Quick Start Guide
D103470X012
Figure 1. Installation Flowchart
Install Heat
Insulator
Configuration: On the Bench or in the Field
Configure the digital level controller before or after installation in the field.
It may be useful to configure the instrument on the bench before installation to ensure proper operation, and to
familiarize yourself with its functionality.
START
Factory mounted
on 249 sensor
No
High
Yes
temperature
application?
No
Mount DLC3020f
to Sensor
Make Electrical
Connections
Power Device
Proceed to
Set Up and Calibration
DLC3020f Digital Level Controller
Yes
