Endress+Hauser SpectraSensors SS2100 Operator's Manual page 93

2. Perform one of the following:
•
If no password has been defined (default), leave both fields blank
and click OK.
•
If a password has been defined, leave the Username blank, type
in the password and click OK.
3. The Web Manager displays the Home screen as shown in Figure 4–2
below. The menu displays on the left side of the window.
The "Network" and "Channel 1 Connection" menus are
recommended for review (see highlighted menus in Figure 4–2).
Bypass all other menus listed in the menu.
4. The Network menu displays the Ethernet ports network settings,
including the IP address. Refer to Figure 4–3 below.
Figure 4–3 Network window (Web Manager)
Operator's Manual
Figure 4–2 Home window (Web Manager)
Ethernet Communications
–
4 3
