QUICK REFERENCE GUIDE - FUNCTIONS
Emergency stop
To quickly stop lift movement
detach the battery and remove it.
Manual raising and lowering
Raise: pump using the full range
of movement.
Brakes
Apply brake: press down
Release brake: push up
Emergency high and low
1
Unplug the hand control.
Lower: press the lowering button.
Backrest
A
Release one of the
catches (A) and raise or lower
the side selected as backrest to
the desired angle.
08.CE.08EN_1 • 07/2020 • Page 1/2
2
Use a blunt object to press.
Raise: press the hole by the up
arrow.
Lower: press the hole by the
down arrow.
Electric raising and lowering
Raise: press the up arrow.
Lower: press down arrow.
Handlebars
During transfer and bath:
Lower the handle bar that is
placed farthest away from
the patient's waist.
