1 - PACKAGING
PACKAGE CONTENT
• 1x ECLSOFTLINEARIP.
• 1x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector).
• User Manual.
• 2x OS27: quick-Lock omega bracket, M10 hole.
• 1x ESLIPFILTERMD: front medium diffusion filter for ECLSOFTLINEARIP.
OPTIONAL ACCESSORIES
• FCLECLSOFTLIP: flight case for 5 pcs of ECLSOFTLINEARIP.
• ESLIPEC60: egg crate for ECLSOFTLINEARIP.
• ESLIPFILTERINT: front intensified diffusion filter for ECLSOFTLINEARIP.
• ESLIPFILTERHD: front high diffusion filter (less output) for ECLSOFTLINEARIP.
• ESLIPFILTERLD: front low diffusion filter (more output) for ECLSOFTLINEARIP.
• ESLIPFY: foot plate kit with tilt for the ECLSOFTLINEARIP (2 pcs).
• EPTWCBHEAD: ball head joint for center mount bracket EPTWCBRK series.
• ESLIPBRK: center mount bracket for ECLSOFTLINEARIP.
• ESLIPSG50: 50° SnapGrid, for ECLSOFTLINEARIP by DoP choice.
• RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black.
• C6002: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt.
• IPTESTBOX: portable vacuum and pressure tester for ProLights IP fixtures.
• WSBBR512G5: blackBox R-512 G5 receiver 512Ch, 2.45GHz & 5.8GHz, DMX/RDM optional.
• WSBBF1G6: BlackBox F-1 G6 transrec, 512ch, 2.45GHz, DMX&RDM,Bluetooth,G3,G4,G4S, G5, CRMX.
• WSBBF1G5: blackBox F-1 G5 transmitter, 2,45GHz & 5.2/5,8 GHz, DMX/RDM, 512Ch.
• TOUR53415L03: dmx cable HC5340. CANC5MXX XLR 5p->CANC5FXX XLR (f) 5p, L.3m.
• 958225L03: 3x2.5mm TH07 Cable, 16A 3p PwCon MXW, 16A 3p PwCon FXW, L. 3m.
• 9513FXWL03: ass. 3x2.5mm TH07 cable, 16A 3p 230V CEE plug, MENAC3FXW socket, L.3 m.
• 9533FXWL03: ass. 3x2.5mm TH07 cable, SHUKO plug, MENAC3FXW socket, L.3m.
• WSBBR512G6: blackBox R-512 G6 receiver 512Ch, 2.45GHz,DMX&RDM,Bluetooth,G3,G4,G4S,G
5,CRMX.
• UPBOX1UP5: firmware uploader kit, USB IN, 5pin XLR DMX OUT, USB OUT.
2 - TECHNICAL DRAWING
1000 mm
85 mm
[39.4in]
[3.3in]
Weight: 7.1 kg - 15.65 lbs
Fig. 01
PROLIGHTS - EclSoft LinearIP
05
