DLC3020f Digital Level Controller
April 2022
Communication Connections
WARNING
Personal injury or property damage caused by fire or explosion may occur if this connection is attempted in a potentially
explosive atmosphere or in an area that has been classified as hazardous. Confirm that area classification and atmosphere
conditions permit the safe removal of the terminal box cap before proceeding.
Note
Host system device manager interfaces, such as Emerson's AMS Device Manager or an Emerson Device Communicator
communicate directly with the device.
F
A fieldbus communicating device, such as an Emerson Device Communicator, interfaces with the
OUNDATION
DLC3020f from any wiring termination point in the segment. If you choose to connect the fieldbus communicating
device directly to the instrument, attach the device to the LOOP + / - clip‐on connections inside the terminal box to
provide local communications with the instrument.
Accessing Configuration and Calibration Procedures
Navigation paths for Configuration and Calibration procedures are included for both AMS Device Manager and the
Device Communicator.
For example, to access Guided Calibrations:
AMS Device Manager Configure > Calibrate > Guided Calibrations
Device Communicator Configure > Calibrate > Full Calibration (Bench) or Full Calibration (Field)
Menu selections are shown in italics, e.g., Full Calibration (Field).
