You will need: (Not to Scale)
10
FTT1100-USB
ONLY
Setup USB Hub
Wind excess USB Hub power cable around Power Adapter
1
Place USB Hub and Power Adapter into Power Tray
2
Route power cable around hook and out through back of Power Tray
3
17
10 Port USB Hub
x1
HOOK
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
Power Adapter
x1
!
Do not pull cable
too tight
Connect USB Hub to power adapter
4
USB Hub Power Cable
