Bari-Breeze
User Manual
Low Air Loss Turn Assist System

Advertisement

Table of Contents
loading

Related Manuals for Arjohuntleigh Bari-Breeze

Summary of Contents for Arjohuntleigh Bari-Breeze

  • Page 1 Bari-Breeze User Manual Low Air Loss Turn Assist System...

  • Page 3: Table Of Contents

    Bari-Breeze Mattress ........
  • Page 4 (ii)
  • Page 5 • Store the pump and mattress in the protective bags supplied. • Only the pump and mattress combination as indicated by ArjoHuntleigh should be used. The correct function of the product cannot be guaranteed if the incorrect pump or mattress combinations are used.
  • Page 6 Caution Electromagnetic compatibility (EMC). This product complies with the requirements of applicable EMC Standards. The use of accessories not specified by the manufacturer may result in increased emissions by, or decreased immunity of, the equipment, affecting its performance. (iv)

  • Page 7: Introduction

    Use it to initially set up the low air loss system, keep it as a reference for day-to-day routines, and as a guide to maintenance. About Bari-Breeze The is designed to maintain a constant low Bari-Breeze pressure support surface.

  • Page 8: Bari-Breeze Mattress

    Bari-Breeze Mattress Cover Pump Connector Safety Air Pad Plug A self contained mattress replacement system with easily detachable components for cleaning.
  • Page 9 21 polyurethane cells approximately 200mm (8”) high Cells providing support to the patient. Manufactured from material to reduce accidental Tubeset kinking. Located at the pump end of the tubeset is a specially Tubeset Connector/CPR designed twin snap lock connector. This design helps prevent accidental disconnection of the mattress from the pump.
  • Page 10 Bari-Breeze Pump Integrated mounting hooks fitted to the rear casing allow Mounting Hooks easy positioning of the pump from the bed foot rail. The keypad is angled to provide the user with a clear Keypad visual display. An LED display and individually illuminated control buttons give precise indications of the status of the system at any point in time.

  • Page 11: Clinical Applications

    2. Clinical Applications Indications The system is indicated for patients Bari-Breeze weighing between 22-455Kgs (50-1000 lbs), including those assessed to be at high risk of developing pressure ulcers and for all grades of pressure ulcer up to and including grade 4 (EPUAP, 1998)

  • Page 12: Installation And Setup

    Bari-Breeze WARNING The Bari-Breeze system must be installed on bed frames that are equipped with Safety Sides. Please raise safety sides on the bed and lock them in position after the patient is on the mattress. NEVER LEAVE A PATIENT UNATTENDED ON THE MATTRESS SYSTEM WITH THE SAFETY SIDES IN THE DOWN POSITION.
  • Page 13 7. If not already fitted, place the protective cover over the mattress and secure in position. Make sure the logo is uppermost and at the foot end ArjoHuntleigh of the mattress. 8. Push the Power/Standby button to turn the pump on and enter the required therapy settings, see “Controls, Alarms and Indicators”...

  • Page 14: Cpr Facility

    4. CPR Facility IMPORTANT In the event of cardiac arrest, depress the two release catches on the tubeset/pump connector, and at the same time pull the tubeset out and away from the pump. Located on the right hand side of the pump is a CPR device marked with an arrow.

  • Page 15: Controls, Alarms And Indicators

    5. Controls, Alarms and Indicators Controls and Indicators LED Display Comfort Control (Firm) Comfort Control (Soft) Turn Angle Button/Indicator Turn Time Turn Options Button/Indicator Button/Indicator Max Flow Lock Out Button/Indicator (Fast Inflate) Power/Standby When the pump has power but is in Standby mode, the Standby 7 segment LED display will show a single bar.

  • Page 16: Alarms

    The time selected for the turn is the amount of time (in Turn Times minutes) the mattress will remain in each position during the selected turn sequence. Four settings are available to select the amount of turn Turn Angle given to the patient. These are selected using the turn angle button , where 4/4 is equal to approximately 40 degrees.

  • Page 17: Operation

    Before using the mattress system, make sure it has been installed Bari-Breeze correctly in accordance with “Installation and Setup” on page 6, and ensure that the side bolster and base plug is secure in the connector at the foot end of the mattress.

  • Page 18: Turn Options

    Turn times are only considered when the pump is operating in mode. Turn To Deflate and Store the Bari-Breeze Mattress To deflate the Bari-Breeze mattress: 1. Activate the CPR control to deflate the mattress. 2. Remove the side bolster and safety air pad plug from the connector on the mattress hose assembly.

  • Page 19: Decontamination

    Healthcare Facility or the country of use. If you are uncertain, you should seek advice from your local Infection Control Specialist. system should be routinely decontaminated between patients and at Bari-Breeze regular intervals while in use; as is good practice for all reusable medical devices. WARNING Remove the power cord from the mains supply before cleaning and decontamination.

  • Page 20: Troubleshooting Guide

    8. Troubleshooting Guide The following table contains fault symptoms, their possible causes and suggests steps to rectify the problem. These may occur during initial installation and power Symptom Possible Cause Check Action Pump keyboard does Lock out is on Lock out button LED Press and hold the lock not respond.
  • Page 21 Symptom Possible Cause Check Action Mattress appears to Comfort Control Assess comfort control Adjust as necessary. be bottoming out. Settings too soft. settings. Patient Weight. Check patient weight is within Refer to User Manual. limit for system. Page 4 Indications. Blower Unit Sounds Air leak from Check connections.

  • Page 22: Spare Parts

    Order Code Description 647301 UK Bari-Breeze Pump 647303 USA Bari-Breeze Pump 647304 Euro Bari-Breeze Pump 647309 ROW Bari-Breeze Pump Mattresses Order Code Description 647311 Bari-Breeze Mattress (84” x 42”) Mattress Covers Order Code Description 647321 Bari-Breeze Mattress Cover (84” x 42”)

  • Page 23: Warranty And Service

    10. Warranty and Service ’s standard terms and conditions apply to all sales. A copy is available ArjoHuntleigh on request. These contain full details of warranty terms and do not limit the statutory right of the consumer. For service, maintenance and any questions regarding this, or any other...

  • Page 24: Technical Data

    11. Technical Data Pump 647301 - UK Bari-Breeze Pump Supply Voltage: 100-240V Electrical Rating: 50/60 Hz Size: Width: 33.5cm (13”) Height: 28.5cm (11”) Depth: 14cm (5.5”) Weight: 4.5kg (10lb) Mattress 647311 - Bari-Breeze Mattress Size (Inflated): Width: 106cm (42”) Height: 29cm (11”)
  • Page 25 Pump Symbols Dangerous Voltage Refer to User Manual Type BF S/N: Serial Number Do not dipose of in a dustbin Alternating Current Environmental Conditions Operating Temperature range: +10°C to +40°C Relative humidity: 30% to 75% (non-condensing) Atmospheric pressure 700 hPa to 1060 hPa Storage Temperature range: -40°C to +70°C...
  • Page 27 United Kingdom United States of America Huntleigh Healthcare Ltd Huntleigh Healthcare L.L.C. 310-312 Dallow Road, Luton 40 Christopher Way Bedfordshire, LU1 1TD Eatontown T: +44 (0)1582 413104 New Jersey 07724-3327 F: +44 (0)1582 459100 T: +1 (732) 578-9898 or +1 (888) 223-1218 F: +1 (732) 578-9889 Australia Nederland...
  • Page 28 © Huntleigh Healthcare Limited 2007 647900EN_01...
