You will need: (Not to Scale)
6
FTT1100
FTT1112
Install Power Strip in Power Tray
1
Loop power cable under power strip as shown
Fit power cable between ribs and Power Strip Mounting Plate
2
Route power cable around hook and out through back of Power Tray
3
Fit 2 keyholes on Power Strip over 2
4
pegs on Power Strip Mounting Plate
12
10-Outlet Power Strip
x1
HOOK
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
3
2
Slide Power Strip back to secure it
5
1
