1 - PACKAGING
PACKAGE CONTENT
• 1x SMARTBATPLUSG2.
• 1x filter frame.
• 1x half top hat.
• 1x connector cover plate.
• 1x SBPG2BAT: single battery for SMARTBATPLUSG2.
• 1x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector).
• User Manual.
OPTIONAL ACCESSORIES
• SBPG2FYBK/WH/CR/GL: floor bracket for SMARTBATPLUSG2, black/white/chrome/gold.
• SBPG2HYBK/WH/CR/GL: hanging bracket for SMARTBATPLUSG2, black/white/ chrome/ gold.
• SBPG2CKBK/WH/CR/GL: cover kit for SMRATBATPLUSG2, black/white/ chrome/ gold.
• SBPG2FILTER20: simmetric 20° light diffusion filter for SMARTBATPLUSG2 projector.
• SBPG2FILTER40B: simmetric 40° light diffusion filter for SMARTBATPLUSG2 projector.
• SBPG2FILTER60: simmetric 60° light diffusion filter for SMARTBATPLUSG2 projector
• SBPG2FILTER1060: asymmetric 10°x60° Light diffusion filter for SMARTBATPLUSG2 projector.
• FCLSMARTBATPG2: flight case for 6 SMARTBATPLUSG2, battery charger included
• PRL-IRC: RGBWA IR: controller, 29 buttons, manual/static colours, auto programs, fade.
• C6002A/B: slim aluminium clamp, 200 kg loading, 48-51 mm tubes, M10 bolt, silver/black.
• RSR0630A/B: steel security cable for hanging bodies, inox steel shackle, L=60 cm, silver/black.
• 9533FXWL03: ass. 3x2.5mm TH07 cable, SHUKO plug, MENAC3FXW socket, L.3m.
• WSBBR512G5: blackBox R-512 G5 receiver 512Ch, 2.45GHz & 5.8GHz, DMX/RDM optional.
• WSBBF1G6: BlackBox F-1 G6 transrec, 512ch, 2.45GHz, DMX&RDM,Bluetooth,G3,G4,G4S, G5, CRMX.
• WSBBF1G5: blackBox F-1 G5 transmitter, 2,45GHz & 5.2/5,8 GHz, DMX/RDM, 512Ch.
• WSBBR512G6: blackBox R-512 G6 receiver 512Ch, 2.45GHz,DMX&RDM,Bluetooth,G3,G4,G4S,G
5,CRMX.
• UPBOX1UP5: firmware uploader kit, USB IN, 5pin XLR DMX OUT, USB OUT.
2 - TECHNICAL DRAWING
Ø182 mm
214 mm
[7.2 in]
[8.4 in]
Weight: 5,7 kg - 12,56 lbs
Fig. 01
PROLIGHTS - SmartBat PlusG2
07
