3.2.4
USB2.0 & USB3.1 Gen1 Connector (CN5)
The Universal Serial Bus connectors are compliant with USB 2.0 (480Mbps) and USB 3.1 Gen1
(5Gbps), and ideally for installing USB peripherals such as keyboard, mouse, scanner, etc.
Pin
Signal
1
5V_USB1
2
USB1_D-
3
USB1_D+
4
GND
5
USB_SS1_RX-
6
USB_SS1_RX+
13
3.2.5

DC Power Jack w/ Screw (CN6)

The CN6 is a DC jack with screw. Firmly insert at least 60W adapter into this connector.
Loose
connection
components/devices are properly installed before connecting.
Pin
Signal
1
12V
2
GND
3.2.6

PCI-Express Mini Card Connector (SCN1)

The AIE100-T2NX supports a full-size PCI-Express Mini Card slots. SCN1 is applying to either
Jumper setting & connector
Pin
Signal
7
GND
8
USB_SS1_TX-
9
USB_SS1_TX+
10
5V_USB2
11
USB2_D-
12
USB2_D+
GND
may
cause
system
AIE100-T2NX Series User's Manual
instability
and
make
sure
all
27
