AIE100-T2NX Series User's Manual
2.2
Installing LTE or Wi-Fi Antenna Cable
Step 1 Install the Mini PCIe card into the Mini PCIe slot and affix it with a screw.
For more details, please refer to section 2.1: Installing the PCI Express
Mini Card.
Step 2 Take the Antenna kit out of its box, and remove the hex nut and washer
from the Antenna cable.
Note:
The LTE and Wi-Fi module comes with the different type of SMA cable, one is IPEX,
and another one is IPEX4, please do not mix and match them.
14
Hardware Installation
