  • Page 1 Resource File The Leeds Teaching Hospitals NHS Trust...

  • Page 2: Table Of Contents

    Contents Nimbus 3 Mattress Replacement System Nimbus Professional Mattress Replacement System Nimbus Paediatric Mattress Replacement System Breeze Low Air Loss Mattress Replacement System Aura Seat Cushion Bari-Breeze Mattress Replacement Contoura 480 Bed Frame Contoura 1080 Plus Size Bed Frame Enterprise 5000 Bed Frame...
  • Page 3 • Advanced dynamic flotation mattress replacement system • Patient weight limit 250kg (39 stones) • Auto-Matt sensor pad for automatic adjustment ® • Anti sink torso section • Heelguard powered down heel section ® • Triple action filtration including Bio-filter •...
  • Page 4 ® ® NIMBUS 3 & NIMBUS 3 PROFESSIONAL Quick Reference Guide This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional aspects of the system. The guide does not replace the general safety warnings, cautions and recommendations provided in the product instructions for use, part number 151996EN.
  • Page 5 Zip the protective cover over the mattress. Make sure that the Transport Vent Valve Control (Nimbus 3 Professional Only) ArjoHuntleigh logo is uppermost and at the foot end of the mattress. Each of the 16 cells in the leg and Closed...

  • Page 6: Nimbus Professional Mattress Replacement System

    Nimbus Professional Mattress Replacement System • Advanced dynamic flotation mattress replacement system • Patient weight limit 250kg (39 stones) • Auto-Matt sensor pad for automatic adjustment ® • Vent Valve Control for therapeutic patient management • Head Section Deflate • Anti-Sink torso section •...
  • Page 7 ® ® NIMBUS 4 & NIMBUS PROFESSIONAL Quick Reference Guide This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional aspects of the system. The guide does not replace the general safety warnings, cautions and recommendations provided in the product instructions for use, part number 649933EN.
  • Page 8 Zip the protective cover over the mattress. Make sure that the Vent Valve Control ArjoHuntleigh logo is uppermost and at the foot end of the mattress. The Nimbus 4 has 5 cells with Vent Valves at the foot end. Check that the transport control is set to Normal and the CPR control The Nimbus Professional has 19 cells all with Vent Valves is closed and locked in position.

  • Page 9: Nimbus Paediatric Mattress Replacement System

    Nimbus Paediatric Mattress Replacement • Advanced dynamic flotation mattress replacement system • Patient weight limit 25kg • Auto-Matt sensor pad for automatic adjustment ® • Dynamic, Static and Autofirm modes • Patented figure of 8 cell design • Transport mode supports patient for 12 hours •...
  • Page 10 Breeze Low Air Loss Mattress Replacement • Low Air Loss mattress replacement system • Patient weight limit 140kg (22 stones) • Pressure reducing support surface • Ideal for patients unable to tolerate a moving surface • 3 modes: Static, Pulsate and Autofirm •...
  • Page 11 BREEZE ® Quick Reference Guide This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional aspects of the system. The guide does not replace the general safety warnings, cautions and recommendations provided in the product instructions for use, part number 624902. Refer to the product instructions for use before using this product.
  • Page 12 Zip the protective cover over the mattress/overlay. Make sure the The six leg cells can be deflated individually using the Inline ArjoHuntleigh logo is uppermost and at the foot end of the mattress/ Turn Valves. Each valve has two positions: overlay.
  • Page 13 Aura Seat Cushion • Pressure relieving seat cushion • Patient weight limit 120kg (19 stones) • 9 fully alternating cells • Modular construction • Lightweight and compact pump • Comfort control • Audible and visual alarms • Suitable for many different seat/chair designs •...
  • Page 14 AURA ® Quick Reference Guide This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional aspects of the system. The guide does not replace the general safety warnings, cautions and recommendations provided in the product instructions for use, part number 500935EN. Refer to the product instructions for use before using this product.
  • Page 15 To complete the seat cushion installation: Zip the protective cover over the cushion. Make sure the ArjoHuntleigh logo is uppermost and at the front of the cushion. Installing the pump: Position the pump feet down on any...

  • Page 16: Bari-Breeze Mattress Replacement

    Bari-Breeze Mattress Replacement • Bariatric Low Air Loss (LAL) mattress replacement system • Patient weight limit 455kg (71 stones) • Pressure redistributing support surface protects vulnerable areas • Micro climate control reduces build up of heat and moisture • Turn Assist lateral rotation with a range of turn time and angle settings •...
  • Page 17 Bari-Breeze ® Quick Reference Guide This Quick Reference Guide has been produced to assist Healthcare Professionals and other users with only the functional aspects of the system. The guide does not replace the general safety warnings, cautions and recommendations provided in the product instructions for use, part number 647901. Refer to the product instructions for use before using this product.
  • Page 18 This is confirmed by the illuminated blue indicator. If not already fitted, place the protective cover over the mattress and secure in position. Make sure the ArjoHuntleigh logo is Turn Times uppermost and at the foot end of the mattress.

  • Page 19: Contoura 480 Bed Frame

    Contoura 480 Profiling Bed Frame • Four section electric profiling bed frame • Safe working load 267kg (42 stones) • Pro-Contour™ profiling • Outstanding pressure, shear and friction reduction • Battery back up • Auto CPR • Nurse and patient handsets •...
  • Page 20 Contoura 480 Quick Reference Guide Patient Handset Auto-Contour Nurse Removable Handset Head and Foot Electric Tilt Ends Auto CPR Removable Deck Sheets Backrest CPR Leve r ACP Lockout Battery Back-Up Brakes Free Steer Bed Stripper Mattress Safety Side Retainer Release HANDSETS NURSE HANDSET PATIENT HANDSET...
  • Page 21 Contoura 1080/1000 Plus Size Medical Bed Frame • IEC60601-2-38 compliant plus size (Bariatric) four section electric profiling • Safe Working Load 500kg bed frame only • Maximum Patient Weight 455kg with Bari-Breeze Low Air Loss Turn Assist mattress replacement system •...
  • Page 22 Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this equipment.
  • Page 23 Patient weighing – Controls (UIM) – C1080 only ‘System stable’ Numerical indicator Secondary input keypad (Patient weight change) display Primary ‘Clear’ (Patient weight) button display ‘Function activated’ indicator(s) Primary (Patient weight) display ’Enter’ Enter ‘decimal’ button ‘minus’ button Set Zero Secondary (Patient button weight change) display...
  • Page 24 Patient weighing – Weight display Patient weighing – Auto-Compensation Add or remove Accessories etc. Patient weighing – Confidentiality MRF-505 8-14...

  • Page 25: Enterprise 5000 Bed Frame

    Enterprise 5000 Bed Frame • Four section electric profiling bed frame • Safe working load 250kg (39 stones) • Exceptional low height of 30cm • Folding safety sides with pendant controls • Patented Bio-Contour profiling system ® • Superior pressure reduction and client comfort •...
  • Page 26 Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this equipment.
  • Page 27 1. Refer to the instructions for use (part no. 746-445) for further information. 2. Check the troubleshooting guide in the product service manual (part no. 746-446). 3. Call the ArjoHuntleigh UK 24 Hour Helpline on 08457 342000. ArjoHuntleigh AB Verkstadsvägen 5 241 38 Eslöv...
  • Page 28 Enterprise 5000X E5X Range Bed Frame • IEC60601-2-52 compliant – four section electric profiling bed frame • Safe working load 250kg • Maximum Patient Weight 185kg with mattress and full accessories loaded onto the bed frame • Exceptional low height of 32cm, low height pause at 40cm •...
  • Page 29 Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this equipment.
  • Page 30 Patient handsets Bio-Contour up Bio-Contour down Raises the Raises the thigh backrest section Lowers the Lowers the thigh backrest section Optional Standard Attendant Control Panel (ACP) Raises the thigh Raises the Raises the section backrest mattress platform Power on indicator Auto-Chair up Battery status indicator...
  • Page 31 Function lockout CPR release Pull the red CPR lever to quickly lower the backrest. To lock or unlock bed functions: press the Function Lock button, then press the Attendant Control Panel button(s) corresponding to the function(s) to be locked or unlocked. The “lock”...

  • Page 32: Enterprise 8000 Bed Frame

    Enterprise 8000 Bed Frame • Four section electric profiling bed frame • Safe working load 250kg (39 stones) • Exceptional low height of 30cm • Split safety sides with built in controls • Patented Bio-Contour profiling system ® • Superior pressure reduction and client comfort •...
  • Page 33 Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this equipment.
  • Page 34 1. Refer to the instructions for use (part no. 746-435) for further information. 2. Check the troubleshooting guide in the product service manual (part no. 746-436). 3. Call the ArjoHuntleigh UK 24 Hour Helpline on 08457 342000. ArjoHuntleigh AB Verkstadsvägen 5 241 38 Eslöv...
  • Page 35 Enterprise 8000X E8X Range Bed Frame • IEC60601-2-52 compliant – four section electric profiling bed frame • Safe working load 250kg • Maximum Patient Weight 250kg with mattress and full accessories loaded onto the bed frame • Exceptional low height of 32cm, low height pause at 40cm •...
  • Page 36 The QRG does not replace the safety warnings, cautions and other important information provided in the Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this medical bed.
  • Page 37 Bed controls Power on indicator Battery indicator Raise / lower mattress platform height Raise / lower backrest Raise / lower thigh section Auto-Chair (described below) Head down tilt (Trendelenburg) CPR - hold down the button to return the bed to a flat position.
  • Page 38 Brakes and steering Side rails The brakes should be applied at all times when the bed is Make sure the side rail is securely locked stationary. The pedals may be linked by a full width brake when in the raised position. bar.

  • Page 39: Enterprise 9000 Bed Frame

    Enterprise 9000 Bed Frame • Four section electric profiling bed frame • Safe working load 250kg (39 stones) • Weighing scale facility • Underbed anti-entrapment system • Bed exit alarm • Exceptional low height of 30cm • Spilt safety sides with built in controls •...
  • Page 40 Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. Some of the functions should only be used by clinically-qualified personnel. The carer should make sure they have read and understood the IFU before using this equipment.
  • Page 41 Backrest Nurse control Knee-break 1. Select one of the function Raise Bio-Contour buttons. Bio-Contour, Backrest, button raises Height or Knee-break. backrestand 2. The indicator light on the knee-break simultaneously selected function will turn green. If the indicator light is yellow, that means the function has been locked out at the Attendant Control Panel.
  • Page 42 Weighing and egress detection The controls for the weighing system and patient egress detection are located on the foot end safety side panel. Enable button Weight Display Auto Compensation button Weight Resolution button Weigh button Bed Egress button Volume control for Zero button bed egress alarm Weighing system operating instructions...
  • Page 43 Enterprise 9000X E9X Range Bed Frame • IEC60601-2-52 compliant – four section electric profiling bed frame • Integrated weigh scales, VariZone bed exit alarm, Anit Entrapment (AES) & Digital Angle Indicator • Enterprise 9000 E9X optional x-ray back rest with flat deck mattress available •...
  • Page 44 QRG does not replace the safety warnings, cautions and other important information provided in the Instructions for Use (IFU) supplied with the equipment; copies of the IFU are available on request from ArjoHuntleigh. understood the IFU before using this medical bed.
  • Page 45 Backrest Nurse control Knee-break 1. Select one of the function Raise Bio-Contour buttons. Bio-Contour, Backrest, button raises Height or Knee-break. backrestand 2. The indicator light on the knee-break simultaneously selected function will turn green. If the indicator light is yellow, that means the function has been locked out at the Attendant Control Panel.
  • Page 46 Brakes and steering Side rails The brakes should be applied at all times when the bed is Make sure the side rail is securely stationary. The pedals may be linked by a full width brake locked when in the raised position bar.
  • Page 47 Patient Weighing and VariZone Movement Detection The controls for the weighing system and VariZone patient movement detection are located on the foot end side rails. Display (shows patient weight and bed section angles.) Weigh. Auto Compensation. Zero. Select Weight Display In Bed.
  • Page 48 VariZone Patient Movement Detection Before setting and activating movement detection, make sure the patient has been weighed, all additional accessories have been accounted for using the Auto Compensation function, and the weighing display is blank. The display will show a moving circular pattern for a few seconds then revert to showing the patient’s weight.

  • Page 49: Pressure Ulcer Classification

    Pressure Ulcer Classification CATEGORY/STAGE I: Nonblanchable Erythema Intact skin with non-blanchable redness of a localized area usually over a bony prominence. Darkly pigmented skin may not have visible blanching; its color may differ from the surrounding area. The area may be painful, firm, soft, warmer or cooler as compared to adjacent tissue.

  • Page 50: Weight Conversion

    Weight conversion Stones (St) Kilograms Stones (St) Kilograms 190.7 12.7 196.8 19.1 200.0 25.4 209.5 31.8 216.0 38.1 222.5 44.5 228.6 50.8 235.0 57.2 241.3 63.5 247.6 69.9 254.0 76.3 260.3 82.6 266.7 89.0 273.0 95.3 279.4 101.7 285.8 108.0 292.1 114.4 298.5...

  • Page 51: Foam Support Surface Testing

    Foam Support Surface Testing Why test foam mattress replacements? • If continually subjected to load, foam support surfaces can suffer a reduction in performance over time due to compression • If the cover material is compromised in any way the core is vulnerable to the ingress of fluids and poses an infection control risk •...

  • Page 52: 30° Tilt

    30° Tilt Recumbent Semi-recumbent The patient’s lower back should be supported with pillows. The lower pillow can be bunched Add a pillow to give support to the lumbar or folded if necessary. region and shoulder. This ‘tilts’ the patient by 30° and lifts the sacrum clear of the mattress.
