EVAL-AD5680DBZ User Guide
EVALUATION BOARD HARDWARE
MOTHERBOARD POWER SUPPLIES
The
EVAL-MBnanoDAC-SDZ
and dual power supplies.
The
EVAL-AD5680DBZ
evaluation board can be powered either
from the SDP-B port, or externally by the J5 and J6 connectors,
as described in Table 1.
The AGND and DGND inputs are provided on the
MBnanoDAC-SDZ
board. The AGND and DGND planes are
connected at one location on the EVAL-MBnanoDAC-SDZ. It is
recommended that AGND and DGND not be connected else-
where in the system to avoid ground loop problems.
All supplies are decoupled to ground with 10 μF tantalum and
0.1 μF ceramic capacitors.
Table 1. Power Supply Connectors
Connector No.
Label
J5, Pin 1 (J5-1)
VDD
J5, Pin 2 (J5-2)
AGND
J5, Pin 3 (J5-3)
VSS
J6, Pin 1 (J6-1)
VLOGIC
J6, Pin 2 (J6-2)
DGND
Table 3. Link Functions
Link Number
Function
REF1 to REF4
These links select the reference source.
Position EXT selects an off board voltage reference via the appropriate EXT_REF_x connector.
Position VDD selects V
Position 4.096V selects the on-board 4.096 V reference as the reference source.
Position 2.5V selects the on-board 2.5 V reference as the reference source.
Position 5V selects the on-board 5 V reference as the reference source.
LK5
This link selects the positive digital-to-analog converter (DAC) analog voltage source.
Position A selects the internal voltage source from the
Position B selects the 3.3 V internal voltage source from the
Position C selects an external supply voltage, V
LK6
This link selects the VLOGIC voltage source.
Position +3V3 selects the digital voltage source from the
Position VLOGIC selects an external digital supply voltage, V
LK7
This link selects the negative DAC analog voltage source.
Position A selects V
Position B selects AGND.
motherboard supports single
EVAL-
Voltage
Analog positive power supply; V
single supply, 5.5 V and dual supply,
±5.5 V.
Analog ground.
Analog negative power supply, V
dual supply −5.5 V.
Digital supply from 1.8 V to V
Digital ground.
as the reference source.
DD
.
SS
LINK OPTIONS
A number of link options are incorporated in the
MBnanoDAC-SDZ
conditions before using the board. Table 2 describes the positions
of the links to control the evaluation board via the
using a PC and external power supplies. The functions of these
link options are described in detail in Table 3. The positions listed
in Table 2 and Table 3 match the evaluation board imprints (see
Figure 9).
Table 2. Link Options Setup for
Link No.
REF1
REF2
REF3
REF4
LK5
DD
LK6
LK7
SS
.
DD
SDP-B
board.
ADP121
.
DD
SDP-B
board, 3.3 V.
.
LOGIC
Rev. 0 | Page 3 of 12
and must be set for the required operating
SDP-B
Position
2.5V
EXT
EXT
EXT
C
+3V3
B
on the motherboard.
UG-989
EVAL-
SDP-B
board
Control (Default)
