ERP机型：
PL3572FCQ-GL-SMT00010A-V1
描述:
说明书:PL3572FCQ/PGD628FNC,SMT000,REV.A(UMPGD62820220707）,196x196mm,
封底、面:128g双粉卡双面过哑油,双面单黑，内页:80g书纸,双面印单黑，16页32面装订本，
RoHS2.0,REACH,Prop65，POPs，PAHs
C
Designed：曹显贵
ERP P/N：
K
7540C
Date：2022-07-07
SECURE PLUS
with Fingerprint and RFID Card
USER MANUAL
REV：1.0
LATCH EDITION
PGD628FC
Advertisement
Table of Contents
Related Manuals for Lockly LATCH EDITION SECURE PLUS
Summary of Contents for Lockly LATCH EDITION SECURE PLUS
- Page 1 REV：1.0 ERP机型： ERP P/N： PL3572FCQ-GL-SMT00010A-V1 描述: 说明书:PL3572FCQ/PGD628FNC,SMT000,REV.A(UMPGD62820220707）,196x196mm, 封底、面:128g双粉卡双面过哑油,双面单黑，内页:80g书纸,双面印单黑，16页32面装订本， RoHS2.0,REACH,Prop65，POPs，PAHs 7540C Designed：曹显贵 Date：2022-07-07 LATCH EDITION SECURE PLUS with Fingerprint and RFID Card USER MANUAL PGD628FC...
-
Page 2: Table Of Contents
Adding Secure Link Cleaning Section 4 - Locking and Unlocking Calibrating the Lock Unlocking using Access Codes Section 9 - Safety Precautions Unlocking using Fingerprint Safety Precautions Locking/Unlocking using App For additional support, visit http://Lockly.com/help or email help@Lockly.com TABLE OF CONTENTS... -
Page 3: Product Features
Live Monitoring and Voice Control Through your smartphone, monitor door access from anywhere in the world and securely control who comes and goes. You can also control your Lockly smart lock using your voice with Amazon Alexa or Google Assistant-enabled devices. -
Page 4: Product Overview - Exterior
2.1 Product Overview - Exterior RFID Card Reader Keypad Buttons Touchscreen Welcome/Safe Mode Battery Indicator OK Button Fingerprint Sensor Bluetooth Indicator Handle Key Hole Cover Key Hole 9V Battery Backup Socket Reboot SECTION 2.1... -
Page 5: Product Overview - Interior
2.2 Product Overview - Interior Battery Compartment Screw Battery Compartment 4 x AA Alkaline Batteries(Included) Battery Compartment Cover Reset Button Beep Alert Program Button Low Battery Indicator/ Door Lock Button Keypad Display Switch Inside Handle SECTION 2.2... -
Page 6: Understanding Your New Lock
™ (OAC) and other features of your lock. To access these features, you will need the Lockly app and a registered account. You may visit the link below to download the app if you haven't done so. For any questions you can always visit http://Lockly.com/help for assistance. -
Page 7: Reset Button
The Activation Code can be found on the Activation Code Card that came with your smart lock. After you have the Activation Code ready, push the reset button on the back panel of the Lockly Secure to perform your reset. See below to see which Reset Process applies for you. Once the smart lock has been reset, all the data previously stored will be deleted. -
Page 8: Rebooting Your Lock
NOTICE will be changed and all Access Codes will still be stored within Lockly. Press and release the reboot button when you want to reboot the lock. Your Lockly will beep once after reboot. Only reboot when necessary. To reboot, find the reboot button located on the bottom of the exterior side of Lockly lock. The reboot button is located in the middle of the two 9V battery backup sockets. -
Page 9: Low Battery
2.7 Low Battery When the battery is in seriously low condition, Lockly will make continuous beeping sounds in addition to the flashing low battery icon on the touch screen. You should replace batteries immediately to avoid your smart lock from shutting down. -
Page 10: Changing The Battery
2.8 Changing The Battery Under normal use, the Lockly battery will last up to a year. Please check battery levels regularly and change your batteries when the low battery notification is issued. For best practice, always use new batteries by a major brand. -
Page 11: Configuring Access
The Default Access Code is Your new Lockly Access Code can be any combination of 6 to 8 digits. Once a new Access Code is entered, the Default Access Code of 123456 would be deleted. A maximum of 16 sets of Access Codes can be stored for use at any given time. -
Page 12: Adding A Fingerprint
3.2 Adding a Fingerprint We are using an advanced biometric sensor, providing the most secure fingerprint authentication. For security reasons, Lockly will only accept fingerprint patterns that consist of cross intersection points. Patterns with no cross intersection points will not be acceptable. - Page 13 3.2 Adding a Fingerprint (Continued) Once you’re in Fingerprint Registration Mode you will see two numbers displayed on keypad. The top number is your Fingerprint Registration number, in this example to the left, “1”. The bottom number will always start with a “6”. You must successfully scan your fingerprint six (6) times for it to properly register.
-
Page 14: Fingerprint Scanning Directions
3.3 Fingerprint Scanning Directions The fingerprint sensor equipped in your smart lock is loaded with powerful fingerprint algorithms to extract only metadata from fingers, even in poor conditions. Placing your finger on the sensor correctly helps consistency in fingerprint recognition. The following directions and tips will guide you on how to scan an optimal fingerprint image. -
Page 15: Fingerprint Scanning Tips & Troubleshoot
• If wet - wipe excess moisture from finger before scanning • If dirty - wipe stains and dirt off from finger before scanning • Make sure the sensor is clean from dirt or smudges - wipe sensor with soft cloth regularly For more troubleshooting help, visit http://Lockly.com/help SECTION 3.4... -
Page 16: Adding An Rfid Card
Lock. If you purchased a Secure Pro model, the Secure Link is included in your package. For all other Lockly products, the Secure Link can be purchased and added anytime. To set up the Lockly Secure smart lock with Secure Link Wi-Fi Hub and Door Sensors, launch the Lockly App on your iOS or Android device. -
Page 17: Unlocking Using Access Codes
Three consecutive wrong attempts will put Lockly in “Safe Mode”. (See Section 4.7) Lock your Lockly by pressing the OK Button or by brushing your hand across the screen anytime when the door is closed. The smart lock will also auto-lock after unlocking based on your set auto-lock settings. -
Page 18: Unlocking Using Fingerprint
4.2 Unlocking Lockly using Fingerprints Unlocking Place a registered finger to the fingerprint scanner located on the exterior side of the lock to the right. To register a fingerprint, please see Section 3.6. If your fingerprint is registered and acknowledged, you will hear a “beep”... -
Page 19: Locking/Unlocking Using App
™ and connect with your Amazon Alexa or Google Assistant-enabled devices. Please download the app by visiting the link below or search “Lockly” from the correct app store. Scan or visit Lockly.com/app... -
Page 20: Unlocking Using Rfid
4.4 Unlocking using RFID Push down the handle and open the door after it chimed. Place your RFID card Light up the screen by touching the keypad. closer to the panel. 4.5 Locking/Unlocking using Physical Key To unlock your lock using the phys- ical key (included), open the key cover by sliding the cover on either clockwise or counterclock-... -
Page 21: Locking/Unlocking Using Voice Assistants
Once your Lockly Smart Lock and Secure Link¹ Wi-Fi Hub has been installed and configured correctly, make sure you enable the Lockly Action on Google or the Amazon Alexa Skill before you can configure your voice to perform voice commands. -
Page 22: Safe Mode
4.7 Safe Mode - Overview Lockly will enter Safe Mode when three (3) consecutive wrong Access Codes are entered within 5 minutes. When in Safe Mode, the lock status icon will start to flash. To disable Safe Mode, you must unlock the door using the correct fingerprint or enter the correct Access Code twice in a row. - Page 23 Option 2 - Lockly Bluetooth App Use the app that is synced to your Lockly to disable Safe Mode by unlocking the door. If you have not downloaded the app to use with your smart lock, you won’t be able to use this option to disable Safe Mode.
-
Page 24: Rain Mode
Like other digital electronic products water can trigger to activate the touchscreen and fingerprint sensor which may cause the batteries to drain. To protect the lock and extend battery life, you can setup your Lockly to enter Rain Mode to shut off keypad and fingerprint reader whenever rain or water is detected. -
Page 25: Shine Mode
4.9 Shine Mode Lockly touchscreen keypad brightness was designed for optimum battery life. However, some users may need to adjust the brightness to their convenience to enter access codes. Swipe your fingers across the keypad to light up to its normal brightness. -
Page 26: Offline Access Code ™ (Oac)
(OAC) is a unique feature of our smart lock. It allows you to grant access to ™ guests remotely without guests needing to download the app. To use the OAC feature, make sure you download the Lockly app for iOS or Android first, and sync your ™... -
Page 27: Sub-Admin Access
Sub-Admin Access can be created to grant access for others to be able to control your lock and grant access to others via Bluetooth when within range of your Lockly smart lock. The sub-admin permission can be setup through the Lockly App then Add A New User. -
Page 28: Important Notes
Please store this card safely as you will need the default Activation Code on that card to master reset your lock in case, for any reason, you have lost the phone paired to Lockly and also forgot your Access Code. -
Page 29: Cleaning
To calibrate the lock, enter access code + 1234 + example: 135790+1234+ NOTE: You may also calibrate the lock using the Lockly App. Open the app, select the lock and go to > Settings > Calibrate. SECTION 8.1 ~ 8.2... -
Page 30: Safety Precautions
9.1 Safety Precautions Please read all instructions carefully. Remind all Lockly users of the safety precautions. Read the following instructions for your own safety Do not attempt to disassemble the smart lock by yourself. It can cause product damage, void warranty, and cause injuries. - Page 31 FCC Warning： This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 32 Bluetooth ® SIG, Inc. , and any use of such marks by Lockly is under license. Other trademarks and trade names are those of their respective owners. Google, Android, Google Play and Google Home are trademarks of Google LLC.
