Arjohuntleigh Bari Breeze Quick Reference Manual

Standby
Power/Standby
Max Flow
Turn Options
Turn Times
60
30
10
MIN
20
Turn Angle
4/4
1/4 3/4
1/2
Comfort Control Level
Lock Out
Power Fail
Low Pressure
Bari Breeze
Quick Reference Guide
(For more detailed instructions, refer to the User Manual)
When the pump has power but is in Standby mode, the 7 segment LED display will
show a single bar.
Press the Power/Standby button to turn the pump on.
Press to enable maximum air flow from the pump. A blue LED on the button will
indicate that Max Flow
The button selects the turn settings of the mattress. Each press of the button
selects the next setting. For instance, to change the mattress from Bi-lateral Turn
( ) to Static ( ) position, press the button twice until is selected.
In Left Turn ( ) mode the right air cushions in the mattress will be held at a constant
high pressure, and the left air cushions will be held at a constant low pressure. This
process is reversed for the Right Turn ( ) mode. When
will alternate between left and right turn, stopping in the central position. During this
time the display will show
The time selected for the turn is the amount of time (in minutes) the mattress will
remain in each position during the selected turn sequence.
Four settings are available to select the amount of turn given to the patient.
These are selected using the turn angle button
approximately 40 degrees.
These controls adjust the firmness of the mattress. Using the
pressure setting, and the
be displayed in the LED display.
Pump functions (including power/standby switch) can be locked out to prevent
unintentional change of modality / cell pressures. To activate, press the lock button
for approximately 2-3 seconds until the blue LED illuminates. To deactivate, press
and hold the lock out button until the LED turns off.
In the event of a power fail situation, the pump will alert the carer by flashing the
amber Power Fail
pump the alarm will cease and the pump will return to its previous operating
settings.
In the event of hose disconnection, an
(representing "Low Pressure") while the buzzer sounds to alert the carer to the
alarm condition. Once the hose is reconnected, the alarm will cease and the pump
resume its previous therapy settings.
®
60
30
10
MIN
20
is active.
to indicate the system is in the centralising phase.
button increases it. The current comfort level (1-9) will
LED and sounding the buzzer. Once the power is restored to the
and
A I
®
4/4
1/4 3/4
1/2
is selected, the system
, where 4/4 is equal to
button reduces the
will alternate on the LED display
