7. Starting
• Bridge the NC safety contacts with a jumper.
Before starting up, check the application type selected. In the case of single door wing automation, set OM=OFF. For sliding
•
gate automation, set JR6=OFF.
• Any limit switches installed must be adjusted so that they are triggered near the mechanical opening and closing end stops.
Set TM=MAX.
NOTE: limit switches must be kept pressed until the operation has been completed.
• If no limit switches are installed, bridge terminals 0-11 and 0-12 with jumpers and set TM to half.
Set RF=3 and R1 to half.
•
• Set TR>3 s in the case of automation with two overlapping door wings.
Switch on power.
•
ATTENTION: The following operations are performed with no safety devices
• Swap the motor polarity if the direction of motion of the door wings is incorrect.
NOTE: the first closing operation requested after a power outage is performed, if TR>MIN, with one door wing at a time (first the
door wing powered by motor M2, then the door wing powered by motor M1), whereas if TR=MIN, the door wings start simultaneously.
• Perform opening and closing commands and check that the automation functions correctly and that the limit switches (if
installed) are correctly set.
Connect the safety devices (removing the relative jumpers) and check that they function correctly.
•
• If required, activate automatic closing and adjust with the TC trimmer.
Set RF to a position that allows the automation to function correctly while ensuring the safety of the user in the event of col-
•
lision.
• Set obstacle thrust with R1.
NOTE: if the door wing closing second encounters an obstacle, both door wings are reopened. The subsequent closing operation
is performed one door wing at a time.
• Ensure that the forces exerted by the door wings are compliant with EN12453-EN12445 regulations.
If required, set the partial aperture of motor 1 with RP.
•
• If required, connect the radio receiver to the relative AUX connector, programme the transmitters as described in the relative
manual and check that all elements function correctly.
WARNING: the plug-in cards must be inserted and removed with the power supply disconnected.
Connect any other accessories and check operation.
•
• Once the start up and check procedures are completed, close the container.
i
NOTE: in the event of servicing or if the control panel is to be replaced, repeat the start-up procedure.
