PLANNING AND
INSTALLATION GUIDE
PMP/PTP 450 Series
Release 24.2.1
Covers:
PMP 450 AP / PMP 450 SM / PTP 450 BH / PMP 450 d
PMP 450i / PTP 450i
PMP 450 b / PTP 450 b
PMP 450 m
PMP 450 MicroPoP
PMP / PTP 450 b Retro
PMP 450v

Advertisement

loading
Need help?

Need help?

Do you have a question about the PMP 450 AP and is the answer not in the manual?

Questions and answers

Related Manuals for Cambium Networks PMP 450 AP

Summary of Contents for Cambium Networks PMP 450 AP

  • Page 1 INSTALLATION GUIDE PMP/PTP 450 Series Release 24.2.1 Covers: PMP 450 AP / PMP 450 SM / PTP 450 BH / PMP 450 d PMP 450i / PTP 450i PMP 450 b / PTP 450 b PMP 450 m PMP 450 MicroPoP...
  • Page 2 Cambium recommends reviewing the Cambium Networks website for the latest changes and updates to products. Cambium does not assume any liability arising out of the application or use of any product, software, or circuit described herein;...
  • Page 3 Contents Contents About This User Guide Purpose Product notation conventions in document Cross references Feedback Important regulatory information Application software USA specific information Canada specific information Renseignements specifiques au Canada EU Declaration of Conformity Specific expertise and training for professional installers Ethernet networking skills Lightning protection Problems and warranty...
  • Page 4 Chapter 1: Product Description Overview of the 450 Platform Family Purpose Wireless operation Time Division Duplexing Encryption MIMO MU-MIMO System management Management agent Web server Remote Authentication Dial-in User Service (RADIUS) Network Time Protocol (NTP) cnMaestro™ Radio recovery mode Chapter 2: System hardware System components Backhaul (PTP) 450 Platform family ODU interfaces...
  • Page 5 450v Series interfaces AP – 5/6 GHz 450v Series interfaces SM/BHM/BHS (4x4) – 5/6 GHz 450v Series interfaces SM/BHM/BHS (2x2) – 5/6 GHz ATEX/HAZLOC variants Diagnostic LEDs Power supply options Power supply – PMP 450m Series Power supply – PMP/PTP 450i Series Power supply –...
  • Page 6 Antenna accessories GPS synchronization Universal GPS (UGPS) Cluster Management Module (CMM5) CMM5 Controller module CMM5 injector module CMM5 injector compatibility matrix CMM5 specifications CMM4/CMM5 (Rack mount) CMM4/CMM5 (Cabinet with switch) CMM4/CMM5 (Cabinet without switch) CMM3/CMMmicro GPS Synchronisation for PMP 450b6 Installing a GPS receiver GPS receiver location Mounting the GPS receiver...
  • Page 7 ODU wind loading Hazardous locations Drop cable grounding points Lightning Protection Unit (LPU) location Radio Frequency planning Regulatory limits Available spectrum Analyzing the RF Environment Channel bandwidth selection Anticipating reflection of radio waves Obstructions in the Fresnel zone Planning for co-location Multiple OFDM AP Clusters Considerations on back-to-back frequency reuse Link planning...
  • Page 8 Developing an IP addressing scheme Address Resolution Protocol (ARP) Allocating subnets Selecting non-routable IP addresses Translation bridging Engineering VLANs Network management planning Planning for Simple Network Management Protocol (SNMP) operation Enabling SNMP Security planning Isolating AP/BHM from the Internet Encrypting radio transmissions Planning for HTTPS operation Planning for SNMPv3 operation Managing module access by passwords...
  • Page 9 Chapter 4: Preparing for installation Safety Hazardous locations Siting of ODU and soundness of structure Working at heights and near power lines Power supply and power safety External cables RF exposure near the antenna Grounding and lightning protection requirements Grounding and protective earth Thermal Safety Preparing for installation ODU pre-configuration...
  • Page 10 General protection installation Installing the copper Cat5e Ethernet interface Install the main drop cable Install the bottom LPU to PSU drop cable Installing external antennas to a connectorised ODU PMP 450i Series PMP 450 Series PMP 450i Series AP 900 MHz PMP 450 Series SM 900 MHz Alignment of the 4x4 PMP 450v SM/BHS Enable two carriers at the AP when aligning the SM...
  • Page 11 Creating a drop cable grounding point Attaching and weatherproofing an N type connector Chapter 6: Compliance with safety standards Electrical safety compliance Electromagnetic compatibility (EMC) compliance Human exposure to radio frequency energy Power density exposure limit Calculation of power density Calculated distances and power compliance margins Tx power limits for PMP 450 MicroPoP Hazardous location compliance...
  • Page 12 Family. It is recommended that all personnel engaged in such activities be properly trained. Cambium Networks disclaims all liability whatsoever, implied or expressed, for any risk of damage, loss, or reduction in system performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the instructions, system parameters, or recommendations made in this document.
  • Page 13 Product Description notation Connectorised/Integrated SM [3 GHz/5 GHz] Connectorised/Integrated PTP 450i BHM/BHS [3 GHz/5 GHz] Connectorised/Integrated 450b Series Refers to 450b Series devices in the following configurations: PMP/PTP 450b Mid-Gain SM [5 GHz] Integrated BHM/BHS [5 GHz] Integrated PMP/PTP 450b Connectorised SM [5 GHz] BHM/BHS [5 GHz] PMP/PTP 450b High Gain...
  • Page 14 Product Description notation Integrated PMP 450 MicroPop Connectorised AP 5 GHz Connectorised 450b Retro Refers to 450b Retro Series devices in the following configurations: Series PMP 450b Retro SM 5 GHz Integrated PTP 450b BHM/BHS 5 GHz Integrated 450v Refers to 450v Series devices in the following configurations: AP 5/6 GHz (4x4) Integrated SM 5/6 GHz (4x4)
  • Page 15 FCC. Cambium Networks supplies variants of the 5 GHz 450, 450i, 450b, and 450m Series specifically for operation in the USA to comply with FCC requirements (KDB 905462 D02 UNII DFS Compliance Procedures New Rules v02).
  • Page 16 Specifically, it must not be possible to disable or modify the radar protection functions that have been demonstrated to ISEDC. To comply with these ISEDC requirements, Cambium Networks supplies variants of the 450 Platform Family for operation in Canada. These variants are only allowed to operate with license keys that comply with ISEDC rules.
  • Page 17 Configuration Guide. EU Declaration of Conformity Hereby, Cambium Networks declares that the Cambium 450 Series, 450b Series, 450i Series, and 450m Series Wireless Ethernet Bridges comply with the essential requirements and other relevant provisions of Radio Equipment Directive 2014/53/EU. The declaration of conformity may be consulted at: https://www.cambiumnetworks.com/eu_dofc...
  • Page 18 Cambium’s standard hardware warranty is for one (1) year from the date of shipment from Cambium Networks or a Cambium distributor. Cambium Networks warrants that hardware will conform to the relevant published specifications and will be free from material defects in material and workmanship under normal use and service.
  • Page 19 Security advice Cambium Networks systems and equipment provide security parameters that can be configured by the operator based on their particular operating environment. Cambium recommends setting and using these parameters following industry recognized security practices. Security aspects to be considered are protecting the confidentiality, integrity, and availability of information and assets.
  • Page 20 In EU countries The following information is provided to enable regulatory compliance with the European Union (EU) directives identified and any amendments made to these directives when using Cambium equipment in EU countries. Disposal of Cambium equipment European Union (EU) Directive 2012/19/EU Waste Electrical and Electronic Equipment (WEEE) Do not dispose of Cambium equipment in landfill sites.
  • Page 21 Chapter 1: Product Description This chapter provides a high-level description of 450 Platform Family products. It describes in general terms the function of the product, the main product variants and the main hardware components. The following topics are described in this chapter: Overview of the 450 Platform Family Wireless operation System management...
  • Page 22 Cambium Networks is using leading edge technology to provide a substantial shift upward in capacity per sector. Key features Cambium PMP 450m Series APs offer the following benefits: MU-MIMO APs provide up to 900 Mbps in 20 MHz channel bandwidth and up to 1.4 Gbps in a 40 MHz channel, depending upon SMs position within sector.
  • Page 23 Cambium PMP/PTP 450i Series APs offer the following benefits: Cambium Networks high performing PMP solution, with up to 310 Mbps (40 MHz channel bandwidth and 5 ms Frame Period) usable throughput for PMP and PTP State-of-the-art MIMO technology...
  • Page 24 Upto 7.5 bps/Hz spectral efficiency Increased packet processing rate Efficient GPS synchronization, scheduled TDD operation for easy AP/BHM site deployment and performance that is consistent regardless of SM/BHS loading A range of cost-effective subscriber device solutions to meet the business case of any network application MIMO B Mode: This technique provides the ability to double the throughput of a radio transmission under proper RF conditions.
  • Page 25 Frequency bands The PMP/PTP 450i Series ODU can operate in the following bands: 900 MHz band: 902 to 928 MHz 3 GHz band: 3300 to 3900 MHz 5 GHz band: 4900 to 5925 MHz Note 900 MHz, 3 GHz, and 5 GHz bands with different frequencies require different hardware components.
  • Page 26 Frequency ODU type PTP 450i BH 3.3 to 3.9 GHz Integrated 19 dBi, SM/BH with MARS antenna Connectorised Use with an external antenna 4.9 to 5.925 GHz (support 4.9, 5.1, 5.2, Integrated 23 dBi flat panel antenna 5.4 and 5.8 GHz) Connectorised Use with an external antenna...
  • Page 27 High Aggregate Throughput: Capable of up to 300 Mbps aggregate in a 40 MHz channel, delivering high-speed data transfer for demanding applications and network requirements. gives a summary of the main PMP/PTP 450b Series characteristics Table 5: Main characteristics of the PMP/PTP 450b Series Characteristic Value Topology...
  • Page 28 23 dBi Dish antenna PMP/PTP 450 Series Cambium Networks PMP/PTP 450 Series networks are designed for wireless PMP and PTP links in the unlicensed/licensed 900 MHz, 2.4 GHz, 3.5 GHz, 3.65 GHz, 5.4 GHz and 5.8 GHz bands. Users must ensure that the PMP/PTP 450 Series complies with local operating regulations.
  • Page 29 3.65 GHz band: 3500 to 3850 MHz 5 GHz band: 5470 to 5875 MHz Hardware components The main hardware components of the PMP/PTP 450 are as follows: PMP 450 AP PMP 450 SM PTP 450 BH (BHM/BHS) The PMP/PTP 450 is supplied in the following configurations:...
  • Page 30 Table 8: PMP/PTP 450 Series hardware configurations Frequency ODU type PMP 450 AP 2.4 GHz Connectorised Use with an external antenna Integrated 18 dBi Dual Slant 3.5/3.65 GHz Connectorised Use with an external antenna Integrated 16 dBi Dual Slant 5 GHz...
  • Page 31 Capable of up to 300 Mbps aggregate in a 40 MHz channel Supports a range of up to 2 miles and a number of subscribers up to 20 To unlock the full capabilities of the platform (range up to 40 miles and number of subscribers up to 238) a license key is available for purchase Efficient GPS synchronized, scheduled TDD operation for easy AP site deployment and performance that is consistent regardless of subscriber loading...
  • Page 32 The PMP 450 MicroPoP Series is supplied in the following configuration: Table 10: PMP 450 MicroPoP Series hardware configurations Frequency ODU type PMP 450 4.9 to 5.925 GHz (support 4.9, 5.1, 5.2, 5.4 Integrated 9 dBi Integrated MicroPoP AP and 5.8 GHz) Omni antenna Integrated...
  • Page 33 Characteristic Value Spectral efficiency Up to 7.5 bps/Hz Timing synchronization CMM4, CMM5, or UGPS/cnPulse Data rate Up to 300 Mbps (40 MHz channel Bandwidth). Frequency bands The PMP/PTP 450b Retro Series ODU can operate in the following band: 5 GHz band: 4900 to 5925 MHz Hardware components The ODU is a self-contained transceiver unit that houses both radio and networking electronics.
  • Page 34 Table 13: PMP 450b Connectorised Series characteristics Characteristic Value Topology PMP, PTP Wireless link condition LOS, near LOS, or non-LOS Range PMP: up to 40 miles Duplexing TDD (symmetric and asymmetric) Connectivity 100/1000BASE-T Ethernet main port with PoE input Operating frequencies 4.9 to 5.925 GHz Tx Power - conducted Max 27 dBm...
  • Page 35 Supports the 5 GHz and 6 GHz bands. 450v 4x4 SM supports up to 4 component carriers with 40 MHz bandwidth each (*). 450v 2x2 SM supports up to 2 component carriers with 40 MHz bandwidth each. Utilizes state-of-the-art MIMO (Multi In Multi Out) technology. Achieves up to 7.5 bps/Hz spectral efficiency.
  • Page 36 Characteristic Value Channel 5, 10, 15, 20, 30, and 40 MHz bandwidth High spectral Up to 7.5 bps/Hz efficiency Timing Onboard GPS synchronization Data rate Up to 310 Mbps (40 MHz channel Bandwidth) for PMP per component carrier, up to 4 component carriers (*) Frequency bands The 450v Series ODU can operate in the following bands: 5 GHz band: 5.150 GHz - 5.925 GHz...
  • Page 37 Frequency Antnenna ODU type Channel Maximum Tx Bandwidth Power 5/6 GHz 450v 5.150 GHz – Integrated 4x4 Integrated 5, 10, 15, 20, 28 dBm (for 5 GHz) BHM/BHS (4x4) 7.125 GHz Antenna 30, 40 MHz 20 dBm (for 6 GHz) 5/6 GHz 450v 5.150 GHz –...
  • Page 38 Band 3.5 and 3.65 PMP 450 PMP 450 SM, PMP 450i SM, PMP 450b SM PMP 450i PMP 450i SM, PMP 450 SM, PMP 450b SM PMP 450m PMP 450i SM, PMP 450 SM, PMP 450b SM 2.4 GHz PMP 450 PMP 450 SM 900 MHz PMP 450i...
  • Page 39 Figure 1: PMP/PTP 450 Platform Family typical bridge deployment Note Lightning protection and power supply differs between variants. Point-to-Multipoint (PMP) The PMP configuration of 450 Platform Family consists of AP and SM ODU. The radio link operates on a single frequency channel in each direction using Time Division Duplexing (TDD). The AP operates in Time Division Multiple Access (TDMA) mode to service multiple SMs.
  • Page 40 PTP (Backhaul) The PTP configuration of 450 Platform Family consists of two BH (Backhaul) ODUs. The customer can decide, via software configuration, if this unit is a BHM (Backhaul Master) or a BHS (Backhaul Slave). The radio link operates on a single frequency channel using TDD. The BHM operates in TDMA mode to service the BHS.
  • Page 41 All power injectors/power supplies in the Cambium Networks range are designed for an indoor environment. Different ODUs require different power requirements, so be sure to select the correct power supply. Surge protection units: A range of surge protectors is available to suit different ODUs The Gigabit Surge Suppressor provides a path to ground (Protective Earth) that protects connected radio equipment from near-miss lightning strikes.
  • Page 42 Figure 2: TDD frame division TDD frame parameters The TDD burst duration varies depending on the following: Channel bandwidth Cyclic prefix (CP) Frame period Frame configuration - Downlink data Link operation – Dynamic rate adaptation OFDM and Channel bandwidth The PMP/PTP 450 Platform Family transmits using Orthogonal Frequency Division Multiplexing (OFDM). This wideband signal consists of many equally spaced subcarriers.
  • Page 43 Cyclic prefix OFDM technology uses a cyclic prefix, where a portion of the end of a symbol (slot) is repeated at the beginning of the symbol (slot) to allow multi-pathing to settle before receiving the desired data. A 1/16 cyclic prefix means that for every 16 bits of throughput data transmitted, an additional bit is used. The 450 Platform Family ODUs have been locked to a 1/16 CP.
  • Page 44 Rate MIMO-B MIMO-A 16-QAM 4X MIMO-B 2X MIMO-A 64-QAM 6X MIMO-B 3X MIMO-A 256-QAM 8X MIMO-B 4X MIMO-A Note MIMO-A achieves half the throughput of MIMO-B but adds a combining diversity (gain) which enhances the link budget or availability. Encryption The 450 Platform Family supports optional encryption for data transmitted over the wireless link.
  • Page 45 An MU-MIMO access point estimates and measures what a transmission from each wireless node sounds like, by applying knowledge of the wireless path characteristics between the access point and the node. Known as channel estimation, this process is of vital importance; without it, the access point cannot distinguish properly between wireless nodes, affecting its performance.
  • Page 46 Web server The 450 Platform Family management agent contains a web server. The web server supports access via the HTTP/HTTPS interface. Web-based management offers a convenient way to manage the 450 Platform Family radios from a locally connected computer or a network management workstation connected through a management network, without requiring any special management software.
  • Page 47 The management agent supports fault and performance management using an SNMP interface. The management agent is compatible with SNMP v2c and SNMP v3 using Management Information Base (MIB) files which are available for download from the Cambium Networks Support website: Chapter 1: Product Description...
  • Page 48 https://support.cambiumnetworks.com/files/ptp450 https://support.cambiumnetworks.com/files/pmp450 Network Time Protocol (NTP) The clock supplies accurate date and time information to the system. It can be set to run with or without a connection to a network time server. It can be configured to display local time by setting the time zone and daylight saving in the Time web page.
  • Page 49 Only selected network branches Provides a script engine that you can use with any script which: The user can define. Cambium Networks supplies. CNUT is available at: https://www.cambiumnetworks.com/products/management/cambium-network-updater-tool/ CNUT is not supported on any 450v PMP radios. These radios must be upgraded either through cnMaestro or directly from the Tools >...
  • Page 50 This plug allows the 450 Series ODUs to be accessed using IP address 169.254.1.1 and no password. During the override session, you can assign any new IP address and set either or both user passwords (display-only and/or full access) as well as make other parameter changes. Refer the Default Mode (or Default/Override Plug) –...
  • Page 51 Chapter 2: System hardware This chapter describes the hardware components of a 450 Platform family series. The chapter covers the following topics: System components 450 Platform family ODU interfaces Power supply options ODU mounting brackets and accessories Lightning protection Cabling Lightning protection unit (LPU) and grounding kit Antennas and antenna cabling GPS synchronization...
  • Page 52 System components The System components section describes the following key elements: The PMP radio is a transceiver device. It is a Connectorised or radiated outdoor unit containing all the radio, networking, and surge suppression electronics. It can be purchased as: PMP 450 Platform family Integrated or Connectorised ODU The PMP 450i Series, PMP 450b Series, PMP 450 MicroPoP Series, and PMP 450 Series ODUs are available in integrated or Connectorised configurations.
  • Page 53 Table 21: PMP 450i Series variants Variant Region Antenna Frequency Channel Max Tx Range Bandwidth Power 900 MHz PMP Connectorised 902 - 928 5, 7, 10, 15, 20 25 dBm 450i AP 3 GHz PMP All, No Encryption Connectorised 3300 – 5, 7, 10, 15, 20, 25 dBm 450i AP...
  • Page 54 25 dBm PMP 450 2.4 GHz FCC ISM Connectorised 2400 – 2483.5 MHz 5, 10, 15, 20 MHz 22 dBm PMP 450 AP Integrated 18 2.4 GHz FCC ISM Connectorised 2400 – 2483.5 MHz 5, 10, 15, 20 MHz 22 dBm...
  • Page 55 Tx Power 3.65 GHz FCC ISM Connectorised 3500 – 3850 MHz 5, 7, 10, 15, 20, 30, 40 25 dBm PMP 450 AP Integrated 16 3.65 GHz FCC ISM Connectorised 3500 – 3850 MHz 5, 7, 10, 15, 20, 30, 40...
  • Page 56 Variant Region Antenna Frequency Channel Maximum Range Bandwidth Tx Power 5/6 GHz 450b6 FCC, and IC Integrated 5.725 GHz – 5, 10, 15, 20, 30, 27 dBm SM Integrated 6.300 GHz 40 MHz (for 5 GHz) Antenna 20 dBm (for 6 GHz) Backhaul (PTP) The backhaul radio is a transceiver device.
  • Page 57 Table 29: PTP 450b Series variants Variant Region Antenna Frequency Channel Maximum Tx Range Bandwidth Power 3 GHz PTP FCC, RoW, Canada, Row 20 dBi Dish 3300 - 5, 7, 10, 15, 20, 29 dBm 450b DES, and Europe antenna 3900 MHz 30, 40 MHz 5 GHz...
  • Page 58 Table 31: PTP 450b Retro Series variants Variant Region Antenna Frequency Channel Maximum Range Bandwidth Tx Power 5 GHz PTP FCC, RoW, Canada, RoW no Integrated 4900-5925 5, 10, 15, 20, 27 dBm 450b Retro BH encryption, Europe 8 dBi 30, 40 MHz Table 32: 5 GHz PTP 450b Connectorised BH variants Frequency Variant...
  • Page 59 450 Platform family ODU interfaces PMP 450m Series interfaces AP – 3 GHz The 3 GHz 450m Series AP interfaces are illustrated in Figure Figure 3: 3 GHz PMP 450m Series interfaces Table 34: PMP 3 GHz 450m Series AP interface descriptions and cabling Interface Function Connector/Cabling...
  • Page 60 Interface Function Connector/Cabling SFP 1 The device accepts SFP modules; however, they are currently not Fiber or copper utilized by the software. SFP 2 The device accepts SFP modules (single or dual). The SFP port can be used as an alternative to the main Ethernet port on the 3 GHz 450m AP.
  • Page 61 Interface Function Connector/Cabling 10/100BASE-T Ethernet with PoE out RJ45/custom Cat 5e The device offers GPS synchronization input and output capabilities, as well as UGPS/cnPulse power output. The device is equipped with an SFP port that accepts SFP modules. Fiber or copper This SFP port can serve as an alternative to the MAIN Ethernet port on the 5 GHz 450m AP.
  • Page 62 Figure 5: PMP/PTP 450i interfaces Table 36: PMP/PTP 450i Series - AP/SM/BH interface descriptions and cabling Interface Function Connector/Cabling The device supports PoE with a range of 48-59 V DC and is 802.3at RJ45/Cat 5e compatible. It also features 10/100/1000BASE-T Ethernet, along with Cambium/Canopy Sync-over-power capability.
  • Page 63 Warning The PMP 450 Ruggedized High Gain integrated SM (Cambium part numbers CO35045CO14A and CO36045CO14A), when encapsulated in a 450i-type enclosure, contains 450 circuitry that requires 30 V DC power. Powering these SMs with a 56 V DC supply damages the device. PMP/PTP 450b Mid-Gain Series interfaces - SM/BH The PMP/PTP 450b Series - SM/BH interfaces are illustrated in below Figure...
  • Page 64 PMP/PTP 450b/450b6 High Gain Series Interfaces - SM/BHS The 450b Series products are illustrated in Figure 7 Figure 8. The interfaces are accessible from the rear of the dish and are located under the cover as shown. Figure 7: 5 GHz 450b Series interfaces (High Gain) Figure 8: 3 GHz 450b Series interfaces (High Gain) Chapter 2: System hardware...
  • Page 65 Table 38: PMP/PTP 450b Series (High Gain) SM/BH interface descriptions and cabling Interface Function Connector/Cabling Main/Power The Canopy-style PoE supports a voltage range of RJ45/Cat 5e Port 20-32 V DC and provides 10/100/1000BASE-T Ethernet, along with Canopy Sync-over-power. Aux Port The device features GPS synchronization input and 3.5 mm TRRS audio/standard output, UGPS/cnPulse power output, and alignment...
  • Page 66 Interface Function Connector/Cabling Aux Port The device supports GPS synchronization input and 3.5 mm TRRS output, UGPS/cnPulse power output, and alignment audio/standard headphones tone audio output. or custom sync cable Ground Lugs Unit chassis ground. Refer to the Installation Instructions 10 AWG copper wire for more information PMP/PTP 450b Connectorised Interfaces - SM/BH...
  • Page 67 Interface Function Connector/Cabling Aux Port The device features GPS synchronization input and output, 3.5 mm TRRS UGPS/cnPulse power output, and alignment tone audio output. audio/standard headphones or custom sync cable RF Ports The SM/BH antenna supports both horizontally and vertically Reverse polarity polarized RF connections.
  • Page 68 Table 41: PMP/PTP 450 Series - AP interface descriptions and cabling – 2.4 GHz and 5 GHz Interface Band Function Connector/Cabling Main/Power The Canopy-style PoE supports 22-32 V DC, RJ45/Cat 5e Port 10/100/1000BASE-T Ethernet, and includes Canopy Sync-over-power functionality. Aux Port The device provides GPS synchronization RJ12/custom Cat 5e input and output, UGPS/cnPulse power...
  • Page 69 PMP/PTP 450 Series interfaces – SM/BH The PMP 450 Series SM/BH interfaces are illustrated in Figure 12 Figure Figure 12: PMP/PTP 450 Series – SM/BH Integrated interfaces PMP/PTP 450 Series – SM/BH Connectorised interfaces Figure 13: Note As per the guidelines of Underwriters Laboratory (UL), the Ground Lug on the radiated SM is not required.
  • Page 70 Figure 14: PMP 450d Series - SM Integrated Dish Figure 15: PMP 450 Series – SM 3 GHz Integrated Chapter 2: System hardware...
  • Page 71 Figure 16: PTP 450 Series – BHM/BHS Table 42: PMP/PTP 450 Series interfaces – SM/BH interface descriptions and cabling Interface Band Function Connector/Cabling Ethernet Canopy-style PoE supports 24-30 VDC and RJ45/Cat 5e 10/100BASE-T Ethernet GPS synchronization input and output, alignment tone RJ12/custom Cat 5e audio output, and a default plug port RF Port A...
  • Page 72 PMP 450 MicroPoP Series (Omni, Sector and Connectorised) interfaces - AP Omni and Sector AP interfaces The PMP 450 MicroPoP Series Omni and Sector AP interfaces are illustrated Figure 17 in and Figure Figure 17: PMP 450 MicroPoP Series Omni Figure 18: PMP 450 MicroPoP Series Sector Table 43: PMP 450 MicroPoP Series Omni/Sector interface details...
  • Page 73 Connectorised AP interfaces The PMP 450 MicroPoP Series Connectorised AP interfaces are illustrated in Figure PMP 450 MicroPoP Series Connectorised AP interfaces Figure 19: Table 44: PMP 450 MicroPoP Series Connectorised interface details Interface Function Connector/Cabling Main/Power PoE supports 46-59 V DC, is 802.3af compatible, and provides RJ45/Cat 5e Port 10/100/1000BASE-T Ethernet, along with Cambium/Canopy...
  • Page 74 450v Series interfaces AP – 5/6 GHz The 5/6 GHz 450v Series AP interfaces are illustrated below. Figure 20: 5/6 GHz 450v Series AP interfaces Table 45: 5/6 GHz 450v Series AP interface details Interface Function Connector/Cabling Main PoE Port (IN) Power over Ethernet 46 - 59 V DC 802.3bt RJ45/Cat 5e compatible, 10/100/1000BASE-T Ethernet, plus...
  • Page 75 Interface Function Connector/Cabling optional SFP+/SFP optical or copper module SFP-10G-SX / SFP-10G-LX using optional SFP optical or copper module AUX Audio Jack GPS synchronization input and output, 3.5 mm TRRS UGPS/cnPulse power output, alignment tone audio/standard audio output headphones or custom sync cable Ground Lug Unit chassis ground.
  • Page 76 450v Series interfaces SM/BHM/BHS (4x4) – 5/6 GHz The 5/6 GHz 450v Series SM/BHM/BHS (4x4) interfaces are illustrated below. Figure 21: 5/6 GHz 450v Series SM/BHM/BHS (4x4) interfaces Table 46: 5/6 GHz 450v Series SM/BHM/BHS (4x4) interface details Interface Function Connector/Cabling Main PoE Port Power over Ethernet 46 - 59 V DC 802.3bt compatible, RJ45/Cat 5e...
  • Page 77 450v Series interfaces SM/BHM/BHS (2x2) – 5/6 GHz The 5/6 GHz 450v Series SM/BHM/BHS (2x2) interfaces are illustrated below. Figure 22: 5/6 GHz 450v Series SM/BHM/BHS i(2x2) nterfaces Table 47: 5/6 GHz 450v Series SM/BHM/BHS (2x2) interface details Interface Function Connector/Cabling Main PoE Port Power over Ethernet 46 - 59 V DC 802.3bt compatible, RJ45/Cat 5e...
  • Page 78 ATEX/HAZLOC variants PTP/PMP 450i series products are available in ATEX/Hazloc variants for operation in locations where explosive gas hazards exist, as defined by Hazloc (USA) and ATEX (Europe). ATEX/HAZLOC variants are similar to the standard product, with the exception that: ODUs supplied with full capacity license Frequency range is restricted to 4940 MHz to 5850 MHz Maximum EIRP generated by ODU is restricted to comply with the ATEX and HAZLOC standards...
  • Page 79 AP/BHM LEDs The diagnostic LEDs report the information about the status of the AP/BHM. 450m AP, 450i AP/BHM and 450 AP/BHM diagnostic LEDs Figure 23: Table 48: 450m AP, 450i AP/BHM and 450 AP/BHM LED descriptions Color when active Status information Notes provided DC power...
  • Page 80 Color when active Status information Notes provided ACT/4 For 450 and 450i Presence of data Flashes during data transfer. Frequency of Yellow activity on the flash is not a diagnostic indication. Ethernet link For 450m Series Aux port link speed Flashes to indicate Ethernet activity on Aux LNK + and activity...
  • Page 81 Figure 24: 5 GHz 450b Mid-Gain and High Gain BHM diagnostic LEDs Table 49: 5 GHz 450b Mid-Gain and High Gain BHM LED descriptions Color when active Status information Notes provided POWER Blue DC power Always lit after 10-20 seconds of power SYNC Green Presence of sync...
  • Page 82 Figure 25: 3 GHz 450b High Gain BHM, 5 GHz 450 MicroPoP Omni/Sector/Connectorised AP, 5 GHz 450b Retro BHM and 5 GHz 450b Connectorised BHM diagnostic LEDs Table 50: 3 GHz 450b High Gain BHM LED descriptions Color when active Status information provided Note Blue...
  • Page 83 Color when active Status information provided Note SES/SYN Yellow/Green Sync status: Generating sync = Yellow Receiving sync = Green Solid = Unit transmitting Blinking = Unit synchronized, but not transmitting Table 51: 5 GHz 450 MicroPoP Omni/Sector/Connectorised AP, 5 GHz 450b Retro BHM and 5 GHz 450b Connectorised BHM LED descriptions Color when active Status information provided...
  • Page 84 Table 52: 5/6 GHz 450v Series AP LED descriptions Color when active Status Notes information provided Yellow: While booting DC power Always lit after 10-20 seconds of power on. Blue: The radio has fully booted. Green Presence of sync Yellow Unused Green Pulse of sync...
  • Page 85 Figure 27: 450i and 450 SM/BHS diagnostic LEDs Table 53: 450i and 450 SM/BHS LED descriptions Status information provided Color when active SM/BHS in SM/BHS in Aiming Note Operating Mode Mode DC power Always lit after 10-20 seconds of power on SYN/1 Yellow Presence of sync...
  • Page 86 Status information provided Color when active SM/BHS in SM/BHS in Aiming Note Operating Mode Mode 10BASE-T = 100BASE-T = Green 1000BASE-T = Orange For 450 Series Ethernet link Continuously lit when link is present. Green Figure 28: 450v 2x2 5/6 GHz SM/BHM/BHS, 5 GHz 450b Mid-Gain and High Gain SM/BHS diagnostic LEDs Chapter 2: System hardware...
  • Page 87 Table 54: 5 GHz High Gain and Mid-Gain 450b SM/BHS LED descriptions Status information provided Color when active SM/BHS in SM/BHS in Note Operating Aiming Mode Mode POWER Blue DC power Flashes Yellow during boot-up. Flashes Blue when operating. Always lit after 10-20 seconds of power on.
  • Page 88 Figure 29: 3 GHz 450b High Gain SM/BHS, 5 GHz 450b Retro SM/BHS and 5 GHz 450b Connectorised SM/BHS diagnostic LEDs Note The 3 GHz 450b has its status LEDs located beneath the cover behind the dish. During installation, the LEDs can be viewed by unclipping the rearmost door. Chapter 2: System hardware...
  • Page 89 Table 55: 3 GHz 450b High Gain SM/BHS LED descriptions Status information provided Color when SM/BHS in Operating SM/BHS in Aiming Note active Mode Mode Blue DC power Always lit after power on Red/Green/ Ethernet Link Flashes during data Orange transfer.
  • Page 90 Table 56: 5 GHz 450b Retro SM/BHS and 5 GHz 450b Connectorised SM/BHS LED descriptions Status information provided Color when active SM/BHS in Operating SM / BHS in Aiming Note Mode Mode Blue/Yellow DC power Always lit after power SYNC Green/Yellow Session status: This LED indicates...
  • Page 91 Color when active SM in "Operating" SM in "Aiming" Mode Notes Mode Blue: The radio has fully booted. Green Presence of sync These three LEDs Lit when the SM is in serve as a bar graph to sync with an AP. indicate the relative quality of alignment.
  • Page 92 Operating Mode Scanning: For hardware with 5, 6 and 8 LEDs: If the SM/BHS is not registered to AP/BHM, then these LEDs cycle on and off from left to right (SYN/1, SES/2, and GPS/3). For hardware with 3 LEDs: If the SM/BHS is not registered to AP/BHM, then SES/SYN session blinks yellow.
  • Page 93 The ODU is powered by a PoE injector, except for the 3 GHz PMP 450m model where power and data are supplied separately. All power injectors/power supplies in the Cambium Networks range are designed for indoor environments. The Cat 5e cable with RJ45 connectors is used to connect the power injector to the ODU and network terminating equipment.
  • Page 94 Model 802.3a 802.3a 802.3b N000900L001B N000900L00 N000000L03 N000000L14 C000000L14 C000065L00 N000000L05 1A -60W, 56 4B (AC) 54V Gigabit (15W) 100Base T (AC) – 30W, 56 -60W, 56V, V, 10GbE (AC+DC) – 240W (15W) - V DC 5GbE 100W obsolete 3 GHz 450m PMP 450 MicroPo...
  • Page 95 Power supply – PMP 450m Series The PMP 450m Series - 5 GHz AP supports powering on from the following power sources: AC+DC enhanced power injector (Power supply – PMP 450m Series) CMM5 56 V power and sync injector module with external 240 W or 600 W power supply Cambium cnMatrix switch PSU part numbers Table 59: PSU part numbers for PMP 450m AP (5/3 GHz)
  • Page 96 The PMP 450 Ruggedized High Gain Integrated Subscriber Module (Cambium part numbers C035045C014A and C036045C014A), while encapsulated in a 450i-type enclosure, requires 30 V DC power for proper operation. Using a 56 V DC power supply can cause damage to the device. Refer to the Cabling section for detailed information regarding the maximum cable lengths between the power injector and PMP/PTP 450i devices.
  • Page 97 Interface Function RJ45 socket for connecting Cat5e cable to network Power (Green) LED Power supply detection AC+DC enhanced power injector C000065L002C The AC+DC Enhanced power injector interfaces are shown in Figure 32 and described in Table Figure 32: AC+DC enhanced power injector interfaces Table 62: AC+DC enhanced power injector interface functions Interface Function...
  • Page 98 Interface Function RJ45 socket for connecting Cat5e cable to network Power - AC Indicates power is applied at the AC power input (green) LED Power - DC Indicates power is applied at the DC In port (green) LED Ethernet The Ethernet traffic detector is used exclusively with the PTP 650 and PTP 700 (yellow) LED families.
  • Page 99 Table 63: -48 V DC power injector interfaces Interface Function DC input 36 to 60 V, 2 A RJ45 sockets Two (Data In and data & power Out) LEDs Two (AC and port) Power supply – PMP/PTP 450b Series The PMP/PTP 450b Series support powering from the following powering sources: Gigabit Ethernet capable power supply –...
  • Page 100 Figure 34: -20 to 32 V DC power injector interfaces Table 64: Power injector interfaces Interface Function PSU/Ethernet -20 to 32 V DC, 2A PSU part numbers Table 65: PSU part numbers for PMP/PTP 450b SM Cambium description Cambium part number Gigabit Ethernet capable power supply -20 - 32 V DC, 15 W N000900L001C Power supply –...
  • Page 101 IEEE 802.3bt power injector Cambium cnMatrix switch Warning Always use an appropriately rated and approved AC supply cord-set in accordance with the regulations of the country where it is being used. Refer to the Cabling section for detailed information regarding the maximum cable lengths between the power injector and 450v devices.
  • Page 102 Figure 35: AC Power Injector interfaces- 5GbE Table 67: AC Power Injector interface functions- 5GbE Interface Function AC power in AC power input (main supply) RJ45 socket for connecting Cat5e cable to ODU RJ45 socket for connecting Cat5e cable to network Power (Green) LED Power supply detection AC Power Injector N000000L141A...
  • Page 103 Figure 36: AC Power Injector interfaces-10GbE Table 68: AC Power Injector interface functions-10GbE Interface Function AC power in AC power input (main supply) RJ45 socket for connecting Cat5e cable to ODU RJ45 socket for connecting Cat5e cable to network Power (Green) LED Power supply detection Power supply –...
  • Page 104 AC line cord that connects the outlet of the same (using IEC-60320 Type 5 connector). A list of available power supply cord options from Cambium Networks are given in PSU part numbers for PMP/PTP 450 Series.
  • Page 105 Power supply, 15 W or 30 W, 56 V with 1000BASE-T or GigE AC+DC enhanced power injector PoE midspan, 60 W, -48 V DC input CMM4/CMM5 with external 56 V power supply and CMM4/CMM5 to PMP 450i Series ODU cable (Dongle) CMM5 56 V power and sync injector module with external 240 W or 600 W power supply IEEE 802.3at power injector...
  • Page 106 Table 72: AC power injector interface functions Interface Function AC power in AC power input (main supply) RJ45 socket for connecting Cat5e cable to ODU RJ45 socket for connecting Cat5e cable to network Power (green) LED Power supply detection ODU mounting brackets and accessories The list of supported mounting brackets are provided in Table The Tilt bracket assembly is the recommended bracket for the AP, SM, or BH integrated units...
  • Page 107 Ethernet connection on the Main port, as well as the C000000L114A DC lightning protection unit kit for the DC PSU port. Cambium Networks does not recommend deploying gas discharge tube-based surge protection on PMP 450i, PMP 450b, or PMP 450 MicroPoP platforms.
  • Page 108 MicroPoP lightning arrester details By lowering the omni antenna (mast O.D. 2.125 inches) on the mast, resulting in a 0.5m higher position than the product, it is possible to achieve lightning protection. However, this adjustment negatively impacts the omni pattern, as depicted in Figure 39 by the orange trace.
  • Page 109 Figure 39: MicroPoP Omni antenna implementation pattern (Horizontal) Chapter 2: System hardware...
  • Page 110 Figure 40: MicroPoP Omni antenna implementation pattern (Vertical) Chapter 2: System hardware...
  • Page 111 Aux port can also be configured to provide Sync out. Cambium Networks provides a dedicated 3-meter accessory cable, N000000127A, designed for use with cnPulse. If a longer cable is needed, it is recommended to acquire a shielded outdoor 4-core cable and follow the wiring instructions provided in the table.
  • Page 112 Table 76: Connections for UGPS to 450b/450v Audio Jack Aux port UGPS RJ11 pin 3.5 mm TRRS jack Signal description GPS Sync in (1PPS) Ring 2 GPS serial data in Ring 1 GPS power out (+5 V DC) Shield/Ground GPS 0 V (return) For PMP 450b6, the AFC functionality requires the use of a certified external GPS receiver.
  • Page 113 Include a drip loop to shed water so that most of the water does not reach the connector at the device. Properly crimp all connectors. Use dielectric grease on all connectors to resist corrosion. Order Superior Essex type BBDGe cable from Cambium Networks (Table 78). Other lengths of this cable are available from Superior Essex.
  • Page 114 Table 79: SFP module kit part numbers Cambium description Cambium part number Single mode optical SFP interface per ODU 1G SFP-1G-LX* Multi-mode optical SFP interface per ODU 1G SFP-1G-SX 10G SFP+ SMF LR Transceiver SFP-10G-LR 10G SFP+ MMF SR Transceiver SFP-10G-SR * Cambium-branded single-mode optical SFP is suitable for 5 GHz 450m APs but is not recommended for 3 GHz 450m APs.
  • Page 115 Table 81: AUX port PoE cable pinout RJ45 pin Interface Ethernet description PoE Out description 1000BASE-T Ethernet with PoE In +TxRx0 –TxRx0 +TxRx1 –Ve –TxRx1 +TxRx2 Data only –TxRx2 +TxRx3 Data only –TxRx3 Note The PoE output on the AUX port provides power on 1, 2 (+Ve) and 3, 6 (-Ve) polarity. Aux port on 450i Table 82: Aux port PoE cable pinout RJ45 pin...
  • Page 116 220 ohm and 0.25 W. However, different resistor values can be used to optimize the audio signal level based on the characteristics of the headset and the ambient noise level. Figure 43: Alignment tone cable Table 83: Aux port PoE cable pinout RJ45 pin (Aux port) Signal description Serial component Jack socket (to jack plug of headset)
  • Page 117 RJ45 connectors are required for plugging Cat5e cables into ODUs, LPUs, PSUs, and other devices. Order RJ45 connectors and crimp tool from Cambium Networks. The ODU for 5 GHz 450m is supplied with one environmental sealing gland and 3 GHz 450m is supplied with two sealing glands for the drop cable.
  • Page 118 Figure 46: Breather vent Table 87: Breather vent part number Cambium description Cambium part number Breather Vent - PG16 size (Qty. 10) N000000L141A Ethernet cable testing This section describes the procedure for testing the RJ45 Ethernet cables used for Main and Aux port connectivity on 450i and 450m radios.
  • Page 119 Measure Approximate resistance Example between Wire 1 and wire 4 Wire 1 and wire 7 Wire 3 and wire 4 Wire 3 and wire 7 Wire 4 and wire 7 Note These figures must be indicative only rather than hard limits. The measurement must be done with a low-voltage DMM, not a high-voltage insulation tester.
  • Page 120 LPU and grounding kit are needed for the Aux drop cable. Kindly place an order for the kits from Cambium Networks, specifying the LPU and grounding kit part number. Table 89: LPU and grounding kit part number...
  • Page 121 Table 90: DC LPU and grounding kit contents LPUs EMC strain relief cable glands LPU grounding point nuts and washers U-bolts, nuts and washers for mounting LPUs ODU to top LPU ground cable (M6-M6), bolt and washers ODU to grounding system ground cable, bottom LPU ground 4-pin connector kits (4 kits, one is cable (2pcs, M6 and M10 lugs), bolt and washers shown below)
  • Page 122 One LPU and grounding kit (LPU and grounding kit contents) is required for the PSU drop cable connection to the ODU. If the ODU is to be connected to an auxiliary device, one additional LPU and grounding kit is required for the Aux drop cable. Order the kits from Cambium Network (DC LPU and grounding kit part number).
  • Page 123 This is crucial to mitigate fire risks and protect the equipment from damage. For each grounding point on the cable, it is necessary to have one grounding kit, specifically the cable grounding kit. You can order the cable grounding kits from Cambium Networks using the LPU and grounding kit part number.
  • Page 124 5 GHz horizontal and vertical polarization antenna for 90 degree sector 85009324001 5 GHz horizontal and vertical polarization antenna for 60 degree sector 85009325001 Note The LINKPlanner, a planning tool offered by Cambium Networks, provides an extensive and comprehensive list of antennas that are compatible with Cambium Products.
  • Page 125 ME or LSXL (not supplied by Cambium Networks). GPS synchronization Cambium Networks offers GPS synchronization to mitigate self-interference within the network. The Cluster Management Module (CMM) delivers Global Positioning System (GPS) synchronization to both the AP and all associated SM. Network operators can choose between UGPS and CMM solutions to select the option that best suits their environment.
  • Page 126 Support for Gigabit Ethernet (1000BaseT) Modular and scalable from 4 ports to 32 ports Direct +/- 48 V DC input (optional AC/DC power supplies are available from Cambium Networks) Uses Cambium Networks UGPS for a synchronization source Dual resilient power inputs...
  • Page 127 Figure 49: Cluster management: Scenario 1 Cluster management: Scenario 2 Table 97 illustrates a CMM5 Cluster Management scenario that includes four PMP 450i APs and four PMP 450 APs. Table 97: CMM5 cluster management scenario 2 Scenario Equipment Needed Features Four PMP 450i APs 56 V injector Gigabit Ethernet support...
  • Page 128 Figure 50: Cluster Management: Scenario 2 CMM5 Controller module The major features of the CMM5 Controller Module are: Auto-detect/control up to 8 power injectors Monitor SYNC/Power/GPS status Manage (up/down ports) Web (HTTPS) and SNMPv2/v3 management (SNMP on roadmap) 1U/ half-width rack-mount Figure 51: Controller Module CMM5 injector module...
  • Page 129 Note There are two different versions of the injector module: 56 V and 29 V. It is crucial to select the correct injector for the types of radios being powered. Both injectors use the same input power supplies and can be powered with +/- 48 V DC.
  • Page 130 CMM5 Power and Sync Injector 56 Volts Surge suppression Lightning suppression for each To Radios RJ45 Port Power Input voltage: + or - 48 V DC Input power consumption: 400 watts Output Voltage: + or - 55 V DC Output Current: 0 - 1.8 A per channel Output Power: 0 - 90 Watts per channel Cabinet temperature -40°...
  • Page 131 The CMM4/CMM5 is equipped with two DC power inputs: one operating at 29 V and the other at 56 V. It can efficiently power and synchronize both legacy 29 V products like the PMP 450 Series and 56 V products such as the PMP 450i Series simultaneously. When connecting the 29 V legacy products to CMM4/CMM5, a 29 V power supply must be connected.
  • Page 132 Table 100: CMM4/CMM5 power adapter cable pinout Plug J1 pin Jack J2 pin Screen Screen Note Pins 5 and 7 are wired in a cross-over configuration. CMM4/CMM5 (Cabinet with switch) The CMM4/CMM5, a cabinet with a switch, is designed to deliver consistent and reliable wireless broadband service.
  • Page 133 CMM4/CMM5 (Cabinet without switch) The CMM4/CMM5 includes all the functionality listed above, except for a built-in switch. This design choice allows the network operator the flexibility to use their preferred switch while still benefiting from the power and synchronization capabilities of the CMM4/CMM5. CMM3/CMMmicro The CMM3 or CMMmicro provides power, GPS timing, and networking connections for an AP cluster.
  • Page 134 Note A CMM3 cannot be used to power up a 450i or 450m Series ODUs. GPS Synchronisation for PMP 450b6 The requirements of the Automatic Frequency Coordination (AFC) system for operating in the 6 GHz band mandate the use of a certified GPS Receiver to obtain latitude, longitude, and altitude parameters. Supporting the AFC system, the 450b6 SM allows for the connection of an external GPS receiver via the 3.5mm Audio Jack Interface (N000045L004A: GPS puck kit for PMP 450b6).
  • Page 135 Mounting the GPS receiver Cabling the GPS Antenna Installing and connecting the GPS LPU Caution Prior to powering up of equipment, ensure that all cables are connected to the correct interfaces of the CMM4/CMM5 unit and the UGPS receiver module. Failure to do so may result in damage to the equipment.
  • Page 136 Mounting the GPS receiver To ensure proper installation of the GPS receiver, follow the manufacturer's instructions. You can mount the GPS receiver on either an external wall (GPS receiver wall installation) or a metal tower or mast (GPS receiver tower or mast installation) Figure 60: GPS antenna mounting Procedure 1: Mounting the GPS receiver...
  • Page 137 (http://www.cambiumnetworks.com/resource/pmp-synchronization-solutions). Installing and connecting the GPS LPU Install and ground the GPS drop cable LPU at the building (or cabinet) entry point, as described in Install the bottom LPU. Installing GPS Module for PMP 450b6 To install the GPS module for the PMP 450b6 device, follow the below steps: 1.
  • Page 138 3. Once the cable is secured, ensure that the GPS module is placed on the pole as shown in the below figure. Chapter 2: System hardware...
  • Page 139 450m/450i Series network migration. It specifies Cambium part numbers for 450 Platform Family components. Order PMP 450m Series, PMP/PTP 450i Series and PMP/PTP 450 Series ODUs from Cambium Networks. PMP 450m Table 101: 3 GHz PMP 450m Series ODU part numbers...
  • Page 140 PMP 450i Table 103: PMP 450i Series ODU part numbers - Connectorised Cambium description Superseded Sales Revised SKU suffix ODU model 450i Connectorised 5085CHH 5085CJH 450i Integrated 90° sector 5082JH 5082KH 450i Integrated High Gain directional 5092JH 5092KH 450i Connectorised ATEX/HAZLOC - ATEX CONTROLLED 5085CHH 5085CJH ITEM    ...
  • Page 141 Cambium description Superseded Sales Revised SKU suffix 3 GHz PMP 450i SM, Integrated High Gain Antenna C030045C002A 5 GHz PMP 450i Connectorised Subscriber Module C050045C001A* C050045C001B** 5 GHz PMP 450i SM, Integrated High Gain Antenna C050045C002A * Previous model end (April 2019)     ** Revised model starts (May 2019) Note The 450i SM does not have license keys.
  • Page 142 Cambium description Superseded Sales Revised SKU suffix 5 GHz PMP 450i Connectorised Access Point (IC),  C050045A017A C050045A017B ATEX/HAZLOC 5 GHz PMP 450i Integrated Access Point, 90° (IC),  C050045A018A C050045A018B ATEX/HAZLOC 5 GHz PMP 450i Connectorised Access Point (DES Only),  C050045A019A C050045A019B ATEX/HAZLOC 5 GHz PMP 450i Integrated Access Point, 90°...
  • Page 143 Cambium description Superseded Sales Revised SKU suffix 450i Integrated High Gain directional ATEX/HAZLOC - 5095HH 5095JH ATEX CONTROLLED ITEM 3 GHz PTP 450i END, Connectorised C030045B001A 3 GHz PTP 450i END, Integrated High Gain Antenna C030045B002A 3 GHz PTP 450i END, Connectorised (DES only) C030045B003A 3 GHz PTP 450i END, Integrated Access Point, 90 degree C035045B004A...
  • Page 144 Cambium description Superseded Sales Revised SKU suffix 450i Integrated 90° Sector ATEX/HAZLOC - ATEX 5085HH 5085JH CONTROLLED ITEM     450i Integrated High Gain directional ATEX/HAZLOC - ATEX 5095HH 5095JH CONTROLLED ITEM 5 GHz PTP 450i END, Connectorised (ROW), ATEX/HAZLOC  C050045B009A C050045B009B 5 GHz PTP 450i END, Integrated High Gain Antenna (ROW),  C050045B010A C050045B010B...
  • Page 145 PMP 450 Table 108: PMP 450 Series ODU part numbers Cambium description Cambium part number PMP 450 AP (Access Point) 2.4 GHz PMP 450 Connectorised Access Point C024045A001A 2.4 GHz PMP 450 Connectorised Access Point (No Encription) C024045A003A 3.5 GHz PMP 450 Connectorised Access Point C035045A001A 3.5 GHz PMP 450 Connectorised Access Point (No Encription)
  • Page 146 Cambium description Cambium part number 2.4 GHz PMP 450 Subscriber Module, 10 Mbps C024045C002A 2.4 GHz PMP 450 Subscriber Module, 20 Mbps C024045C003A 2.4 GHz PMP 450 Subscriber Module, uncapped C024045C004A 2.4 GHz PMP 450 Connectorised Subscriber Module, 4 Mbps C024045C005A 2.4 GHz PMP 450 Connectorised Subscriber Module, 10 Mbps C024045C006A...
  • Page 147 Cambium description Cambium part number 5 GHz PMP 450 Connectorised Subscriber Module, 10 Mbps C054045C006B 5 GHz PMP 450 Connectorised Subscriber Module, 20 Mbps C054045C007B 5 GHz PMP 450 Connectorised Subscriber Module, uncapped C054045C008B 5 GHz PMP 450d Subscriber Module, 20 Mbps – 4-pack C054045H013B 5 GHz PMP 450d Subscriber Module, uncapped –...
  • Page 148 C054045B006A PMP/PTP 450/450i Series Accessories Table 110: PMP/PTP 450/450i Series Accessories Cambium description Cambium part number PMP 450 AP antenna options 900 MHz 65° sector antenna (Dual slant) N009045D001A 900 MHz 12 dBi gain directional antenna (Dual slant) N009045D003A 2.4 GHz Dual slant antenna for 60° sector C024045D601A 3.5 GHz and 3.6 GHz dual slant antenna for 90°...
  • Page 149 Cambium description Cambium part number Power supply, 60 W, 56 V with Gbps support N000065L001B AC+DC enhanced power injector C000065L002C Line cord, Fig 8 – US N000065L003A Line cord, Fig 8 – UK N000065L004A Line cord, Fig 8 – EU N000065L005A PoE midspan, 60 W, -48 V DC input N000000L036A...
  • Page 150 Cambium description Cambium part number Cable, UL power supply cord set, EU N000900L008A Cable, UL power supply cord set, UK N000900L009A 53CM offset, reflector dish kit, 4PK HK2022A Alignment tool headset ACATHS-01A IP67 doors and glands for 450b High Gain, 4-pack N000000L135A Accessories Surge suppressor (30 V DC)
  • Page 151 Cambium description Cambium part number Extended warranty PMP 450 Platform AP extended warranty, 1 additional year SG00TS4009A PMP 450 Platform AP extended warranty, 2 additional years SG00TS4017A PMP 450 Platform AP extended warranty, 4 additional years SG00TS4025A PMP 450 Platform SM extended warranty, 1 additional year SG00TS4010A PMP 450 Platform SM extended warranty, 2 additional years SG00TS4018A...
  • Page 152 Note Some models may have a part number ending in “A” instead of “B”. This indicates a previous manufacturing location and does not affect the fit, form, or function of the radio. Chapter 2: System hardware...
  • Page 153 Chapter 3: System Planning This chapter provides information that helps you plan a PMP/PTP 450 Platform link. The chapter covers the following topics: Typical deployment Site planning Hazardous locations Radio frequency planning Link planning Planning for connectorised units Data network planning Network management planning Security planning Remote AP deployment...
  • Page 154 Figure 61: Mast or tower installation Chapter 3: System Planning...
  • Page 155 Figure 62: Wall installation Chapter 3: System Planning...
  • Page 156 Figure 63: Roof installation Chapter 3: System Planning...
  • Page 157 Figure 64: GPS receiver wall installation Chapter 3: System Planning...
  • Page 158 Figure 65: GPS receiver tower or mast installation Site planning This section describes factors to be considered when choosing sites for PMP or PTP radios, power supplies, CMM4/CMM5 and UGPS. Site selection for PMP/PTP radios When selecting a site for the ODU, consider the following factors: Height and location to achieve the best radio path.
  • Page 159 Power supply site selection When selecting a site for the ODU power supply, consider the following factors: Indoor location with no possibility of condensation, flooding or high humidity. Availability of a mains electricity supply. Located in an environment where it is not likely to exceed its operational temperature rating, allowing for natural convection cooling.
  • Page 160 designated as Zone B, indicating it falls within the protection zone. Likewise, if the sphere rests on two finials, the area underneath is also considered part of the protection zone. Figure 66: Rolling sphere method to determine the lightning protection zones Zone A: In this zone, a direct lightning strike is possible.
  • Page 161 2. Compliance with Safety Distances: Maintain adherence to calculated safe separation distances for personnel. 3. Lightning Protection and Structure Height: Position the equipment below the top of the supporting structure (e.g., tower, mast, or building) or its lightning air terminal. 4.
  • Page 162 Up to 200 mph (322 kph) for PMP 450m Series – AP 5 GHz Up to 124 mph (200 kph) for PMP 450m Series – AP 3 GHz Up to 124 mph (Integrated) for PMP/PTP 450i – all models 3 GHz and 5 GHz Up to 200 mph (Connectorised) for PMP/PTP 450i –...
  • Page 163 Table 113: PMP/PTP 450i Series wind loading (Newton) Type of ODU Max surface area (square Wind speed (kilometer per hour) meters) Connectorised 0.035 Directional Yagi antenna - 900 0.025 External 65º sector antenna – 900 0.253 1058 Directional antenna – 3.x GHz Integrated 90º...
  • Page 164 Table 116: PMP/PTP 450 Series wind loading (Newton) Type of ODU Max surface area (square Wind speed (kilometer per hour) meters) External 60º sector antenna – 2.4 0.27 1019 1129 GHz AP External 60º sector antenna – 5 0.066 GHz AP External 90º...
  • Page 165 Table 119: PMP 450b Series wind loading (lb force) Type of ODU Max surface area (square feet) Wind speed (miles per hour) Integrated Mid-Gain 0.33 Integrated High Gain 1.41 Hazardous locations Confirm that the ODUs are not exposed to hazardous gases, as defined by HAZLOC (USA) and ATEX (Europe) regulations.
  • Page 166 Bond the drop cable shield to the building grounding system at its upper entry point (typically on the roof). Bond the drop cable shield to the building grounding system at the entry point to the equipment room. Lightning Protection Unit (LPU) location Select a location for the bottom LPU that fulfills the following criteria: Ensure that the bottom LPU can be connected to the drop cable from the ODU.
  • Page 167 The UK and some other European countries have allocated a portion of the 5.8 GHz band to Road Transport and Traffic Telematics (RTTT) systems. The number and identity of restricted channels within a given regulatory band depend on the channel bandwidth and channel raster selected.
  • Page 168 Foliage from trees and plants within the Fresnel Zone can contribute to signal loss. The degree of loss may vary based on seasonal foliage density, moisture content, and other factors such as wind. If it's necessary to transmit through foliage, consider conducting frequent and regular link tests to assess and mitigate the impact.
  • Page 169 Co-location between Cambium 3 GHz PMP devices and LTE and 5G-NR devices When co-locating deployments in the same geographical area it is important to select the correct system parameters in order to avoid interference. Cambium PMP, LTE, and 5G-NR are all TDD systems, which means that the same frequency resources are used both in the downlink and in the uplink but multiplexed in time.
  • Page 170 Table 121: LTE frame configuration options Configuration Frame time Subframe number 5 ms 5 ms 5 ms 10 ms 10 ms 10 ms 5 ms Frame length TDD systems can be co-located only if they have the same frame length. Figure 67 shows why it is not possible to co-locate APs supporting mismatched frame lengths.
  • Page 171 Since in the Cambium PMP system all frames have the same downlink/uplink structure, the Cambium PMP system cannot be co-located with an LTE system operating with Frame Configuration 6. In the Cambium PMP UI the frame length is selected in the Configuration > Radio > Radio Configuration page under Frame Period, as shown in Chapter This parameter must be configured to 5 ms.
  • Page 172 align to the beginning of subframe 4, not subframe 0. With this shift, the sequence of subframes in the LTE frame becomes D, D, S, U, U, which is the same structure as the Cambium PMP frame (downlink, turnaround time, uplink). When selecting one of the LTE Frame Configuration options from the Co-located Frame Configuration Option drop-down menu, a shift is applied to the Cambium PMP frame to correctly line up with the selected LTE frame.
  • Page 173 Once the LTE Frame Configuration is selected from the drop-down menu, the LTE downlink and uplink times are defined. The Cambium PMP frame times are determined by the following configuration parameters: Channel bandwidth: This parameter defines the amount of spectrum allocated for communication in the sector.
  • Page 174 Starting with Release 22.0, the radio automatically adjusts the duty cycle to allow co-location, but the co- location tool is described here because it can still be used as a reference ahead of time, to know what to expect in terms of the radio’s calculations of the duty cycle. The PMP –...
  • Page 175 Automatic duty cycle adjustment Starting in Release 22.0, the user no longer needs to use the PMP-LTE co-location tool. The AP now automatically adjusts the allowed range of Downlink Data percentage (duty cycle) on the AP’s Configuration > Radio page to ensure no overlap with the LTE system occurs. Figure 76: Example of co-location Downlink Data range and additional LTE parameters Figure 76...
  • Page 176 5G-NR frame configuration options The 5G-NR standard offers a lot of flexibility in terms of frame structure options. The PMP system will first allow co-location with some of these options, and more can be added over time as needed. Currently, co-location with these 5G-NR frame options is supported: DDDSU Frame length: 2.5 ms Number of full DL slots: 3...
  • Page 177 Disable 5G-NR Frame DDDSU Co-location options with 2.5 ms frame Figure 77: If the Frame Period is selected as 5 ms, the options in the Co-located Frame Configuration Option are: Disable LTE Frame Configuration 0 LTE Frame Configuration 1 LTE Frame Configuration 2 5G-NR Frame DDDDDDDSUU Figure 78: Co-location options with 5 ms frame...
  • Page 178 However, other parameters affect the PMP frame structure, and the user could adjust some of those parameters instead of or in addition to just changing the duty cycle. To help with the selection of system parameters, Cambium Networks offers a PMP – 5G-NR co-location tool, available at https://support.cambiumnetworks.com/files/colocationtool/.
  • Page 179 Figure 81: Example of PMP – 5G-NR co-location with invalid parameters Using the tool, parameters can be updated to find a set of values that allows for co-location. For example, changing the duty cycle of the PMP AP from 75% to 80% makes both equations true, and there is no longer an overlap between one AP transmitting and the other receiving.
  • Page 180 different pattern of channel assignments. Figure 84: Example layout of 16 AP sectors (ABCD), 90-degree sectors An example of frequency channel assignments is provided in Table 122. Table 122: Example 5.8 GHz 4-channel assignment by access site Symbol Frequency 5.740 GHz 5.780 GHz 5.760 GHz 5.800 GHz...
  • Page 181 5.740 GHz 5.760 GHz 5.780 GHz Considerations on back-to-back frequency reuse When considering back-to-back frequency reuse, Cambium Networks recommends employing the ABAB frequency reuse pattern, (Figure 85 in the example layout of 16 AP sectors (ABCD) with 90-degree sectors. This approach allows for the creation of a base site with four sectors using only two frequencies, which is particularly effective in situations where high capacity is needed within a limited spectrum.
  • Page 182 4. Absence of reflecting objects: There must be no large reflecting objects within the exclusion zones defined in this section. 5. Line-of-Sight (LoS): SMs must not have a typical line-of-sight to an interfering base station. In the example layout of 16 AP sectors, the worst-case range ratio is 5:1, providing only 14 dB protection in LoS, which falls short of the required 30 dB for 256QAM capability.
  • Page 183 Assuming that the potential reflecting object is visible to both the AP and the SM, several factors come into play, including object sizes and specific zones where we can anticipate interference that may affect throughput when both Sector 1 and Sector 3 are transmitting data. The Sector Antenna and cnMedusa Antenna diagrams depict regions labeled as A, B, C, and D.
  • Page 184 Chapter 3: System Planning...
  • Page 185 Figure 88: cnMedusa Antenna Chapter 3: System Planning...
  • Page 186 Both the Sector Antenna and cnMedusa Antenna have three figures with measurements scaled in meters, assuming a typical down tilt of 4°. In each set of figures: The top figure illustrates the clearances required at zero azimuth. The middle figure shows the scaling required in relation to the top Figure to account for variations in the azimuth of the reflecting object.
  • Page 187 PMP 450m installation recommendations For optimal performance, it is advisable to maintain a clearance zone around the mast. The size of this clearance zone varies depending on the surrounding environment and the down tilt of the antenna. In situations where the mast is surrounded by metal structures, a larger clearance is necessary compared to areas with foliage.
  • Page 188 By thoroughly evaluating these factors, you can make informed decisions about the link feasibility, antenna placement, and radio frequency band selection for your deployment. This helps optimize performance and minimizes the impact of obstacles on your wireless network. Path loss Path loss is a critical factor that measures the attenuation of a radio signal as it travels between two points in a wireless link.
  • Page 189 Seasonal Fading (dB) Equipment Capability (dB) Calculating Link Loss The link loss is the total attenuation of the wireless signal between two point-to-multipoint units. The link loss calculation is presented below: Link Loss (dB) = Transmit power of the remote wireless unit (dBm) - Tx Cable loss (dB) - Received power at the local unit (dBm) - Rx cable loss (dB) + Antenna gain at the remote unit (dBi) + Antenna gain at the local unit (dBi).
  • Page 190 The Rx signal level calculation presumes that a clear line of sight is established between the transmitter and receiver and that no objects encroach in the Fresnel zone. Calculating fade margin Free space path loss is a significant factor in determining the received (Rx) signal level. The Rx signal level, in turn, plays a crucial role in calculating the system's operating margin, also known as the fade margin.
  • Page 191 Calculating RF cable length (5.8 GHz FCC only) The FCC approval for the 5.8 GHz band for this product is based on tests conducted with a cable loss between the ODU and antenna not less than 1.2 dB. If the cable loss falls below 1.2 dB when using a 1.3 m (4 ft) diameter external antenna, the connectorised 450 Platform Family may exceed the maximum radiated spurious emissions allowed under FCC 5.8 GHz rules.
  • Page 192 DNS Client The DNS Client serves the purpose of resolving names for management servers within the operator's management domain, as described in the Cambium Networks Management Domain. This feature facilitates hostname configuration for various servers, including NTP servers, Authorization Servers, DHCP relay servers, and SNMP trap servers.
  • Page 193 Network Address Translation (NAT) NAT, DHCP Server, DHCP Client and DMZ in SM The system provides NAT (network address translation) for SMs in the following combinations of NAT and DHCP (Dynamic Host Configuration Protocol): NAT Disabled NAT with DHCP Client (DHCP selected as the Connection Type of the WAN interface) and DHCP Server NAT with DHCP Client (DHCP selected as the Connection Type of the WAN interface) NAT with DHCP Server...
  • Page 194 Each module necessitates an IP address within the network, which is exclusively designated for management purposes. For security considerations, you must adhere to one of the following practices: 1. Assign a non-routable IP address. 2. Assign a routable IP address only when a firewall is present to safeguard the module. Allocate IP addresses to computers and network components using either static or dynamic IP addressing methods.
  • Page 195 Unique MAC address IP address of 169.254.1.1 Subnet mask of 255.255.0.0 Network gateway address of 169.254.0.0 To ensure security, assign an IP address for each radio and CMM4/CMM5 that aligns with your network's IP addressing plan and cannot be accessed from the Internet. It's important to note that IP addresses within the following ranges are not routable from the Internet, regardless of whether a firewall is configured: 10.0.0.0 –...
  • Page 196 The Translation Bridging feature can be enabled or disabled through the General page of the Configuration web page in the AP. When this feature is disabled, the configuration of the "Send Untranslated ARP" parameter does not impact packet forwarding, as all packets are forwarded without modification (with the source MAC address intact).
  • Page 197 SM membership in VLANs With the supported VLAN functionality, the radios determine bridge forwarding on the basis of not only the destination MAC address, but also the VLAN ID of the destination. This provides flexibility in how SMs are used: Each SM can be a member in its own VLAN.
  • Page 198 any combination of with a VID not Local Egress VLAN in the parameter settings membership table Priority on VLANs (802.1p) The radios can prioritize traffic based on the eight priorities described in the IEEE 802.1p specification. When the high-priority channel is enabled on a SM, regardless of whether VLAN is enabled on the AP for the sector, packets received with a priority of 4 through 7 in the 802.1p field are forwarded onto the high- priority channel.
  • Page 199 Network management planning This section describes how to plan for 450 Platform Family links to be managed remotely using SNMP. Planning for Simple Network Management Protocol (SNMP) operation In SNMP , Cambium modules provide various SNMP traps to notify a Network Management System (NMS) about specific events or conditions.
  • Page 200 Note The proprietary Management Information Bases (MIBs) for the 450 Platform Family are available for download from the support website of Cambium Networks. These MIBs are essential for managing and monitoring Cambium modules using SNMP (Simple Network Management Protocol). If you need access to these MIBs, you can refer to the support website or contact Cambium Networks for assistance on where to find and download them.
  • Page 201 AES (Advanced Encryption Standard): An over-the-air link encryption option that uses the Rijndael algorithm and 128-bit keys to establish a higher level of security than DES. AES products are certified as compliant with the Federal Information Processing Standards (FIPS 197) in the U.S.A. The default encryption setting for 450 Platform Family ODU is None.
  • Page 202 Read Only System Administrator Determine the security level for each security role. Three security levels are available: No authentication, no privacy Authentication, no privacy Authentication, privacy If authentication is necessary, specify the protocol (available: MD5). If privacy is used, specify the protocol (available: cbc-des). Managing module access by passwords By default, each module comes with a preconfigured administrator-level account named "root,"...
  • Page 203 To enhance security from the factory default state, configure passwords for both the root and admin accounts at the ADMINISTRATOR permission level using the Account > Change Users Password page. If you choose to configure only one of them, be aware that the other account still have no password for access, posing a security risk.
  • Page 204 Protocol and port filtering is set per AP/SM/BH. Except for filtering of SNMP ports, filtering occurs as packets leave the AP/SM/BH. For example, if SM is configured to filter SNMP, then SNMP packets are blocked from entering the SM and, thereby, from interacting with the SNMP portion of the protocol stack on the SM. Port filtering with NAT Enabled When NAT is enabled on the SM/BHS, port filtering can be applied to user-defined ports.
  • Page 205 SNMP Filter Direction – Upstream and Downstream ARP (Address Resolution Protocol) Figure 92: Categorical protocol filtering Here are example situations where protocol filtering is configured when NAT is disabled: 1. If you block a subscriber from using only PPPoE and SNMP, the subscribers still have access to all other protocols and all ports.
  • Page 206 Protocol Selected Port Filtered (Blocked) User Defined Port 1.3 User defined ports for filtering UDP and TCP IPv4 Multicast Block IPv4 packet types except other filters defined IPv6 Multicast Block IPv6 packet types except other filters defined Filter all Ethernet packet type 806 Upstream Applies packet filtering to traffic coming into the FEC interface Downstream...
  • Page 207 To configure the SM Isolation feature in the AP, navigate to the General tab of the Configuration web page and select one of the following options from the drop-down menu: 1. Disable SM Isolation (the default selection): This permits full communication between SMs. 2.
  • Page 208 DHCP option 81 DHCP Option 81 allows DHCP-enabled clients to register and update DNS resource records (PTR and A records) through the DHCP server. This option allows clients to provide their fully qualified domain name (FQDN) and specify how the DHCP server must handle DNS dynamic updates on their behalf. The hostname is constructed as SiteName.DomainName under the following conditions: If SiteName is not provided (default), the MAC address is used instead.
  • Page 209 Figure 93: Remote AP deployment The co-located SM receives data in one channel, and the remote AP must redistribute the data in a different channel. The two channels need to have a frequency gap equal to at least two times the used channel bandwidth.
  • Page 210 a higher-level 5 GHz AP. In such cases, the 900-MHz wavelength demonstrates its effectiveness in overcoming obstructions, particularly in environments with dense foliage over short distances, effectively addressing the issue of foliage penetration. An example of this use case is shown inFigure 94 The 5 GHz AP operates as a PMP 450i AP in the 5.8 GHz band, utilizing a 20 MHz channel with a 2.5 ms frame.
  • Page 211 SMs with their corresponding APs. Table 131: Passing Sync in an Additional Hop Devices PMP 450 AP/BHM PMP 450i AP/BHM PMP 450m AP PMP 450 SM/BHS PMP 450i SM/BHS Examples of passing sync over cable are shown in Table 131.
  • Page 212 Figure 95: Remote AP wired to SM that also serves a customer If the SM simply serves as a relay, you must use a straight-through RJ-45 female-to-female coupler and wire the SM to the remote AP as shown in Chapter Remote AP wired to SM that serves as a relay Figure 96: Chapter 3: System Planning...
  • Page 213 Passing Sync signal Passing sync in a single hop Network sync can be passed in a single hop in the following network designs: Design 1 A CMM provides sync to a co-located AP. This AP sends the sync over the air to SMs. Design 2 A CMM provides sync to a co-located BH timing master.
  • Page 214 Figure 97: Additional link to extend network sync, Design 3 Design 4 A CMM provides sync to a co-located AP. This AP sends the sync over the air to an SM. This SM delivers the sync to a co-located BHM. This BHM passes the sync in the additional link over the air to a BHS.
  • Page 215 Design 5 A CMM provides sync to a co-located BHM or the BHM generates timing. This BHM sends the sync over the air to a BHS. This BHS delivers the sync to a co-located AP. This AP passes the sync in the additional link over the air to SMs. This design is illustrated in Figure Additional link to extend network sync, Design 5...
  • Page 216 4. Set the Sync Output to Aux Port parameter on the Configuration page of the co-located AP or BH timing master to Disabled. 5. Set the UGPS Power parameter on the Configuration page of the co-located AP or BH timing master to Disabled.
  • Page 217 Chapter 4: Preparing for installation This chapter describes how to stage and test the hardware for a 450 Platform family series. The chapter covers the following topics: Safety Preparing for installation Testing system components Configuring Link for Test Safety Hazardous locations Warning When installing the PMP/PTP 450i ATEX/HAZLOC product variants in hazardous locations, follow the instructions contained in the PMP/PTP 450i Series Hazardous Location Guide...
  • Page 218 External cables Use outdoor rated cables for connections that will be exposed to the outdoor environment. Install Cambium recommended cables. Safety may be compromised if outdoor rated cables are not used for connections that will be exposed to the outdoor environment. For outdoor copper Cat5e Ethernet interfaces, always use Cat5e cable that is gel-filled and shielded with copper-plated steel.
  • Page 219 Grounding cables must not be installed with drip loops. Grounding conductors must be securely fastened. Braided grounding conductors must not be used. Approved bonding techniques must be used for the connection of dissimilar metals. Ensure that the installation meets the requirements defined in Grounding and lightning protection on page 1.
  • Page 220 If the units are to be pre-configured during staging, the safety precautions below MUST be observed. Preparing personnel In no event shall Cambium Networks be liable for any injury or damage caused during the installation of the Cambium 450 Platform Family ODU.
  • Page 221 Carefully unpack the equipment, verify that all the components have arrived as per order and are in good condition. Save all packaging materials for equipment transportation to the installation site. Preparing the ODU After the equipment is unpacked, the units may be configured for staging tests. Use either of two methods to configure an AP/BHM: Use the Quick Start feature of the product (via GUI menu Quick Start) Manually set each parameter...
  • Page 222 Table 132: 5/6 GHz 450b BHM LED descriptions Color when Status Notes active information provided POWER Blue DC power Always lit after 10-20 seconds of power on. SYNC Green Presence of sync Yellow Unused Pulse of sync Lit when the BHM is getting a sync pulse from a GPS source goes along with SYNC.
  • Page 223 Equipment to Be Tools Required Installed AP or BHM or BHS 13 mm Spanner Wrench (or Ratchet Spanner Wrench) Pair Antenna Used for connecting the antenna (sector or omni for AP, or directional for BH) base to the pole/mast mounting bracket Self-amalgamating and PVC Tape Used for weatherproofing N-type connections N-type Torque Wrench (not required but recommended)
  • Page 224 Include a 2-ft (0.6-m) service loop on each end of the cable to allow for thermal expansion and contraction and to facilitate terminating the cable again when needed. Include a drip loop to shed water so that most of the water does not reach the connector at the device.
  • Page 225 Aux port pinout Table 136: Aux port pinout RJ45 pin Description +TxRx0 –TxRx0 +TxRx1 GPS power out, Alignment tone out, GPS data out GPS data in –TxRx1 GPS 0v GPS Sync in RJ-45 Pinout for straight-through Ethernet cable Figure 102: Straight-through Ethernet Cable Table 137: RJ-45 pinout for straight-through Ethernet cable Signal...
  • Page 226 RJ-45 Pinout for crossover Ethernet cable Crossover Ethernet Cable Figure 103: Table 138: RJ-45 pinout for crossover Ethernet cable Connection 1 Connection 2 Signal Pair Color Signal Pair Color TP1+ White/orange stripe TP2+ White/green stripe TP1- Orange solid TP2- Green solid TP2+ White/green stripe TP1+...
  • Page 227 Table 139: AP/BHM to UGPS cable pinout 450i Series AP RJ 45 UGPS RJ 12 Connector Connector Connector 8 on RJ 45 5 on RJ 45 4 on RJ 12 4 on RJ 45 3 on RJ 12 7 on RJ 45 6 on RJ 12 1 on RJ 12 Alignment tone cable (for PMP/PTP 450i)
  • Page 228 Figure 106: RJ-12 pinout for the default plug Configuring Link for Test It is important to stage the AP/BHM and SM/BHS units first to verify proper registration before deploying the modules to the site. To begin configuring the modules for test, see the sections below: Configuring the management PC To configure the local management PC to communicate with the AP, SM, BHM or BHS, proceed as follows:...
  • Page 229 Procedure 3 Bypassing browser proxy settings to access module web pages Launch Microsoft Internet Explorer Select Tools, Internet Options, Connections, LAN Settings. Alternate web browser menu selections may differ. Uncheck the Use a proxy server box. In the address bar of your browser, enter the IP address of the AP/BHM. (For example, enter http://169.254.1.1 to access the AP/BHM through its default IP address).
  • Page 230 Chapter 5: Installation This chapter describes how to install and test the hardware for a 450 Platform family series. The chapter covers the following topics: ODU variants and mounting bracket options Mount the ODU, LPU and surge suppressor Installation Installing external antennas to a connectorised ODU Installing ODU Installing the AC Power Injector Supplemental installation information...
  • Page 231 Mount the ODU, LPU and surge suppressor To install the ODU and top LPU, use the following procedures: Attach ground cables to the ODU Mount the ODU on the mast Mount the top LPU Mount the Surge Suppressor Attach ground cables to the ODU PMP 450m Series –...
  • Page 232 Tighten the Ground post screws. Securely connect the copper wires to the grounding system (Protective Earth) and the LPU or Gigabit Ethernet Surge Suppressor according to applicable regulations. PMP 450 AP Fasten an AWG 10 (or 6mm ) copper ground cable to each...
  • Page 233 PMP 450 SM Fasten an AWG 10 (or 6mm ) copper ground cable to each ODU grounding point using the M6 (small) lugs Tighten the Ground post locking nut in the copper wire Securely connect the copper wire to the grounding system (Protective Earth) according to applicable regulations.
  • Page 234 Figure 107: PMP 450 900 MHz SM grounding Mount the ODU on the mast PMP 450m Series – AP See - PMP 450m Series – 5 GHz AP for Installation for an integrated ODU Remove the rear bracket strap from upper and lower brackets of Attach the upper and lower bracket of ODU to the mount point by closing the rear strap around the pole Secure the four-serrated flange M8 nuts by applying 10 Nm...
  • Page 235 PMP/PTP 450i Series – AP/SM/BH, PMP 450 3 GHz Ruggedized SM Caution Do not reverse the bracket clamp, as this arrangement may lead to failure of the assembly. Do not over-tighten the bolts as this may lead to failure of the assembly. Fix the mounting plate to the back of the ODU using the four bolts, and spring and plain washers provided.
  • Page 236 Loosen the adjuster wingnut on the bracket and set the required SM tilt angle. Retighten the adjuster wingnut by hand to secure the SM at the chosen angle. PMP 450b High Gain – IP55 Version The 450b High Gain unit is supplied as an IP55 version from Q4 2019. Follow the assembly instructions below for the IP55 version.
  • Page 237 Snap in the center feed tube (radio) to the assembly. Tighten the center feed tube lock screw to a maximum of 5 Nm. Do not overtighten to avoid damaging the feed tube. Assemble the pole bracket to the Rear housing bracket, using the M8 bolts Chapter 5: Installation...
  • Page 238 Slide the cover onto the body of the radio, ensuring that the two sliding rails engage with the slots in the dish body. Attach and tighten the two cover screws to the body. Tighten to 5 Nm torque. Unclip the door nearest the dish by squeezing at the two thumb marks.
  • Page 239 Use a tie wrap to secure the Ethernet cable to center post of the cover. On the pole bracket, loosen the M8 nuts to remove outer clamp. Slip clamp over pole and tighten M8 nuts by applying 8 Nm torque. Do not over tighten to prevent aligning the dish.
  • Page 240 Locate an IP55 cover from the dish kit. Unclip the rear door and locate the breakout. Use pincers to break out the piece of plastic and trim with a sharp blade. Check that synchronization cable fits the opening. Chapter 5: Installation...
  • Page 241 Assemble unit as in steps 1 to 8 above. Connect the synchronization cable to the rear 3.5 mm jack socket and replace the door. Continue with steps 9 and 10 above ensuring both cables are secured to the center post with a tie wrap.
  • Page 242 Remove the cable gland from bottom cover. Feed the RJ45 cable though the gland, bottom cover and connect to the radio. Keep part loose and screw gland to the bottom cover. Audio cable is not shown in the figure. Chapter 5: Installation...
  • Page 243 Tighten gland, bottom cover screws and connect to the radio. On the pole bracket, loosen the M8 nuts to remove outer clamp. Slip clamp over pole and tighten M8 nuts by applying 8 Nm torque. Do not over tighten to prevent aligning the dish.
  • Page 244 2. Secure pole mounting bracket to the radio with M8 nut and bolt by applying 3.0 Nm torque. 3. Insert hose clamps through the pole mounting bracket and attach to pole by applying 3.0 Nm torque. Chapter 5: Installation...
  • Page 245 4. Remove the cable gland from bottom of the radio. Feed the RJ45 cable though the gland, bottom cover and connect to the radio. PMP 450 MicroPoP - Sector 1. Assemble the pole mounting bracket to the radio with two screws. Chapter 5: Installation...
  • Page 246 2. Secure pole mounting bracket with M8 nut and bolt by applying 3.0 Nm torque. 3. Insert hose clamps through pole mounting bracket and clamp to pole by applying 3.0 Nm torque. Chapter 5: Installation...
  • Page 247 4. Remove the cable gland from bottom of the radio. Feed the RJ45 cable though the gland, bottom cover and connect to the radio. 5. Align radio to required angle by tilting up and down. The maximum radio tilting angle is ±40°, with an incremental of 10°.
  • Page 248 PMP 450 MicroPoP - Connectorised 1. Assemble the pole mounting bracket to the radio with two screws. 2. Secure pole mounting bracket to the radio with M8 nut and bolt by applying 3.0 Nm torque. 3. Insert hose clamps through the pole mounting bracket and attach to pole by applying 3.0 Nm torque.
  • Page 249 4. Remove the cable gland from bottom of the radio. Feed the RJ45 cable though the gland, bottom cover and connect to the radio. Chapter 5: Installation...
  • Page 250 PMP 450b Retro Pole Mount 1. Insert hose clamps on the device bracket and attach to the pole by applying 3.0 Nm torque. 2. Release the bottom cap and insert RJ45 cable on the bottom of the device. Chapter 5: Installation...
  • Page 251 3. Place the cap back on the device after the cable installation. Chapter 5: Installation...
  • Page 252 Dish Mount 1. Slide the device into the dish slot as shown in the below figure. 2. Insert hose clamps on the device bracket and attach to the dish by applying 3.0 Nm torque. Chapter 5: Installation...
  • Page 253 3. Release the bottom cap and insert RJ45 cable on the bottom of the device. 4. Place the cap back on the device after the cable installation. Chapter 5: Installation...
  • Page 254 450v AP 1. Attach the brackets to the antenna and radio with a torque of 5 Nm torque. Chapter 5: Installation...
  • Page 255 2. Attach the pole mounting brackets to the radio. Fully tighten the top screws with 5 Nm torque, and keep the vertical screws loosened. Tighten the loosened screws (3 Nm torque) later during angle adjustment. Chapter 5: Installation...
  • Page 256 3. Fit the nuts for pole mount loosely, and avoid tightening them. Chapter 5: Installation...
  • Page 257 4. Adjust the brackets and tighten the nuts onto the pole mount. Chapter 5: Installation...
  • Page 258 5. Tighten the nuts onto the pole mount with 5 Nm torque. Chapter 5: Installation...
  • Page 259 6. Connect all the ports and secure the cable glands. Chapter 5: Installation...
  • Page 260 7. Slightly loosen the bolt, adjust the angle, and then tighten to 5 Nm torque. Chapter 5: Installation...
  • Page 261 450v SM/BHM/BHS (4X4) 1. Assemble the subreflector with the dish using the screws and apply 1.6 Nm torque. Chapter 5: Installation...
  • Page 262 2. Connect the L bracket to the dish using screws. Apply 6 Nm torque, ensuring alignment with the subreflector. You can attach the L bracket to the dish, either on the left-hand side (Option 1) or the right-hand side (Option 2) depending on the pole's location. Chapter 5: Installation...
  • Page 263 Chapter 5: Installation...
  • Page 264 3. Assemble the pole mount bracket. Tighten the first two screws with 5 Nm torque. Keep the second set of screws loosely mounted for attachment to the pole later. 4. Attach the pole mount bracket to the L bracket with 1 Nm torque. Tighten it further after angle adjustments.
  • Page 265 5. Attach the radio to the assembled pole and L bracket with the provided screws, applying 6 Nm torque. 6. Tighten the pole mount attachment with 10 Nm torque (Previously instructed to be loosely tightened). The recommended pole diameter is 40–70 mm, and it must not be less than 35 mm in diameter.
  • Page 266 7. Connect all the ports and secure the cable glands. Chapter 5: Installation...
  • Page 267 8. Align the dish and tighten the angle adjustments with 8 Nm torque. Chapter 5: Installation...
  • Page 268 Chapter 5: Installation...
  • Page 269 450v SM/BHM/BHS (2x2) 1. Bracket placement: You have two options for placing the bracket: either on the left-hand side (Option 1) or the right- hand side (Option 2), depending on the pole’s availability or accessibility. The following instructions continue with Option 1, where the bracket is placed on the left-hand side. 2.
  • Page 270 3. Assembling the Radio: Slide the radio into position on the bracket. Secure the radio by adding an M6 screw on the back side and tightening it with 5 Nm torque. 4. Pole mount bracket preparation: The pole mount bracket comes pre-assembled in the box. Place it on the pole and loosely fit the nut on the pre-assembled pole mount bracket.
  • Page 271 5. Attaching the dish assembly: Slide the dish assembly into the loose screw head of the pole mount bracket. The dish assembly includes grooves that will align with the screw head and allow the assembly to fall into place. 6. Final adjustments: After determining the correct angle for the dish, tighten the screws to secure the dish.
  • Page 272 7. Final tightening: Align the radio, and tighten the pole mount bracket with 10 Nm torque. Secure the dish brackets with 8 Nm torque. Chapter 5: Installation...
  • Page 273 PMP 450 AP Using an 8mm nut driver, attach the pole mount’s AP housing bracket to the unit using the 4 M5 x 16mm bolts included with the Using the included (depending on pole diameter): M8 x 70mm hex cap bolts (2 quantity)
  • Page 274 PMP 450 SM 900 MHz (Connectorised) The PMP 450 900 MHz connectorised SM mounting procedure is different from other radios. It does not get directly mounted on pole. Align the 900 MHz SM to E bracket of Yagi antenna Slide the radio towards right to lock on the antenna Mount the top LPU...
  • Page 275 Ground using the terminal on the back of the units. Use the supplied Tubular Lug and 6 mm2 (10 AWG) stranded cable, max length 600 mm (24”). Waterproof the cable lug with heat shrink sleeving. Secure the Cable assembly to the unit using the supplied screw and washer.
  • Page 276 Figure 108: Gigabit Ethernet Surge Suppressor PMP/PTP 450 Series The PMP/PTP 450 Series uses 600SSH Surge Suppressor. The inside of the surge suppressor is shown in Installation. Caution The PMP 450 SM 900 MHz is based off of the 450 Series, be sure to use a 600SS to protect this radio type.
  • Page 277 Figure 109: 600SSH Surge Suppressor – inside Key to Callouts 600SSH Holes—for mounting the Surge Suppressor to a flat surface (such as an outside wall). The distance between centers is 4.25 inches (108 mm). RJ-45 connectors—One side (neither side is better than the other for this purpose) connects to the product (AP, SM, AC Adapter, or cluster management module).
  • Page 278 The 600SSH surge suppressor is shipped in the “isolated” position (pin 4 isolated by 68V from protective earth).  If packet error issues occur over the Ethernet link (verify by pinging the device through the 600SSH), configure the 600SSH to “grounded” position (by moving the 600SSH switch from “isolated”...
  • Page 279 Braided grounding conductors must not be used. Approved bonding techniques must be used for the connection of dissimilar metals. Grounding cable minimum bend radius and angle Figure 110: Caution Do not attach grounding cables to the ODU mounting bracket bolts, as this arrangement will not provide full protection.
  • Page 280 The equipment must be lower than the top of the building or its lightning air terminal. The building must be correctly grounded. Schematic examples of wall installations are shown in Installation. Chapter 5: Installation...
  • Page 281 Figure 111: Grounding and lightning protection on wall Protection requirements for a mast or tower installation If the ODU is to be mounted on a metal tower or mast, then in addition to the general protection requirements (above), the following requirements must be observed: The equipment must be lower than the top of the tower or its lightning air terminal.
  • Page 282 Figure 112: Grounding and lightning protection on mast or tower Protection requirements on a multi-floor building If the ODU is to be mounted on a high-rise building, it is likely that cable entry is at roof level (Roof installation) and the equipment room is several floors below. The following additional requirements must be observed: The ODU must be below the lightning terminals and finials.
  • Page 283 Figure 113: Grounding and lightning protection on building Installing the copper Cat5e Ethernet interface To install the copper Cat5e Ethernet interface, use the following procedures: Install the main drop cable Install the bottom LPU to PSU drop cable Installing external antennas to a connectorised ODU Caution To avoid damage to the installation, do not connect or disconnect the drop cable when power is applied to the PSU or network terminating equipment.
  • Page 284 Always use Cat5e cable that is gel-filled and shielded with copper-plated steel. Alternative types of Cat5e cable are not supported by Cambium Networks. Cambium Networks supply this cable (Cambium part numbers WB3175 and WB3176), RJ45 connectors (Cambium part number WB3177) and a crimp tool (Cambium part number WB3211).
  • Page 285 Figure 114: RJ45 connector and cable color code Color Color Pins on plug face (Supplied (Conventional) cable) Light Orange White/Orange Orange Orange Light Green White/Green Blue Blue Light Blue White/Blue Green Green Light Brown White/Brown Brown Brown Figure 115: RJ45 cable Install the bottom LPU to PSU drop cable Install the bottom LPU Install the bottom LPU, ground it, and connect it to the main drop cable.
  • Page 286 Connect the main drop cable using the EMC cable gland to the bottom LPU. Fasten one ground cable to the bottom LPU using the M6 (small) lug. Tighten both nuts to a torque of 5 Nm (3.9 lb ft): Select a building grounding point near the LPU bracket. Remove paint from the surface and apply anti-oxidant compound.
  • Page 287 Cut the drop cable to the length required from bottom LPU to PSU. At the LPU end only: Fit one cable gland and one RJ45 connector by following the procedure Terminate with RJ45 connectors. Connect this cable and gland to the bottom LPU. At the PSU end only: Do not fit a cable gland.
  • Page 288 Ground the antenna cables to the supporting structure within 0.3 meters (1 foot) of the ODU and antennas using the Cambium grounding kit (part number 01010419001): Chapter 5: Installation...
  • Page 289 Fix the antenna cables to the supporting structure using site approved methods. Ensure that no undue strain is placed on the ODU or antenna connectors. Ensure that the cables do not flap in the wind, as flapping cables are prone to damage and induce unwanted vibrations in the supporting structure.
  • Page 290 Figure 116: AP antenna parts 2. Remove top plate from the antenna as shown in Antenna top plate. Figure 117: Antenna top plate 3. Attach the antenna plate to the AP as shown in Attaching antenna plate to the AP. Chapter 5: Installation...
  • Page 291 Note Please use the four “thin neck” M6 bolts and split washers provided with the connectorised units rather that the ones provided in the antenna kit. Attaching antenna plate to the AP Figure 118: 4. Attach the plate mounted AP to the antenna and tighten the (4) serrated flange nuts using a spanner wrench Figure 119: Attaching the plate...
  • Page 292 Figure 120: Connect the port A and B to the PMP 450i AP 6. Assemble the upper bracket by attaching the (2) 7” hex bolts to the bracket using (2) serrated flange nuts Figure 121: AP antenna upper bracket assembly 7.
  • Page 293 Figure 122: AP antenna upper bracket attached to upper adjustment arms 8. Attach the rear strap to the upper bracket using (2) serrated flange nuts and (1) retaining bracket. Do not tighten the nuts now. Figure 123: Rear strap connected to upper AP antenna bracket 9.
  • Page 294 Figure 124: Assembled upper bracket connected to AP antenna 10. Begin assembling the lower bracket by attaching the (2) 7” hex bolts to the bracket using (2) serrated flange nuts AP Antenna Lower Bracket Assembly Figure 125: 11. Attach the rear strap to the bracket using (2) serrated flange nuts and (1) retaining bracket. Do not tighten the nuts now.
  • Page 295 Figure 126: Lower bracket attached to AP antenna Chapter 5: Installation...
  • Page 296 Figure 127: Completed AP and antenna assembly PMP 450 Series Assembling the PMP 450 AP antenna To assemble a PMP 450 Series AP antenna, perform the following steps. Note Cambium recommends assembling the antenna, attach the AP and cabling, and to seal the RF connections before installing the unit at the deployment site.
  • Page 297 Begin assembling the upper bracket by attaching the (2) 7” hex bolts to the bracket using (2) serrated flange nuts AP antenna upper bracket assembly Figure 129: Attach the upper bracket to the adjustment arms using (2) hex bolts, (2) flat washers and (2) lock washers. ...
  • Page 298 Attach the rear strap to the upper bracket using (2) serrated flange nuts and (1) retaining bracket.  Do not tighten the nuts now. Figure 131: Rear strap connected to upper AP antenna bracket Attach the entire upper bracket to the antenna using (2) hex bolts, (2) flat washers and (2) lock washers. ...
  • Page 299 Note Use shielded cable for all infrastructure connections associated with APs, SMs, and CMMs. The environment that these modules operate in often has significant unknown or varying RF energy. Operator experience consistently indicates that the additional cost of shielded cables is more than compensated by predictable operation and reduced costs for troubleshooting and support.
  • Page 300 Figure 134: Lower bracket attached to AP antenna Attaching the PMP 450 AP to the antenna To attach a PMP 450 Series AP to the antenna, perform the following steps. Note Use shielded cable for all infrastructure connections associated with APs, SMs, and CMMs.
  • Page 301 Attach the AP to the antenna by sliding the bracket onto the bolts and tighten the (4) serrated flange nuts using a 13-mm spanner wrench. Figure 136: Lower bracket attached to AP antenna Note If using a non-standard antenna, do not cover the equilibrium membrane vent located on the back of the unit Chapter 5: Installation...
  • Page 302 Figure 137: Mounted PMP 450 AP and antenna assembly, viewed from back and back Attaching the PMP 450 Series AP and antenna to the mount point Attach the upper bracket of the antenna to the mount point by closing the rear strap around the pole and tightening the (2) serrated flange nuts using a 13mm spanner wrench.
  • Page 303 Attach the lower bracket of the antenna to the mount point by closing the rear strap around the pole and tightening the (2) serrated flange nuts using a 13mm spanner wrench. These must be tightened evenly on the pole to avoid jumping/stripping threads. Figure 139: Attaching the AP antenna lower bracket to the pole Use a local map, compass, and/or GPS device as needed to determine the direction that one or...
  • Page 304 The proper angle of tilt can be calculated as a factor of both the difference in elevation and the distance that the link spans. Even in this case, a plumb line and a protractor can be helpful to ensure the proper tilt. This tilt is typically minimal. The number of degrees to offset (from vertical) the mounting hardware leg of the support tube is equal to the angle of elevation from the lower module to the higher module (<B in the example provided in Straight-through Ethernet Cable).
  • Page 305 Where: expressed in feet expressed in miles The angle of depression from the higher module is identical to the angle of elevation from the lower module. Connect the coax cables to the antenna and to the AP Weatherproof the connector on the coax cables (see section Attaching and weatherproofing an N type connector).
  • Page 306 (1) Unfold the upper bracket assembly of the antenna. Chapter 5: Installation...
  • Page 307 (2) Unfold the lower bracket assembly. (3) Loose the radio assembly plate by untightening M8 four bolds. (4) Remove the radio assembly top plate by sliding towards upper bracket assembly. (1) Place the radio assembly plate on the radio and align holes with radio enclosure.
  • Page 308 (2) Insert M6 bolts through plate into radio enclosure (3) Fix the plate by tightening four bolts with a torque setting on 2 ± 0.5 Nm Chapter 5: Installation...
  • Page 309 (1) Place the radio mounted plate on sector antenna as shown in the figure. Ensure that the orientation of RF port of antenna and radio are in same direction (2) Line up the radio assembly to four bolts and slide towards lower bracket assembly to lock. (3) Tighten the radio assembly plate using four M8 bolts to a torque setting of 2 ±0.5 Nm.
  • Page 310 (1) Connect the port A of AP to vertical and port B of AP to horizontal polarization interfaces of the antenna with RF cable. Ensure that the RF cables are pass-through inside the lower bracket assembly (2) Hand tighten the N type connectors and the torque should not exceed more than 1 Nm Mounting of PMP 450i AP 900 MHz antenna to the pole The mounting procedure of PMP 450i AP 900 MHz and antenna to the pole is given below:...
  • Page 311 Attach the upper and lower bracket of the antenna to the mount point by closing the rear strap around the pole. Note Before mounting the radio on the pole, secure the upper and lower bracket assemblies with a torque setting of 3 to 4 Nm as shown in Figure 1. Also, ensure that inner strap of upper bracket is set to zero-degree marking.
  • Page 312 Tighten the four-serrated flange M10 nuts on the upper and lower rear straps using a 17 mm spanner wrench. These must be tightened evenly on the pole to avoid jumping/stripping threads Sector antenna alignment The 900 MHz sector antenna horizontal and vertical alignment procedure is shown in 900 MHz sector antenna alignment.
  • Page 313 upper bracket assembly. Figure 144: 900 MHz sector antenna alignment Horizontal alignment Vertical alignment Vertical alignment upward tilt PMP 450 Series SM 900 MHz Attaching the SM 900 MHz directional antenna to the pole Unbox the directional Yagi antenna. Figure 145: PMP 450i SM 900 MHz external directional antenna Chapter 5: Installation...
  • Page 314 Attach the directional antenna to the pole and insert the two U clamps into the mounting bracket of the antenna Figure 146: Attach the antenna to the pole Tighten all nuts to approximately 6 to 7 Nm or less to avoid deforming the pole. Fixing the nuts Figure 147: Chapter 5: Installation...
  • Page 315 Radio mounting to the antenna Align the radio to E bracket and slide towards right to lock on the antenna as shown in below figure. Figure 148: Fixing the radio to the antenna Chapter 5: Installation...
  • Page 316 Connect the port A of SM to vertical and port B of SM to horizontal polarization interfaces of the antenna with RF cable. Figure 149: Connecting RF cable to the radio Directional Yagi antenna alignment The directional Yagi antenna horizontal and vertical alignment procedure is shown below. The Yagi antenna can be aligned for +15 to -15 degree.
  • Page 317 Figure 150: Yagi antenna alignment - horizontally Figure 151: Yagi antenna alignment - upward tilt Chapter 5: Installation...
  • Page 318 Figure 152: Yagi antenna alignment - downward tilt Alignment of the 4x4 PMP 450v SM/BHS The 4x4 PMP 450v SM/BHS is the first SM in the Cambium PMP line with four chains. All previous SM/BHS had two orthogonal chains with a single peak in the azimuth antenna pattern, while the 4x4 SM/BHS has two peaks because the two carrier feeds are offset as part of the design.
  • Page 319 Each pair of chains transmits and receives a signal in one of the two carriers. Note The difference between carrier and component carrier: Carrier: center frequency of a Tx/Rx chain. Each Tx/Rx chain is used to transmit/receive all modulated component carriers that are wholly contained in the BW of the Tx/Rx chain.
  • Page 320 Enable two carriers at the AP when aligning the SM Assume the AP is operating on a single carrier. Out of the two pairs of chains in the SM, one pair receives the signal, while the other does not receive anything. When moving the SM to look for the peak of the beam, the beam associated with the one active carrier will be aligned with the AP.
  • Page 321 Start with the SM with a negative azimuth offset, and slowly move it to a positive azimuth offset. Monitor the Receive Power Carrier 1 value: it will start low, peak, and get low again. Note when the peak of Carrier 1 occurs. Now repeat and monitor the Receive Power Carrier 2 value: this will also start low, peak, and get low again, but the peak will be at a different location.
  • Page 322 Installing an integrated ODU Caution Do not reverse the bracket clamp, as this arrangement may lead to failure of the assembly. Do not over-tighten the bolts as this may lead to failure of the assembly. PMP 450m Series – 5 GHz AP To mount and connect an integrated ODU, proceed as follows: Inventory the parts to ensure that you have them all PMP 450m Series - 5 GHz AP unbox view...
  • Page 323 Attach the top bracket to the projecting studs on the ODU and secure the top bracket using two M8 nuts by applying 5 Nm torque. Fix the front and rear strap assembly to the upper bracket using two bolts. Do not tighten the nuts now. Note  The PMP 450m antenna operates with 2 degrees of electrical down-tilt.
  • Page 324 See PMP 450m Series – AP for the grounding procedure. See PMP 450m Series – AP for the mounting procedure. PMP 450m Series – 3 GHz AP To mount and connect an integrated ODU, proceed as follows: Inventory the parts to ensure that PMP 450m Series - 3 GHz AP unbox view you have them all before you begin.
  • Page 325 Attach the bottom bracket to the ODU using (2) hex bolts and secure the M8 bolts by applying 5 Nm torque. Chapter 5: Installation...
  • Page 326 Attach the top bracket to the projecting studs on the ODU and secure the top bracket using two M8 nuts by applying 5 Nm torque. Chapter 5: Installation...
  • Page 327 Fix the front and rear strap assembly to the upper bracket using two bolts. Do not tighten the nuts now. Note The PMP 450m antenna operates with 2 degrees of electrical down-tilt. Fix the front and rear strap assembly to the bottom bracket using two bolts.
  • Page 328 Figure 153: Fixing the mounting plate to the back of the ODU 2. Attach the bracket body to the mounting plate using the M8 bolt, spring and plain washers. 3. Hoist the ODU to the mounting position. 4. Attach the bracket body to the pole using the bracket clamp, M8 bolts, and spring and plain washers.
  • Page 329 Insert the RJ45 plug into the socket in the unit, making sure that the locking tab snaps home. Support the drop cable and gently hand screw the gland body into the unit until the bushing seal is flush to the unit body. Note Do not fit the back shell prior to securing the gland body.
  • Page 330 Figure 156: Ethernet cable gland for PMP/PTP 450i Series Disconnecting an RJ45 and gland from a unit To disconnect the Ethernet cable and gland from a unit, proceed as follows: Hold the Ethernet cable and remove the gland back shell. Use a small flathead screwdriver (0.2”/5mm wide or greater) to gently release the black plastic watertight bushing from the compression fins, being careful not to damage the bushing.
  • Page 331 Begin with the AP in the powered-down state. Choose the best mounting location for your particular application. Modules need not be mounted next to each other. They can be distributed throughout a given site. However, the 60° offset must be maintained. Mounting can be done with supplied clamps. See Installing external antennas to a connectorised ODUfor connecting an external antenna to PMP 450i Series, PMP 450 Series, PMP 450m Series –...
  • Page 332 Wrap a drip loop in the cable. For Connectorised Models, Install the external antenna according to the manufacturer’s instructions. For Connectorised Models, connect the SM’s N-type antenna connectors to the external antenna, ensuring that the polarity matches between the SM cable labeling and the antenna port labels. Connectorised SM Antenna Cable Label Antenna Connection Vertical...
  • Page 333 Installing a 450 Platform Family BHM To install a 450 Platform Family BHM, perform the following steps. Procedure 7: Installing a BHM Choose the best mounting location for your particular application. Align the BHM as follows: Move the module to where the link will be unobstructed by the radio horizon and no objects penetrate the Fresnel zone.
  • Page 334 Listen to the alignment tone for pitch, which indicates greater signal power (RSSI/dBm) by higher pitch. Adjust the module slightly until you hear the highest pitch and highest volume When you have achieved the best signal (highest pitch, loudest volume), lock the BHS in place with the mounting hardware Configuring the Link See Configuring remote access in Configuration Guide.
  • Page 335 Note For instructions on CMM3 (CMMmicro) or CMM4/CMM5 installation, including the outdoor temperature range in which it is acceptable to install the unit, tools required, mounting and cabling instructions, and connectivity verification, please see the PMP Synchronization Solutions User Guide located on the Cambium website. Installing CMM4, CMM5, and cnMatrix For CMM3, CMM4, and CMM5 installation details, refer to the PMP Synchronization documentation on the Cambium Products site:...
  • Page 336 When preparing the drop cable for connection to the 450 Platform PSU (without a cable gland), use the following measurements: Creating a drop cable grounding point Use this procedure to connect the screen of the main drop cable to the metal of the supporting structure using the cable grounding kit (Cambium part number 01010419001).
  • Page 337 Fold the ground wire strap around the drop cable screen and fit cable ties. Tighten the cable ties with pliers. Cut the surplus from the cable ties. Cut a 38mm (1.5 inches) section of self-amalgamating tape and wrap it completely around the joint between the drop and ground cables.
  • Page 338 Wrap a layer of PVC tape from bottom to top, starting from 25 mm (1 inch) below and finishing 25 mm (1 inch) above the edge of the self-amalgamating tape, overlapping at half width. Repeat with a further four layers of PVC tape, always overlapping at half width. Wrap the layers in alternate directions (top to bottom, then bottom to top).
  • Page 339 Clamp the bottom lug of the grounding cable to the supporting structure using site approved methods. Use a two-hole lug secured with fasteners in both holes. This provides better protection than a single-hole lug. Attaching and weatherproofing an N type connector The following procedure should be used to weatherproof the N type connectors fitted to the connectorised ODU (AP/sM/BH) and antenna.
  • Page 340 Cut a 125mm (5 inches) length of rubber tape (self-amalgamating): Expand the width of the tape by stretching it so that it will wrap completely around the connector and cable: Press the tape edges together so that there are no gaps. The tape should extend 25 mm (1 inch) beyond the PVC tape: Wrap a layer of 50 mm (2 inch) PVC tape from bottom to top, starting from 25 mm (1 inch) below the edge of the self-amalgamating tape, overlapping at half width.
  • Page 341 Repeat with a further four layers of 19 mm (0.75 inch) PVC tape, always overlapping at half width. Wrap the layers in alternate directions: Second layer: top to bottom. Third layer: bottom to top. Fourth layer: top to bottom. Fifth layer: bottom to top. The bottom edge of each layer should be 25 mm (1 inch) below the previous layer.
  • Page 342 Chapter 6: Compliance with safety standards This section lists the safety specifications against which the 450 Platform Family has been tested and certified. It also describes how to keep RF exposure within safe limits. Electrical safety compliance The 450 Platform Family hardware has been tested for compliance to the electrical safety specifications listed in Safety compliance specifications.
  • Page 343 Health Canada Safety Code 6 limits for the general population. See the Health Canada web site at https://www.canada.ca/en/health-canada/services/environmental-workplace- health/consultations/limits-human-exposure-radiofrequency-electromagnetic-energy-frequency- range-3-300.html and RSS-102. BS EN 50385:2017 Product standard to demonstrate the compliances of radio base stations and fixed terminal stations for wireless telecommunication systems with the basic restrictions or the reference levels related to human exposure to radio frequency electromagnetic fields (110 MHz –...
  • Page 344 Calculated distances and power compliance margins The following tables show calculated minimum separation distances, recommended distances and resulting margins for each frequency band and antenna combination for the USA and Canada. These are conservative distances that include compliance margins. At these and greater separation distances, the power density from the RF field is below generally accepted limits for the general population.
  • Page 345 Band (GHz) Antenna (dBi) (W/ m2) Dish 0.501 24.0 10.0 1.00 Patch Array 0.501 17.0 10.0 0.45 On-board 0.501 10.0 0.06 Dish 0.501 24.0 10.0 1.00 Patch Array 0.501 17.0 10.0. 0.45 On-board 0.501 10.0 0.06 Dish 0.004 24.0 10.0 0.09 Patch Array 0.020...
  • Page 346 Band (GHz) Antenna P (W) G (dBi) S (W/ m2) d (m) Omni 0.125 10.0 0.09 Sector 0.050 10.0 0.09 Connectorised 10.0 0.09 Omni 0.501 10.0. 0.18 Sector 0.199 10.0 0.18 Connectorised 10.0 0.18 (*) It depends on the external antenna gain Table 146: FCC minimum safe distances –...
  • Page 347 Band Antenna P burst P (W) d (m) G (dBi) (W/m 4.9 GHz Omni-directional 0.2138 0.2512 10.0 0.17 20.0 (13 dBi) 90° sector antenna 0.2138 0.2512 10.0 0.26 50.0 (17 dBi) 2ft directional flat plate 0.2138 0.2512 10.0 0.93 631.0 (28 dBi) 4ft directional parabolic 0.851 0.1000...
  • Page 348 Band Antenna P burst P (W) d (m) G (dBi) (W/m 5.8 GHz Omni-directional 0.24 0.28 20.0 (13 dBi) 10.0 0.18 90° sector 0.10 0.12 50.0 (17 dBi) 10.0 0.18 2ft directional flat plate 0.54 0.63 708.0 (28.5 dBi) 10.0 1.57 4ft directional parabolic 0.54...
  • Page 349 Table 149: FCC minimum safe distances – 450v AP 5.1 GHz, 5.8 GHz, and 6 GHz Band (GHz) Antenna P (W) G (dBi) S (W/ m2) d (m) Integrated 0.18 Integrated 0.18 Integrated 0.18 Table 150: FCC minimum safe distances – 450v 4x4 SM/BHS 5.1 GHz, 5.8 GHz, and 6 GHz Band (GHz) Antenna P (W)
  • Page 350 Band (GHz) Antenna PG (W) S (W/ m2) d (m) Dish 9.69 1.14 Dish 9.92 0.18 Table 155: ISEDC minimum safe distances – PMP 450m 3GHz and 5 GHz (4.9 GHz, 5.4 GHz and 5.8 GHz) Band (GHz) Antenna PG (W) S (W/ m2) d (m) 3.45...
  • Page 351 Table 157: ISED minimum safe distances – PMP/PTP 450b Retro APs 4.9 GHz, 5.1 GHz, 5.2 GHz, 5.4 GHz and 5.8 GHz Band Antenna P (W) G (dBi) S (W/ m2) d (m) S @ 20 cm (GHz) (W/ m2) Integrated 0.501 8.71...
  • Page 352 Table 159: ISEDC minimum safe distances – PMP/PTP 450i, 900 MHz, 3.5 GHz, 3.65 GHz, 4.9 GHz, 5.2 GHz, 5.4 GHz, and 5.8 GHz Band Antenna P burst (dBi) 900 MHz Sector 20.0 (13 dBi) 2.74 0.11 3.5 GHz 90° sector antenna, 0.316 50.0 (17 dBi) 6.99...
  • Page 353 Band Antenna P burst (dBi) 5.4 GHz Omni-directional 0.036 0.042 20.0 (13.0 9.39 0.07 dBi) 90° sector 0.014 0.017 50.1 (17.0 9.39 0.07 dBi) 2ft directional flat plate 0.001 0.001 707.9 (28.5 9.39 0.07 dBi) 2ft directional parabolic 0.001 0.001 707.9 (28.5 9.39 0.06...
  • Page 354 Band Antenna P burst (dBi) (W/ m2) 3.65 GHz (upper Canada) Sector 0.316 32 (15 dBi) 38.20 0.14 Integrated 0.316 6 (8 dBi) 38.20 0.06 Reflector 0.20 100 (20 dBi) 38.20 0.20 High Gain Ruggedized 0.003 79 (19 dBi) 38.20 0.23 5.4 GHz Sector...
  • Page 355 Note If there are no EIRP limits in the country of deployment, use the distance calculations for FCC 5.8 GHz for all frequency bands. At FCC 5.8 GHz, for antennas between 0.6m (2ft) and 1.8m (6ft), alter the distance proportionally to the antenna gain. Remarque Si aucune limite de PIRE existe pour le pays de déploiement, utilisez les calculs de distance pour FCC 5,8 GHz pour toutes les bandes de fréquence.
  • Page 356 Hazardous location compliance The PMP/PTP 450i series IECEx/ATEX/HAZLOC ODUs have been certified for operation in the following hazardous locations: ATEX The products have been approved under an “Intrinsic Safety” assessment as defined in EN60079-11:2012. The approval is given by certificate number EMT126ATEX0003X, issued by Element Materials Technology, with the specific level of coverage shown below: II 3 G Ex ic IIC T4 II - Equipment group (surface applications)
  • Page 357 Caution Changes or modifications not expressly approved by Cambium Networks could void the user’s authority to operate the system. Caution For the connectorised version of the product and in order to reduce potential...
  • Page 358 provided it does not cause interference. The system is not guaranteed protection against interference from other products and installations. The radio specification type approvals that have been granted for 450 Platform Family frequency variants are listed under Radio certifications. Table 161: Radio certifications Region/Country Band Specification...
  • Page 359 Brazil specific information Brazil notification For compliant operation in the 5.4 GHz band, the Equivalent Isotropic Radiated Power from the integrated antenna or connectorised antenna shall not exceed 30 dBm (0.5 W). The operator is responsible for enabling the DFS feature on any Canopy 5.4 GHz radio by setting the Country Code to “Brazil”, including after the module is reset to factory defaults.
  • Page 360 Canadian Installation Procedures (900 MHz 450i) 1. << En effet, il est conçu pour être approvisionné par un bloc d’alimentation PoE listé UL et portant la mention <<LPS>> ou <<PS2 complied>>. 2. Encapsulé dans un boîtier de type 450i, il comporte 450 circuits qui sont obligatoirement alimentés par 30V dc.
