NS 5.14 Firmware

Modbus accessible parameter definitions

For definitions of the Modbus accessible parameters shown in Table 3–2 below.
For more detailed information, refer to "Measurement and Control
Parameters Defined" on page 2-15.
•
% ConvFactor 02: Sets a custom conversion factor when the
parameter Concentration Unit = 2 (%) and this value is greater than
0.0. When it is equal to 0.0, the default conversion factor is used.
•
2 Way Com Port: Sets the port that allows two-way
communications, including Modbus and the diagnostic protocol.
•
4-20 mA Alarm Action: Determines the current loop state upon an
alarm condition.
•
4-20 mA Input Value: The current value of the 4-20 mA input for
pipeline pressure in mA's.
•
4-20 mA Output Value: The current value of the 4-20 mA output
for concentration in mA's.
•
4-20 mA Val Action: Sets the operation mode of the 4-20 mA
current loop during validation cycles.
•
Alarm Flags: Bitwise value identifying the status of each individual
alarm in the analyzer, as listed in Table 3–2 below.
Table 3–2 Assignable Alarm functionality
Bit Hex Value
0 0000001
1 0000002
2 0000004
3 0000008
4 0000010
5 0000020
6 0000040
7 0000080
8 0000100
9 0000200
10 0000400
11 0000800
12 0001000
13 0002000
14 0004000
15 0008000
–
3 20
Functionality
Any alarm active or happened in the past.
Any alarm active (general fault).
Laser power is too low.
Laser power is too high.
Laser zero is too low.
Laser zero is too high.
Laser current is too low.
Laser current is too high.
Pressure is too low.
Pressure is too high.
Temperature is too low.
Temperature is too high.
Concentration is too low.
Concentration is too high.
Peak tracking restart exceeds limit.
Fitting restart exceeds limit.
