Val 1 Concentration

The Val 1 Concentration parameter sets the concentration value of validation
gas supply #1. The analyzer can be configured for a zero gas by setting this
parameter to 0.0, and then setting the Zero Val Tolerance to the maximum
acceptable reading. Otherwise, set this parameter to the concentration value
of the validation gas supply and set Validation Allowance to the allowable
variation range (±%).
When procuring a gas standard, make sure the background gas is
that specified or a mix that closely resembles the contents of the
process stream. Have the gas standard certified to better than the
specified precision of the analyzer, if possible.

Val 2 Concentration

The Val 2 Concentration parameter sets the concentration value of validation
gas supply #2. The analyzer can be configured for a zero gas by setting this
parameter to 0.0, and then setting the Zero Val Tolerance to the maximum
acceptable reading. Otherwise, set this parameter to the concentration value
of the validation gas supply and set Validation Allowance to the allowable
variation range (±%).
When procuring a gas standard, make sure the background gas is
that specified or a mix that closely resembles the contents of the
process stream. Have the gas standard certified to better than the
specified precision of the analyzer, if possible.

Val Attempts

This parameter only applies to permeation type validation.
The Val Attempts parameter sets the maximum number of times the analyzer
attempts to measure the validation gas within the set tolerances (see Zero Val
–
2 32
<SET PARAMETER MODE>
Val 1 Concentration
60.0
0:ZeroGas >0:ppmvVal
<SET PARAMETER MODE>
Val 2 Concentration
280.000
0:ZeroGas >0:ppmvVal
