AIE100-T2NX Series User's Manual
Step 8 Apply another two thermal pads on the M.2 2280 Key M SSD drive.
Note:
The thickness of the SSD drive may be different by the different manufacturers, to
avoid system damaged by forced closing of the bottom cover and improperly installed.
Please check M.2 thickness first to decide to apply how many pieces thermal pads on
the M.2 SSD Drive, or please install the M.2 SSD Drive suggested by Axiomtek.
Note:
Thermal Pads dimension: 60mm (L) x 25mm (W) x 2mm (H)
20
Hardware Installation
