You will need: (Not to Scale)
4
Install remaining shelves
1
Install 4 shelves in top tub, leaving three empty slots between each shelf
Install three shelves in bottom tub, leaving two empty slots between each shelf
2
!
Now fully tighten all 4 screws holding middle shelves in place
10
3
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
Shelf
x7
3
