DITEC Entrematic LOGICM Installation Manual page 3

Index
1. General safety precautions
2. EC declaration of conformity
3. Technical data
3.1 Applications
4. Commands
4.1 Self-controlled safety edge
5. Outputs and accessories
6. Adjustments
6.1 Trimmer
6.2 Dip-switch
6.3 Jumper
6.4 Signals
7. Start-up
8. Troubleshooting
9. Example application for two-motors swing gates
10. Example application for one-motor swing gate
11. Example application for sliding gate
12. Example application for barrier
13. Example of parallel
Caption
This symbol indicates instructions or notes regarding safety issues which require particular attention.
i
This symbol indicates informations which are useful for correct product function.
This symbol indicates instructions or notes intended for technical and expert personnel.
This symbol indicates operations not to be effected for not compromise the correct operation of the automation.
STOP
This symbol indicates options and parameters which are only available with the indicated item.
This symbol indicates options and parameters which are not available with the indicated item.
Subject
3
Page
4
4
4
4
5
5
6
7
7
7
8
8
9
10
11
12
13
13
14
