Copernicus Tech Tub2 Assembly Manual page 4

FTT1100
Before beginning, you should have:
Additional tools required:
FTT1100
Shelf
x9
(23261)
Device Positioning Rail
x9
(23271)
Power Tray and Shield
x1
(23262)-Tray
(23263)-Shield
10 Device Tech Tub
Main Body
x1
4
Parts
Adjustable wrench 1x
10-Outlet Power Strip
x1
(255154)
Power Strip Mounting Plate
x1
(23275)
Hook & Loop
Straps
x10
(43321)
2 ®
FTT1100, FTT1100-USB, FTT1112 - Version A - Released July 7, 2022 - Copernicus Educational Products Inc.
Screwdriver
+
Back Foot Anchor Pin
In FTT1100
A
x2
M5 Washer
B
x2
C M5 Lock Nut
x2
M4 x 15mm Screw
D
x4
E M5 Square Nut
x4
F M5 x 15mm Screw
x4
Front Pin Bracket
(23275)
x1
Keys
x2
5mm Driver
Allen Key
x1
Hardware
Actual Size
Not to Scale
