (policer) counters are displayed in granularity of 64 bits. The following commands display rate meter counters for the available frame types and Ethertypes: eth type eth [x/x]>rate-meter unicast show statistics clear-on-read <clear-on-read>...

  • Page 541: Configuring Marking (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Marking (CLI) Configuring Marking (CLI) This section includes:  Marking Overview (CLI)  Configuring Marking Mode on a Service Point (CLI)  Marking Table for C-VLAN UP Bits (CLI)  Marking Table for S-VLAN UP Bits (CLI) Marking Overview (CLI) When enabled, PTP 820’s marking mechanism modifies each frame’s 802.1p UP bit and CFI/DEI bits according to the classifier decision.
  • Page 542 Chapter 18: Quality of Service (QoS) (CLI) Configuring Marking (CLI) Table 165 Marking Mode on Service Point CLI Parameters Parameter Input Type Permitted Values Description sp-id Number 1-32 for P2P and The Service Point ID. MP services. 1-30 for MNG services.

  • Page 543: Marking Table For C-Vlan Up Bits (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Marking (CLI) Marking Table for C-VLAN UP Bits (CLI) When marking is performed, the following table is used by the marker to decide which CoS and Color to use as the egress CoS and Color bits for C-VLAN-tagged frames. Table 166 Marking Table for C-VLAN UP Bits Color 802.1q (Configurable)

  • Page 544: Marking Table For S-Vlan Up Bits (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Marking (CLI) Table 167 802.1q CoS and Color to UP and CFI Bit Mapping Table CLI Parameters Parameter Input Type Permitted Values Description Number 0 – 7 The CoS value to be mapped. color Variable green...
  • Page 545 Chapter 18: Quality of Service (QoS) (CLI) Configuring Marking (CLI) 802.1ad UP Color (Configurable) DEI Color (Configurable) Green Yellow Green Yellow To modify the 802.1ad CoS and Color to UP and DEI bit mapping table, enter the following command in root view: root>...

  • Page 546: Configuring Wred (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring WRED (CLI) Configuring WRED (CLI) This section includes:  WRED Overview (CLI)  Configuring WRED Profiles (CLI)  Assigning a WRED Profile to a Queue (CLI) WRED Overview (CLI) Weighted Random Early Detection (WRED) enables differentiation between higher and lower priority traffic based on CoS.
  • Page 547 Chapter 18: Quality of Service (QoS) (CLI) Configuring WRED (CLI) Note Each queue always has a WRED profile assigned to it. By default, WRED Profile 31 is assigned to every queue until a different profile is assigned. Table 170 WRED Profile CLI Parameters Parameter Input Type Permitted Values...

  • Page 548: Assigning A Wred Profile To A Queue (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring WRED (CLI) The new profile has the following parameters:  profile-id – 2  green-min-threshold – 8000 Kbytes  green-max-threshold – 8000 Kbytes  green-max-drop – 100%  yellow-min-threshold – 8000 Kbytes ...
  • Page 549 Chapter 18: Quality of Service (QoS) (CLI) Configuring WRED (CLI) Parameter Input Type Permitted Values Description Number 0 – 7 Assigns the WRED profile to a queue in the designated service bundle. profile-id Number 1 – 32 A unique ID that identifies the profile.

  • Page 550: Configuring Shapers (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) Configuring Shapers (CLI) This section includes:  Overview of Egress Shaping (CLI)  Configuring Shapers (CLI)  Configuring Service Bundle Shapers (CLI)  Configuring Egress Line Compensation for Shaping (CLI) Overview of Egress Shaping (CLI) Egress shaping determines the traffic profile for each queue.
  • Page 551 Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) root> ethernet qos queue-shaper-profile-tbl add profile-id <profile-id> cir <cir> shaper-profile-name <shaper-profile-name> To edit the parameters of an existing queue shaper profile, enter the following command in root view: root> ethernet qos queue-shaper-profile-tbl edit profile-id <profile-id> cir <cir>...
  • Page 552 Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) To attach a queue shaper profile to a queue, go to interface view for the interface and enter the following command: eth type eth [x/x]> queue-shaper add capability service-bundle-id <service-bundle-id> cos <cos> admin-state <admin-state> profile-id <profile-id>...

  • Page 553: Configuring Service Bundle Shapers (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) Examples The following command adds Queue Shaper Profile 5 to queues with CoS 0, on Service Bundle 1, on GbE 1, and enables shaping on these queues. eth type eth [1/1]> queue-shaper add capability service-bundle-id 1 cos 0 admin-state enable profile-id 5 The following command changes the Queue Shaper Profile assigned in the previous command to Queue Shaper Profile 2:...
  • Page 554 Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) root> ethernet qos service-bundle-shaper-profile-tbl edit profile-id <profile-id> cir <cir> pir <pir> shaper-profile-name <shaper-profile- name> To display the parameters of a service bundle shaper profile, enter the following command in root view: root>...
  • Page 555 Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) To attach a service bundle shaper profile to a service bundle, go to interface view for the service bundle and enter the following command: eth type eth [x/x]> service-bundle-shaper add capability service-bundle- id <service-bundle-id>...

  • Page 556: Configuring Egress Line Compensation For Shaping (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Shapers (CLI) Configuring Egress Line Compensation for Shaping (CLI) You can configure a line compensation value for all the shapers under a specific logical interface. This value is used to compensate for Layer 1 non-effective traffic bytes on egress. To set the egress line compensation value, go to interface view for the interface and enter the following command: eth type eth [x/x]>shaping-compensation-value set <value>...

  • Page 557: Configuring Scheduling (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Configuring Scheduling (CLI) This section includes:  Overview of Egress Scheduling (CLI)  Configuring Queue Priority (CLI)  Configuring Interface Priority Profiles (CLI)  Attaching a Priority Profile to an Interface (CLI) ...

  • Page 558: Configuring Interface Priority Profiles (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Table 177 Interface Priority Profile Example Profile ID (1-9) Green Priority Yellow Priority (user defined) (read only) Description Best Effort Data Service 4 Data Service 3 Data Service 2 Data Service 1 Real Time 2 (Video with large buffer) Real Time 1 (Video with small buffer)
  • Page 559 Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) root> ethernet qos port-priority-profile-tbl edit profile-id <profile-id> cos0-priority <cos0-priority> description <description> cos1-priority <cos1-priority> description <description> cos2-priority <cos2-priority> description <description> cos3-priority <cos3-priority> description <description> cos4-priority <cos4-priority> description <description> cos5-priority <cos5-priority> description <description> cos6-priority <cos6-priority>...
  • Page 560 Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Parameter Permitted Input Type Values Description cos4-priority Number 1 – 4 The Green priority for the CoS 4 queue, from 4 (highest) to 1 (lowest). This priority is applied to Green frames with CoS 4 egressing the service bundle to which the profile is assigned.

  • Page 561: Attaching A Priority Profile To An Interface (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Green Priority Yellow Priority Description (user defined) (read only) c4_p2 c5_p3 c6_p4 c7_p4 The following command edits the profile you created in the previous command so that CoS 6 queues have a Green priority of 3 instead of 4, and a description of “c6_p3”. root>...

  • Page 562: Configuring Weighted Fair Queuing (Wfq) (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) best effort data service data service data service data service real time real time management eth type eth [1/1]> Configuring Weighted Fair Queuing (WFQ) (CLI) This section includes:  Overview of WFQ (CLI) ...
  • Page 563 Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Profile ID (1-7) Queue Weight (Green) Queue Weight (Yellow – not visible to users, and cannot be edited) You can attach one of the configured interface WFQ profiles to each interface. By default, the interface is assigned Profile ID 1, the pre-defined system profile.
  • Page 564 Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Parameter Permitted Input Type Values Description cos5- weight Number 1 - 20 The relative weight for the CoS 5 queue. cos6- weight Number 1 - 20 The relative weight for the CoS 6 queue. cos7- weight Number 1 - 20...
  • Page 565 Chapter 18: Quality of Service (QoS) (CLI) Configuring Scheduling (CLI) Attaching a WFQ Profile to an Interface (CLI) To attach a WFQ profile to an interface, go to interface view for the interface and enter the following command: eth type eth [x/x]> port-wfq set profile-id <profile-id> To display which WFQ profile is attached to an interface, go to interface view for the interface and enter the following command: eth type eth [x/x]>...

  • Page 566: Displaying Egress Statistics (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Displaying Egress Statistics (CLI) Displaying Egress Statistics (CLI) PTP 820 collects egress PMs at the queue level and the service bundle level. Displaying Queue-Level PMs (CLI) PTP 820 supports the following counters per queue at the queue level: ...

  • Page 567: Displaying Service Bundle-Level Pms (Cli)

    Chapter 18: Quality of Service (QoS) (CLI) Displaying Egress Statistics (CLI) Parameter Permitted Input Type Values Description clear-on- Boolean If you enter yes, the statistics are cleared read once you display them. layer-1 Boolean – Statistics are represented as Layer 1 statistics, including preamble and IFG.
  • Page 568 Chapter 18: Quality of Service (QoS) (CLI) Displaying Egress Statistics (CLI) Table 186 Egress Service Bundle Level PMs CLI Parameters Parameter Permitted Input Type Values Description service- Number 1 – 63 The service bundle for which you want to bundle-id display PMs.

  • Page 569: Ethernet Protocols (Cli)

    Chapter 19: Ethernet Protocols (CLI) Displaying Egress Statistics (CLI) Ethernet Protocols (CLI) This section includes:  Configuring Adaptive Bandwidth Notification (ABN) (CLI)  Configuring LLDP (CLI) Related Topics:  Configuring Service OAM (SOAM) Fault Management (FM) phn-3963_004v000 Page 19-376...

  • Page 570: Configuring Adaptive Bandwidth Notification (Abn) (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring Adaptive Bandwidth Notification (ABN) (CLI) Configuring Adaptive Bandwidth Notification (ABN) (CLI) This section includes:  Adaptive Bandwidth Notification Overview (CLI)  Configuring an ABN Entity (CLI) Adaptive Bandwidth Notification Overview (CLI) Adaptive Bandwidth Notification (ABN), also known as Ethernet Operation and Maintenance (EOAM), enables third party applications to learn about bandwidth changes in a radio link when ACM is active.
  • Page 571 Chapter 19: Ethernet Protocols (CLI) Configuring Adaptive Bandwidth Notification (ABN) (CLI) root> ethernet abn abn-entity-create abn-name <abn-name> monitored-group <monitored-group> control-interface <control-interface> control-slot <control-slot> control-port <control-port> vlan <vlan> To create an ABN entity consisting of an interface group as the monitored interface and an interface group as the control interface, enter the following command in root view: root>...
  • Page 572 The group must be defined before lag3 you create the ABN entity. lag4 Note: Multi-Carrier ABC and HSP mc-abc1 protection are only relevant mc-abc2 for PTP 820C units. mc-abc3 mc-abc4 control- Variable This parameter is always set to interface ethernet.
  • Page 573 ABN entity. lag4 Note: Multi-Carrier ABC and HSP mc-abc1 protection are only relevant mc-abc2 for PTP 820C units. mc-abc3 mc-abc4 vlan Variable untag The VLAN on which messages are transmitted (optional). 1 - 4094, except...
  • Page 574 1 monitored-port 1 control-interface ethernet control-slot 1 control-port 1 vlan 1 The following command creates an ABN entity in a PTP 820C unit with radio interface 2 as the monitored interface and LAG group lag1 as the control interface. It also specifies to transmit bandwidth messages on VLAN 55: root>...

  • Page 575: Configuring Lldp (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Configuring LLDP (CLI) Link Layer Discovery Protocol (LLDP) is a vendor-neutral layer 2 protocol that can be used by a network element attached to a specific LAN segment to advertise its identity and capabilities and to receive identity and capacity information from physically adjacent layer 2 peers.

  • Page 576: Displaying The General Lldp Parameters (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Table 188 General LLDP CLI Parameters Parameter Input Type Permitted Values Description tx-interval Number 5-3600 The interval, in seconds, at which LLDP frames are transmitted. The default value is 30. hold- Number 2-10 The TTL Multiplier, which is multiplier...

  • Page 577: Configuring Lldp Port Parameters (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI)  Tx Credit Max - The maximum number of consecutive LLDPDUs that can be transmitted at any one time. In this release, the Tx Credit Max is set at 5.  Message Fast Tx - The interval, in seconds, at which LLDP frames are transmitted during fast transmission periods, such as when the unit detects a new neighbor.

  • Page 578: Displaying Lldp Port Parameters (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Parameter Input Type Permitted Values Description agent-admin Variable txOnly Defines how the LLDP protocol operates for this port: rxOnly - The LLDP agent transmits txOnly txAndRx LLDP frames on this port but does disabled not update information about its peer.

  • Page 579: Displaying Lldp Local System Parameters (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Displaying LLDP Local System Parameters (CLI) This section includes:  Displaying Local Unit Parameters (CLI)  Displaying Local Port Parameters (CLI)  Displaying Local Unit Management Information (CLI)  Displaying Local Unit Management Information per Port (CLI) ...
  • Page 580 Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) 8 - cVLANComponent 9 - sVLANComponent 10 - twoPortMACRelay  local System Cap Enabled - A bitmap value used to identify which system capabilities are enabled on the local system, as included in TLVs transmitted by the LLDP agent. The bitmap is defined by the following parameters: 0 - other 1 - repeater...

  • Page 581: Displaying The Lldp Remote System Parameters (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI)  Mng Addr OID - Reserved for future use. Displaying Local Unit Management Information per Port (CLI) To display the local unit's management information per port, enter the following command in root view: root>...
  • Page 582 Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Table 190 LLDP Remote Unit CLI Parameters Parameter Input Type Permitted Values Description slot Number The slot in which the card resides. port Number The port for which you want to configure LLDP. agent-start- Date Use the format:...
  • Page 583 Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) 10 - twoPortMACRelay  Rem System Cap Enabled - The bitmap value used to identify which system capabilities are enabled on the peer. The bitmap is defined by the following parameters: 0 - other 1 - repeater 2 - bridge 3 - wlanAccessPoint...

  • Page 584: Displaying Lldp Statistics (Cli)

    Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI)  Remote Mng Addr subType - The type of management address identifier encoding used in the associated LLDP Agent Remote Management Address.  Remote Mng Address - The octet string used to identify the management address component associated with the remote system.
  • Page 585 Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI) Displaying LLDP Transmission Statistics (CLI) To display statistics about LLDP transmissions and transmission errors, enter the following command in root view: root> ethernet lldp statistics-port-tx-show The following information is displayed:  LLDP TX Statistics Ifindex - The index value used to identify the port in LLDP transmissions. ...
  • Page 586 Chapter 19: Ethernet Protocols (CLI) Configuring LLDP (CLI)  RX Ageouts - The number of age-outs that occurred on the port. An age-out is the number of times the complete set of information advertised by the remote system has been deleted from the unit's database because the information timeliness interval has expired.

  • Page 587: Synchronization (Cli)

    Chapter 20: Synchronization (CLI) Configuring LLDP (CLI) Synchronization (CLI) Configuring SyncE Regenerator (CLI) In SyncE PRC pipe regenerator mode, frequency is transported between two interfaces through the radio link. With the system acting as a simple link, no distribution mechanism is necessary, resulting in improved frequency distribution performance with PRC quality and a simplified configuration.
  • Page 588 The following command removes SyncE pipe 1: root> platform sync pipe remove pipe-id 1 PTP 820C and PTP 820S use 1588v2-compliant Transparent Clock to counter the effects of delay variation. Transparent Clock measures and adjusts for delay variation, enabling the PTP 820C/S to guarantee ultra-low PDV.
  • Page 589 To display the Transparent Clock settings, enter the following command in root view: The following commands enable Transparent Clock on radio carrier 1 and configure the radio to send PTP packets downstream: Table 193 Parameter Input Type Permitted Values Description slot Number PTP 820C/S: 2 port Number phn-3963_004v000 Page 20-396...

  • Page 590: Access Management And Security (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring LLDP (CLI) Access Management and Security (CLI) This section includes:  Configuring the General Access Control Parameters (CLI)  Configuring the Password Security Parameters (CLI)  Configuring Users (CLI)  Configuring RADIUS (CLI) ...

  • Page 591: Configuring The General Access Control Parameters (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring the General Access Control Parameters (CLI) Configuring the General Access Control Parameters (CLI) To avoid unauthorized login to the system, the following parameters should be set:  Inactivity Timeout  Blocking access due to login failures ...

  • Page 592: Configuring Blocking Of Unused Accounts (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring the General Access Control Parameters (CLI) To configure the number of failed login attempts that will temporarily block the user from logging into the system, enter the following command in root view: root>...
  • Page 593 Chapter 21: Access Management and Security (CLI) Configuring the General Access Control Parameters (CLI) To configure the blocking of unused accounts period, enter the following command in root view: root> platform security access-control block-unused-account period set <period> Once the user is blocked, you can use the following command to unblock the user: root>...

  • Page 594: Configuring The Password Security Parameters (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring the Password Security Parameters (CLI) Configuring the Password Security Parameters (CLI) You can configure enhanced security requirements for user passwords. This section includes:  Configuring Password Aging (CLI)  Configuring Password Strength Enforcement (CLI) ...

  • Page 595: Forcing Password Change Upon First Login (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring the Password Security Parameters (CLI) Table 198 Password Strength Enforcement CLI Parameters Parameter Input Type Permitted Values Description password Number 0, 20 - 90 The number of days that user aging passwords will remain valid from the first time the user logs into the system.

  • Page 596: Displaying The System Password Settings (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring the Password Security Parameters (CLI) Displaying the System Password Settings (CLI) Use the following command to display the system password settings: root> platform security access-control password show-all phn-3963_004v000 Page 21-403...

  • Page 597: Configuring Users (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring Users (CLI) Configuring Users (CLI) This section includes:  User Configuration Overview (CLI)  Configuring User Profiles (CLI)  Configuring User Accounts (CLI) Related topics:  Logging On (CLI) User Configuration Overview (CLI) User configuration is based on the Role-Based Access Control (RBAC) model.

  • Page 598: Configuring User Profiles (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring Users (CLI) Configuring User Profiles (CLI) User profiles enable you to define system access levels. Each user must be assigned a user profile. Each user profile contains a detailed set of read and write permission levels per functionality group.

  • Page 599: Configuring User Accounts (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring Users (CLI) Limiting Access Protocols for a User Profile (CLI) The user profile can limit the access channels that users with the user profile can use to access the system. By default, a user profile includes all access channels. Use the following command to limit the protocols users with this user profile can use to access the system.
  • Page 600 Chapter 21: Access Management and Security (CLI) Configuring Users (CLI) To create a new user account, enter the following command: root> platform security access-control user-account add user-name <user- name> profile-name <profile-name> expired-date <expired-date> When you create a new user account, the system will prompt you to enter a default password. If Enforce Password Strength is activated (refer to Configuring Password Strength Enforcement (CLI)), the password must meet the following criteria:...
  • Page 601 Chapter 21: Access Management and Security (CLI) Configuring Users (CLI) Parameter Input Type Permitted Values Description expired-date Date Use the format: Optional. The date on which the YYYY-MM-DD user account will expire. On this date, the user automatically becomes inactive. block Variable yes - blocks the account.

  • Page 602: Configuring Radius (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring RADIUS (CLI) Configuring RADIUS (CLI) This section includes:  RADIUS Overview (CLI)  Activating RADIUS Authentication (CLI)  Configuring the RADIUS Server Attributes (CLI)  Viewing RADIUS Access Control and Server Attributes (CLI) ...

  • Page 603: Viewing Radius Access Control And Server Attributes (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring RADIUS (CLI) Table 204 Configure RADIUS Server CLI Parameters Parameter Input Type Permitted Values Description server-id Number 1 - The primary Radius server 2 - The secondary Radius server. ip-address Dotted Any valid IP The IP address of the Radius decimal address...
  • Page 604 Chapter 21: Access Management and Security (CLI) Configuring RADIUS (CLI)  User ID - The user name  Access Channels - The permitted access channels.  User Instances - The number of currently open sessions.  Security Func Group Read level – The Read access level in the Security functional group: None, Regular or Advanced.

  • Page 605: Configuring X.509 Csr Certificates And Https (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) The web interface protocol for accessing PTP 820 can be configured to HTTP (default) or HTTPS. It cannot be set to both at the same time. Before setting the protocol to HTTPS, you must: Create and upload a CSR file.
  • Page 606 Chapter 21: Access Management and Security (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) To display the currently-configured SFTP parameters for CSR upload, enter the following command in root view: root> platform security csr-show-server-parameters To generate and upload a CSR, enter the following command in root view: root>...

  • Page 607: Downloading A Certificate (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) Parameter Input Type Permitted Values Description server-path Text String The directory path to which you are uploading the CSR. Enter the path relative to the SFTP user's home directory, not the absolute path.

  • Page 608: Enabling Https (Cli)

    Chapter 21: Access Management and Security (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) Table 206 Certificate Download and Install CLI Parameters Parameter Input Type Permitted Values Description server-ipv4 Dotted Any valid IPv4 IP The IPv4 address of the PC or decimal address.
  • Page 609 Chapter 21: Access Management and Security (CLI) Configuring X.509 CSR Certificates and HTTPS (CLI) root> platform security url-protocol-set url-protocol http To display which protocol is currently enabled, enter the following command in root view: root> platform security url-protocol-show phn-3963_004v000 Page 21-416...

  • Page 610: Blocking Telnet Access (Cli)

    Chapter 21: Access Management and Security (CLI) Blocking Telnet Access (CLI) Blocking Telnet Access (CLI) You can block telnet access to the unit. By default, telnet access is not blocked. To block telnet access, enter the following command: root> platform security protocols-control telnet admin set disable To unblock telnet access, enter the following command: root>...

  • Page 611: Uploading The Security Log (Cli)

    Chapter 21: Access Management and Security (CLI) Uploading the Security Log (CLI) Uploading the Security Log (CLI) The security log is an internal system file which records all changes performed to any security feature, as well as all security related events. In order to read the security log, you must upload the log to an FTP or SFTP server.
  • Page 612 Chapter 21: Access Management and Security (CLI) Uploading the Security Log (CLI) Parameter Input Type Permitted Values Description protocol Variable sftp username Text String The user name for the FTP or SFTP session. password Text String The password for the FTP or SFTP session.

  • Page 613: Uploading The Configuration Log (Cli)

    Chapter 21: Access Management and Security (CLI) Uploading the Configuration Log (CLI) Uploading the Configuration Log (CLI) The configuration log lists actions performed by users to configure the system. This file is mostly used for security, to identify suspicious user actions. It can also be used for troubleshooting. In order to upload the configuration log, you must install an FTP or SFTP server on the laptop or PC from which you are performing the upload.
  • Page 614 Chapter 21: Access Management and Security (CLI) Uploading the Configuration Log (CLI) Parameter Input Type Permitted Values Description file-name Text String The name you want to give the file you are exporting. Note: You must add the suffix .zip to the file name. Otherwise, the file import may fail.
  • Page 615 Chapter 21: Access Management and Security (CLI) Uploading the Configuration Log (CLI) root> platform security configuration-log-upload-params set path \file- name cfg_log ip-address 192.168.1.99 protocol ftp username anonymous password 12345 root> platform unit-info channel set protocol frp The following command exports the configuration log to the external server location: root>...

  • Page 616: Alarm Management And Troubleshooting (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Uploading the Configuration Log (CLI) Alarm Management and Troubleshooting (CLI) This section includes:  Viewing Current Alarms (CLI)  Viewing the Event Log (CLI)  Editing Alarm Text and Severity (CLI)  Uploading Unit Info (CLI) ...

  • Page 617: Viewing Current Alarms (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Viewing Current Alarms (CLI) Viewing Current Alarms (CLI) To display all alarms currently raised on the unit, enter the following command in root view: root> platform status current-alarm show module unit To display the most severe alarm currently raised in the unit, enter the following command in root view: root>...

  • Page 618: Viewing The Event Log (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Viewing the Event Log (CLI) Viewing the Event Log (CLI) The Event Log displays a list of current and historical events and information about each event. To display the event log, enter the following command in root view: root>...

  • Page 619: Editing Alarm Text And Severity (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Editing Alarm Text and Severity (CLI) Editing Alarm Text and Severity (CLI) You can view a list of alarm types, edit the severity level assigned to individual alarm types, and add additional descriptive text to individual alarm types. This section includes: ...

  • Page 620: Setting Alarms To Their Default Values (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Editing Alarm Text and Severity (CLI) Example The following command changes the severity level of alarm type 401 (Ethernet Loss of Carrier) to minor: root> platform status alarm-management set alarm-id 401 severity-level minor Setting Alarms to their Default Values (CLI) To restore an alarm type’s severity level and description to their default values, enter the following command in root view:...

  • Page 621: Uploading Unit Info (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Uploading Unit Info (CLI) Uploading Unit Info (CLI) You can generate a unit information file, which includes technical data about the unit. This file can be forwarded to customer support, at their request, to help in analyzing issues that may occur. In order to export a unit information file, you must install an FTP or SFTP server on the laptop or PC from which you are performing the upload.
  • Page 622 Chapter 22: Alarm Management and Troubleshooting (CLI) Uploading Unit Info (CLI) Parameter Input Type Permitted Values Description server-ipv6 Eight Any valid IPv6 The IPv6 address of the PC or groups of address. laptop you are using as the FTP or four SFTP server.
  • Page 623 Chapter 22: Alarm Management and Troubleshooting (CLI) Uploading Unit Info (CLI) Example The following commands configures an FTP channel for unit information file export to IP address 192.168.1.99, in the directory “current”, with file name “version_8_backup.zip”, user name “anonymous”, and password “12345.” root>...

  • Page 624: Performing Diagnostics (Cli)

    Chapter 22: Alarm Management and Troubleshooting (CLI) Performing Diagnostics (CLI) Performing Diagnostics (CLI) This section includes:  Performing Radio Loopback (CLI)  Performing Ethernet Loopback (CLI) Performing Radio Loopback (CLI) You can perform loopback on a radio. To set the timeout for a radio loopback, enter the following command: radio[x/x]>...
  • Page 625 Chapter 22: Alarm Management and Troubleshooting (CLI) Performing Diagnostics (CLI) eth type eth[x/x]> loopback admin <loopback-admin-state> To configure the loopback duration time, go to interface view for the interface and enter the following command: eth type eth[x/x]> loopback set duration <loopback-duration> You can select whether to swap DA and SA MAC addresses during the loopback.

  • Page 626: Working In Cw Mode (Single Or Dual Tone) (Cli)

    The following commands set a single-tone transmit frequency of 5050 KHz on radio interface 1 on a PTP 820C or PTP 820S unit, then exit CW mode and return the interface to normal operation: root> radio slot 2 port 1...

  • Page 627: Maintenance

    Chapter 23: Maintenance Working in CW Mode (Single or Dual Tone) (CLI) Maintenance This section includes:  PTP 820C Connector Pin-outs  PTP 820C LEDs  PTP 820S Connector Pin-outs  PTP 820S LEDs phn-3963_004v000 Page 23-434...

  • Page 628: Ptp 820C Connector Pin-Outs

    PTP 820C Connector Pin-outs PTP 820C Connector Pin-outs Figure 258 PTP 820C Interfaces MIMO Port Eth1/PoE - GbE Electrical+PoE/Optical Table 215: PTP 820C Eth1/PoE Interface- RJ-45/SFP Pinouts Pin no. Description BI_DA+ (Bi-directional pair +A) BI_DA- (Bi-directional pair -A) BI_DB+ (Bi-directional pair +B)

  • Page 629: Eth2 - Gbe Electrical/Optical

    Chapter 23: Maintenance PTP 820C Connector Pin-outs Eth2 - GbE Electrical/Optical Table 216 PTP 820C Eth2 Interface - RJ-45/SFP Pinouts Pin no. Description BI_DA+ (Bi-directional pair +A) BI_DA- (Bi-directional pair -A) BI_DB+ (Bi-directional pair +B) BI_DC+ (Bi-directional pair +C) BI_DC- (Bi-directional pair -C)

  • Page 630: Mgt/Prot - Management (Fe-Standard) And Protection (Fe-Non-Standard)

    Chapter 23: Maintenance PTP 820C Connector Pin-outs MGT/PROT - Management (FE-Standard) and Protection (FE- Non-Standard) Table 218 PTP 820C MGT/PROT Interface - RJ-45 Pinouts Pin no. Description Protection - Non-Standard 100Base-T 4 Wire Protection - Non-Standard 100Base-T 4 Wire The DC port is UL-60950 compliant, with a 2-pin connector.

  • Page 631: Rsl Interface

    Chapter 23: Maintenance PTP 820C Connector Pin-outs RSL Interface PTP 820C uses a weather-proof BNC connector Source Sharing PTP 820C uses a TNC connector for source sharing. This connector is marked EXT/REF. phn-3963_004v000 Page 23-438...

  • Page 632: Ptp 820C Leds

    Chapter 23: Maintenance PTP 820C LEDs PTP 820C LEDs The PTP 820C provides the following LEDs to indicate the status of the unit's interfaces, and the unit as a whole:  Electrical GbE Interface (RJ-45) LEDs  Optical GbE Interface (SFP) LEDs ...

  • Page 633: Radio Led

    Chapter 23: Maintenance PTP 820C LEDs  Off - Admin is Disabled .  Green - Admin is Enabled . If the MGT interface is being used for protection, the Orange LED indicates the status of the mate unit.: ...

  • Page 634: Ptp 820S Connector Pin-Outs

    Chapter 23: Maintenance PTP 820S Connector Pin-outs PTP 820S Connector Pin-outs Figure 260 PTP 820S Interfaces Eth1/PoE - GbE Electrical+PoE/Optical Table 219 PTP 820S Eth1/PoE Interface- RJ-45/SFP Pinouts Pin no. Description BI_DA+ (Bi-directional pair +A) BI_DA- (Bi-directional pair -A) BI_DB+ (Bi-directional pair +B) BI_DC+ (Bi-directional pair +C) BI_DC- (Bi-directional pair -C) BI_DB- (Bi-directional pair +B)

  • Page 635: Eth2 - Gbe Electrical/Optical

    Chapter 23: Maintenance PTP 820S Connector Pin-outs Eth2 - GbE Electrical/Optical Table 220 PTP 820S Eth2 Interface - RJ-45/SFP Pinouts Pin no. Description BI_DA+ (Bi-directional pair +A) BI_DA- (Bi-directional pair -A) BI_DB+ (Bi-directional pair +B) BI_DC+ (Bi-directional pair +C) BI_DC- (Bi-directional pair -C) BI_DB- (Bi-directional pair +B) BI_DD+ (Bi-directional pair +D) BI_DD- (Bi-directional pair -D)

  • Page 636: Mgt/Prot - Management (Fe-Standard) And Protection (Fe-Non-Standard)

    Chapter 23: Maintenance PTP 820S Connector Pin-outs MGT/PROT - Management (FE-Standard) and Protection (FE- Non-Standard) Table 222 PTP 820S MGT/PROT Interface - RJ-45 Pinouts Pin no. Description Management - Standard 100Base-T 4 Wire Protection - Non-Standard 100Base-T 4 Wire The DC port is UL-60950 compliant, with a 2-pin connector. Figure 261 PTP 820S DC Connector RSL Interface PTP 820S uses a weather-proof BNC connector.

  • Page 637: Ptp 820S Leds

    Chapter 23: Maintenance PTP 820S LEDs PTP 820S LEDs The PTP 820S provides the following LEDs to indicate the status of the unit's interfaces, and the unit as a whole:  Electrical GbE Interface (RJ-45) LEDs  Optical GbE Interface (SFP) LEDs ...

  • Page 638: Status Led

    Chapter 23: Maintenance PTP 820S LEDs If the MGT interface is being used for protection, the Orange LED indicates the status of the mate unit.:  Off – Admin is Disabled or no cable is connected to the interface..  Orange –...

  • Page 639: Poe Injector Pin-Outs

    Chapter 23: Maintenance PoE Injector Pin-outs PoE Injector Pin-outs Figure 262: PoE Injector Connectors PoE Port PoE Injector PoE Port - RJ-45 Pinouts Table 223 Pin no. Description BI_DA+ (Bi-directional pair +A) BI_DA- (Bi-directional pair -A) BI_DB+ (Bi-directional pair +B) BI_DC+ (Bi-directional pair +C) BI_DC- (Bi-directional pair -C) BI_DB- (Bi-directional pair +B)

  • Page 640: Poe Injector Leds

    Chapter 23: Maintenance PoE Injector LEDs Pin no. Description BI_DC- (Bi-directional pair -C) BI_DB- (Bi-directional pair +B) BI_DD+ (Bi-directional pair +D) BI_DD- (Bi-directional pair -D) One or two DC ports, depending on the PoE Injector model: Two models of the PoE Injector are available: ...

  • Page 641: Alarms List

    Chapter 24: Alarms List PoE Injector LEDs Alarms List The following table lists all alarms used in the PTP 820C/S products. Alarm ID Type Description Severity Probable Cause Corrective Action Notes User enabled framer digital Disable framer digital Alarm Framer digital loopback Warning loopback.
  • Page 642 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Wait till loopback timeout Alarm Loopback is active Major Ethernet loopback is active. expires or disable loopback. Slot X port XX is Mirroring is enabled by Alarm mirrored to slot Y port Minor...
  • Page 643 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Event Ethernet interface is down Warning Check link performance. Fade in the link. Check IF cable and replace Defective IF cable. if required. Alarm Radio excessive BER Major...
  • Page 644 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Reset the system. Alarm Corrupted inventory file Warning The inventory file is corrupted Reinstall the software. Reset the system. Alarm Inventory file not found Warning The inventory file is missing Reinstall the software.
  • Page 645 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes License key validation has Alarm License signature failure Major failed due to invalid product Replace the IDU serial number License violation sanction Event Major is enforced Essential internal license...
  • Page 646 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes System failed in attempt to Failure in configuration file 1152 Event Warning create backup configuration backup generation file Configuration successfully Configuration restore finished 1153 Event Warning...
  • Page 647 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes CLI Configuration script 1164 Event Warning executed successfully Verify script in the relevant Syntax Error. line, and run again. CLI Configuration script 1165 Event Warning Error returned by system...
  • Page 648 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes 1601 Alarm IF loopback Warning User enabled IF loopback Disable IF loopback 1602 Check IF cable and connectors. Verify that the N-Type connector inner pin is not Cable is not connected to RMC 1701 Alarm...
  • Page 649 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check IF cable and connectors. Verify that N-Type Defective IF cable. connector inner pin is not IF cable not connected spliced. properly. Replace RMC (Radio Defective RMC (Radio Modem Card).
  • Page 650 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check if problem repeats and if errors/alarms RFU frequency was set 1708 Event Warning Defective RFU reported. automatically Replace RFU. 1709 Alarm RFU hardware failure 1 Critical Defective RFU.
  • Page 651 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes User has activated RFU 1722 Alarm RFU loopback is active Major Disable RFU loopback. loopback. RFU mode changed to 1723 Event Indeterminate Combined RFU mode changed to 1724 Event...
  • Page 652 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check that the fault is not due to rain/multi-path fading or lack of LOS. Improper installation. Check link settings (TX power, RFU RX level path2 out of 1729 Alarm Warning...
  • Page 653 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check that the RMCs are in allowed slots. Populate the RMCs in Signaling between RMCs different allowed location 1772 Alarm Radio XPIC sync loss Major (Radio Modem Cards) for XPIC in the chassis.
  • Page 654 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes New installed software Reset the radio carrier to MRMC running script is package does has an updated 1781 Event Warning reacquire the new updated updated version of the running MRMC MRMC radio script...
  • Page 655 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Remote STM-1/OC-3 signal is missing (LOS/LOF/MS-AIS/AIS-L on remote STM-1/OC-3 MS-AIS/AIS-L on Radio interface). 2105 Alarm Minor Check remote equipment. Interface detected. STM-1/OC-3 Channel removed due to reduced radio capacity on remote side.
  • Page 656 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check link performance. STM-1/OC-3 Channel Reduced capacity. 2113 Alarm Removed alarm (due to Warning Check radio alarms for Fading. reduced radio capacity). channel. Check link performance.
  • Page 657 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Check link performance on all radio channels in Multi Carrier ABC group. Check radio alarms for All channels in Multi Carrier 2200 Alarm Multi Carrier ABC LOF.
  • Page 658 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Replace RMC. Hardware failure between Replace TCC. 2209 Alarm LVDS RX Error Slot 8. Major RMC and TCC cards. Replace chassis. Replace RMC. Hardware failure between Replace TCC.
  • Page 659 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Compare Channel ID Multi Carrier ABC Channel 2223 Alarm Warning Configuration failure. configuration with remote Id Mismatch Ch5. side. Compare Channel ID Multi Carrier ABC Channel 2224 Alarm Warning...
  • Page 660 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Multi Carrier ABC Channel Admin state for channel is Enable admin state for 2242 Alarm Warning Id Manual Disabled Ch8. down. channel. Apply copy-to-mate command The configuration between the Protection configuration to copy the configuration from...
  • Page 661 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes The sync-source quality 5011 Event Major level was changed System Synchronization 5012 Alarm Reference in Holdover Critical Mode The system's reference- 5013 Event Major quality changed The pipe interface clock-...
  • Page 662 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes 1. Radio LOF on Tx/Rx 1. Validate the MSE on 5102 Alarm Payload Encryption Critical direction. both sides of the link. failure 2. The session key does 2.
  • Page 663 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Faulty coaxial cable Try re-initiation of MIMO. between master and slave If still fails: RFUs. Replace faulty coaxial Clock source sharing Hardware failure in 30007 Event Critical...
  • Page 664 Chapter 24: Alarms List PoE Injector LEDs Alarm ID Type Description Severity Probable Cause Corrective Action Notes Not all MIMO carriers are Load same MIMO set to same radio script or compatible radio script to script is not compatible all MIMO carriers. for MIMO.
  • Page 665 FIPS Bypass Self-Test Disk failure 5107 Alarm Critical failed Power On Self-Test System failure Reboot the unit. 5108 Alarm Critical Failed (1) Supported by PTP 820C and PTP 820S (2) Supported by PTP 820C only phn-3963_004v000 Page 24-472...

  • Page 666: Glossary

    Glossary Term Definition Adaptive Bandwidth Control Adaptive Bandwidth Notification Alternating Current ACAP Adjacent Channel Alternate Polarization ACCP Adjacent Channel Co-Polarization Adaptive Coded Modulation Adaptive Clock Recovery Advanced Encryption Standard Automatic Gain Control Alarm Indicating Signal Automatic Level Control ANSI American National Standards Institute ASIC Application Specified Integrated Circuit ATPC...
  • Page 667 Term Definition Comité Consultatif International de Télégraph et des Télécommunications CCITT (ITU) Carrier-Ethernet Transport Connectivity Fault Management Committed Information Rate Command Line Interface Clock CODEC Coder/Decoder Class of Service Destination Address Direct Current Diversity Circulator Block Data Communication Channel Digital Cross Connect DSCP Differentiated Services Code Point Excess Burst Size...
  • Page 668 Term Definition Generic Framing Procedure (Procedure for mapping of Ethernet traffic over a transport network) Ground Generic Routing Encapsulation GPRS Tunneling Protocol HBER High Bit Error Rate HDLC High-level Data Link Control High Frequency (3-30 MHz) Hot-Standby HTTP Hypertext Transfer Protocol HTTPS Secured Hypertext Transfer Protocol Indoor Controller...
  • Page 669 Term Definition Link Loss Forwarding License Management System Local Oscillator Loss of Carrier Loss of Frame Loss of Signal Large Scale Integration Long-Term Evolution MAID Maintenance Association Identifier MPLS Multi Protocol Label Switching Multiplex Section Protection Multiplexer Network Element Network Management System Network Time Protocol Operation Administration &...
  • Page 670 Term Definition Peak Information Rate Phase Locked Loop Performance Monitoring Provider Network PROM Programmable Read Only Memory Packet Switched Network Precision Timing Protocol Power Quality of Experience Quality of Service RBAC Role Based Access Control RCVR Receiver Reverse Defect Indication Radio Frequency Routing Information Protocol RMON...
  • Page 671 Term Definition SNMP Simple Network Management Protocol Service Network Point Signal to Noise Ratio SNTP Simple Network Time Protocol Section OverHead (ETSI) SONET Synchronous Optical NETwork Service Point Secured Shell (Protocol) Synchronization Status Message Spanning Tree Protocol SyncE Synchronous Ethernet SVCE Service Channel Equipment Traffic Class...
  • Page 672 Term Definition XCVR Transceiver (Transmitter/Receiver) XMTR Transmitter Crystal Oscillator Cross Polar Differentiation Cross Polariztion Isolation XPIC Cross Polarization Interference Cancellation phn-3963_004v000 Page VII...

This manual is also suitable for:

Ptp 820s

Table of Contents

Save PDF
