1
FTT700
Model Specific Instructions
ONLY
Please Note:
Steps 5-9 are for Power Strip setup (FTT1100 or FTT1112)
Steps 10 & 11 are for USB Hub setup (FTT1100-USB)
1
You will need: (Not to Scale)
5
FTT700
ONLY
FTT1100
FTT1112
Install Power Strip Mounting Bracket onto Power Tray
1
Insert side with four pegs into keyholes
11
Power Tray with Shield
x1
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
Power Strip Mounting Plate
x1
2
Slide back until you hear a CLICK!
