FTT-AC1
Tech Tub Accessory Kit
Assembly Guide
FTT-AC1_2016_B
Check out our other products online at
www.copernicused.com
WARNING
Contents
Tub Rail Left
x1
Tub Rail Right
x1
1
Remove Cable Pocket Wall
At the back of the Cable Pocket Wall, there are two tabs. Press in on tabs and pull wall out.
2
®
This product is meant to be assembled by an adult.
In its unassembled state, small parts present a choking hazard.
To be used under direct supervision of an adult.
FTT-AC1 - Version B - Released July 19th, 2016 - Copernicus Educational Products Inc.
For assistance, please contact us:
1-800-267-8494
Email info@copernicused.com
Have your packing slip ready for reference
M5x5mm Screw
A
x4
M6 Lock Washer
C
x4
4mm Driver
Allen Key
Not to Scale
(43281)
x2
Top Tab
Bottom Tab
M6 Washer
B
x4
M5 Barrel Nut
D
x4
