Copernicus Tech Tub2 Assembly Manual page 9

1
Actual Size:
3
FTT700
F
ONLY
Install shelves with nuts installed into tubs
1 Install shelves in middle position in both tubs (aligned with holes for screws)
2
Insert screws (both sides) but do not fully tighten until all shelves are installed
2
9
M5 Screw
x4
1
2
1
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
You will need: (Not to Scale)
Shelf
(with M5 square nuts installed from previous step )
x2
2
2
