Card Bring-Up and Validation

After installing the XRT and deployment platform, the card installation can be verified using the

following commands, which are explained in more detail below.

• lspci

• xbmgmt flash

• xbmgmt partition

• xbutil validate

The lspci Linux command is used to confirm the card, is seen by the OS, as was done when

installing the card.

The additional commands use the xbmgmt and xbutil utilities included during the XRT package

installation. These utilities include multiple commands to validate and identify the installed

card(s) and report additional card details including memory, PCIe

information. See Vitis Unified Software Platform Documentation: Application Acceleration

Development (UG1393) for a detailed list of commands.

Set the environment to use the utilities by running the following command. Note that the

command is dependent on the command shell you are using.

Use the following command in csh shell:

$ source /opt/xilinx/xrt/setup.csh

Use the following command in bash shell:

$ source /opt/xilinx/xrt/setup.sh

Running lspci

1. Enter the following command:

$ sudo lspci -vd 10ee:

UG1301 (v1.8) February 5, 2021

Getting Started with Alveo Accelerator Cards
